1JEC - JenaLib

Asymmetric Unit (28, 28)

No.	Name	Evidence	Residues	Description
01	AC1	SOFTWARE	ASP A:168 , HIS A:235 , HIS A:236 , SO4 A:525 , ACY A:535	BINDING SITE FOR RESIDUE CD A 512
02	AC2	SOFTWARE	PRO A:39 , CYS A:43 , HOH A:827 , HOH A:966 , HOH A:1035	BINDING SITE FOR RESIDUE CD A 513
03	AC3	SOFTWARE	LEU A:18 , GLU A:22 , HIS A:319 , ACY A:526 , HOH A:849	BINDING SITE FOR RESIDUE CD A 514
04	AC4	SOFTWARE	GLU A:182 , ACY A:533	BINDING SITE FOR RESIDUE CD A 515
05	AC5	SOFTWARE	ASP A:189 , HIS A:494 , ACY A:527 , ACY A:534	BINDING SITE FOR RESIDUE CD A 516
06	AC6	SOFTWARE	ASP A:151	BINDING SITE FOR RESIDUE CA A 517
07	AC7	SOFTWARE	GLU A:409 , HOH A:1038	BINDING SITE FOR RESIDUE CD A 518
08	AC8	SOFTWARE	LYS A:297 , ASP A:303	BINDING SITE FOR RESIDUE CA A 519
09	AC9	SOFTWARE	ASP A:489 , HOH A:603 , HOH A:615 , HOH A:856	BINDING SITE FOR RESIDUE CA A 520
10	BC1	SOFTWARE	GLU A:46 , PRO A:164 , HIS A:166 , HOH A:1026	BINDING SITE FOR RESIDUE MG A 521
11	BC2	SOFTWARE	ASP A:309 , HOH A:911	BINDING SITE FOR RESIDUE NA A 1522
12	BC3	SOFTWARE	HIS A:204 , HOH A:723 , HOH A:770 , HOH A:944	BINDING SITE FOR RESIDUE NA A 1537
13	BC4	SOFTWARE	ASP A:322 , HOH A:703 , HOH A:796 , HOH A:802	BINDING SITE FOR RESIDUE NA A 1538
14	BC5	SOFTWARE	THJ A:540 , HOH A:1033	BINDING SITE FOR RESIDUE CD A 600
15	BC6	SOFTWARE	HIS A:166 , ASP A:168 , ARG A:173 , SER A:417 , CD A:512 , ACY A:535	BINDING SITE FOR RESIDUE SO4 A 525
16	BC7	SOFTWARE	GLN A:195 , THR A:196 , ARG A:197 , MET A:263 , HIS A:292 , ALA A:293 , CD A:600 , HOH A:637 , HOH A:638	BINDING SITE FOR RESIDUE THJ A 540
17	BC8	SOFTWARE	ALA A:17 , LEU A:18 , LYS A:20 , ASN A:21 , GLU A:22 , HIS A:319 , CD A:514 , HOH A:825 , HOH A:849	BINDING SITE FOR RESIDUE ACY A 526
18	BC9	SOFTWARE	GLN A:187 , ASP A:189 , PRO A:491 , SER A:493 , HIS A:494 , CD A:516 , ACY A:534	BINDING SITE FOR RESIDUE ACY A 527
19	CC1	SOFTWARE	ASN A:216 , GLU A:490 , PRO A:491 , HIS A:494	BINDING SITE FOR RESIDUE ACY A 528
20	CC2	SOFTWARE	LYS A:174 , LEU A:181 , GLU A:182 , SER A:185	BINDING SITE FOR RESIDUE ACY A 529
21	CC3	SOFTWARE	GLU A:130 , ARG A:134	BINDING SITE FOR RESIDUE ACY A 530
22	CC4	SOFTWARE	PRO A:55 , THR A:57 , ASP A:64 , HOH A:801	BINDING SITE FOR RESIDUE ACY A 531
23	CC5	SOFTWARE	THR A:70 , ASP A:71	BINDING SITE FOR RESIDUE ACY A 532
24	CC6	SOFTWARE	GLY A:171 , LYS A:174 , GLU A:182 , ARG A:186 , PHE A:255 , CD A:515	BINDING SITE FOR RESIDUE ACY A 533
25	CC7	SOFTWARE	ASP A:189 , HIS A:494 , CD A:516 , ACY A:527 , HOH A:678	BINDING SITE FOR RESIDUE ACY A 534
26	CC8	SOFTWARE	HIS A:236 , SER A:417 , CD A:512 , SO4 A:525 , HOH A:1034	BINDING SITE FOR RESIDUE ACY A 535
27	CC9	SOFTWARE	ASN A:251 , HOH A:667	BINDING SITE FOR RESIDUE ACY A 536
28	DC1	SOFTWARE	GLY A:425 , SER A:449 , HOH A:602 , HOH A:672 , HOH A:1006	BINDING SITE FOR RESIDUE ACY A 537

SS Bonds (0, 0)

Cis Peptide Bonds (1, 1)

Sequence-Structure Mapping

SAPs(SNPs)/Variants (0, 0)

PROSITE Motifs (0, 0)

Exons (1, 1)

Sequences/Alignments

Asymmetric Unit

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain A from PDB  Type:PROTEIN  Length:510
 aligned with MET3_YEAST | P08536 from UniProtKB/Swiss-Prot  Length:511

    Alignment length:510
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361       371       381       391       401       411       421       431       441       451       461       471       481       491       501       511
           MET3_YEAST     2 PAPHGGILQDLIARDALKKNELLSEAQSSDILVWNLTPRQLCDIELILNGGFSPLTGFLNENDYSSVVTDSRLADGTLWTIPITLDVDEAFANQIKPDTRIALFQDDEIPIAILTVQDVYKPNKTIEAEKVFRGDPEHPAISYLFNVAGDYYVGGSLEAIQLPQHYDYPGLRKTPAQLRLEFQSRQWDRVVAFQTRNPMHRAHRELTVRAAREANAKVLIHPVVGLTKPGDIDHHTRVRVYQEIIKRYPNGIAFLSLLPLAMRMSGDREAVWHAIIRKNYGASHFIVGRDHAGPGKNSKGVDFYGPYDAQELVESYKHELDIEVVPFRMVTYLPDEDRYAPIDQIDTTKTRTLNISGTELRRRLRVGGEIPEWFSYPEVVKILRESNPPRPKQGFSIVLGNSLTVSREQLSIALLSTFLQFGGGRYYKIFEHNNKTELLSLIQDFIGSGSGLIIPNQWEDDKDSVVGKQNVYLLDTSSSADIQLESADEPISHIVQKVVLFLEDNGFFVF 511
               SCOP domains d1jeca1 A:2-168 ATP sulfurylase N-terminal domain                                                                                                                      d1jeca2 A:169-389 ATP sulfurylase catalytic domain                                                                                                                                                                           d1jeca3 A:390-511 ATP sulfurylase C-terminal domain                                                                        SCOP domains
               CATH domains 1jecA02 A:2-189 Sulfate adenylyltransferase                                                                                                                                                 1jecA01 A:190-389 Tyrosyl-Transfer RNA Synthetase , subunit E, domain 1                                                                                                                                 1jecA03 A:390-511 P-loop containing nucleotide triphosphate hydrolases                                                     CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author .........hhhhhh..hhhhhhhhhh....eeee.hhhhhhhhhhhhh.......ee.hhhhhhhhhhhh.............eeehhhhhhh.....eeeeee...eeeeeeeeeeee..hhhhhhhhhhh....hhhhhhhhhh...eeeeeeeee..............hhhhhhhhhhhh....eeeeee....hhhhhhhhhhhhhhhh.eeeeee..........hhhhhhhhhhhhhhhh....eee.........hhhhhhhhhhhhhhhh...eee....................hhhhhhhhhhhhhhh.eee....eee.hhhh.eee.hhh..........hhhhhhhhhhhh........hhhhhhhhhhhh.hhhhh.eeeee......hhhhhhhhhhhhhh.......eee.....hhhhhhhhhhhhhh..eeee....hhhhhhhh....eeeee......ee......hhhhhhhhhhhhhhhh..... Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ PROSITE
               Transcript 1 Exon 1.1  PDB: A:2-511 UniProt: 1-511 [INCOMPLETE]                                                                                                                                                                                                                                                                                                                                                                                                                                                                             Transcript 1
                 1jec A   2 PAPHGGILQDLIARDALKKNELLSEAQSSDILVWNLTPRQLCDIELILNGGFSPLTGFLNENDYSSVVTDSRLADGTLWTIPITLDVDEAFANQIKPDTRIALFQDDEIPIAILTVQDVYKPNKTIEAEKVFRGDPEHPAISYLFNVAGDYYVGGSLEAIQLPQHYDYPGLRKTPAQLRLEFQSRQWDRVVAFQTRNPMHRAHRELTVRAAREANAKVLIHPVVGLTKPGDIDHHTRVRVYQEIIKRYPNGIAFLSLLPLAMRMSGDREAVWHAIIRKNYGASHFIVGRDHAGPGKNSKGVDFYGPYDAQELVESYKHELDIEVVPFRMVTYLPDEDRYAPIDQIDTTKTRTLNISGTELRRRLRVGGEIPEWFSYPEVVKILRESNPPRPKQGFSIVLGNSLTVSREQLSIALLSTFLQFGGGRYYKIFEHNNKTELLSLIQDFIGSGSGLIIPNQWEDDKDSVVGKQNVYLLDTSSSADIQLESADEPISHIVQKVVLFLEDNGFFVF 511
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361       371       381       391       401       411       421       431       441       451       461       471       481       491       501       511

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Classification and Annotation

SCOP Domains (3, 3)

CATH Domains (3, 3)

Pfam Domains (0, 0)

Gene Ontology (13, 13)

Asymmetric Unit(hide GO term definitions)

Chain A (MET3_YEAST | P08536)

molecular function
	GO:0005524	ATP binding	Interacting selectively and non-covalently with ATP, adenosine 5'-triphosphate, a universally important coenzyme and enzyme regulator.
	GO:0000166	nucleotide binding	Interacting selectively and non-covalently with a nucleotide, any compound consisting of a nucleoside that is esterified with (ortho)phosphate or an oligophosphate at any hydroxyl group on the ribose or deoxyribose.
	GO:0016779	nucleotidyltransferase activity	Catalysis of the transfer of a nucleotidyl group to a reactant.
	GO:0004781	sulfate adenylyltransferase (ATP) activity	Catalysis of the reaction: ATP + sulfate = diphosphate + adenylylsulfate.
	GO:0016740	transferase activity	Catalysis of the transfer of a group, e.g. a methyl group, glycosyl group, acyl group, phosphorus-containing, or other groups, from one compound (generally regarded as the donor) to another compound (generally regarded as the acceptor). Transferase is the systematic name for any enzyme of EC class 2.
biological process
	GO:0008652	cellular amino acid biosynthetic process	The chemical reactions and pathways resulting in the formation of amino acids, organic acids containing one or more amino substituents.
	GO:0019344	cysteine biosynthetic process	The chemical reactions and pathways resulting in the formation of cysteine, 2-amino-3-mercaptopropanoic acid.
	GO:0070814	hydrogen sulfide biosynthetic process	The chemical reactions and pathways resulting in the formation of hydrogen sulfide, H2S.
	GO:0009086	methionine biosynthetic process	The chemical reactions and pathways resulting in the formation of methionine (2-amino-4-(methylthio)butanoic acid), a sulfur-containing, essential amino acid found in peptide linkage in proteins.
	GO:0000103	sulfate assimilation	The pathways by which inorganic sulfate is processed and incorporated into sulfated compounds.
	GO:0019379	sulfate assimilation, phosphoadenylyl sulfate reduction by phosphoadenylyl-sulfate reductase (thioredoxin)	The pathway by which inorganic sulfate is processed and incorporated into sulfated compounds, where the phosphoadenylyl sulfate reduction step is catalyzed by the enzyme phosphoadenylyl-sulfate reductase (thioredoxin) (EC:1.8.4.8).
	GO:0000096	sulfur amino acid metabolic process	The chemical reactions and pathways involving amino acids containing sulfur, comprising cysteine, homocysteine, methionine and selenocysteine.
cellular component
	GO:0005737	cytoplasm	All of the contents of a cell excluding the plasma membrane and nucleus, but including other subcellular structures.

Visualization

Interactive Views

Asymmetric Unit
	Complete Structure
		Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
		WebMol \| AstexViewer[tm]@PDBe (Java Applets, require no local installation except for Java; loading may be slow)
		STRAP (Java WebStart application, automatic local installation, requires Java; full application with system access!)
		RasMol (require local installation)
		Molscript (VRML) (requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

	Ligands, Modified Residues, Ions
		ACY	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		CA	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		CD	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		MG	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		NA	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		SO4	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		THJ	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]

	Sites
		AC1	[ RasMol ]	+environment [ RasMol ]
		AC2	[ RasMol ]	+environment [ RasMol ]
		AC3	[ RasMol ]	+environment [ RasMol ]
		AC4	[ RasMol ]	+environment [ RasMol ]
		AC5	[ RasMol ]	+environment [ RasMol ]
		AC6	[ RasMol ]	+environment [ RasMol ]
		AC7	[ RasMol ]	+environment [ RasMol ]
		AC8	[ RasMol ]	+environment [ RasMol ]
		AC9	[ RasMol ]	+environment [ RasMol ]
		BC1	[ RasMol ]	+environment [ RasMol ]
		BC2	[ RasMol ]	+environment [ RasMol ]
		BC3	[ RasMol ]	+environment [ RasMol ]
		BC4	[ RasMol ]	+environment [ RasMol ]
		BC5	[ RasMol ]	+environment [ RasMol ]
		BC6	[ RasMol ]	+environment [ RasMol ]
		BC7	[ RasMol ]	+environment [ RasMol ]
		BC8	[ RasMol ]	+environment [ RasMol ]
		BC9	[ RasMol ]	+environment [ RasMol ]
		CC1	[ RasMol ]	+environment [ RasMol ]
		CC2	[ RasMol ]	+environment [ RasMol ]
		CC3	[ RasMol ]	+environment [ RasMol ]
		CC4	[ RasMol ]	+environment [ RasMol ]
		CC5	[ RasMol ]	+environment [ RasMol ]
		CC6	[ RasMol ]	+environment [ RasMol ]
		CC7	[ RasMol ]	+environment [ RasMol ]
		CC8	[ RasMol ]	+environment [ RasMol ]
		CC9	[ RasMol ]	+environment [ RasMol ]
		DC1	[ RasMol ]	+environment [ RasMol ]

	Cis Peptide Bonds
		Ser A:54 - Pro A:55	[ RasMol ]

Biological Unit
	Complete Structure
		Biological Unit 1	[ Jena3D ]

Still Images

Databases and Analysis Tools

Databases

Access by PDB/NDB ID
	1jec
		Family and Domain Information	:	ProDom \| SYSTERS
		General Structural Information	:	GlycoscienceDB \| MMDB \| NDB \| OCA \| PDB \| PDBe \| PDBj \| PDBsum \| PDBWiki \| PQS \| PROTEOPEDIA
		Orientation in Membranes	:	OPM
		Protein Surface	:	SURFACE
		Secondary Structure	:	DSSP (structure derived) \| HSSP (homology derived)
		Structural Genomics	:	GeneCensus
		Structural Neighbours	:	CE \| VAST
		Structure Classification	:	CATH \| Dali \| SCOP
		Validation and Original Data	:	BMRB Data View \| BMRB Restraints Grid \| EDS \| PROCHECK \| RECOORD \| WHAT_CHECK

Access by UniProt ID/Accession number
	MET3_YEAST \| P08536
		Comparative Protein Structure Models	:	ModBase
		Genomic Information	:	Ensembl
		Protein-protein Interaction	:	DIP
		Sequence, Family and Domain Information	:	InterPro \| Pfam \| SMART \| UniProtKB/SwissProt

Access by Enzyme Classificator (EC Number)
	2.7.7.4
		General Enzyme Information	:	BRENDA \| EC-PDB \| Enzyme \| IntEnz
		Pathway	:	KEGG \| MetaCyc

Access by Disease Identifier (MIM ID)
	(no 'MIM ID' available)
		Disease Information	:	OMIM

Access by GenAge ID
	(no 'GenAge ID' available)
		Age Related Information	:	GenAge

Description

Compounds

Structural Features

Chains, Units

Ligands, Modified Residues, Ions (7, 28)

Sites (28, 28)
