(-) Description

Title :  STRUCTURE AT 2.5-ANGSTROMS RESOLUTION OF CHEMICALLY SYNTHESIZED HUMAN IMMUNODEFICIENCY VIRUS TYPE 1 PROTEASE COMPLEXED WITH A HYDROXYETHYLENE*-BASED INHIBITOR

Authors :  M. Jaskolski, M. Miller, A. G. Tomasselli, T. K. Sawyer, D. G. Staples, R. L. Heinrikson, J. Schneider, S. B. H. Kent, A. Wlodawer
Date :  26 Oct 90  (Deposition) - 31 Oct 93  (Release) - 13 Jul 11  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  2.50
Chains :  Asym./Biol. Unit :  A,B,I
Keywords :  Acid Proteinase, Hydrolase-Hydrolase Inhibitor Complex (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  M. Jaskolski, A. G. Tomasselli, T. K. Sawyer, D. G. Staples, R. L. Heinrikson, J. Schneider, S. B. Kent, A. Wlodawer
Structure At 2. 5-A Resolution Of Chemically Synthesized Human Immunodeficiency Virus Type 1 Protease Complexed With A Hydroxyethylene-Based Inhibitor.
Biochemistry V. 30 1600 1991
PubMed-ID: 1993177  |  Reference-DOI: 10.1021/BI00220A023
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - HIV-1 PROTEASE
    Chains: A, B
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Taxid: 562
    Organism Scientific: HUMAN IMMUNODEFICIENCY VIRUS 1
    Organism Taxid: 11676

Molecule 2 - INHIBITOR VAL-SER-GLN-ASN-LEU-PSI(CH(OH)-CH2)-VAL-ILE-VAL (U-85548E)
    Chains: I
    Engineered: YES
    Synthetic: YES

 Structural Features

(-) Chains, Units

  123
Asymmetric/Biological Unit : ABI

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (2, 5)

Asymmetric/Biological Unit (2, 5)
No.NameCountTypeFull Name
1ABA4Mod. Amino AcidALPHA-AMINOBUTYRIC ACID
2LOV1Mod. Amino Acid5-AMINO-4-HYDROXY-2-ISOPROPYL-7-METHYL-OCTANOIC ACID

(-) Sites  (3, 3)

Asymmetric Unit (3, 3)
No.NameEvidenceResiduesDescription
1AC1SOFTWAREARG A:8 , LEU A:23 , ASP A:25 , GLY A:27 , ALA A:28 , ASP A:29 , ASP A:30 , ILE A:47 , GLY A:48 , GLY A:49 , ILE A:50 , ILE A:84 , HOH A:115 , ARG B:8 , LEU B:23 , ASP B:25 , GLY B:27 , ALA B:28 , ASP B:29 , ASP B:30 , ILE B:47 , GLY B:48 , VAL B:82 , ILE B:84 , HOH I:9 , HOH I:10BINDING SITE FOR CHAIN I OF INHIBITOR VAL-SER- GLN-ASN-LEU-PSI(CH(OH)-CH2)-VAL-ILE-VAL
2DTAUNKNOWNASP A:25 , THR A:26 , GLY A:27NULL
3DTBUNKNOWNASP B:25 , THR B:26 , GLY B:27NULL

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 8HVP)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 8HVP)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 8HVP)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 8HVP)

(-) Exons   (0, 0)

(no "Exon" information available for 8HVP)

(-) Sequences/Alignments

Asymmetric/Biological Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:99

               SCOP domains d8hvpa_ A: Human immunodeficiency virus type 1 protease                                             SCOP domains
               CATH domains 8hvpA00 A:1-99 Acid Proteases                                                                       CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author eeee....eeeeeee..eeeeeeee.....eeee........eeeeeee..eeeeeeeeeeeeeee..eeeeeeeeee....eeehhhhhhhhh.eeee Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------- Transcript
                  8hvp A  1 PQITLWQRPLVTIRIGGQLKEALLDTGADDTVLEEMNLPGKWKPKMIGGIGGFIKVRQYDQIPVEIaGHKAIGTVLVGPTPVNIIGRNLLTQIGaTLNF 99
                                    10        20        30        40        50        60      | 70        80        90    |
                                                                                             67-ABA                      95-ABA


Chain B from PDB  Type:PROTEIN  Length:99

               SCOP domains d8hvpb_ B: Human immunodeficiency virus type 1 protease                                             SCOP domains
               CATH domains 8hvpB00 B:1-99 Acid Proteases                                                                       CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author eeee....eeeeeee..eeeeeeee.....eeee........eeeeeee..eeeeeeeeeeeeeee..eeeeeeeeee....eeehhhhhhhhh.eeee Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------- Transcript
                  8hvp B  1 PQITLWQRPLVTIRIGGQLKEALLDTGADDTVLEEMNLPGKWKPKMIGGIGGFIKVRQYDQIPVEIaGHKAIGTVLVGPTPVNIIGRNLLTQIGaTLNF 99
                                    10        20        30        40        50        60      | 70        80        90    |
                                                                                             67-ABA                      95-ABA


Chain I from PDB  Type:PROTEIN  Length:7

               SCOP domains ------- SCOP domains
               CATH domains ------- CATH domains
               Pfam domains ------- Pfam domains
         Sec.struct. author ....... Sec.struct. author
                 SAPs(SNPs) ------- SAPs(SNPs)
                    PROSITE ------- PROSITE
                 Transcript ------- Transcript
                  8hvp I  1 VSQNxIV  8
                                ||
                                5-LOV
                                 7
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 2)

Asymmetric/Biological Unit
(-)
Class: All beta proteins (24004)

(-) CATH Domains  (1, 2)

Asymmetric/Biological Unit
(-)
Class: Mainly Beta (13760)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 8HVP)

(-) Gene Ontology  (45, 45)

Asymmetric/Biological Unit(hide GO term definitions)

 Visualization

(-) Interactive Views

Asymmetric/Biological Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    ABA  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]
    LOV  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    DTA  [ RasMol ]  +environment [ RasMol ]
    DTB  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 8hvp)


(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym./Biol. Unit PNG format | Asym./Biol. Unit - sites PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)
