(-) Description

Title :  THE STRUCTURE OF MYCOBACTERIUM MARINUM ARYLAMINE N-ACETYLTRANSFERASE IN COMPLEX WITH COA

Authors :  E. Fullam, I. M. Westwood, M. C. Anderton, E. D. Lowe, E. Sim, M. E. M. Nob
Date :  02 Nov 07  (Deposition) - 18 Dec 07  (Release) - 13 Jul 11  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  2.70
Chains :  Asym. Unit :  A,B
Biol. Unit 1:  A  (1x)
Biol. Unit 2:  B  (1x)
Keywords :  Transferase (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  E. Fullam, I. M. Westwood, M. C. Anderton, E. D. Lowe, E. Sim, M. E. M. Noble
Divergence Of Cofactor Recognition Across Evolution: Coenzyme A Binding In A Prokaryotic Arylamine N-Acetyltransferase.
J. Mol. Biol. V. 375 178 2008
PubMed-ID: 18005984  |  Reference-DOI: 10.1016/J.JMB.2007.10.019

(-) Compounds

Molecule 1 - ARYLAMINE N-ACETYLTRANSFERASE
    Chains: A, B
    EC Number: 2.3.1.5
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Strain: BL21(DE3)PLYSS
    Expression System Taxid: 469008
    Expression System Vector: PET28B
    Organism Scientific: MYCOBACTERIUM MARINUM
    Organism Taxid: 1781

 Structural Features

(-) Chains, Units

  12
Asymmetric Unit : AB
Biological Unit 1 (1x): A
Biological Unit 2 (1x):  B

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (1, 2)

Asymmetric Unit (1, 2)
No.NameCountTypeFull Name
1COA2Ligand/IonCOENZYME A
Biological Unit 1 (1, 1)
No.NameCountTypeFull Name
1COA1Ligand/IonCOENZYME A
Biological Unit 2 (1, 1)
No.NameCountTypeFull Name
1COA1Ligand/IonCOENZYME A

(-) Sites  (2, 2)

Asymmetric Unit (2, 2)
No.NameEvidenceResiduesDescription
1AC1SOFTWARECYS B:70 , TRP B:97 , LEU B:98 , PHE B:130 , GLY B:131 , GLY B:132 , GLU B:152 , VAL B:169 , ARG B:170 , ALA B:210 , ASN B:220 , MET B:222 , HIS B:229 , THR B:234 , LYS B:236 , HOH B:2090 , HOH B:2125BINDING SITE FOR RESIDUE COA B1276
2AC2SOFTWARECYS A:70 , TRP A:97 , LEU A:98 , PHE A:130 , GLY A:131 , GLY A:132 , GLU A:152 , VAL A:169 , ARG A:170 , PHE A:204 , MET A:209 , ALA A:210 , ASN A:220 , MET A:222 , HIS A:229 , GLY A:232 , LYS A:236 , HOH A:2097BINDING SITE FOR RESIDUE COA A1276

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 2VFC)

(-) Cis Peptide Bonds  (9, 9)

Asymmetric Unit
No.Residues
1Arg A:15 -Gly A:16
2Gly A:160 -Asp A:161
3Asp A:215 -Asp A:216
4Val A:260 -Gly A:261
5Cys A:274 -Phe A:275
6Gly B:160 -Asp B:161
7Asp B:215 -Asp B:216
8Gly B:232 -Gly B:233
9Cys B:274 -Phe B:275

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 2VFC)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 2VFC)

(-) Exons   (0, 0)

(no "Exon" information available for 2VFC)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:272
 aligned with B2HIZ6_MYCMM | B2HIZ6 from UniProtKB/TrEMBL  Length:280

    Alignment length:272
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273
         B2HIZ6_MYCMM     4 DLTGYLDRINYRGATDPTLDVLRDLVSAHTGAIAFENLDPLMGVPVDDLSAEALADKLVDRRRGGYCYEHNGLIGYVLAELGYRVRRLAGRVVWLAPPDAPTPAQTHTVLAVTFPGCQGPYLVDVGFGGMTPTAPLRLETGTVQQTALEPYRLDDRGDGLVLQAMVRDEWQALYEFSTLTRPQVDLRVGSWFVSTHPTSHFVTGLMAATVADDARWNLMGRNLAIHRRGGTEKILLEDAAAVVDTLGDRFGINVADVGERGRLEARIDKVCF 275
               SCOP domains d2vfca_ A: automated matches                                                                                                                                                                                                                                                     SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhh........hhhhhhhhhhhhhhhh.eehhhhhh.......hhhhhhhhhh......hhhhhhhhhhhhhhhhh.eeeeeeeee............eeeeeeeee.......eee............ee.....ee......eeeeee..eeeeeeee..eeeeeeee.....hhhhhhhhhhhhhhh..hhhhhh.eeeeee..eeeeee..eeeeee..eeeeee..hhhhhhhhhhh....hhhhhhhhhhhhhhhhhh.. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2vfc A   4 DLTGYLDRINYRGATDPTLDVLRDLVSAHTGAIAFENLDPLMGVPVDDLSAEALADKLVDRRRGGYCYEHNGLIGYVLAELGYRVRRLAGRVVWLAPPDAPTPAQTHTVLAVTFPGCQGPYLVDVGFGGMTPTAPLRLETGTVQQTALEPYRLDDRGDGLVLQAMVRDEWQALYEFSTLTRPQVDLRVGSWFVSTHPTSHFVTGLMAATVADDARWNLMGRNLAIHRRGGTEKILLEDAAAVVDTLGDRFGINVADVGERGRLEARIDKVCF 275
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273


Chain B from PDB  Type:PROTEIN  Length:271
 aligned with B2HIZ6_MYCMM | B2HIZ6 from UniProtKB/TrEMBL  Length:280

    Alignment length:272
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273
         B2HIZ6_MYCMM     4 DLTGYLDRINYRGATDPTLDVLRDLVSAHTGAIAFENLDPLMGVPVDDLSAEALADKLVDRRRGGYCYEHNGLIGYVLAELGYRVRRLAGRVVWLAPPDAPTPAQTHTVLAVTFPGCQGPYLVDVGFGGMTPTAPLRLETGTVQQTALEPYRLDDRGDGLVLQAMVRDEWQALYEFSTLTRPQVDLRVGSWFVSTHPTSHFVTGLMAATVADDARWNLMGRNLAIHRRGGTEKILLEDAAAVVDTLGDRFGINVADVGERGRLEARIDKVCF 275
               SCOP domains d2vfcb_ B:  automated matches                                                                                                                                                                                                                                                    SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author hhhhhhhhh..-.....hhhhhhhhhhhhhhhh.eehhhhhh.......hhhhhhhhhh......hhhhhhhhhhhhhhhhh.eeeeeeeee............eeeeeeeee.......eee............ee.............eeeeee..eeeeeee....eeeeeee.....hhhhhhhhhhhhhhh..hhhhhh.eeeeee..eeeeee..eeeeee....eeee..hhhhhhhhhhh....hhhhhhhhhhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2vfc B   4 DLTGYLDRINY-GATDPTLDVLRDLVSAHTGAIAFENLDPLMGVPVDDLSAEALADKLVDRRRGGYCYEHNGLIGYVLAELGYRVRRLAGRVVWLAPPDAPTPAQTHTVLAVTFPGCQGPYLVDVGFGGMTPTAPLRLETGTVQQTALEPYRLDDRGDGLVLQAMVRDEWQALYEFSTLTRPQVDLRVGSWFVSTHPTSHFVTGLMAATVADDARWNLMGRNLAIHRRGGTEKILLEDAAAVVDTLGDRFGINVADVGERGRLEARIDKVCF 275
                                    13| |     23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273
                                     14 |
                                       16
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 2)

Asymmetric Unit
(-)
Class: Alpha and beta proteins (a+b) (23004)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 2VFC)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 2VFC)

(-) Gene Ontology  (3, 3)

Asymmetric Unit(hide GO term definitions)
Chain A,B   (B2HIZ6_MYCMM | B2HIZ6)
molecular function
    GO:0016407    acetyltransferase activity    Catalysis of the transfer of an acetyl group to an acceptor molecule.
    GO:0016740    transferase activity    Catalysis of the transfer of a group, e.g. a methyl group, glycosyl group, acyl group, phosphorus-containing, or other groups, from one compound (generally regarded as the donor) to another compound (generally regarded as the acceptor). Transferase is the systematic name for any enzyme of EC class 2.
biological process
    GO:0008152    metabolic process    The chemical reactions and pathways, including anabolism and catabolism, by which living organisms transform chemical substances. Metabolic processes typically transform small molecules, but also include macromolecular processes such as DNA repair and replication, and protein synthesis and degradation.

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    COA  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    AC2  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
    Arg A:15 - Gly A:16   [ RasMol ]
    Asp A:215 - Asp A:216   [ RasMol ]
    Asp B:215 - Asp B:216   [ RasMol ]
    Cys A:274 - Phe A:275   [ RasMol ]
    Cys B:274 - Phe B:275   [ RasMol ]
    Gly A:160 - Asp A:161   [ RasMol ]
    Gly B:160 - Asp B:161   [ RasMol ]
    Gly B:232 - Gly B:233   [ RasMol ]
    Val A:260 - Gly A:261   [ RasMol ]

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Asym. Unit - sites PNG format | Biol. Unit 1 PNG format | Biol. Unit 1 - sites PNG format | Biol. Unit 2 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  2vfc
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  B2HIZ6_MYCMM | B2HIZ6
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/TrEMBL

Access by Enzyme Classificator   (EC Number)
  2.3.1.5
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  B2HIZ6_MYCMM | B2HIZ6
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/TrEMBL
        B2HIZ6_MYCMM | B2HIZ6: 2vfb 3ltw 4b55 4c5p

(-) Related Entries Specified in the PDB File

2vfb THE STRUCTURE OF MYCAOBACTERIUM MARINUM ARYLAMINE N-ACETYLTRANSFERASE
