(-) Description

Title :  THE UDP COMPLEX STRUCTURE OF THE SIXTH GENE PRODUCT OF THE F1-ATPASE OPERON OF RHODOBACTER BLASTICUS

Authors :  C. Enroth, A. Strid
Date :  29 Jun 07  (Deposition) - 22 Jan 08  (Release) - 13 Jul 11  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  1.65
Chains :  Asym. Unit :  A,B
Biol. Unit 1:  A,B  (1x)
Biol. Unit 2:  A,B  (2x)
Keywords :  Majastridin, Atpase Operon, Glycosyl Transferase, Rossmann Fold, Udp- Complex, Transferase (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  C. Enroth, A. Strid
Crystal Structure Of A Protein, Structurally Related To Glycosyltransferases, Encoded In The Rhodobacter Blasticus Atp Operon.
Biochim. Biophys. Acta V. 1784 379 2008
PubMed-ID: 18067873  |  Reference-DOI: 10.1016/J.BBAPAP.2007.11.005

(-) Compounds

Molecule 1 - ATP SYNTHASE SUBUNITS REGION ORF 6
    Chains: A, B
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Strain: BL21(DE3)PLYSS
    Expression System Taxid: 562
    Organism Scientific: RHODOBACTER BLASTICUS
    Organism Taxid: 1075

 Structural Features

(-) Chains, Units

  12
Asymmetric Unit : AB
Biological Unit 1 (1x): AB
Biological Unit 2 (2x): AB

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (2, 3)

Asymmetric Unit (2, 3)
No.NameCountTypeFull Name
1MN2Ligand/IonMANGANESE (II) ION
2UDP1Ligand/IonURIDINE-5'-DIPHOSPHATE
Biological Unit 1 (1, 1)
No.NameCountTypeFull Name
1MN-1Ligand/IonMANGANESE (II) ION
2UDP1Ligand/IonURIDINE-5'-DIPHOSPHATE
Biological Unit 2 (1, 2)
No.NameCountTypeFull Name
1MN-1Ligand/IonMANGANESE (II) ION
2UDP2Ligand/IonURIDINE-5'-DIPHOSPHATE

(-) Sites  (3, 3)

Asymmetric Unit (3, 3)
No.NameEvidenceResiduesDescription
1AC1SOFTWAREHIS A:82 , ASP A:84 , HIS A:202 , HOH A:429 , HOH A:435BINDING SITE FOR RESIDUE MN A 300
2AC2SOFTWAREHIS B:82 , ASP B:84 , HIS B:202 , UDP B:800BINDING SITE FOR RESIDUE MN B 300
3AC3SOFTWARELEU B:23 , ARG B:25 , ASN B:54 , ASN B:58 , HIS B:82 , GLU B:83 , ASP B:84 , PHE B:175 , HIS B:202 , GLY B:204 , ARG B:205 , MN B:300 , HOH B:803 , HOH B:804 , HOH B:807 , HOH B:1119 , HOH B:1145BINDING SITE FOR RESIDUE UDP B 800

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 2QGI)

(-) Cis Peptide Bonds  (2, 2)

Asymmetric Unit
No.Residues
1Val A:146 -Pro A:147
2Val B:146 -Pro B:147

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 2QGI)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 2QGI)

(-) Exons   (0, 0)

(no "Exon" information available for 2QGI)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:248
 aligned with YAT6_RHOBL | P05449 from UniProtKB/Swiss-Prot  Length:249

    Alignment length:248
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241
           YAT6_RHOBL     2 KPVPTYVQDKDESTLMFSVCSLVRDQAKYDRLLESFERFGFTPDKAEFLAADNREGNQFHGFSWHKQMLPRCKGRYVIFCHEDVELVDRGYDDLVAAIEALEEADPKWLVAGVAGSPWRPLNHSVTAQALHISDVFGNDRRRGNVPCRVESLDECFLLMRRLKPVLNSYDMQGFHYYGADLCLQAEFLGGRAYAIDFHLHHYGRAIADENFHRLRQEMAQKYRRWFPGRILHCVTGRVALGGGWYEAR 249
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ....eee.........eeeeeee.hhhhhhhhhhhhhhh......eeeeeee..........hhhhhhhhhh...eeeeee..ee....hhhhhhhhhhhhhhhh..eeeee.eeee...........eeeeee..eeeeee....eeeeee...eeeee...............hhhhhhhhhhhhh..eeee.....ee......hhhhhhhhhhhhhhhh......eeee..eeee..hhhhhh. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2qgi A   2 KPVPTYVQDKDESTLMFSVCSLVRDQAKYDRLLESFERFGFTPDKAEFLAADNREGNQFHGFSWHKQMLPRCKGRYVIFCHEDVELVDRGYDDLVAAIEALEEADPKWLVAGVAGSPWRPLNHSVTAQALHISDVFGNDRRRGNVPCRVESLDECFLLMRRLKPVLNSYDMQGFHYYGADLCLQAEFLGGRAYAIDFHLHHYGRAIADENFHRLRQEMAQKYRRWFPGRILHCVTGRVALGGGWYEAR 249
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241


Chain B from PDB  Type:PROTEIN  Length:248
 aligned with YAT6_RHOBL | P05449 from UniProtKB/Swiss-Prot  Length:249

    Alignment length:248
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241
           YAT6_RHOBL     2 KPVPTYVQDKDESTLMFSVCSLVRDQAKYDRLLESFERFGFTPDKAEFLAADNREGNQFHGFSWHKQMLPRCKGRYVIFCHEDVELVDRGYDDLVAAIEALEEADPKWLVAGVAGSPWRPLNHSVTAQALHISDVFGNDRRRGNVPCRVESLDECFLLMRRLKPVLNSYDMQGFHYYGADLCLQAEFLGGRAYAIDFHLHHYGRAIADENFHRLRQEMAQKYRRWFPGRILHCVTGRVALGGGWYEAR 249
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
           Pfam domains (1) ----------------Glyco_tranf_2_5-2qgiB01 B:18-223                                                                                                                                                                              -------------------------- Pfam domains (1)
           Pfam domains (2) ----------------Glyco_tranf_2_5-2qgiB02 B:18-223                                                                                                                                                                              -------------------------- Pfam domains (2)
         Sec.struct. author ....eee.........eeeeeee.hhhhhhhhhhhhhhh......eeeeeee..........hhhhhhhhhh...eeeeee..ee....hhhhhhhhhhhhhhhh..eeeee.eeee...........eeeeee..eeeeee....eeeeee...eeeee...............hhhhhhhhhhhhh..eeee.....ee......hhhhhhhhhhhhhhhh......eeee..eeee..hhhhhh. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2qgi B   2 KPVPTYVQDKDESTLMFSVCSLVRDQAKYDRLLESFERFGFTPDKAEFLAADNREGNQFHGFSWHKQMLPRCKGRYVIFCHEDVELVDRGYDDLVAAIEALEEADPKWLVAGVAGSPWRPLNHSVTAQALHISDVFGNDRRRGNVPCRVESLDECFLLMRRLKPVLNSYDMQGFHYYGADLCLQAEFLGGRAYAIDFHLHHYGRAIADENFHRLRQEMAQKYRRWFPGRILHCVTGRVALGGGWYEAR 249
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 2QGI)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 2QGI)

(-) Pfam Domains  (1, 2)

Asymmetric Unit
(-)
Clan: GT-A (172)

(-) Gene Ontology  (0, 0)

Asymmetric Unit(hide GO term definitions)
    (no "Gene Ontology" information available for 2QGI)

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    MN  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]
    UDP  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    AC2  [ RasMol ]  +environment [ RasMol ]
    AC3  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
    Val A:146 - Pro A:147   [ RasMol ]
    Val B:146 - Pro B:147   [ RasMol ]

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Asym. Unit - sites PNG format | Biol. Unit 1 PNG format | Biol. Unit 1 - sites PNG format | Biol. Unit 2 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  2qgi
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  YAT6_RHOBL | P05449
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/SwissProt

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  YAT6_RHOBL | P05449
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/Swiss-Prot
        YAT6_RHOBL | P05449: 2nxv

(-) Related Entries Specified in the PDB File

2nxv THE STRUCTURE OF THE APO FORM OF THE SAME PROTEIN WITHOUT UDP
