1OPG - JenaLib

Asym./Biol. Unit - manually (Jmol Viewer)

Asym./Biol. Unit (Jmol Viewer)

Title :   OPG2 FAB FRAGMENT

Authors :   R. Kodandapani, B. Veerapandian, K. R. Ely

Date :   28 Apr 95 (Deposition) - 31 Jul 95 (Release) - 24 Feb 09 (Revision)

Method :   X-RAY DIFFRACTION

Resolution :   2.00

Chains :   Asym./Biol. Unit : H,L

Keywords :   Cell Adhesion Molecule, Immunoglobulin (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :   R. Kodandapani, B. Veerapandian, T. J. Kunicki, K. R. Ely
Crystal Structure Of The Opg2 Fab. An Antireceptor Antibody That Mimics An Rgd Cell Adhesion Site.
J. Biol. Chem. V. 270 2268 1995
PubMed-ID: 7836460 | Reference-DOI: 10.1074/JBC.270.5.2268
(for further references see the PDB file header)

Molecule 1 - OPG2 FAB (LIGHT CHAIN)
	Chains	:	L
	Organism Common	:	HUMAN
	Organism Scientific	:	HOMO SAPIENS
	Organism Taxid	:	9606
	Tissue	:	PLATELET

Molecule 2 - OPG2 FAB (HEAVY CHAIN)
	Chains	:	H
	Organism Common	:	HUMAN
	Organism Scientific	:	HOMO SAPIENS
	Organism Taxid	:	9606
	Tissue	:	PLATELET

		1	2
Asymmetric/Biological Unit	:	H	L

Summary Information (see also Sequences/Alignments below)

(no "Ligand,Modified Residues,Ions" information available for 1OPG)

(no "Site" information available for 1OPG)

Asymmetric/Biological Unit

No.	Residues
1	H:22	-	H:96
2	H:152	-	H:207
3	L:23	-	L:88
4	L:134	-	L:194

Asymmetric/Biological Unit

No.	Residues
1	Ser L:7	-	Pro L:8
2	Trp L:94	-	Pro L:95
3	Tyr L:140	-	Pro L:141
4	Phe H:158	-	Pro H:159
5	Glu H:160	-	Pro H:161

(no "SAP(SNP)/Variant" information available for 1OPG)

(no "PROSITE Motif" information available for 1OPG)

(no "Exon" information available for 1OPG)

Asymmetric/Biological Unit

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain H from PDB  Type:PROTEIN  Length:227

               SCOP domains d1opgh1 H:1-125 Immunoglobulin heavy chain variable domain, VH                                                               d1opgh2 H:126-227 Immunoglobulin heavy chain gamma constant domain 1, CH1-gamma                        SCOP domains
               CATH domains 1opgH01 H:1-125 Immunoglobulins                                                                                              1opgH02 H:126-223 Immunoglobulins                                                                 ---- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeee..........eeeeeeee...hhh..eeeeee.....eeeeeee................eeeeee....eeeeee....hhh.eeeeeeee............eeee...eee..........eeeee..........eeeeeeeeeee.....eeeehhh.....eeee..eee..eeeeeeeeeee.........eeeeeehhh.eeeeee...... Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1opg H   1 EVQLVQSGGGLVNPGRSLKLSCAASGFTFSSYGMSWVRQTPEKRLEWVAAISGGGTYIHYPDSVKGRFTISRDNAKNNLYLQMSSLRSEDTALYYCTRHPFYRYDGGNYYAMDHWGQGTSVTVSAAKTTPPSVYPLAPGSAAQTNSMVTLGCLVKGYFPEPVTVTWNSGSLSSGVHTFPAVLQSDLYTLSSSVTVPSSPRPSETVTCNVAHPASSTKVDKKIVPRDC 227
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220

Chain L from PDB  Type:PROTEIN  Length:214

               SCOP domains d1opgl1 L:1-107 Immunoglobulin light chain kappa variable domain, VL-kappa                                 d1opgl2 L:108-214 Immunoglobulin light chain kappa constant domain, CL-kappa                                SCOP domains
               CATH domains 1opgL01 L:1-107 Immunoglobulins                                                                            1opgL02 L:108-211 Immunoglobulins                                                                       --- CATH domains
               Pfam domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...eeee...........eeeeeee.......eeeeee......eeee.hhh.........eeeeee..eeeeee....hhh..eeeeee.......................eeeee......hhh.eeeeeeeee......eeeeeee..eee...eeeee...........eeeeeeeehhhhhh..eeeeeeee......eeeeee.... Sec.struct. author
                 SAPs(SNPs) ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1opg L   1 DELLTQSPATLSVTPGDSVSLSCRASQSISNNLHWYQQKSHESPRLLIKYASQSISGIPSRFSGSGSGTDFTLSINSVETEDFGMYFCQQSNSWPLTFGGGSKLEIKRADAAPTVSIFPPSSEQLTSGGASVVCFLNNFYPKDINVKWKIDGSERQNGVLNSWTDQDSKDSTYSMSSTLTLTKDEYERHNSYTCEATHKTSTSPIVKSFNRNEC 214
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Asymmetric/Biological Unit

Classes(

)

Architectures( (-)

)

Topologies( (-)

)

Homologous Superfamilies( (-)

)

Organisms( (-)

)

Class: Mainly Beta (13760)

Architecture: Sandwich (5577)

Topology: Immunoglobulin-like (3897)

Homologous Superfamily: Immunoglobulins (2282)

Human (Homo sapiens) (912)

1a	1opgL02	L:108-211
1b	1opgH02	H:126-223
1c	1opgH01	H:1-125
1d	1opgL01	L:1-107

(no "Pfam Domain" information available for 1OPG)

Asymmetric/Biological Unit(hide GO term definitions)

Asymmetric/Biological Unit
	Complete Structure
		Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
		WebMol \| AstexViewer[tm]@PDBe (Java Applets, require no local installation except for Java; loading may be slow)
		STRAP (Java WebStart application, automatic local installation, requires Java; full application with system access!)
		RasMol (require local installation)
		Molscript (VRML) (requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

	Ligands, Modified Residues, Ions
(no "Ligands, Modified Residues, Ions" information available for 1opg)

	Sites
(no "Sites" information available for 1opg)

	Cis Peptide Bonds
		Glu H:160 - Pro H:161	[ RasMol ]
		Phe H:158 - Pro H:159	[ RasMol ]
		Ser L:7 - Pro L:8	[ RasMol ]
		Trp L:94 - Pro L:95	[ RasMol ]
		Tyr L:140 - Pro L:141	[ RasMol ]

Jmol
	protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick [ Asym./Biol. Unit PNG format ](automatic orientation, automatically generated)
Molscript
	protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick [ mono PDF format \| stereo PDF format ](default orientation, automatically generated)
