Title :   CRYSTAL STRUCTURE OF GAMMA-GLUTAMYL TRANSPEPTIDASE FROM ESCHERICHIA COLI IN COMPLEX WITH HYDROLYZED GLUTATHIONE

Authors :   T. Okada, K. Wada, K. Fukuyama

Date :   08 Mar 06 (Deposition) - 18 Apr 06 (Release) - 13 Jul 11 (Revision)

Method :   X-RAY DIFFRACTION

Resolution :   1.60

Chains :   Asym. Unit : A,B,C,D
Biol. Unit 1: A,B  (1x)
Biol. Unit 2: C,D  (1x)

Keywords :   Gamma-Glutamyltransferase, Ggt, Gamma-Gt, Glutathione, Transferase (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :   T. Okada, H. Suzuki, K. Wada, H. Kumagai, K. Fukuyama
Crystal Structures Of Gamma-Glutamyltranspeptidase From Escherichia Coli, A Key Enzyme In Glutathione Metabolism, And Its Reaction Intermediate.
Proc. Natl. Acad. Sci. Usa V. 103 6471 2006
PubMed-ID: 16618936 | Reference-DOI: 10.1073/PNAS.0511020103

Molecule 1 - GAMMA-GLUTAMYLTRANSPEPTIDASE
	Chains	:	A, C
	EC Number	:	2.3.2.2
	Engineered	:	YES
	Expression System	:	ESCHERICHIA COLI
	Expression System Plasmid	:	PSH1291
	Expression System Strain	:	SH1603
	Expression System Taxid	:	562
	Expression System Vector Type	:	PLASMID
	Fragment	:	LARGE SUBUNIT
	Gene	:	GGT
	Organism Scientific	:	ESCHERICHIA COLI K12
	Organism Taxid	:	83333
	Strain	:	K-12

Molecule 2 - GAMMA-GLUTAMYLTRANSPEPTIDASE
	Chains	:	B, D
	EC Number	:	2.3.2.2
	Engineered	:	YES
	Expression System	:	ESCHERICHIA COLI
	Expression System Plasmid	:	PSH1291
	Expression System Strain	:	SH1603
	Expression System Taxid	:	562
	Expression System Vector Type	:	PLASMID
	Fragment	:	SMALL SUBUNIT
	Gene	:	GGT
	Organism Scientific	:	ESCHERICHIA COLI K12
	Organism Taxid	:	83333
	Strain	:	K-12

		1	2	3	4
Asymmetric Unit	:	A	B	C	D
Biological Unit 1 (1x)	:	A	B
Biological Unit 2 (1x)	:			C	D

Summary Information (see also Sequences/Alignments below)

Asymmetric Unit (4, 37)

No.	Name	Count	Type	Full Name
1	CA	2	Ligand/Ion	CALCIUM ION
2	GLU	2	Mod. Amino Acid	GLUTAMIC ACID
3	GOL	1	Ligand/Ion	GLYCEROL
4	MSE	32	Mod. Amino Acid	SELENOMETHIONINE

Biological Unit 1 (3, 18)

No.	Name	Count	Type	Full Name
1	CA	-1	Ligand/Ion	CALCIUM ION
2	GLU	1	Mod. Amino Acid	GLUTAMIC ACID
3	GOL	1	Ligand/Ion	GLYCEROL
4	MSE	16	Mod. Amino Acid	SELENOMETHIONINE

Biological Unit 2 (2, 17)

No.	Name	Count	Type	Full Name
1	CA	-1	Ligand/Ion	CALCIUM ION
2	GLU	1	Mod. Amino Acid	GLUTAMIC ACID
3	GOL	-1	Ligand/Ion	GLYCEROL
4	MSE	16	Mod. Amino Acid	SELENOMETHIONINE

Asymmetric Unit (5, 5)

No.	Name	Evidence	Residues	Description
1	AC1	SOFTWARE	ASP B:569 , SER B:572 , ASP B:575 , HOH B:1860 , HOH B:1861 , HOH B:1862 , HOH B:1863	BINDING SITE FOR RESIDUE CA B 701
2	AC2	SOFTWARE	ASP D:569 , SER D:572 , ASP D:575 , HOH D:1864 , HOH D:1865 , HOH D:1866 , HOH D:1867	BINDING SITE FOR RESIDUE CA D 702
3	AC3	SOFTWARE	ARG A:114 , THR B:391 , ASN B:411 , GLN B:430 , ASP B:433 , TYR B:444 , SER B:462 , SER B:463 , MSE B:464 , GLY B:483 , GLY B:484 , HOH B:1067	BINDING SITE FOR RESIDUE GLU B 601
4	AC4	SOFTWARE	ARG C:114 , THR D:391 , ASN D:411 , GLN D:430 , ASP D:433 , TYR D:444 , SER D:462 , SER D:463 , MSE D:464 , GLY D:483 , GLY D:484 , HOH D:1058 , HOH D:1669	BINDING SITE FOR RESIDUE GLU D 602
5	AC5	SOFTWARE	GLN A:366 , GLU A:377 , ILE A:378 , ARG A:379 , HOH A:1074 , HOH A:1524 , HOH A:1540 , HOH A:1623	BINDING SITE FOR RESIDUE GOL A 703

(no "SS Bond" information available for 2DG5)

Asymmetric Unit

No.	Residues
1	Pro A:292	-	Pro A:293
2	Leu B:519	-	Pro B:520
3	Pro C:292	-	Pro C:293
4	Leu D:519	-	Pro D:520

(no "SAP(SNP)/Variant" information available for 2DG5)

Asymmetric Unit (1, 2)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	G_GLU_TRANSPEPTIDASE	PS00462	Gamma-glutamyltranspeptidase signature.	GGT_ECOLI	391-415	2	B:391-415 D:391-415

Biological Unit 1 (1, 1)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	G_GLU_TRANSPEPTIDASE	PS00462	Gamma-glutamyltranspeptidase signature.	GGT_ECOLI	391-415	1	B:391-415 -

Biological Unit 2 (1, 1)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	G_GLU_TRANSPEPTIDASE	PS00462	Gamma-glutamyltranspeptidase signature.	GGT_ECOLI	391-415	1	- D:391-415

(no "Exon" information available for 2DG5)

Asymmetric Unit

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain A from PDB  Type:PROTEIN  Length:351
 aligned with GGT_ECOLI | P18956 from UniProtKB/Swiss-Prot  Length:580

    Alignment length:351
                                    46        56        66        76        86        96       106       116       126       136       146       156       166       176       186       196       206       216       226       236       246       256       266       276       286       296       306       316       326       336       346       356       366       376       386
            GGT_ECOLI    37 EEDVFHPVRAKQGMVASVDATATQVGVDILKEGGNAVDAAVAVGYALAVTHPQAGNLGGGGFMLIRSKNGNTTAIDFREMAPAKATRDMFLDDQGNPDSKKSLTSHLASGTPGTVAGFSLALDKYGTMPLNKVVQPAFKLARDGFIVNDALADDLKTYGSEVLPNHENSKAIFWKEGEPLKKGDTLVQANLAKSLEMIAENGPDEFYKGTIAEQIAQEMQKNGGLITKEDLAAYKAVERTPISGDYRGYQVYSMPPPSSGGIHIVQILNILENFDMKKYGFGSADAMQIMAEAEKYAYADRSEYLGDPDFVKVPWQALTNKAYAKSIADQIDINKAKPSSEIRPGKLAPYE 387
               SCOP domains d2dg5.1 A:37-387,B:391-580 Gamma-glutamyltranspeptidase, GGT                                                                                                                                                                                                                                                                                                    SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .......eee...eeee.hhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhh........eeeeeee.....eeeeee....................hhhhhhhhhhhh...hhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhee.hhhhhhhhhhhhhhhhhhhhhhhhhhee..ee.....ee.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh....hhhhhhhh..eee..eeeee..eeeee.....hhhhhhhhhhhhhh..hhhhhh..hhhhhhhhhhhhhhhhhhhhhhh........hhhhhhhhhhhhhhhh........hhhhh....hhhhh Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2dg5 A  37 EEDVFHPVRAKQGmVASVDATATQVGVDILKEGGNAVDAAVAVGYALAVTHPQAGNLGGGGFmLIRSKNGNTTAIDFREmAPAKATRDmFLDDQGNPDSKKSLTSHLASGTPGTVAGFSLALDKYGTmPLNKVVQPAFKLARDGFIVNDALADDLKTYGSEVLPNHENSKAIFWKEGEPLKKGDTLVQANLAKSLEmIAENGPDEFYKGTIAEQIAQEmQKNGGLITKEDLAAYKAVERTPISGDYRGYQVYSmPPPSSGGIHIVQILNILENFDmKKYGFGSADAmQImAEAEKYAYADRSEYLGDPDFVKVPWQALTNKAYAKSIADQIDINKAKPSSEIRPGKLAPYE 387
                                    46   |    56        66        76        86        96  |    106       116       126       136       146       156       166       176       186       196       206       216       226      |236       246       256       266       276       286   |   296       306     | 316      |326       336       346       356       366       376       386
                                        50-MSE                                           99-MSE          116-MSE  125-MSE                                164-MSE                                                              233-MSE               255-MSE                            290-MSE               312-MSE    323-MSE
                                                                                                                                                                                                                                                                                                                           326-MSE

Chain B from PDB  Type:PROTEIN  Length:190
 aligned with GGT_ECOLI | P18956 from UniProtKB/Swiss-Prot  Length:580

    Alignment length:190
                                   400       410       420       430       440       450       460       470       480       490       500       510       520       530       540       550       560       570       580
            GGT_ECOLI   391 TTHYSVVDKDGNAVAVTYTLNTTFGTGIVAGESGILLNNQMDDFSAKPGVPNVYGLVGGDANAVGPNKRPLSSMSPTIVVKDGKTWLVTGSPGGSRIITTVLQMVVNSIDYGLNVAEATNAPRFHHQWLPDELRVEKGFSPDTLKLLEAKGQKVALKEAMGSTQSIMVGPDGELYGASDPRSVDDLTAGY 580
               SCOP domains d2dg5.1 A:37-387,B:391-580 Gamma-glutamyltranspeptidase, GGT                                                                                                                                   SCOP domains
               CATH domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeeeee.....eeeeeee..........hhhhh....hhhhhh................................eeeee..eeeeee...hhhhhhhhhhhhhhhhhh...hhhhhhhh..ee.......eee....hhhhhhhhhhh...eee.......eeeee.....eeeee.......eeee. Sec.struct. author
                 SAPs(SNPs) ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE G_GLU_TRANSPEPTIDASE     --------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2dg5 B 391 TTHYSVVDKDGNAVAVTYTLNTTFGTGIVAGESGILLNNQmDDFSAKPGVPNVYGLVGGDANAVGPNKRPLSSmSPTIVVKDGKTWLVTGSPGGSRIITTVLQmVVNSIDYGLNVAEATNAPRFHHQWLPDELRVEKGFSPDTLKLLEAKGQKVALKEAmGSTQSImVGPDGELYGASDPRSVDDLTAGY 580
                                   400       410       420       430|      440       450       460   |   470       480       490   |   500       510       520       530       540       550      |560       570       580
                                                                  431-MSE                          464-MSE                       494-MSE                                                 550-MSE  |
                                                                                                                                                                                                557-MSE

Chain C from PDB  Type:PROTEIN  Length:351
 aligned with GGT_ECOLI | P18956 from UniProtKB/Swiss-Prot  Length:580

    Alignment length:351
                                    46        56        66        76        86        96       106       116       126       136       146       156       166       176       186       196       206       216       226       236       246       256       266       276       286       296       306       316       326       336       346       356       366       376       386
            GGT_ECOLI    37 EEDVFHPVRAKQGMVASVDATATQVGVDILKEGGNAVDAAVAVGYALAVTHPQAGNLGGGGFMLIRSKNGNTTAIDFREMAPAKATRDMFLDDQGNPDSKKSLTSHLASGTPGTVAGFSLALDKYGTMPLNKVVQPAFKLARDGFIVNDALADDLKTYGSEVLPNHENSKAIFWKEGEPLKKGDTLVQANLAKSLEMIAENGPDEFYKGTIAEQIAQEMQKNGGLITKEDLAAYKAVERTPISGDYRGYQVYSMPPPSSGGIHIVQILNILENFDMKKYGFGSADAMQIMAEAEKYAYADRSEYLGDPDFVKVPWQALTNKAYAKSIADQIDINKAKPSSEIRPGKLAPYE 387
               SCOP domains d2dg5.2 C:37-387,D:391-580 Gamma-glutamyltranspeptidase, GGT                                                                                                                                                                                                                                                                                                    SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .......eee..eeeee.hhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhh........eeeeeee.....eeeeee....................hhhhhhhhhhhh...hhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhee.hhhhhhhhhhhhhhhhhhhhhhhhhhee..ee.....ee.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh....hhhhhhhh..eee..eeeee..eeeee.....hhhhhhhhhhhhhh..hhhhhh..hhhhhhhhhhhhhhhhhhhhhhh........hhhhhhhhhhhhhhhh........hhhhh....hhhhh Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2dg5 C  37 EEDVFHPVRAKQGmVASVDATATQVGVDILKEGGNAVDAAVAVGYALAVTHPQAGNLGGGGFmLIRSKNGNTTAIDFREmAPAKATRDmFLDDQGNPDSKKSLTSHLASGTPGTVAGFSLALDKYGTmPLNKVVQPAFKLARDGFIVNDALADDLKTYGSEVLPNHENSKAIFWKEGEPLKKGDTLVQANLAKSLEmIAENGPDEFYKGTIAEQIAQEmQKNGGLITKEDLAAYKAVERTPISGDYRGYQVYSmPPPSSGGIHIVQILNILENFDmKKYGFGSADAmQImAEAEKYAYADRSEYLGDPDFVKVPWQALTNKAYAKSIADQIDINKAKPSSEIRPGKLAPYE 387
                                    46   |    56        66        76        86        96  |    106       116       126       136       146       156       166       176       186       196       206       216       226      |236       246       256       266       276       286   |   296       306     | 316      |326       336       346       356       366       376       386
                                        50-MSE                                           99-MSE          116-MSE  125-MSE                                164-MSE                                                              233-MSE               255-MSE                            290-MSE               312-MSE    323-MSE
                                                                                                                                                                                                                                                                                                                           326-MSE

Chain D from PDB  Type:PROTEIN  Length:190
 aligned with GGT_ECOLI | P18956 from UniProtKB/Swiss-Prot  Length:580

    Alignment length:190
                                   400       410       420       430       440       450       460       470       480       490       500       510       520       530       540       550       560       570       580
            GGT_ECOLI   391 TTHYSVVDKDGNAVAVTYTLNTTFGTGIVAGESGILLNNQMDDFSAKPGVPNVYGLVGGDANAVGPNKRPLSSMSPTIVVKDGKTWLVTGSPGGSRIITTVLQMVVNSIDYGLNVAEATNAPRFHHQWLPDELRVEKGFSPDTLKLLEAKGQKVALKEAMGSTQSIMVGPDGELYGASDPRSVDDLTAGY 580
               SCOP domains d2dg5.2 C:37-387,D:391-580 Gamma-glutamyltranspeptidase, GGT                                                                                                                                   SCOP domains
               CATH domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeeeee.....eeeeeee..........hhhhh....hhhhhh................................eeeee..eeeeee...hhhhhhhhhhhhhhhhhh...hhhhhhhh..ee.......eee....hhhhhhhhhhh...eee.......eeeee.....eeeee.......eeeee Sec.struct. author
                 SAPs(SNPs) ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE G_GLU_TRANSPEPTIDASE     --------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2dg5 D 391 TTHYSVVDKDGNAVAVTYTLNTTFGTGIVAGESGILLNNQmDDFSAKPGVPNVYGLVGGDANAVGPNKRPLSSmSPTIVVKDGKTWLVTGSPGGSRIITTVLQmVVNSIDYGLNVAEATNAPRFHHQWLPDELRVEKGFSPDTLKLLEAKGQKVALKEAmGSTQSImVGPDGELYGASDPRSVDDLTAGY 580
                                   400       410       420       430|      440       450       460   |   470       480       490   |   500       510       520       530       540       550      |560       570       580
                                                                  431-MSE                          464-MSE                       494-MSE                                                 550-MSE  |
                                                                                                                                                                                                557-MSE

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Asymmetric Unit

Classes(

)

Folds(

)

Superfamilies( (-)

)

Families(

)

Protein Domains( (-)

)

Organisms( (-)

)

Class: Alpha and beta proteins (a+b) (23004)

Fold: Ntn hydrolase-like (356)

Superfamily: N-terminal nucleophile aminohydrolases (Ntn hydrolases) (352)

Family: Gamma-glutamyltranspeptidase-like (11)

Protein domain: Gamma-glutamyltranspeptidase, GGT (8)

Escherichia coli [TaxId: 562] (7)

1a	d2dg5.1	A:37-387,B:391-580
1b	d2dg5.2	C:37-387,D:391-580

(no "CATH Domain" information available for 2DG5)

(no "Pfam Domain" information available for 2DG5)

Asymmetric Unit(hide GO term definitions)

Chain A,B,C,D (GGT_ECOLI | P18956)

molecular function
	GO:0036374	glutathione hydrolase activity	Catalysis of the reaction: glutathione + H2O = L-cysteinylglycine + L-glutamate.
	GO:0016787	hydrolase activity	Catalysis of the hydrolysis of various bonds, e.g. C-O, C-N, C-C, phosphoric anhydride bonds, etc. Hydrolase is the systematic name for any enzyme of EC class 3.
	GO:0003840	obsolete gamma-glutamyltransferase activity	OBSOLETE. Catalysis of the reaction: (5-L-glutamyl)-peptide + an amino acid = peptide + 5-L-glutamyl-amino acid.
	GO:0008233	peptidase activity	Catalysis of the hydrolysis of a peptide bond. A peptide bond is a covalent bond formed when the carbon atom from the carboxyl group of one amino acid shares electrons with the nitrogen atom from the amino group of a second amino acid.
	GO:0016740	transferase activity	Catalysis of the transfer of a group, e.g. a methyl group, glycosyl group, acyl group, phosphorus-containing, or other groups, from one compound (generally regarded as the donor) to another compound (generally regarded as the acceptor). Transferase is the systematic name for any enzyme of EC class 2.
	GO:0016746	transferase activity, transferring acyl groups	Catalysis of the transfer of an acyl group from one compound (donor) to another (acceptor).
biological process
	GO:0006750	glutathione biosynthetic process	The chemical reactions and pathways resulting in the formation of glutathione, the tripeptide glutamylcysteinylglycine, which acts as a coenzyme for some enzymes and as an antioxidant in the protection of sulfhydryl groups in enzymes and other proteins.
	GO:0006749	glutathione metabolic process	The chemical reactions and pathways involving glutathione, the tripeptide glutamylcysteinylglycine, which acts as a coenzyme for some enzymes and as an antioxidant in the protection of sulfhydryl groups in enzymes and other proteins; it has a specific role in the reduction of hydrogen peroxide (H2O2) and oxidized ascorbate, and it participates in the gamma-glutamyl cycle.
	GO:0006508	proteolysis	The hydrolysis of proteins into smaller polypeptides and/or amino acids by cleavage of their peptide bonds.
cellular component
	GO:0042597	periplasmic space	The region between the inner (cytoplasmic) and outer membrane (Gram-negative Bacteria) or cytoplasmic membrane and cell wall (Fungi and Gram-positive Bacteria).

Asymmetric Unit
	Complete Structure
		Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
		WebMol \| AstexViewer[tm]@PDBe (Java Applets, require no local installation except for Java; loading may be slow)
		STRAP (Java WebStart application, automatic local installation, requires Java; full application with system access!)
		RasMol (require local installation)
		Molscript (VRML) (requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

	Ligands, Modified Residues, Ions
		CA	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		GLU	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		GOL	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		MSE	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]

	Sites
		AC1	[ RasMol ]	+environment [ RasMol ]
		AC2	[ RasMol ]	+environment [ RasMol ]
		AC3	[ RasMol ]	+environment [ RasMol ]
		AC4	[ RasMol ]	+environment [ RasMol ]
		AC5	[ RasMol ]	+environment [ RasMol ]

	Cis Peptide Bonds
		Leu B:519 - Pro B:520	[ RasMol ]
		Leu D:519 - Pro D:520	[ RasMol ]
		Pro A:292 - Pro A:293	[ RasMol ]
		Pro C:292 - Pro C:293	[ RasMol ]

Biological Units
	Complete Structure
		Biological Unit 1	[ Jena3D ]
		Biological Unit 2	[ Jena3D ]

Jmol
	protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick [ Asym. Unit PNG format \| Asym. Unit - sites PNG format \| Biol. Unit 1 PNG format \| Biol. Unit 1 - sites PNG format \| Biol. Unit 2 PNG format ](automatic orientation, automatically generated)
Molscript
	protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick [ mono PDF format \| stereo PDF format ](default orientation, automatically generated)

Access by PDB/NDB ID
	2dg5
		Family and Domain Information	:	ProDom \| SYSTERS
		General Structural Information	:	GlycoscienceDB \| MMDB \| NDB \| OCA \| PDB \| PDBe \| PDBj \| PDBsum \| PDBWiki \| PQS \| PROTEOPEDIA
		Orientation in Membranes	:	OPM
		Protein Surface	:	SURFACE
		Secondary Structure	:	DSSP (structure derived) \| HSSP (homology derived)
		Structural Genomics	:	GeneCensus
		Structural Neighbours	:	CE \| VAST
		Structure Classification	:	CATH \| Dali \| SCOP
		Validation and Original Data	:	BMRB Data View \| BMRB Restraints Grid \| EDS \| PROCHECK \| RECOORD \| WHAT_CHECK

Access by UniProt ID/Accession number
	GGT_ECOLI \| P18956
		Comparative Protein Structure Models	:	ModBase
		Genomic Information	:	Ensembl
		Protein-protein Interaction	:	DIP
		Sequence, Family and Domain Information	:	InterPro \| Pfam \| SMART \| UniProtKB/SwissProt

Access by Enzyme Classificator (EC Number)
	2.3.2.2
		General Enzyme Information	:	BRENDA \| EC-PDB \| Enzyme \| IntEnz
		Pathway	:	KEGG \| MetaCyc

Access by Disease Identifier (MIM ID)
	(no 'MIM ID' available)
		Disease Information	:	OMIM

Access by GenAge ID
	(no 'GenAge ID' available)
		Age Related Information	:	GenAge

Access by PDB/NDB ID
		Domain Information	:	XDom
		Interatomic Contacts of Structural Units	:	CSU
		Ligand-protein Contacts	:	LPC
		Protein Cavities	:	castP
		Sequence and Secondary Structure	:	PDBCartoon
		Structure Alignment	:	STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
		Structure and Sequence Browser	:	STING

Access by UniProt ID/Accession number
	GGT_ECOLI \| P18956
		Protein Disorder Prediction	:	DisEMBL \| FoldIndex \| GLOBPLOT (for more information see DisProt)

UniProtKB/Swiss-Prot
	GGT_ECOLI \| P18956	:	2dbu 2dbw 2dbx 2e0w 2e0x 2e0y 2z8i 2z8j 2z8k 5b5t

2dbu	THE SAME PROTEIN
2dbw	THE SAME PROTEIN, ACYL-ENZYME INTERMEDIATE
2dbx	THE SAME PROTEIN COMPLEXED WITH L-GLUTAMATE

Description

Compounds

Structural Features

Chains, Units

Ligands, Modified Residues, Ions (4, 37)

Sites (5, 5)

SS Bonds (0, 0)

Cis Peptide Bonds (4, 4)

Sequence-Structure Mapping

SAPs(SNPs)/Variants (0, 0)

PROSITE Motifs (1, 2)

Exons (0, 0)

Sequences/Alignments

Classification and Annotation

SCOP Domains (1, 2)

CATH Domains (0, 0)

Pfam Domains (0, 0)

Gene Ontology (10, 10)

Visualization

Interactive Views

Still Images

Databases and Analysis Tools

Databases

Analysis Tools

Related Entries

Entries Sharing at Least One Protein Chain (UniProt ID)

Related Entries Specified in the PDB File
