(-) Description

Title :  STRUCTURAL CHARACTERIZATION OF A GII.4 2004 NOROVIRUS VARIANT (TCH05) BOUND TO A TRISACCHARIDE

Authors :  S. Shanker, J. -M. Choi, B. Sankaran, R. L. Atmar, M. K. Estes, B. V. V. Pra
Date :  24 Jun 11  (Deposition) - 13 Jul 11  (Release) - 29 Oct 14  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  2.68
Chains :  Asym. Unit :  A,B,C,D,E,F,G,H,I,J
Biol. Unit 1:  A,C  (1x)
Biol. Unit 2:  B,E  (1x)
Biol. Unit 3:  D,F  (1x)
Biol. Unit 4:  G,J  (1x)
Biol. Unit 5:  H  (1x)
Biol. Unit 6:  I  (1x)
Keywords :  Viral Protein, Hbga Binding Domain, Hbga (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  S. Shanker, J. M. Choi, B. Sankaran, R. L. Atmar, M. K. Estes, B. V. Prasa
Structural Analysis Of Histo-Blood Group Antigen Binding Specificity In A Norovirus Gii. 4 Epidemic Variant: Implications For Epochal Evolution.
J. Virol. V. 85 8635 2011
PubMed-ID: 21715503  |  Reference-DOI: 10.1128/JVI.00848-11

(-) Compounds

Molecule 1 - CAPSID
    Chains: A, B, C, D, E, F, G, H, I, J
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Taxid: 562
    Fragment: PROTRUDING DOMAIN (UNP RESIDUES 221-531)
    Organism Scientific: NOROVIRUS HU/GII.4/2004/NL
    Organism Taxid: 311380

 Structural Features

(-) Chains, Units

  12345678910
Asymmetric Unit : ABCDEFGHIJ
Biological Unit 1 (1x): A C
Biological Unit 2 (1x):  B  E
Biological Unit 3 (1x):    D F
Biological Unit 4 (1x):       G  J
Biological Unit 5 (1x):        H
Biological Unit 6 (1x):         I

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (3, 24)

Asymmetric Unit (3, 24)
No.NameCountTypeFull Name
1A2G8Ligand/IonN-ACETYL-2-DEOXY-2-AMINO-GALACTOSE
2FUC8Ligand/IonALPHA-L-FUCOSE
3GAL8Ligand/IonBETA-D-GALACTOSE
Biological Unit 1 (3, 6)
No.NameCountTypeFull Name
1A2G2Ligand/IonN-ACETYL-2-DEOXY-2-AMINO-GALACTOSE
2FUC2Ligand/IonALPHA-L-FUCOSE
3GAL2Ligand/IonBETA-D-GALACTOSE
Biological Unit 2 (3, 6)
No.NameCountTypeFull Name
1A2G2Ligand/IonN-ACETYL-2-DEOXY-2-AMINO-GALACTOSE
2FUC2Ligand/IonALPHA-L-FUCOSE
3GAL2Ligand/IonBETA-D-GALACTOSE
Biological Unit 3 (3, 6)
No.NameCountTypeFull Name
1A2G2Ligand/IonN-ACETYL-2-DEOXY-2-AMINO-GALACTOSE
2FUC2Ligand/IonALPHA-L-FUCOSE
3GAL2Ligand/IonBETA-D-GALACTOSE
Biological Unit 4 (3, 6)
No.NameCountTypeFull Name
1A2G2Ligand/IonN-ACETYL-2-DEOXY-2-AMINO-GALACTOSE
2FUC2Ligand/IonALPHA-L-FUCOSE
3GAL2Ligand/IonBETA-D-GALACTOSE
Biological Unit 5 (0, 0)
No.NameCountTypeFull Name
1A2G-1Ligand/IonN-ACETYL-2-DEOXY-2-AMINO-GALACTOSE
2FUC-1Ligand/IonALPHA-L-FUCOSE
3GAL-1Ligand/IonBETA-D-GALACTOSE
Biological Unit 6 (0, 0)
No.NameCountTypeFull Name
1A2G-1Ligand/IonN-ACETYL-2-DEOXY-2-AMINO-GALACTOSE
2FUC-1Ligand/IonALPHA-L-FUCOSE
3GAL-1Ligand/IonBETA-D-GALACTOSE

(-) Sites  (24, 24)

Asymmetric Unit (24, 24)
No.NameEvidenceResiduesDescription
01AC1SOFTWAREGAL A:2 , FUC A:3 , HIS A:347 , ASP A:374 , LYS C:348 , SER C:442BINDING SITE FOR RESIDUE A2G A 1
02AC2SOFTWAREA2G A:1 , FUC A:3 , HOH C:760BINDING SITE FOR RESIDUE GAL A 2
03AC3SOFTWAREA2G A:1 , GAL A:2 , SER A:343 , THR A:344 , ARG A:345 , ASP A:374 , GLY C:443 , TYR C:444BINDING SITE FOR RESIDUE FUC A 3
04AC4SOFTWAREGAL B:2 , FUC B:3 , HIS B:347 , ASP B:374 , LYS E:348BINDING SITE FOR RESIDUE A2G B 1
05AC5SOFTWAREA2G B:1 , FUC B:3 , HOH B:532BINDING SITE FOR RESIDUE GAL B 2
06AC6SOFTWAREA2G B:1 , GAL B:2 , SER B:343 , THR B:344 , ARG B:345 , ASP B:374 , GLY E:443 , TYR E:444BINDING SITE FOR RESIDUE FUC B 3
07AC7SOFTWARELYS A:348 , GAL C:2 , FUC C:3 , HIS C:347BINDING SITE FOR RESIDUE A2G C 1
08AC8SOFTWAREA2G C:1 , FUC C:3BINDING SITE FOR RESIDUE GAL C 2
09AC9SOFTWAREGLY A:443 , TYR A:444 , A2G C:1 , GAL C:2 , SER C:343 , THR C:344 , ARG C:345 , ASP C:374BINDING SITE FOR RESIDUE FUC C 3
10BC1SOFTWAREGAL D:2 , FUC D:3 , HIS D:347 , LYS F:348BINDING SITE FOR RESIDUE A2G D 1
11BC2SOFTWAREA2G D:1 , FUC D:3BINDING SITE FOR RESIDUE GAL D 2
12BC3SOFTWAREA2G D:1 , GAL D:2 , SER D:343 , THR D:344 , ARG D:345 , ASP D:374 , GLY F:443 , TYR F:444BINDING SITE FOR RESIDUE FUC D 3
13BC4SOFTWAREGAL E:2 , FUC E:3 , HIS E:347 , ASP E:374BINDING SITE FOR RESIDUE A2G E 1
14BC5SOFTWAREA2G E:1 , FUC E:3BINDING SITE FOR RESIDUE GAL E 2
15BC6SOFTWAREGLY B:443 , TYR B:444 , A2G E:1 , GAL E:2 , SER E:343 , THR E:344 , ARG E:345 , ASP E:374BINDING SITE FOR RESIDUE FUC E 3
16BC7SOFTWAREGAL F:2 , FUC F:3BINDING SITE FOR RESIDUE A2G F 1
17BC8SOFTWAREA2G F:1 , FUC F:3BINDING SITE FOR RESIDUE GAL F 2
18BC9SOFTWARESER D:442 , GLY D:443 , TYR D:444 , A2G F:1 , GAL F:2 , SER F:343 , THR F:344 , ARG F:345 , ASP F:374BINDING SITE FOR RESIDUE FUC F 3
19CC1SOFTWAREGAL G:2 , HIS G:347 , ASP G:374 , LYS J:348BINDING SITE FOR RESIDUE A2G G 1
20CC2SOFTWAREA2G G:1 , FUC G:3BINDING SITE FOR RESIDUE GAL G 2
21CC3SOFTWAREGAL G:2 , SER G:343 , THR G:344 , ARG G:345 , ASP G:374 , SER J:442 , GLY J:443 , TYR J:444BINDING SITE FOR RESIDUE FUC G 3
22CC4SOFTWARELYS G:348 , SER G:442 , GAL J:2 , FUC J:3 , HIS J:347 , ASP J:374BINDING SITE FOR RESIDUE A2G J 1
23CC5SOFTWAREA2G J:1 , FUC J:3BINDING SITE FOR RESIDUE GAL J 2
24CC6SOFTWARESER G:442 , GLY G:443 , A2G J:1 , GAL J:2 , SER J:343 , THR J:344 , ARG J:345 , ASP J:374BINDING SITE FOR RESIDUE FUC J 3

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 3SLD)

(-) Cis Peptide Bonds  (9, 9)

Asymmetric Unit
No.Residues
1Glu A:399 -Pro A:400
2Glu B:399 -Pro B:400
3Glu C:399 -Pro C:400
4Glu D:399 -Pro D:400
5Glu E:399 -Pro E:400
6Glu F:399 -Pro F:400
7Glu G:399 -Pro G:400
8Glu H:399 -Pro H:400
9Glu J:399 -Pro J:400

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 3SLD)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 3SLD)

(-) Exons   (0, 0)

(no "Exon" information available for 3SLD)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:309
 aligned with Q5EGK8_9CALI | Q5EGK8 from UniProtKB/TrEMBL  Length:540

    Alignment length:309
                                   232       242       252       262       272       282       292       302       312       322       332       342       352       362       372       382       392       402       412       422       432       442       452       462       472       482       492       502       512       522
         Q5EGK8_9CALI   223 RTKPFSVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGVLLGTTQLSPVNICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
               SCOP domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..........hhhhh..........eeeee.................................eeeeeee.....eeeeee.........................eeeeeeeee......eeeeeeeee......hhhh.eeeeee...........eeeeeeeee.......................................eeeeeeeee..eeee....eeee..hhhhhhhhhhhh......eeeeeeee....eeeeeeeee....eeee....ee.......eeeeeeee.......... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3sld A 223 RTKPFTVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGALLGTTQLSPVDICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
                                   232       242       252       262       272       282       292       302       312       322       332       342       352       362       372       382       392       402       412       422       432       442       452       462       472       482       492       502       512       522


Chain B from PDB  Type:PROTEIN  Length:308
 aligned with Q5EGK8_9CALI | Q5EGK8 from UniProtKB/TrEMBL  Length:540

    Alignment length:308
                                   233       243       253       263       273       283       293       303       313       323       333       343       353       363       373       383       393       403       413       423       433       443       453       463       473       483       493       503       513       523
         Q5EGK8_9CALI   224 TKPFSVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGVLLGTTQLSPVNICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .........hhhhh..........eeeee.................................eeeeeeee....eeeeee.........................eeeeeeeee......eeeeeeeee......hhhh.eeeeee...........eeeeeeee........................................eeeeeeeee..........eeee..hhhhhhhhhhhh......eeeeeeee....eeeeeeeee....eeee....ee.......eeeeeeee.......... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3sld B 224 TKPFTVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGALLGTTQLSPVDICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
                                   233       243       253       263       273       283       293       303       313       323       333       343       353       363       373       383       393       403       413       423       433       443       453       463       473       483       493       503       513       523


Chain C from PDB  Type:PROTEIN  Length:311
 aligned with Q5EGK8_9CALI | Q5EGK8 from UniProtKB/TrEMBL  Length:540

    Alignment length:311
                                   230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380       390       400       410       420       430       440       450       460       470       480       490       500       510       520       530
         Q5EGK8_9CALI   221 ESRTKPFSVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGVLLGTTQLSPVNICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
               SCOP domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ............hhhhh..........eeeee.................................eeeeeee.....eeeeee.........................eeeeeeeee......eeeeeeeee......hhhh.eeeeee...........eeeeeeeee.......................................eeeeeeeee..eeee....eeee..hhhhhhhhhhhh......eeeeeee......eeeeeeee....eeee....ee.......eeeeeeee.......... Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3sld C 221 ESRTKPFTVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGALLGTTQLSPVDICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
                                   230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380       390       400       410       420       430       440       450       460       470       480       490       500       510       520       530


Chain D from PDB  Type:PROTEIN  Length:307
 aligned with Q5EGK8_9CALI | Q5EGK8 from UniProtKB/TrEMBL  Length:540

    Alignment length:307
                                   234       244       254       264       274       284       294       304       314       324       334       344       354       364       374       384       394       404       414       424       434       444       454       464       474       484       494       504       514       524
         Q5EGK8_9CALI   225 KPFSVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGVLLGTTQLSPVNICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ........hhhhh..........eeee..................................eeeeeeee....eeeeee.........................eeeeeeeeee....eeeeeeeeee......hhhh.eeeeee..........eeeeeeeeee.......................................eeeeeeeee..eeee....eeee..hhhhhhhhhhhh......eeeeeee......eeeeeeee....eeee....ee.......eeeeeeee.......... Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3sld D 225 KPFTVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGALLGTTQLSPVDICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
                                   234       244       254       264       274       284       294       304       314       324       334       344       354       364       374       384       394       404       414       424       434       444       454       464       474       484       494       504       514       524


Chain E from PDB  Type:PROTEIN  Length:309
 aligned with Q5EGK8_9CALI | Q5EGK8 from UniProtKB/TrEMBL  Length:540

    Alignment length:309
                                   231       241       251       261       271       281       291       301       311       321       331       341       351       361       371       381       391       401       411       421       431       441       451       461       471       481       491       501       511       521
         Q5EGK8_9CALI   222 SRTKPFSVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGVLLGTTQLSPVNICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPM 530
               SCOP domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...........hhhhh..........eeeee.................................eeeeeee.....eeeeee.........................eeeeeeeee......eeeeeeeee...........eeeeee...........eeeeeeeee.......................................eeeeeeeee..eee.....eeee..hhhhhhhhhhhh......eeeeeee......eeeeeeee....eeee....ee.......eeeeeeee......... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3sld E 222 SRTKPFTVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGALLGTTQLSPVDICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPM 530
                                   231       241       251       261       271       281       291       301       311       321       331       341       351       361       371       381       391       401       411       421       431       441       451       461       471       481       491       501       511       521


Chain F from PDB  Type:PROTEIN  Length:308
 aligned with Q5EGK8_9CALI | Q5EGK8 from UniProtKB/TrEMBL  Length:540

    Alignment length:308
                                   233       243       253       263       273       283       293       303       313       323       333       343       353       363       373       383       393       403       413       423       433       443       453       463       473       483       493       503       513       523
         Q5EGK8_9CALI   224 TKPFSVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGVLLGTTQLSPVNICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .........hhhhh..........eeeee.................................eeeeeee.....eeeeee.........................eeeeeeeee......eeeeeeeee...........eeeeee...........eeeeeeeee.......................................eeeeeeeee..eeee....eeee..hhhhhhhhhhhh......eeeeeee......eeeeeeee...eeeee....ee.......eeeeeeee.......... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3sld F 224 TKPFTVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGALLGTTQLSPVDICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
                                   233       243       253       263       273       283       293       303       313       323       333       343       353       363       373       383       393       403       413       423       433       443       453       463       473       483       493       503       513       523


Chain G from PDB  Type:PROTEIN  Length:308
 aligned with Q5EGK8_9CALI | Q5EGK8 from UniProtKB/TrEMBL  Length:540

    Alignment length:308
                                   233       243       253       263       273       283       293       303       313       323       333       343       353       363       373       383       393       403       413       423       433       443       453       463       473       483       493       503       513       523
         Q5EGK8_9CALI   224 TKPFSVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGVLLGTTQLSPVNICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .........hhhhh..........eeeee.................................eeeeeee.....eeeeee.........................eeeeeeeee......eeeeeeeee......hhhh.eeeeee...........eeeeeeeee...................hhhhh...............eeeeeeeee..eeee....eeee..hhhhhhhhhhhh......eeeeeee......eeeeeeee...eeeee....ee.......eeeeeeee.......... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3sld G 224 TKPFTVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGALLGTTQLSPVDICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
                                   233       243       253       263       273       283       293       303       313       323       333       343       353       363       373       383       393       403       413       423       433       443       453       463       473       483       493       503       513       523


Chain H from PDB  Type:PROTEIN  Length:293
 aligned with Q5EGK8_9CALI | Q5EGK8 from UniProtKB/TrEMBL  Length:540

    Alignment length:311
                                   230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380       390       400       410       420       430       440       450       460       470       480       490       500       510       520       530
         Q5EGK8_9CALI   221 ESRTKPFSVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGVLLGTTQLSPVNICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
               SCOP domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ............hhhhh..........eeeee..........................hhhhh..eeeeeeee....eeeeee.........................eeeeeee...........eeeeee......hhhh.eeeee...--.......eeeeeeee.---------..............................eeeeeeeee..-------.eeee..hhhhhhhhhhhh......eeeeeeee....eeeeeeeee...eeeee....ee.......eeeeeeee.......... Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3sld H 221 ESRTKPFTVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGALLGTTQLSPVDICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDT--DFETGQNTRFTPVGVV---------EPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMP-------MNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
                                   230       240       250       260       270       280       290       300       310       320       330       340       350       360       370|  |   380        |-       400       410       420       430        |-      |450       460       470       480       490       500       510       520       530
                                                                                                                                                                                371  |            389       399                                     439     447
                                                                                                                                                                                   374


Chain I from PDB  Type:PROTEIN  Length:286
 aligned with Q5EGK8_9CALI | Q5EGK8 from UniProtKB/TrEMBL  Length:540

    Alignment length:310
                                   230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380       390       400       410       420       430       440       450       460       470       480       490       500       510       520       530
         Q5EGK8_9CALI   221 ESRTKPFSVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGVLLGTTQLSPVNICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPM 530
               SCOP domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ............hhhhh..........eeee...........................hhhhh..eeeeeee.....eeeeee.........................eeeeeee..........eeeeeee......hhhh.eeeee.----.......eeeeeee.-------------...........................eeeeeeee....-------.eee..hhhhhhhhhhhh......eeeeeee......eeeeeeee...eeeee....ee.......eeeeeeee......... Sec.struct. author
                 SAPs(SNPs) ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3sld I 221 ESRTKPFTVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGALLGTTQLSPVDICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFST----DFETGQNTRFTPVGV-------------QWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPG-------NLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPM 530
                                   230       240       250       260       270       280       290       300       310       320       330       340       350       360        |-   |   380       | -         - |     410       420       430       440       450       460       470       480       490       500       510       520       530
                                                                                                                                                                              369  374           388           402                                   440     448


Chain J from PDB  Type:PROTEIN  Length:307
 aligned with Q5EGK8_9CALI | Q5EGK8 from UniProtKB/TrEMBL  Length:540

    Alignment length:307
                                   234       244       254       264       274       284       294       304       314       324       334       344       354       364       374       384       394       404       414       424       434       444       454       464       474       484       494       504       514       524
         Q5EGK8_9CALI   225 KPFSVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGVLLGTTQLSPVNICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ........hhhhh..........eeee..................................eeeeeee.....eeeeee.........................eeeeeeeee......eeeeeeeee...........eeeeee...........eeeeeeeee.......................................eeeeeeeee..eeee....eeee..hhhhhhhhhhhh......eeeeeee......eeeeeeee...eeeee....ee.......eeeeeeee.......... Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3sld J 225 KPFTVPILTVEEMTNSRFPIPLEKLFTGPSSAFVVQPQNGRCTTDGALLGTTQLSPVDICTFRGDVTHIAGTQNYTMNLASQNWNNYDPTEEIPAPLGTPDFVGKIQGVLTQTTRRDGSTRGHKATVSTGSVHFTPKLGSVQFSTDTSNDFETGQNTRFTPVGVVQDGSTTHQNEPQQWVLPDYSGRDSHNVHLAPAVAPTFPGEQLLFFRSTMPGCSGYPNMNLDCLLPQEWVQHFYQESAPAQSDVALLRFVNPDTGRVLFECKLHKSGYVTVAHTGQHDLVIPPNGYFRFDSWVNQFYTLAPMG 531
                                   234       244       254       264       274       284       294       304       314       324       334       344       354       364       374       384       394       404       414       424       434       444       454       464       474       484       494       504       514       524
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 3SLD)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 3SLD)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 3SLD)

(-) Gene Ontology  (1, 1)

Asymmetric Unit(hide GO term definitions)
Chain A,B,C,D,E,F,G,H,I,J   (Q5EGK8_9CALI | Q5EGK8)
molecular function
    GO:0046872    metal ion binding    Interacting selectively and non-covalently with any metal ion.

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    A2G  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]
    FUC  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]
    GAL  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    AC2  [ RasMol ]  +environment [ RasMol ]
    AC3  [ RasMol ]  +environment [ RasMol ]
    AC4  [ RasMol ]  +environment [ RasMol ]
    AC5  [ RasMol ]  +environment [ RasMol ]
    AC6  [ RasMol ]  +environment [ RasMol ]
    AC7  [ RasMol ]  +environment [ RasMol ]
    AC8  [ RasMol ]  +environment [ RasMol ]
    AC9  [ RasMol ]  +environment [ RasMol ]
    BC1  [ RasMol ]  +environment [ RasMol ]
    BC2  [ RasMol ]  +environment [ RasMol ]
    BC3  [ RasMol ]  +environment [ RasMol ]
    BC4  [ RasMol ]  +environment [ RasMol ]
    BC5  [ RasMol ]  +environment [ RasMol ]
    BC6  [ RasMol ]  +environment [ RasMol ]
    BC7  [ RasMol ]  +environment [ RasMol ]
    BC8  [ RasMol ]  +environment [ RasMol ]
    BC9  [ RasMol ]  +environment [ RasMol ]
    CC1  [ RasMol ]  +environment [ RasMol ]
    CC2  [ RasMol ]  +environment [ RasMol ]
    CC3  [ RasMol ]  +environment [ RasMol ]
    CC4  [ RasMol ]  +environment [ RasMol ]
    CC5  [ RasMol ]  +environment [ RasMol ]
    CC6  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
    Glu A:399 - Pro A:400   [ RasMol ]
    Glu B:399 - Pro B:400   [ RasMol ]
    Glu C:399 - Pro C:400   [ RasMol ]
    Glu D:399 - Pro D:400   [ RasMol ]
    Glu E:399 - Pro E:400   [ RasMol ]
    Glu F:399 - Pro F:400   [ RasMol ]
    Glu G:399 - Pro G:400   [ RasMol ]
    Glu H:399 - Pro H:400   [ RasMol ]
    Glu J:399 - Pro J:400   [ RasMol ]

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]
    Biological Unit 3  [ Jena3D ]
    Biological Unit 4  [ Jena3D ]
    Biological Unit 5  [ Jena3D ]
    Biological Unit 6  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Asym. Unit - sites PNG format | Biol. Unit 1 PNG format | Biol. Unit 1 - sites PNG format | Biol. Unit 2 PNG format | Biol. Unit 3 PNG format | Biol. Unit 4 PNG format | Biol. Unit 5 PNG format | Biol. Unit 6 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  3sld
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  Q5EGK8_9CALI | Q5EGK8
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/TrEMBL

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  Q5EGK8_9CALI | Q5EGK8
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/TrEMBL
        Q5EGK8_9CALI | Q5EGK8: 3sej 3sjp 3skb 3sln

(-) Related Entries Specified in the PDB File

3sej 3sjp 3skb 3sln
