1OFQ - JenaLib

Asymmetric Unit (Jmol Viewer)

Asym. Unit - sites (Jmol Viewer)

Biological Unit 1 (Jmol Viewer)

Biol. Unit 1 - sites (Jmol Viewer)

Biological Unit 2 (Jmol Viewer)

Title :   CRYSTAL STRUCTURE OF THE TYROSINE-REGULATED 3-DEOXY-D-ARABINO-HEPTULOSONATE-7-PHOSPHATE SYNTHASE FROM SACCHAROMYCES CEREVISIAE IN COMPLEX WITH MANGANESE(II)

Authors :   V. Koenig, A. Pfeil, G. Heinrich, G. H. Braus, T. R. Schneider

Date :   17 Apr 03 (Deposition) - 15 Apr 04 (Release) - 24 Feb 09 (Revision)

Method :   X-RAY DIFFRACTION

Resolution :   2.70

Chains :   Asym. Unit : A,B,C,D
Biol. Unit 1: A,B  (1x)
Biol. Unit 2: C,D  (1x)

Keywords :   Beta-Alpha-Barrel, Lyase, Aromatic Amino-Acid Biosynthesis Synthase, Aldolase, Synthetase, Manganese (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :   V. Koenig, A. Pfeil, G. H. Braus, T. R. Schneider
Substrate And Metal Complexes Of 3-Deoxy-D- Arabino-Heptulosonate-7-Phosphate Synthase From Saccharomyces Cerevisiae Provide New Insights Into The Catalytic Mechanism
J. Mol. Biol. V. 337 675 2004
PubMed-ID: 15019786 | Reference-DOI: 10.1016/J.JMB.2004.01.055
(for further references see the PDB file header)

Molecule 1 - PHOSPHO-2-DEHYDRO-3-DEOXYHEPTONATE ALDOLASE
	Chains	:	A, B, C, D
	EC Number	:	4.1.2.15
	Engineered	:	YES
	Expression System	:	SACCHAROMYCES CEREVISIAE
	Expression System Taxid	:	4932
	Organism Common	:	BAKER'S YEAST
	Organism Scientific	:	SACCHAROMYCES CEREVISIAE
	Organism Taxid	:	4932
	Other Details	:	METAL ION: MANGANESE(II)
	Strain	:	RH1326
	Synonym	:	PHOSPHO-2-KETO-3-DEOXYHEPTONATE ALDOLASE DAHP SYNTHETASE, 3-DEOXY-D-ARABINO-HEPTULOSONATE 7-PHOSPHATE SYNTHASE, PHOSPHO-2-DEHYDRO- 3-DEOXYHEPTONATE ALDOLASE

		1	2	3	4
Asymmetric Unit	:	A	B	C	D
Biological Unit 1 (1x)	:	A	B
Biological Unit 2 (1x)	:			C	D

Summary Information (see also Sequences/Alignments below)

Asymmetric Unit (1, 4)

No.	Name	Count	Type	Full Name
1	MN	4	Ligand/Ion	MANGANESE (II) ION

Biological Unit 1 (0, 0)

No.	Name	Count	Type	Full Name
1	MN	-1	Ligand/Ion	MANGANESE (II) ION

Biological Unit 2 (0, 0)

No.	Name	Count	Type	Full Name
1	MN	-1	Ligand/Ion	MANGANESE (II) ION

Asymmetric Unit (4, 4)

No.	Name	Evidence	Residues	Description
1	AC1	SOFTWARE	CYS A:1076 , HIS A:1282 , GLU A:1316 , ASP A:1342	BINDING SITE FOR RESIDUE MN A1000
2	AC2	SOFTWARE	CYS B:2076 , HIS B:2282 , GLU B:2316 , ASP B:2342	BINDING SITE FOR RESIDUE MN B2000
3	AC3	SOFTWARE	CYS C:3076 , HIS C:3282 , GLU C:3316 , ASP C:3342	BINDING SITE FOR RESIDUE MN C3000
4	AC4	SOFTWARE	HOH D:2002 , CYS D:4076 , HIS D:4282 , GLU D:4316 , ASP D:4342	BINDING SITE FOR RESIDUE MN D4000

(no "SS Bond" information available for 1OFQ)

(no "Cis Peptide Bond" information available for 1OFQ)

(no "SAP(SNP)/Variant" information available for 1OFQ)

(no "PROSITE Motif" information available for 1OFQ)

Asymmetric Unit (1, 4)

	ENSEMBL					UniProtKB			PDB
No.	Transcript ID	Exon	Exon ID	Genome Location	Length	ID	Location	Length	Count	Location	Length
1.1	YBR249C	1	YBR249C.1	II:717989-716877	1113	AROG_YEAST	1-370	370	4	A:1023-1369 (gaps) B:2023-2370 (gaps) C:3023-3369 (gaps) D:4023-4369 (gaps)	347 348 347 347

Asymmetric Unit

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain A from PDB  Type:PROTEIN  Length:343
 aligned with AROG_YEAST | P32449 from UniProtKB/Swiss-Prot  Length:370

    Alignment length:347
                                    32        42        52        62        72        82        92       102       112       122       132       142       152       162       172       182       192       202       212       222       232       242       252       262       272       282       292       302       312       322       332       342       352       362
          AROG_YEAST     23 VRILGYDPLASPALLQVQIPATPTSLETAKRGRREAIDIITGKDDRVLVIVGPCSIHDLEAAQEYALRLKKLSDELKGDLSIIMRAYLEKPRTTVGWKGLINDPDVNNTFNINKGLQSARQLFVNLTNIGLPIGSEMLDTISPQYLADLVSFGAIGARTTESQLHRELASGLSFPVGFKNGTDGTLNVAVDACQAAAHSHHFMGVTKHGVAAITTTKGNEHCFVILRGGKKGTNYDAKSVAEAKAQLPAGSNGLMIDYSHGNSNKDFRNQPKVNDVVCEQIANGENAITGVMIESNINEGNQGIPAEGKAGLKYGVSITDACIGWETTEDVLRKLAAAVRQRREVNK  369
               SCOP domains d1ofqa_ A: 3-deoxy-D-arabino-heptulosonate-7-phosphate synthase (DAHP synthase, AroG)                                                                                                                                                                                                                                                                       SCOP domains
               CATH domains 1ofqA00 A:1023-1369 Aldolase class I                                                                                                                                                                                                                                                                                                                        CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeee...hhhhhhhhh..hhhhhhhhhhhhhhhhhhhh.....eeeeee.....hhhhhhhhhhhhhhhhhhhh..eeeeee......---...hhhhhh.......hhhhhhhhhhhhhhhhhh....eeeee....hhhhhhhhh.eeee.hhhh.hhhhhhhhhhh...eeee......hhhhhhhhhhhhh..eeeee.-...eeeeee.....eeeee.........hhhhhhhhhhh.......eeee.hhhhhh.hhhhhhhhhhhhhhhhhh....eeeeeee.............hhhhh...........hhhhhhhhhhhhhhhhhhhhhhh. Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
               Transcript 1 Exon 1.1  PDB: A:1023-1369 (gaps) UniProt: 1-370 [INCOMPLETE]                                                                                                                                                                                                                                                                                               Transcript 1
                1ofq A 1023 VRILGYDPLASPALLQVQIPATPTSLETAKRGRREAIDIITGKDDRVLVIVGPCSIHDLEAAQEYALRLKKLSDELKGDLSIIMRAYLEKP---VGWKGLINDPDVNNTFNINKGLQSARQLFVNLTNIGLPIGSEMLDTISPQYLADLVSFGAIGARTTESQLHRELASGLSFPVGFKNGTDGTLNVAVDACQAAAHSHHFMGVT-HGVAAITTTKGNEHCFVILRGGKKGTNYDAKSVAEAKAQLPAGSNGLMIDYSHGNSNKDFRNQPKVNDVVCEQIANGENAITGVMIESNINEGNQGIPAEGKAGLKYGVSITDACIGWETTEDVLRKLAAAVRQRREVNK 1369
                                  1032      1042      1052      1062      1072      1082      1092      1102      1112|   | 1122      1132      1142      1152      1162      1172      1182      1192      1202      1212      1222     |1232      1242      1252      1262      1272      1282      1292      1302      1312      1322      1332      1342      1352      1362
                                                                                                                   1113   |                                                                                                           1228 |
                                                                                                                       1117                                                                                                             1230

Chain B from PDB  Type:PROTEIN  Length:343
 aligned with AROG_YEAST | P32449 from UniProtKB/Swiss-Prot  Length:370

    Alignment length:348
                                    32        42        52        62        72        82        92       102       112       122       132       142       152       162       172       182       192       202       212       222       232       242       252       262       272       282       292       302       312       322       332       342       352       362
          AROG_YEAST     23 VRILGYDPLASPALLQVQIPATPTSLETAKRGRREAIDIITGKDDRVLVIVGPCSIHDLEAAQEYALRLKKLSDELKGDLSIIMRAYLEKPRTTVGWKGLINDPDVNNTFNINKGLQSARQLFVNLTNIGLPIGSEMLDTISPQYLADLVSFGAIGARTTESQLHRELASGLSFPVGFKNGTDGTLNVAVDACQAAAHSHHFMGVTKHGVAAITTTKGNEHCFVILRGGKKGTNYDAKSVAEAKAQLPAGSNGLMIDYSHGNSNKDFRNQPKVNDVVCEQIANGENAITGVMIESNINEGNQGIPAEGKAGLKYGVSITDACIGWETTEDVLRKLAAAVRQRREVNKK  370
               SCOP domains d1ofqb_ B: 3-deoxy-D-arabino-heptulosonate-7-phosphate synthase (DAHP synthase, AroG)                                                                                                                                                                                                                                                                        SCOP domains
               CATH domains 1ofqB00 B:2023-2370 Aldolase class I                                                                                                                                                                                                                                                                                                                         CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author ..eeeee...hhhhhhhhh..hhhhhhhhhhhhhhhhhhhh.....eeeeee.....hhhhhhhhhhhhhhhhhhhh..eeeeee....-....--..............hhhhhhhhhhhhhhhhhh....eeee.....hhhhhhhhh.eeee......hhhhhhhhh.....eeee......hhhhhhhhhhhh...eeeee.....eeeeee.....eeeeeee.......hhhhhhhhhhhh......eeeeeeee....hhhhhhhhhhhhhhhhhh....eeeeeee..........--.hhhhh...........hhhhhhhhhhhhhhhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ PROSITE
               Transcript 1 Exon 1.1  PDB: B:2023-2370 (gaps) UniProt: 1-370 [INCOMPLETE]                                                                                                                                                                                                                                                                                                Transcript 1
                1ofq B 2023 VRILGYDPLASPALLQVQIPATPTSLETAKRGRREAIDIITGKDDRVLVIVGPCSIHDLEAAQEYALRLKKLSDELKGDLSIIMRAYLE-PRTT--WKGLINDPDVNNTFNINKGLQSARQLFVNLTNIGLPIGSEMLDTISPQYLADLVSFGAIGARTTESQLHRELASGLSFPVGFKNGTDGTLNVAVDACQAAAHSHHFMGVTKHGVAAITTTKGNEHCFVILRGGKKGTNYDAKSVAEAKAQLPAGSNGLMIDYSHGNSNKDFRNQPKVNDVVCEQIANGENAITGVMIESNINEGNQGI--EGKAGLKYGVSITDACIGWETTEDVLRKLAAAVRQRREVNKK 2370
                                  2032      2042      2052      2062      2072      2082      2092      2102        |-|  |  2122      2132      2142      2152      2162      2172      2182      2192      2202      2212      2222      2232      2242      2252      2262      2272      2282      2292      2302      2312      2322   |  2332      2342      2352      2362
                                                                                                                 2111 |  |  |                                                                                                                                                                                                           2326  |
                                                                                                                   2113  |  |                                                                                                                                                                                                              2329
                                                                                                                      2116  |
                                                                                                                         2119

Chain C from PDB  Type:PROTEIN  Length:344
 aligned with AROG_YEAST | P32449 from UniProtKB/Swiss-Prot  Length:370

    Alignment length:347
                                    32        42        52        62        72        82        92       102       112       122       132       142       152       162       172       182       192       202       212       222       232       242       252       262       272       282       292       302       312       322       332       342       352       362
          AROG_YEAST     23 VRILGYDPLASPALLQVQIPATPTSLETAKRGRREAIDIITGKDDRVLVIVGPCSIHDLEAAQEYALRLKKLSDELKGDLSIIMRAYLEKPRTTVGWKGLINDPDVNNTFNINKGLQSARQLFVNLTNIGLPIGSEMLDTISPQYLADLVSFGAIGARTTESQLHRELASGLSFPVGFKNGTDGTLNVAVDACQAAAHSHHFMGVTKHGVAAITTTKGNEHCFVILRGGKKGTNYDAKSVAEAKAQLPAGSNGLMIDYSHGNSNKDFRNQPKVNDVVCEQIANGENAITGVMIESNINEGNQGIPAEGKAGLKYGVSITDACIGWETTEDVLRKLAAAVRQRREVNK  369
               SCOP domains d1ofqc_ C: 3-deoxy-D-arabino-heptulosonate-7-phosphate synthase (DAHP synthase, AroG)                                                                                                                                                                                                                                                                       SCOP domains
               CATH domains 1ofqC00 C:3023-3369 Aldolase class I                                                                                                                                                                                                                                                                                                                        CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeee...hhhhhhhhh..hhhhhhhhhhhhhhhhhhhh.....eeeeee.....hhhhhhhhhhhhhhhhhhhh..eeeeee.......--...hhhhhh.......hhhhhhhhhhhhhhhhhh....eeeee....hhhhhhhhh.eeee.hhhh.hhhhhhhhhhh...eeee......hhhhhhhhhhhhh..eeeee.-...eeeeee.....eeeee.........hhhhhhhhhhh.......eeee.hhhhhh.hhhhhhhhhhhhhhhhhh....eeeeeee.............hhhhh...........hhhhhhhhhhhhhhhhhhhhhhh. Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
               Transcript 1 Exon 1.1  PDB: C:3023-3369 (gaps) UniProt: 1-370 [INCOMPLETE]                                                                                                                                                                                                                                                                                               Transcript 1
                1ofq C 3023 VRILGYDPLASPALLQVQIPATPTSLETAKRGRREAIDIITGKDDRVLVIVGPCSIHDLEAAQEYALRLKKLSDELKGDLSIIMRAYLEKPR--VGWKGLINDPDVNNTFNINKGLQSARQLFVNLTNIGLPIGSEMLDTISPQYLADLVSFGAIGARTTESQLHRELASGLSFPVGFKNGTDGTLNVAVDACQAAAHSHHFMGVT-HGVAAITTTKGNEHCFVILRGGKKGTNYDAKSVAEAKAQLPAGSNGLMIDYSHGNSNKDFRNQPKVNDVVCEQIANGENAITGVMIESNINEGNQGIPAEGKAGLKYGVSITDACIGWETTEDVLRKLAAAVRQRREVNK 3369
                                  3032      3042      3052      3062      3072      3082      3092      3102      3112 |  | 3122      3132      3142      3152      3162      3172      3182      3192      3202      3212      3222     |3232      3242      3252      3262      3272      3282      3292      3302      3312      3322      3332      3342      3352      3362
                                                                                                                    3114  |                                                                                                           3228 |
                                                                                                                       3117                                                                                                             3230

Chain D from PDB  Type:PROTEIN  Length:346
 aligned with AROG_YEAST | P32449 from UniProtKB/Swiss-Prot  Length:370

    Alignment length:347
                                    32        42        52        62        72        82        92       102       112       122       132       142       152       162       172       182       192       202       212       222       232       242       252       262       272       282       292       302       312       322       332       342       352       362
          AROG_YEAST     23 VRILGYDPLASPALLQVQIPATPTSLETAKRGRREAIDIITGKDDRVLVIVGPCSIHDLEAAQEYALRLKKLSDELKGDLSIIMRAYLEKPRTTVGWKGLINDPDVNNTFNINKGLQSARQLFVNLTNIGLPIGSEMLDTISPQYLADLVSFGAIGARTTESQLHRELASGLSFPVGFKNGTDGTLNVAVDACQAAAHSHHFMGVTKHGVAAITTTKGNEHCFVILRGGKKGTNYDAKSVAEAKAQLPAGSNGLMIDYSHGNSNKDFRNQPKVNDVVCEQIANGENAITGVMIESNINEGNQGIPAEGKAGLKYGVSITDACIGWETTEDVLRKLAAAVRQRREVNK  369
               SCOP domains d1ofqd_ D: 3-deoxy-D-arabino-heptulosonate-7-phosphate synthase (DAHP synthase, AroG)                                                                                                                                                                                                                                                                       SCOP domains
               CATH domains 1ofqD00 D:4023-4369 Aldolase class I                                                                                                                                                                                                                                                                                                                        CATH domains
           Pfam domains (1) -----------------DAHP_synth_1-1ofqD01 D:4040-4355                                                                                                                                                                                                                                                                                            -------------- Pfam domains (1)
           Pfam domains (2) -----------------DAHP_synth_1-1ofqD02 D:4040-4355                                                                                                                                                                                                                                                                                            -------------- Pfam domains (2)
           Pfam domains (3) -----------------DAHP_synth_1-1ofqD03 D:4040-4355                                                                                                                                                                                                                                                                                            -------------- Pfam domains (3)
           Pfam domains (4) -----------------DAHP_synth_1-1ofqD04 D:4040-4355                                                                                                                                                                                                                                                                                            -------------- Pfam domains (4)
         Sec.struct. author ..eeeeee..hhhhhhhhh..hhhhhhhhhhhhhhhhhhhh.....eeeeee.....hhhhhhhhhhhhhhhhhhhh..eeeeee....-....................hhhhhhhhhhhhhhhhhh....eeee.....hhhhhhhhh.eeee......hhhhhhhhh.....eeee......hhhhhhhhhhhh...eeeee.....eeeeee.....eeeeeee.......hhhhhhhhhhhh......eeeeeeee....hhhhhhhhhhhhhhhhhh....eeeeeee.............hhhhh...........hhhhhhhhhhhhhhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
               Transcript 1 Exon 1.1  PDB: D:4023-4369 (gaps) UniProt: 1-370 [INCOMPLETE]                                                                                                                                                                                                                                                                                               Transcript 1
                1ofq D 4023 VRILGYDPLASPALLQVQIPATPTSLETAKRGRREAIDIITGKDDRVLVIVGPCSIHDLEAAQEYALRLKKLSDELKGDLSIIMRAYLE-PRTTVGWKGLINDPDVNNTFNINKGLQSARQLFVNLTNIGLPIGSEMLDTISPQYLADLVSFGAIGARTTESQLHRELASGLSFPVGFKNGTDGTLNVAVDACQAAAHSHHFMGVTKHGVAAITTTKGNEHCFVILRGGKKGTNYDAKSVAEAKAQLPAGSNGLMIDYSHGNSNKDFRNQPKVNDVVCEQIANGENAITGVMIESNINEGNQGIPAEGKAGLKYGVSITDACIGWETTEDVLRKLAAAVRQRREVNK 4369
                                  4032      4042      4052      4062      4072      4082      4092      4102        |-|     4122      4132      4142      4152      4162      4172      4182      4192      4202      4212      4222      4232      4242      4252      4262      4272      4282      4292      4302      4312      4322      4332      4342      4352      4362
                                                                                                                 4111 |
                                                                                                                   4113

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Asymmetric Unit

Classes(

)

Architectures( (-)

)

Topologies( (-)

)

Homologous Superfamilies( (-)

)

Organisms( (-)

)

Class: Alpha Beta (26913)

Architecture: Alpha-Beta Barrel (2994)

Topology: TIM Barrel (2806)

Homologous Superfamily: Aldolase class I (887)

Baker's yeast (Saccharomyces cerevisiae) (49)

1a	1ofqA00	A:1023-1369
1b	1ofqB00	B:2023-2370
1c	1ofqC00	C:3023-3369
1d	1ofqD00	D:4023-4369

Asymmetric Unit

Clans(

)

Families(

)

Organisms( (-)

)

Clan: TIM_barrel (694)

Family: DAHP_synth_1 (46)

Saccharomyces cerevisiae (strain ATCC 204508 / S288c) (Bakers yeast) (9)

1a	DAHP_synth_1-1ofqD01	D:4040-4355
1b	DAHP_synth_1-1ofqD02	D:4040-4355
1c	DAHP_synth_1-1ofqD03	D:4040-4355
1d	DAHP_synth_1-1ofqD04	D:4040-4355

Asymmetric Unit(hide GO term definitions)

Chain A,B,C,D (AROG_YEAST | P32449)

molecular function
	GO:0003849	3-deoxy-7-phosphoheptulonate synthase activity	Catalysis of the reaction: D-erythrose 4-phosphate + H(2)O + phosphoenolpyruvate = 7-phospho-2-dehydro-3-deoxy-D-arabino-heptonate + phosphate.
	GO:0003824	catalytic activity	Catalysis of a biochemical reaction at physiological temperatures. In biologically catalyzed reactions, the reactants are known as substrates, and the catalysts are naturally occurring macromolecular substances known as enzymes. Enzymes possess specific binding sites for substrates, and are usually composed wholly or largely of protein, but RNA that has catalytic activity (ribozyme) is often also regarded as enzymatic.
	GO:0016740	transferase activity	Catalysis of the transfer of a group, e.g. a methyl group, glycosyl group, acyl group, phosphorus-containing, or other groups, from one compound (generally regarded as the donor) to another compound (generally regarded as the acceptor). Transferase is the systematic name for any enzyme of EC class 2.
biological process
	GO:0009073	aromatic amino acid family biosynthetic process	The chemical reactions and pathways resulting in the formation of aromatic amino acid family, amino acids with aromatic ring (phenylalanine, tyrosine, tryptophan).
	GO:0009058	biosynthetic process	The chemical reactions and pathways resulting in the formation of substances; typically the energy-requiring part of metabolism in which simpler substances are transformed into more complex ones.
	GO:0008652	cellular amino acid biosynthetic process	The chemical reactions and pathways resulting in the formation of amino acids, organic acids containing one or more amino substituents.
	GO:0009423	chorismate biosynthetic process	The chemical reactions and pathways resulting in the formation of the unsymmetrical ether derived from phosphoenolpyruvate and 5-phosphoshikimic acid formed as an intermediate in the biosynthesis of aromatic amino acids and many other compounds.
