(-) Description

Title :  CRYSTAL STRUCTURE OF 7,8-DIHYDRONEOPTERIN ALDOLASE IN COMPLEX WITH GUANINE

Authors :  S. Bauer, A. K. Schott, V. Illarionova, A. Bacher, R. Huber, M. Fischer
Date :  19 Mar 04  (Deposition) - 08 Jun 04  (Release) - 24 Feb 09  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  2.20
Chains :  Asym. Unit :  A,B,C,D,E,F,G,H,I,J,K,L,M,N,O,P
Biol. Unit 1:  A,B,C,D,E,F,G,H  (1x)
Biol. Unit 2:  I,J,K,L,M,N,O,P  (1x)
Keywords :  Tetrahydrofolate Biosynthesis, Aldolase Classes, Retroaldol Reaction, Purin Binding, Schiff Base, Lyase (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  S. Bauer, A. K. Schott, V. Illarionova, A. Bacher, R. Huber, M. Fischer
Biosynthesis Of Tetrahydrofolate In Plants: Crystal Structure Of 7, 8-Dihydroneopterin Aldolase From Arabidopsis Thaliana Reveals A Novel Adolase Class.
J. Mol. Biol. V. 339 967 2004
PubMed-ID: 15165863  |  Reference-DOI: 10.1016/J.JMB.2004.04.034
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - DIHYDRONEOPTERIN ALDOLASE
    Chains: A, B, C, D, E, F, G, H, I, J, K, L, M, N, O, P
    Organism Common: THALE CRESS
    Organism Scientific: ARABIDOPSIS THALIANA
    Organism Taxid: 3702
    Strain: M15[PREP4]

 Structural Features

(-) Chains, Units

  12345678910111213141516
Asymmetric Unit : ABCDEFGHIJKLMNOP
Biological Unit 1 (1x): ABCDEFGH
Biological Unit 2 (1x):         IJKLMNOP

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (1, 16)

Asymmetric Unit (1, 16)
No.NameCountTypeFull Name
1GUN16Ligand/IonGUANINE
Biological Unit 1 (1, 8)
No.NameCountTypeFull Name
1GUN8Ligand/IonGUANINE
Biological Unit 2 (1, 8)
No.NameCountTypeFull Name
1GUN8Ligand/IonGUANINE

(-) Sites  (16, 16)

Asymmetric Unit (16, 16)
No.NameEvidenceResiduesDescription
01AC1SOFTWAREILE A:51 , SER A:52 , TYR A:53 , HOH A:1010 , LEU D:71 , LEU D:72 , GLU D:73BINDING SITE FOR RESIDUE GUN A 1001
02AC2SOFTWARELEU A:71 , LEU A:72 , GLU A:73 , LEU B:4 , THR B:50 , ILE B:51 , SER B:52 , TYR B:53 , HOH B:1010BINDING SITE FOR RESIDUE GUN B 1002
03AC3SOFTWARELEU B:71 , LEU B:72 , GLU B:73 , HOH B:1066 , ILE C:51 , SER C:52 , TYR C:53BINDING SITE FOR RESIDUE GUN B 1003
04AC4SOFTWARELEU C:71 , LEU C:72 , GLU C:73 , HOH C:128 , ILE D:51 , SER D:52 , TYR D:53BINDING SITE FOR RESIDUE GUN D 1004
05AC5SOFTWARELEU E:4 , THR E:50 , ILE E:51 , SER E:52 , TYR E:53 , LEU H:71 , LEU H:72 , GLU H:73 , HOH H:1029 , HOH H:1070BINDING SITE FOR RESIDUE GUN H 1005
06AC6SOFTWARELEU E:71 , LEU E:72 , GLU E:73 , LEU F:47 , THR F:50 , ILE F:51 , SER F:52 , TYR F:53 , HOH F:1022BINDING SITE FOR RESIDUE GUN F 1006
07AC7SOFTWARELEU F:71 , LEU F:72 , GLU F:73 , LEU G:4 , THR G:50 , ILE G:51 , SER G:52 , TYR G:53 , HOH G:1035BINDING SITE FOR RESIDUE GUN G 1007
08AC8SOFTWARELEU G:71 , LEU G:72 , GLU G:73 , HOH G:1021 , HOH G:1073 , LEU H:4 , LEU H:47 , THR H:50 , ILE H:51 , SER H:52 , TYR H:53BINDING SITE FOR RESIDUE GUN G 1008
09AC9SOFTWARELEU I:4 , LEU I:47 , THR I:50 , ILE I:51 , SER I:52 , TYR I:53 , LEU L:71 , LEU L:72 , GLU L:73 , HOH L:1019BINDING SITE FOR RESIDUE GUN I 1009
10BC1SOFTWARELEU I:71 , LEU I:72 , GLU I:73 , HOH I:1066 , ILE J:51 , SER J:52 , TYR J:53 , HOH J:1057BINDING SITE FOR RESIDUE GUN J 1010
11BC2SOFTWARELEU J:71 , LEU J:72 , GLU J:73 , HOH J:1013 , HOH J:1079 , ILE K:51 , SER K:52 , TYR K:53 , HOH K:131BINDING SITE FOR RESIDUE GUN J 1011
12BC3SOFTWARELEU K:71 , LEU K:72 , GLU K:73 , HOH K:132 , HOH K:180 , LEU L:4 , THR L:50 , ILE L:51 , SER L:52 , TYR L:53BINDING SITE FOR RESIDUE GUN L 1012
13BC4SOFTWARELEU M:4 , THR M:50 , ILE M:51 , SER M:52 , TYR M:53 , LEU P:71 , LEU P:72 , GLU P:73 , HOH P:1030BINDING SITE FOR RESIDUE GUN P 1013
14BC5SOFTWARELEU M:71 , LEU M:72 , GLU M:73 , HOH M:1019 , ILE N:51 , SER N:52 , TYR N:53BINDING SITE FOR RESIDUE GUN M 1014
15BC6SOFTWARELEU N:71 , LEU N:72 , GLU N:73 , LEU O:4 , THR O:50 , ILE O:51 , SER O:52 , TYR O:53 , HOH O:1023BINDING SITE FOR RESIDUE GUN O 1015
16BC7SOFTWARELEU O:71 , LEU O:72 , GLU O:73 , THR P:50 , ILE P:51 , SER P:52 , TYR P:53 , HOH P:1026BINDING SITE FOR RESIDUE GUN P 1016

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 1SQL)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 1SQL)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 1SQL)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 1SQL)

(-) Exons   (0, 0)

(no "Exon" information available for 1SQL)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:120
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:120
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQR 140
               SCOP domains d1sqla_ A: 7,8-dihydroneopterin aldolase                                                                                 SCOP domains
               CATH domains 1sqlA00 A:1-120  [code=3.30.1130.10, no name defined]                                                                    CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------ Transcript
                 1sql A   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQR 120
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain B from PDB  Type:PROTEIN  Length:121
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:121
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 141
               SCOP domains d1sqlb_ B: 7,8-dihydroneopterin aldolase                                                                                  SCOP domains
               CATH domains 1sqlB00 B:1-121  [code=3.30.1130.10, no name defined]                                                                     CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhhh....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee.. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql B   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 121
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain C from PDB  Type:PROTEIN  Length:122
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:122
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRNT 142
               SCOP domains d1sqlc_ C: 7,8-dihydroneopterin aldolase                                                                                   SCOP domains
               CATH domains 1sqlC00 C:1-122  [code=3.30.1130.10, no name defined]                                                                      CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee....hhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql C   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRNT 122
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain D from PDB  Type:PROTEIN  Length:120
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:120
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQR 140
               SCOP domains d1sqld_ D: 7,8-dihydroneopterin aldolase                                                                                 SCOP domains
               CATH domains 1sqlD00 D:1-120  [code=3.30.1130.10, no name defined]                                                                    CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------ Transcript
                 1sql D   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQR 120
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain E from PDB  Type:PROTEIN  Length:120
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:120
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQR 140
               SCOP domains d1sqle_ E: 7,8-dihydroneopterin aldolase                                                                                 SCOP domains
               CATH domains 1sqlE00 E:1-120  [code=3.30.1130.10, no name defined]                                                                    CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------ Transcript
                 1sql E   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQR 120
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain F from PDB  Type:PROTEIN  Length:121
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:121
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 141
               SCOP domains d1sqlf_ F: 7,8-dihydroneopterin aldolase                                                                                  SCOP domains
               CATH domains 1sqlF00 F:1-121  [code=3.30.1130.10, no name defined]                                                                     CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee.. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql F   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 121
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain G from PDB  Type:PROTEIN  Length:121
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:121
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 141
               SCOP domains d1sqlg_ G: 7,8-dihydroneopterin aldolase                                                                                  SCOP domains
               CATH domains 1sqlG00 G:1-121  [code=3.30.1130.10, no name defined]                                                                     CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeeeeeeee......hhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee.. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql G   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 121
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain H from PDB  Type:PROTEIN  Length:122
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:122
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRNT 142
               SCOP domains d1sqlh_ H: 7,8-dihydroneopterin aldolase                                                                                   SCOP domains
               CATH domains 1sqlH00 H:1-122  [code=3.30.1130.10, no name defined]                                                                      CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql H   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRNT 122
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain I from PDB  Type:PROTEIN  Length:121
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:121
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 141
               SCOP domains d1sqli_ I: 7,8-dihydroneopterin aldolase                                                                                  SCOP domains
               CATH domains 1sqlI00 I:1-121  [code=3.30.1130.10, no name defined]                                                                     CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee.. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql I   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 121
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain J from PDB  Type:PROTEIN  Length:123
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:123
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRNTS 143
               SCOP domains d1sqlj_ J: 7,8-dihydroneopterin aldolase                                                                                    SCOP domains
               CATH domains 1sqlJ00 J:1-123  [code=3.30.1130.10, no name defined]                                                                       CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeee..... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql J   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRNTS 123
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain K from PDB  Type:PROTEIN  Length:120
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:120
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQR 140
               SCOP domains d1sqlk_ K: 7,8-dihydroneopterin aldolase                                                                                 SCOP domains
               CATH domains 1sqlK00 K:1-120  [code=3.30.1130.10, no name defined]                                                                    CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------ Transcript
                 1sql K   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQR 120
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain L from PDB  Type:PROTEIN  Length:122
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:122
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRNT 142
               SCOP domains d1sqll_ L: 7,8-dihydroneopterin aldolase                                                                                   SCOP domains
               CATH domains 1sqlL00 L:1-122  [code=3.30.1130.10, no name defined]                                                                      CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql L   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRNT 122
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain M from PDB  Type:PROTEIN  Length:123
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:123
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRNTS 143
               SCOP domains d1sqlm_ M: 7,8-dihydroneopterin aldolase                                                                                    SCOP domains
               CATH domains 1sqlM00 M:1-123  [code=3.30.1130.10, no name defined]                                                                       CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee.... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql M   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRNTS 123
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain N from PDB  Type:PROTEIN  Length:121
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:121
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 141
               SCOP domains d1sqln_ N: 7,8-dihydroneopterin aldolase                                                                                  SCOP domains
               CATH domains 1sqlN00 N:1-121  [code=3.30.1130.10, no name defined]                                                                     CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee.. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql N   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 121
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain O from PDB  Type:PROTEIN  Length:120
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:120
                                    30        40        50        60        70        80        90       100       110       120       130       140
          FOLB1_ARATH    21 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQR 140
               SCOP domains d1sqlo_ O: 7,8-dihydroneopterin aldolase                                                                                 SCOP domains
               CATH domains 1sqlO00 O:1-120  [code=3.30.1130.10, no name defined]                                                                    CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author ..eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhh.....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------ Transcript
                 1sql O   1 GDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQR 120
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain P from PDB  Type:PROTEIN  Length:122
 aligned with FOLB1_ARATH | Q9SF23 from UniProtKB/Swiss-Prot  Length:146

    Alignment length:122
                                    29        39        49        59        69        79        89        99       109       119       129       139
          FOLB1_ARATH    20 LGDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 141
               SCOP domains d1sqlp_ P: 7,8-dihydroneopterin aldolase                                                                                   SCOP domains
               CATH domains 1sqlP00 P:0-121  [code=3.30.1130.10, no name defined]                                                                      CATH domains
           Pfam domains (1) ----FolB-1sqlP01 P:4-118                                                                                               --- Pfam domains (1)
           Pfam domains (2) ----FolB-1sqlP02 P:4-118                                                                                               --- Pfam domains (2)
           Pfam domains (3) ----FolB-1sqlP03 P:4-118                                                                                               --- Pfam domains (3)
           Pfam domains (4) ----FolB-1sqlP04 P:4-118                                                                                               --- Pfam domains (4)
           Pfam domains (5) ----FolB-1sqlP05 P:4-118                                                                                               --- Pfam domains (5)
           Pfam domains (6) ----FolB-1sqlP06 P:4-118                                                                                               --- Pfam domains (6)
           Pfam domains (7) ----FolB-1sqlP07 P:4-118                                                                                               --- Pfam domains (7)
           Pfam domains (8) ----FolB-1sqlP08 P:4-118                                                                                               --- Pfam domains (8)
           Pfam domains (9) ----FolB-1sqlP09 P:4-118                                                                                               --- Pfam domains (9)
          Pfam domains (10) ----FolB-1sqlP10 P:4-118                                                                                               --- Pfam domains (10)
          Pfam domains (11) ----FolB-1sqlP11 P:4-118                                                                                               --- Pfam domains (11)
          Pfam domains (12) ----FolB-1sqlP12 P:4-118                                                                                               --- Pfam domains (12)
          Pfam domains (13) ----FolB-1sqlP13 P:4-118                                                                                               --- Pfam domains (13)
          Pfam domains (14) ----FolB-1sqlP14 P:4-118                                                                                               --- Pfam domains (14)
          Pfam domains (15) ----FolB-1sqlP15 P:4-118                                                                                               --- Pfam domains (15)
          Pfam domains (16) ----FolB-1sqlP16 P:4-118                                                                                               --- Pfam domains (16)
         Sec.struct. author ...eeeeeeeeeee....hhhhhhhheeeeeeeeee..hhhhhhhhhhhhh.hhhhhhhhhhhhhhh....hhhhhhhhhhhhhhhhh....eeeeeeee...........eeeeeeeee.. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------- Transcript
                 1sql P   0 LGDKLILKGLKFYGFHGAIAEERTLGQMFLVDIDAWVSLKKAGESDNLEDTISYVDIFSLAKEIVEGSPRNLLETVAELIASKTLEKFHQINAVRVKLSKPNVALIKSTIDYLGVDIFRQRN 121
                                     9        19        29        39        49        59        69        79        89        99       109       119
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 16)

Asymmetric Unit
(-)
Class: Alpha and beta proteins (a+b) (23004)

(-) CATH Domains  (1, 16)

Asymmetric Unit
(-)
Class: Alpha Beta (26913)
(-)
Architecture: 2-Layer Sandwich (8480)
(-)
Topology: GTP Cyclohydrolase I, domain 2 (31)
(-)
Homologous Superfamily: [code=3.30.1130.10, no name defined] (31)
(-)
Thale cress (Arabidopsis thaliana) (1)
1a1sqlJ00J:1-123
1b1sqlM00M:1-123
1c1sqlN00N:1-121
1d1sqlA00A:1-120
1e1sqlD00D:1-120
1f1sqlE00E:1-120
1g1sqlK00K:1-120
1h1sqlO00O:1-120
1i1sqlC00C:1-122
1j1sqlH00H:1-122
1k1sqlL00L:1-122
1l1sqlP00P:0-121
1m1sqlB00B:1-121
1n1sqlF00F:1-121
1o1sqlG00G:1-121
1p1sqlI00I:1-121

(-) Pfam Domains  (1, 16)

Asymmetric Unit
(-)
Clan: THBO-biosyn (64)
(-)
Family: FolB (15)
(-)
Arabidopsis thaliana (Mouse-ear cress) (1)
1aFolB-1sqlP01P:4-118
1bFolB-1sqlP02P:4-118
1cFolB-1sqlP03P:4-118
1dFolB-1sqlP04P:4-118
1eFolB-1sqlP05P:4-118
1fFolB-1sqlP06P:4-118
1gFolB-1sqlP07P:4-118
1hFolB-1sqlP08P:4-118
1iFolB-1sqlP09P:4-118
1jFolB-1sqlP10P:4-118
1kFolB-1sqlP11P:4-118
1lFolB-1sqlP12P:4-118
1mFolB-1sqlP13P:4-118
1nFolB-1sqlP14P:4-118
1oFolB-1sqlP15P:4-118
1pFolB-1sqlP16P:4-118

(-) Gene Ontology  (6, 6)

Asymmetric Unit(hide GO term definitions)
Chain A,B,C,D,E,F,G,H,I,J,K,L,M,N,O,P   (FOLB1_ARATH | Q9SF23)
molecular function
    GO:0004150    dihydroneopterin aldolase activity    Catalysis of the reaction: 2-amino-4-hydroxy-6-(D-erythro-1,2,3-trihydroxypropyl)-7,8-dihydropteridine = 2-amino-4-hydroxy-6-hydroxymethyl-7,8-dihydropteridine + glycolaldehyde.
    GO:0016829    lyase activity    Catalysis of the cleavage of C-C, C-O, C-N and other bonds by other means than by hydrolysis or oxidation, or conversely adding a group to a double bond. They differ from other enzymes in that two substrates are involved in one reaction direction, but only one in the other direction. When acting on the single substrate, a molecule is eliminated and this generates either a new double bond or a new ring.
biological process
    GO:0046656    folic acid biosynthetic process    The chemical reactions and pathways resulting in the formation of folic acid, pteroylglutamic acid.
    GO:0006760    folic acid-containing compound metabolic process    The chemical reactions and pathways involving a folic acid-containing compound, i.e. any of a group of heterocyclic compounds based on the pteroic acid skeleton conjugated with one or more L-glutamic acid or L-glutamate units.
    GO:0046654    tetrahydrofolate biosynthetic process    The chemical reactions and pathways resulting in the formation of tetrahydrofolate, 5,6,7,8-tetrahydrofolic acid, a folate derivative bearing additional hydrogens on the pterin group.
cellular component
    GO:0005829    cytosol    The part of the cytoplasm that does not contain organelles but which does contain other particulate matter, such as protein complexes.

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    GUN  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    AC2  [ RasMol ]  +environment [ RasMol ]
    AC3  [ RasMol ]  +environment [ RasMol ]
    AC4  [ RasMol ]  +environment [ RasMol ]
    AC5  [ RasMol ]  +environment [ RasMol ]
    AC6  [ RasMol ]  +environment [ RasMol ]
    AC7  [ RasMol ]  +environment [ RasMol ]
    AC8  [ RasMol ]  +environment [ RasMol ]
    AC9  [ RasMol ]  +environment [ RasMol ]
    BC1  [ RasMol ]  +environment [ RasMol ]
    BC2  [ RasMol ]  +environment [ RasMol ]
    BC3  [ RasMol ]  +environment [ RasMol ]
    BC4  [ RasMol ]  +environment [ RasMol ]
    BC5  [ RasMol ]  +environment [ RasMol ]
    BC6  [ RasMol ]  +environment [ RasMol ]
    BC7  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 1sql)

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Asym. Unit - sites PNG format | Biol. Unit 1 PNG format | Biol. Unit 1 - sites PNG format | Biol. Unit 2 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  1sql
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  FOLB1_ARATH | Q9SF23
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/SwissProt

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  FOLB1_ARATH | Q9SF23
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

(no "Entries Sharing at Least One Protein Chain" available for 1SQL)

(-) Related Entries Specified in the PDB File

(no "Related Entries Specified in the PDB File" available for 1SQL)
