(-) Description

Title :  CRYSTAL STRUCTURE OF YPP1

Authors :  X. Wu, R. J. Chi, J. M. Baskin, L. Lucast, C. G. Burd, P. De Camilli, K. M. R
Date :  09 Oct 13  (Deposition) - 22 Jan 14  (Release) - 19 Mar 14  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  3.25
Chains :  Asym. Unit :  A,B,C,D,E,F,G,H
Biol. Unit 1:  A  (1x)
Biol. Unit 2:  B  (1x)
Biol. Unit 3:  C  (1x)
Biol. Unit 4:  D  (1x)
Biol. Unit 5:  E  (1x)
Biol. Unit 6:  F  (1x)
Biol. Unit 7:  G  (1x)
Biol. Unit 8:  H  (1x)
Keywords :  Heat-Like Repeat, Component Of Stt4 Complex, Efr3, Stt4, Plasma Membrane, Protein Binding (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  X. Wu, R. J. Chi, J. M. Baskin, L. Lucast, C. G. Burd, P. De Camilli, K. M. Reinisch
Structural Insights Into Assembly And Regulation Of The Plasma Membrane Phosphatidylinositol 4-Kinase Complex.
Dev. Cell V. 28 19 2014
PubMed-ID: 24360784  |  Reference-DOI: 10.1016/J.DEVCEL.2013.11.012

(-) Compounds

Molecule 1 - CARGO-TRANSPORT PROTEIN YPP1
    Chains: A, B, C, D, E, F, G, H
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Strain: BL21(DE3)
    Expression System Taxid: 469008
    Fragment: RESIDUES 11-731 AND 742-817
    Gene: YPP1, YGR198W, G7594
    Organism Common: BAKER'S YEAST
    Organism Scientific: SACCHAROMYCES CEREVISIAE
    Organism Taxid: 559292
    Strain: ATCC 204508 / S288C
    Synonym: ALPHA-SYNUCLEIN PROTECTIVE PROTEIN 1

 Structural Features

(-) Chains, Units

  12345678
Asymmetric Unit : ABCDEFGH
Biological Unit 1 (1x): A
Biological Unit 2 (1x):  B
Biological Unit 3 (1x):   C
Biological Unit 4 (1x):    D
Biological Unit 5 (1x):     E
Biological Unit 6 (1x):      F
Biological Unit 7 (1x):       G
Biological Unit 8 (1x):        H

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (1, 129)

Asymmetric Unit (1, 129)
No.NameCountTypeFull Name
1MSE129Mod. Amino AcidSELENOMETHIONINE
Biological Unit 1 (1, 17)
No.NameCountTypeFull Name
1MSE17Mod. Amino AcidSELENOMETHIONINE
Biological Unit 2 (1, 17)
No.NameCountTypeFull Name
1MSE17Mod. Amino AcidSELENOMETHIONINE
Biological Unit 3 (1, 17)
No.NameCountTypeFull Name
1MSE17Mod. Amino AcidSELENOMETHIONINE
Biological Unit 4 (1, 17)
No.NameCountTypeFull Name
1MSE17Mod. Amino AcidSELENOMETHIONINE
Biological Unit 5 (1, 15)
No.NameCountTypeFull Name
1MSE15Mod. Amino AcidSELENOMETHIONINE
Biological Unit 6 (1, 15)
No.NameCountTypeFull Name
1MSE15Mod. Amino AcidSELENOMETHIONINE
Biological Unit 7 (1, 15)
No.NameCountTypeFull Name
1MSE15Mod. Amino AcidSELENOMETHIONINE
Biological Unit 8 (1, 16)
No.NameCountTypeFull Name
1MSE16Mod. Amino AcidSELENOMETHIONINE

(-) Sites  (0, 0)

(no "Site" information available for 4N5C)

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 4N5C)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 4N5C)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 4N5C)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 4N5C)

(-) Exons   (0, 0)

(no "Exon" information available for 4N5C)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:745

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..hhhhhhhhhhhhhh........hhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh...hhhhhhhhhh....hhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhhh.........hhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhh.....hhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhh.......hhhhhhhhhhhhh....hhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...........hhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhh..hhhhhhhhhhhhh.hhhhhhhhhhhhhh..hhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh....hhhhhhhhhhhhhhhh.....hhhhhh. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4n5c A  14 SKIIDVVDQALRARLLGGSTFNSGFDSLDSVLNLQFRLHYHVIGSNGPAKPVCDVLLKESQNLEKNmSmmEELNDYPEITKLVEKILFNCLGILFFHRGQFQESQRCLLHSLKIHNNTAKTALmEQYDRYLIVENLYYRGLVSQDINImQNVFYKELLAHVDTIPPESNGLLFEYISLIVAKLRFNQIQDLAENFKTTVENPFILFLYmIKKFQSPLKKHIDNDDLYLKFGQNVLLKAKFPTASETNDEALEHFNVFLQYYFKFTHIKKIKVNPSWYNFIISSmEKTFQSIEVSKTAmFLFQNLSDNSNDEIKKKTFKRESILNFVNFVKYNDKYYQLHDNSHRDIISFIDAYSFILQNSSKTDSIENVFDYDNTVSTFATSLNSFYKEYNLPLmSQSESLDWLENSTRCVYPGNISKVLTNAWSTLYEIRKYQLDFLVSNNLTSYLCNAmmLSGEEEKALRELQFKYSYTLAQQRHIETAIKTLESLILSKNPNYYKAWHLLALCRSVQEDKEmSYKIVCSVLEAmNESLQNNTLLLNDRWQFIHLKLTQLALIEEIFGTLEALETLPEVFELYATLFPDSSmGPKYSQTKEYLLQmVWIFAANmYmRTKDNDEDAKAAIKEASNVNLNCNIANGYLSIIPGVALKEFETVLYYDENNLDALVGFAELIFPVNDTDRSAAYARLKFLLECAILESIEAYYSPEVWWYLSLIYEKYQDDEYKNSLLKCIKYQELNPIRSLRYCNY 817
                                    23        33        43        53        63        73      | 83        93       103       113       123       135   |   145       155       165       175       185       195       205       215       225       235       245       255       265       275       285       295   |   305       315       325       335       345       355       365       375       385       395       405    |  415       425       435       445       455       465|| ||  489       499       509       519       529       539    |  549      |559       569       579       589       599       609 |||   624       634     | 644       654      |669       679||     692       702       712 ||    752       762       772       782       792       802       812
                                                                                             80-MSE                                             132|   |                      164-MSE                                                     224-MSE                                                                    299-MSE       313-MSE                                                                                          410-MSE                                                 466-MSE                                                         544-MSE     556-MSE                                                611||           632-MSE 640-MSE              661|          680|                           714|
                                                                                               82-MSE                                            135   |                                                                                                                                                                                                                                                                                                                                     467-MSE                                                                                                                            617|                     642-MSE             667           684                            745
                                                                                                83-MSE                                               139-MSE                                                                                                                                                                                                                                                                                                                                   469|                                                                                                                              618-MSE
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                484


Chain B from PDB  Type:PROTEIN  Length:741

               SCOP domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhhhhhh........hhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhh....hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh...hhhhhhhhh.....hhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh..........hhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhh...hhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhh.....hhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhh......hhhhhhhhhhhhh....hhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh..........hhhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhh..hhhhhhhhhhhhh.hhhhhhhhhhhhhh..hhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhh.....hhhhhh. Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4n5c B  13 PSKIIDVVDQALRARLLGGSTFNSGFDSLDSVLNLQFRLHYHVIGSNGPAKPVCDVLLKESQNLEKNmSmmEELNDYPEITKLVEKILFNCLGILFFHRGQFQESQRCLLHSLKIHNNTKTALmEQYDRYLIVENLYYRGLVSQDINImQNVFYKELLAHVDTIPPESNGLLFEYISLIVAKLRFNQIQDLAENFKTTVENPFILFLYmIKKFQSPLKKHIDNDDLYLKFGQNVLLKAKFPTASETNDEALEHFNVFLQYYFKFTHIKKIKVNPSWYNFIISSmEKTFQSIEVSKTAmFLFQNLSDNSNDEIKKKTFKRESILNFVNFVKYNDKYYQLHDNSHRDIISFIDAYSFILQNSSKTDSIENVFDYDNTVSTFATSLNSFYKEYNLPLmSQSESLDWLENSTRCVYPGNISKVLTNAWSTLYEIRKYQLDFLVSNNLTSYLCNAmmLSGEEEKALRELQFKYSYTLAQQRHIETAIKTLESLILSKNPNYYKAWHLLALCRSVQEDKEmSYKIVCSVLEAmNESLQNNTLLLNDRWQFIHLKLTQLALIEEIFGTLEALETLPEVFELYATLFPDSmGPKYSQTKEYLLQmVWIFAANmYmRTKDNDEDAKAAIKEASNVNLNCNIANGYLSIIPGVALKEFETVLYYDENNLDALVGFAELIFFVNDTDRSAAYARLKFLLECAILESIEAYYSPEVWWYLSLIYEKDEYKNSLLKCIKYQELNPIRSLRYCNY 817
                                    22        32        42        52        62        72       |82|       92       102       112       122       135   |   145       155       165       175       185       195       205       215       225       235       245       255       265       275       285       295   |   305       315       325       335       345       355       365       375       385       395       405    |  415       425       435       445       455       465|| ||  489       499       509       519       529       539    |  549      |559       569       579       589       599       609 ||    625      |635    | |645       655     ||670       680|      693       703       713|      753       763       773       783   ||  796       806       816
                                                                                              80-MSE                                            131|   |                      164-MSE                                                     224-MSE                                                                    299-MSE       313-MSE                                                                                          410-MSE                                                 466-MSE                                                         544-MSE     556-MSE                                                611|           632-MSE 640-MSE              661|          680|                          713|                                        787|
                                                                                                82-MSE                                           135   |                                                                                                                                                                                                                                                                                                                                     467-MSE                                                                                                                            618-MSE                 642-MSE             667           684                           744                                         791
                                                                                                 83-MSE                                              139-MSE                                                                                                                                                                                                                                                                                                                                   469|
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                484


Chain C from PDB  Type:PROTEIN  Length:737

               SCOP domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhhhhh........hhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh...hhhhhhhhhh....hhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhhh.........hhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhh......hhhhhh..........hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhh.......hhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh..........hhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhh.hhhhhhhhhhhhh.hhhhhhhhhhhhhh..hhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhh....hhhhhh. Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4n5c C  14 SKIIDVVDQALRARLLGGSTFNSGFDSLDSVLNLQFRLHYHVIGSNGPAKPVCDVLLKESQNLEKNmSmmEELNDYPEITKLVEKILFNCLGILFFHRGQFQESQRCLLHSLKIHNKTALmEQYDRYLIVENLYYRGLVSQDINImQNVFYKELLAHVDTIPPESNGLLFEYISLIVAKLRFNQIQDLAENFKTTVENPFILFLYmIKKFQSPLKKHIDNDDLYLKFGQNVLLKAKFPTASETNDEALEHFNVFLQYYFKFTHIKKIKVNPSWYNFIISSmEKTFQSIEVSKTAmFLFQNLSDNSNDEIKKKTFKRESILNFVNFVKYNDKYYQLHDNSHRDIISFIDAYSFILQNSSKTDSIENVFDYDNTVSTFATSLNSFYKEYNLPLmSQSESLDWLENSTRCVYPGNISKVLTNAWSTLYEIRKYQLDFLVSNNLTSYLCNAmmLSGEEEKALRELQFKYSYTLAQQRHIETAIKTLESLILSKNPNYYKAWHLLALCRSVQEDKEmSYKIVCSVLEAmNESLQNNTLLLNDRWQFIHLKLTQLALIEEIFGTLEALETLPEVFELYATLFPDSmGPKYSQTKEYLLQmVWIFAANmYmRTKDNDEDAKAAIKEASNNLNCNIANGYLSIIPGVALKEFETVLYYDENNLDALVGFAELIFFVNDTDRSAAYARLKFLLECAILESIEAYYSPEVWWYLSLIYEKDEYKNSLLKCIKYQELNPIRSLRYCNY 817
                                    23        33        43        53        63        73      | 83        93       103       113       123     ||138|      148       158     | 168       178       188       198       208       218     | 228       238       248       258       268       278       288       298|      308    |  318       328       338       348       358       368       378       388       398       408 |     418       428       438       448       458       468||     492       502       512       522       532       542 |     552   |   562       572       582       592       602       618       628   |   638 | |   648       658 ||    674     ||687       697       707     ||747       757       767       777       787|      800       810
                                                                                             80-MSE                                          129|   |                      164-MSE                                                     224-MSE                                                                    299-MSE       313-MSE                                                                                          410-MSE                                                 466-MSE                                                         544-MSE     556-MSE                                                611|           632-MSE 640-MSE             660|          680|                          713|                                        787|
                                                                                               82-MSE                                         135   |                                                                                                                                                                                                                                                                                                                                     467-MSE                                                                                                                            618-MSE                 642-MSE            667           684                           744                                         791
                                                                                                83-MSE                                            139-MSE                                                                                                                                                                                                                                                                                                                                   469|
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                             484


Chain D from PDB  Type:PROTEIN  Length:757

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhhhhhhh........hhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh...hhhhhhhhhh....hhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh..........hhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhh.......hhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh....hhhhh.......hhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhh......hhhhhhhhhhhhhh.hhhhhhhhhhhhhhhh..hhhhhhhhhhhhh....hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhh.....hhhhhh. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4n5c D  12 VPSKIIDVVDQALRARLLGGSTFNSGFDSLDSVLNLQFRLHYHVIGSNGPAKPVCDVLLKESQNLEKNmSmmEELNDYPEITKLVEKILFNCLGILFFHRGQFQESQRCLLHSLKIHNNKTALmEQYDRYLIVENLYYRGLVSQDINImQNVFYKELLAHVDTIPPESNGLLFEYISLIVAKLRFNQIQDLAENFKTTVENPFILFLYmIKKFQSPLKKHIDNDDLYLKFGQNVLLKAKFPTASETNDEALEHFNVFLQYYFKFTHIKKIKVNPSWYNFIISSmEKTFQSIEVSKTAmFLFQNLSDNSNDEIKKKTFKRESILNFVNFVKYNDKYYQLHDNSHRDIISFIDAYSFILQNSSKTDSIENVFDYDNTVSTFATSLNSFYKEYNLPLmSQSESLDWLENSTRCVYPGNISKVLTNAWSTLYEIRKYQLDFLVSNNLTSYLCNAmmLSGEEEKALRELQFKYSYTLAQQRHIETAIKTLESLILSKNPNYYKAWHLLALCRSVQEDKEmSYKIVCSVLEAmNESLQNNTLLLNDRWQFIHLKLTQLALIEEIFGTLEALETLPEVFELYATLFPDSQPELNSmGPKYSQTKEYLLQmVWIFAANmYmRTKDNDEDAKAAIKEASNVESKFKNLNCNIANGYLSIIKDEPGVALKEFETVLYYDENNLDALVGFAELIFLTFVNDTDRSAAYARLKFLLECAILESIEAYYSPEVWWYLSLIYEKDEYKNSLLKCIKYQELNPIRSLRYCNY 817
                                    21        31        41        51        61        71        81||      91       101       111       121       135   |   145       155       165       175       185       195       205       215       225       235       245       255       265       275       285       295   |   305       315       325       335       345       355       365       375       385       395       405    |  415       425       435       445       455       465|| ||  489       499       509       519       529       539    |  549      |559       569       579       589       599       609       619       629  |    639| |    649       659       669       679       689       699       709   ||  747       757       767       777       787|      800       810
                                                                                               80-MSE                                           130|   |                      164-MSE                                                     224-MSE                                                                    299-MSE       313-MSE                                                                                          410-MSE                                                 466-MSE                                                         544-MSE     556-MSE                                                       618-MSE       632-MSE 640-MSE                                                                  713|                                          787|
                                                                                                 82-MSE                                          135   |                                                                                                                                                                                                                                                                                                                                     467-MSE                                                                                                                                                          642-MSE                                                                 742                                           791
                                                                                                  83-MSE                                             139-MSE                                                                                                                                                                                                                                                                                                                                   469|
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                484


Chain E from PDB  Type:PROTEIN  Length:727

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhhhhh........hhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh...hhhhhhhhhh....hhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhhh.........hhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhh.......hhhhhhhhhhhhh....hhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhh...hhhhhhhhhhhhh.hhhhhhhhhhhhhh..hhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhh....hhhhhh. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4n5c E  14 SKIIDVVDQALRARLLGGSTFNSGFDSLDSVLNLQFRLHYHVIGSNGPAKPVCDVLLKESQNLEKNmSYPEITKLVEKILFNCLGILFFHRGQFQESQRCLLHSLKIHNNKTALmEQYDRYLIVENLYYRGLVSQDINImQNVFYKELLAHVDTIPPESNGLLFEYISLIVAKLRFNQIQDLAENFKTTVENPFILFLYmIKKFQSPLKKHIDNDDLYLKFGQNVLLKAKFPTASETNDEALEHFNVFLQYYFKFTHIKKIKVNPSWYNFIISSmEKTFQSIEVSKTAmFLFQNLSDNSNDEIKKKTFKRESILNFVNFVKYNDKYYQLHDNSHRDIISFIDAYSFILQNSSKTDSIENVFDYDNTVSTFATSLNSFYKEYNLPLmSQSESLDWLENSTRCVYPGNISKVLTNAWSTLYEIRKYQLDFLVSNNLTSYLCNAmmLSGEEEKALRELQFKYSYTLAQQRHIETAIKTLESLILSKNPNYYKAWHLLALCRSVQEDKEmSYKIVCSVLEAmNESLQNNTLLLNDRWQFIHLKLTQLALIEEIFGTLEALETLPEVFELYATLFPDSmGPKYSQTKEYLLQmVWIFAANmYmRTKDNDEDAKAAIKEASNVFKNLNCNIANGYLSIPGVALKEFETVLYYDENNLDALVGFAELIFDRSAAYARLKFLLECAILESIEAYYSPEVWWYLSLIYEKEYKNSLLKCIKYQELNPIRSLRYCNY 817
                                    23        33        43        53        63        73      ||90       100       110       120       130|   |  144       154       164       174       184       194       204       214       224       234       244       254       264       274       284       294    |  304       314       324       334       344       354       364       374       384       394       404     | 414       424       434       444       454       464 || || 488       498       508       518       528       538     | 548       558       568       578       588       598       608  ||   624       634     | 644       654      |667       677 ||    691       701       711 ||    756       766       776       786||     800       810
                                                                                             80-MSE                                    130|   |                      164-MSE                                                     224-MSE                                                                    299-MSE       313-MSE                                                                                          410-MSE                                                 466-MSE                                                         544-MSE     556-MSE                                                611|           632-MSE 640-MSE              661|           679|                          713|                                   787|
                                                                                              81|                                       135   |                                                                                                                                                                                                                                                                                                                                     467-MSE                                                                                                                            618-MSE                 642-MSE             665            684                           749                                    792
                                                                                               89                                           139-MSE                                                                                                                                                                                                                                                                                                                                   469|
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                       484


Chain F from PDB  Type:PROTEIN  Length:727

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhhhh........hhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh...hhhhhhhhhh....hhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh..........hhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhh.hhhhh.....hhhhhhhhhhhhhhhhhhhh.......hhhhh..........hhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhh......hhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh..........hhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhh.hhhhhhhhhhh..hhhhhhhhhhhhhh..hhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhh....hhhhhh. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4n5c F  15 KIIDVVDQALRARLLGGSTFNSGFDSLDSVLNLQFRLHYHVIGSNGPAKPVCDVLLKESQNLEKNmSPEITKLVEKILFNCLGILFFHRGQFQESQRCLLHSLKIHNNTKTALmEQYDRYLIVENLYYRGLVSQDINImQNVFYKELLAHVDTIPPESNGLLFEYISLIVAKLRFNQIQDLAENFKTTVENPFILFLYmIKKFQSPLKKHIDNDDLYLKFGQNVLLKAKFPTASETNDEALEHFNVFLQYYFKFTHIKKIKVNPSWYNFIISSmEKTFQSIEVSKTAmFLFQNLSDNSNDEIKKKTFKRESILNFVNFVKYNDKYYQLHDNSHRDIISFIDAYSFILQNSSKTDSIENVFDYDNTVSTFATSLNSFYKEYNLPLmSQSESLDWLENSTRCVYPGNISKVLTNAWSTLYEIRKYQLDFLVSNNLTSYLCNAmmLSGEEEKALRELQFKYSYTLAQQRHIETAIKTLESLILSKNPNYYKAWHLLALCRSVQEDKEmSYKIVCSVLEAmNESLQNNTLLLNDRWQFIHLKLTQLALIEEIFGTLEALETLPEVFELYATLFPDSmGPKYSQTKEYLLQmVWIFAANmYmRTKDNDEDAKAAIKEASNNLNCNIANGYLSIPGVALKEFETVLYYDENNLDALVGFAELIFNDTDRSAAYARLKFLLECAILESIEAYYSPEVWWYLSLIYEKDEYKNSLLKCIKYQELNPIRSLRYCNY 817
                                    24        34        44        54        64        74     |||92       102       112       122       135   |   145       155       165       175       185       195       205       215       225       235       245       255       265       275       285       295   |   305       315       325       335       345       355       365       375       385       395       405    |  415       425       435       445       455       465|| ||  489       499       509       519       529       539    |  549      |559       569       579       589       599       609 ||    625      |635    | |645       655    || 671       685       695       705       747       757       767       777       787|      800       810
                                                                                            80-MSE                                    131|   |                      164-MSE                                                     224-MSE                                                                    299-MSE       313-MSE                                                                                          410-MSE                                                 466-MSE                                                         544-MSE     556-MSE                                                611|           632-MSE 640-MSE             660|         679|                          713|                                      787|
                                                                                             81|                                       135   |                                                                                                                                                                                                                                                                                                                                     467-MSE                                                                                                                            618-MSE                 642-MSE            667          684                           746                                       791
                                                                                              90                                           139-MSE                                                                                                                                                                                                                                                                                                                                   469|
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      484


Chain G from PDB  Type:PROTEIN  Length:735

               SCOP domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhhhhh........hhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhh....hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh...hhhhhhhhh.....hhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhhh.........hhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhh.hhhhh.....hhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhh......hhhhhhhhhhhhh....hhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhh....hhhhhhhhhh...hhhhhhhhhhhhhh..hhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhh....hhhhhh. Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4n5c G  14 SKIIDVVDQALRARLLGGSTFNSGFDSLDSVLNLQFRLHYHVIGSNGPAKPVCDVLLKESQNLEKNmSLNDYPEITKLVEKILFNCLGILFFHRGQFQESQRCLLHSLKIHNNTASQKTALmEQYDRYLIVENLYYRGLVSQDINImQNVFYKELLAHVDTIPPESNGLLFEYISLIVAKLRFNQIQDLAENFKTTVENPFILFLYmIKKFQSPLKKHIDNDDLYLKFGQNVLLKAKFPTASETNDEALEHFNVFLQYYFKFTHIKKIKVNPSWYNFIISSmEKTFQSIEVSKTAmFLFQNLSDNSNDEIKKKTFKRESILNFVNFVKYNDKYYQLHDNSHRDIISFIDAYSFILQNSSKTDSIENVFDYDNTVSTFATSLNSFYKEYNLPLmSQSESLDWLENSTRCVYPGNISKVLTNAWSTLYEIRKYQLDFLVSNNLTSYLCNAmmLSGEEEKALRELQFKYSYTLAQQRHIETAIKTLESLILSKNPNYYKAWHLLALCRSVQEDKEmSYKIVCSVLEAmNESLQNNTLLLNDRWQFIHLKLTQLALIEEIFGTLEALETLPEVFELYATLFmGPKYSQTKEYLLQmVWIFAANmYmRTKDNDEDAKAAIKEASNVESNLNCNIANGYLSIPGVALKEFETVLYYDENNLDALVGFAELIFNDTDRSAAYARLKFLLECAILESIEAYYSPEVWWYLSLIYEKDEYKNSLLKCIKYQELNPIRSLRYCNY 817
                                    23        33        43        53        63        73      ||87        97       107       117       127       137 |     147       157      |167       177       187       197       207       217      |227       237       247       257       267       277       287       297 |     307     | 317       327       337       347       357       367       377       387       397       407  |    417       427       437       447       457       467 ||    491       501       511       521       531       541  |    551    |  561       571       581       591       601      |620       630 |     640 |     650       660  ||   673     ||687       697       707     ||749       759       769       779       792       802       812
                                                                                             80-MSE                                                139-MSE                  164-MSE                                                     224-MSE                                                                    299-MSE       313-MSE                                                                                          410-MSE                                                 466-MSE                                                         544-MSE     556-MSE                                             608|           632-MSE 640-MSE                663|         679|                          713|                                      787|
                                                                                              81|                                                                                                                                                                                                                                                                                                                                                                                          467-MSE                                                                                                                         618-MSE                 642-MSE               667          684                           746                                       791
                                                                                               86                                                                                                                                                                                                                                                                                                                                                                                            469|
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              484


Chain H from PDB  Type:PROTEIN  Length:734

               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..hhhhhhhhhhhhhh........hhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhh...hhhhhhhhhh....hhhhhhhhhhhhhhh.......hhhhhhhhhhhhhhhh.........hhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhh.hhhhh.....hhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhh.....hhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhh....hhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh....hhhhhhhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhh.......hhhhhhhhhhhh.hhhhhhhhhhhhh...hhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhh....hhhhhh. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4n5c H  14 SKIIDVVDQALRARLLGGSTFNSGFDSLDSVLNLQFRLHYHVIGSNGPAKPVCDVLLKESQNLEKNmSmNDYPEITKLVEKILFNCLGILFFHRGQFQESQRCLLHSLKIHNKTALmEQYDRYLIVENLYYRGLVSQDINImQNVFYKELLAHVDTIPPESNGLLFEYISLIVAKLRFNQIQDLAENFKTTVENPFILFLYmIKKFQSPLKKHIDNDDLYLKFGQNVLLKAKFPTASETNDEALEHFNVFLQYYFKFTHIKKIKVNPSWYNFIISSmEKTFQSIEVSKTAmFLFQNLSDNSNDEIKKKTFKRESILNFVNFVKYNDKYYQLHDNSHRDIISFIDAYSFILQNSSKTDSIENVFDYDNTVSTFATSLNSFYKEYNLPLmSQSESLDWLENSTRCVYPGNISKVLTNAWSTLYEIRKYQLDFLVSNNLTSYLCNAmmLSGEEEKALRELQFKYSYTLAQQRHIETAIKTLESLILSKNPNYYKAWHLLALCRSVQEDKEmSYKIVCSVLEAmNESLQNNTLLLNDRWQFIHLKLTQLALIEEIFGTLEALETLPEVFELYATLFPmGPKYSQTKEYLLQmVWIFAANmYmRTKDNDEDAKAAIKEASNVESKFKNLNCNIANGYLSIPGVALKEFETVLYYDENNLDALVGFAELIFNDTDRSAAYARLKFLLECAILESIEAYYSPEVWWYLSLIYEKDEYKNSLLKCIKYQELNPIRSLRYCNY 817
                                    23        33        43        53        63        73      | 87        97       107       117       127 ||   |142       152       162 |     172       182       192       202       212       222 |     232       242       252       262       272       282       292      |302       312|      322       332       342       352       362       372       382       392       402       412       422       432       442       452       462   || |486       496       506       516       526       536       546       556       566       576       586       596       606  ||   624       634     | 644       654       664       674    || 688       698       708    || 750       760       770       780      |793       803       813
                                                                                             80-MSE                                      129|   |                      164-MSE                                                     224-MSE                                                                    299-MSE       313-MSE                                                                                          410-MSE                                                 466-MSE                                                         544-MSE     556-MSE                                              609|           632-MSE 640-MSE                                679|                          713|                                      787|
                                                                                               82-MSE                                     135   |                                                                                                                                                                                                                                                                                                                                     467-MSE                                                                                                                          618-MSE                 642-MSE                               684                           746                                       791
                                                                                                87                                            139-MSE                                                                                                                                                                                                                                                                                                                                   469|
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                         484
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 4N5C)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 4N5C)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 4N5C)

(-) Gene Ontology  (12, 12)

Asymmetric Unit(hide GO term definitions)

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    MSE  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
(no "Sites" information available for 4n5c)

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 4n5c)

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]
    Biological Unit 3  [ Jena3D ]
    Biological Unit 4  [ Jena3D ]
    Biological Unit 5  [ Jena3D ]
    Biological Unit 6  [ Jena3D ]
    Biological Unit 7  [ Jena3D ]
    Biological Unit 8  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Biol. Unit 1 PNG format | Biol. Unit 2 PNG format | Biol. Unit 3 PNG format | Biol. Unit 4 PNG format | Biol. Unit 5 PNG format | Biol. Unit 6 PNG format | Biol. Unit 7 PNG format | Biol. Unit 8 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  4n5c
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  YPP1_YEAST | P46951
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/SwissProt

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  YPP1_YEAST | P46951
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

(no "Entries Sharing at Least One Protein Chain" available for 4N5C)

(-) Related Entries Specified in the PDB File

4n5a INTERACTING PARTNER OF YPP1
