(-) Description

Title :  CRYSTAL STRUCTURE OF PSEUDOMONAS FLUORESCENS HPPD

Authors :  L. Serre, A. Sailland, D. Sy, P. Boudec, A. Rolland, E. Pebay-Peroulla, C. Cohen-Addad
Date :  20 Apr 99  (Deposition) - 26 Apr 00  (Release) - 24 Feb 09  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  2.40
Chains :  Asym./Biol. Unit :  A,B,C,D
Keywords :  Oxidoreductase, Dioxygenase, Iron (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  L. Serre, A. Sailland, D. Sy, P. Boudec, A. Rolland, E. Pebay-Peyroula, C. Cohen-Addad
Crystal Structure Of Pseudomonas Fluorescens 4-Hydroxyphenylpyruvate Dioxygenase: An Enzyme Involved In The Tyrosine Degradation Pathway.
Structure Fold. Des. V. 7 977 1999
PubMed-ID: 10467142  |  Reference-DOI: 10.1016/S0969-2126(99)80124-5
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - 4-HYDROXYPHENYLPYRUVATE DIOXYGENASE
    Cell Line: A32
    Chains: A, B, C, D
    EC Number: 1.13.11.27
    Engineered: YES
    Expression System: PSEUDOMONAS FLUORESCENS
    Expression System Cell Line: A32
    Expression System Taxid: 294
    Expression System Vector: PBBRIMES
    Organism Scientific: PSEUDOMONAS FLUORESCENS
    Organism Taxid: 294

 Structural Features

(-) Chains, Units

  1234
Asymmetric/Biological Unit : ABCD

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (3, 12)

Asymmetric/Biological Unit (3, 12)
No.NameCountTypeFull Name
1ACT4Ligand/IonACETATE ION
2EMC4Ligand/IonETHYL MERCURY ION
3FE24Ligand/IonFE (II) ION

(-) Sites  (16, 16)

Asymmetric Unit (16, 16)
No.NameEvidenceResiduesDescription
01AC1SOFTWAREHIS A:161 , HIS A:240 , GLU A:322 , ACT A:631BINDING SITE FOR RESIDUE FE2 A 629
02AC2SOFTWAREHIS B:161 , HIS B:240 , GLU B:322 , ACT B:631BINDING SITE FOR RESIDUE FE2 B 629
03AC3SOFTWAREHIS C:161 , HIS C:240 , GLU C:322 , ACT C:631BINDING SITE FOR RESIDUE FE2 C 629
04AC4SOFTWAREHIS D:161 , HIS D:240 , GLU D:322 , ACT D:631BINDING SITE FOR RESIDUE FE2 D 629
05AC5SOFTWAREGLU A:17 , ALA A:66 , CYS A:78 , PRO A:123 , TYR A:125BINDING SITE FOR RESIDUE EMC A 630
06AC6SOFTWAREGLU B:17 , ALA B:66 , CYS B:78 , TYR B:125BINDING SITE FOR RESIDUE EMC B 630
07AC7SOFTWAREGLU C:17 , ALA C:66 , CYS C:78 , TYR C:125BINDING SITE FOR RESIDUE EMC C 630
08AC8SOFTWAREGLU D:17 , ASN D:59 , ALA D:66 , CYS D:78 , TYR D:125BINDING SITE FOR RESIDUE EMC D 630
09AC9SOFTWAREHIS A:161 , HIS A:240 , GLN A:309 , GLU A:322 , PHE A:337 , FE2 A:629BINDING SITE FOR RESIDUE ACT A 631
10ASAAUTHORHIS A:161 , HIS A:240 , GLU A:322IRON-BINDING SITE
11ASBAUTHORHIS B:161 , HIS B:240 , GLU B:322IRON-BINDING SITE
12ASCAUTHORHIS C:161 , HIS C:240 , GLU C:322IRON-BINDING SITE
13ASDAUTHORHIS D:161 , HIS D:240 , GLU D:322IRON-BINDING SITE
14BC1SOFTWAREHIS B:161 , HIS B:240 , GLN B:309 , GLU B:322 , PHE B:337 , FE2 B:629 , HOH B:652BINDING SITE FOR RESIDUE ACT B 631
15BC2SOFTWAREHIS C:161 , HIS C:240 , GLN C:309 , GLU C:322 , PHE C:337 , FE2 C:629 , HOH C:656BINDING SITE FOR RESIDUE ACT C 631
16BC3SOFTWAREHIS D:161 , HIS D:240 , GLN D:309 , GLU D:322 , PHE D:337 , FE2 D:629 , HOH D:657BINDING SITE FOR RESIDUE ACT D 631

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 1CJX)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 1CJX)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 1CJX)

(-) PROSITE Motifs  (1, 8)

Asymmetric/Biological Unit (1, 8)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1VOCPS51819 Vicinal oxygen chelate (VOC) domain profile.HPPD_PSEUJ12-129



158-313


 		  8A:12-129
B:12-129
C:12-129
D:12-129
A:159-313
B:159-313
C:159-313
D:159-313

(-) Exons   (0, 0)

(no "Exon" information available for 1CJX)

(-) Sequences/Alignments

Asymmetric/Biological Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:353
 aligned with HPPD_PSEUJ | P80064 from UniProtKB/Swiss-Prot  Length:357

    Alignment length:353
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273       283       293       303       313       323       333       343       353
           HPPD_PSEUJ     4 YENPMGLMGFEFIELASPTPNTLEPIFEIMGFTKVATHRSKDVHLYRQGAINLILNNEPHSVASYFAAEHGPSVCGMAFRVKDSQKAYKRALELGAQPIHIETGPMELNLPAIKGIGGAPLYLIDRFGEGSSIYDIDFVFLEGVDRHPVGAGLKIIDHLTHNVYRGRMAYWANFYEKLFNFREIRYFDIKGEYTGLTSKAMTAPDGMIRIPLNEESSKGAGQIEEFLMQFNGEGIQHVAFLSDDLIKTWDHLKSIGMRFMTAPPDTYYEMLEGRLPNHGEPVGELQARGILLDGSSESGDKRLLLQIFSETLMGPVFFEFIQRKGDDGFGEGNFKALFESIERDQVRRGVLST 356
               SCOP domains d1cjxa1 A:4-153 4-hydroxyphenylpyruvate dioxygenase, HppD                                                                                             d1cjxa2 A:154-356 4-hydroxyphenylpyruvate dioxygenase, HppD                                                                                                                                                 SCOP domains
               CATH domains 1cjxA01 A:4-153 2,3-Dihydroxybiphenyl 1,2-Dioxygenase, domain 1                                                                                       1cjxA02 A:154-356 2,3-Dihydroxybiphenyl 1,2-Dioxygenase, domain 1                                                                                                                                           CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .........eeeeee........hhhhhhh..eeeeee....eeeeee..eeeeee.....hhhhhhhhh.....eeeee...hhhhhhhhhh..................eee.hhh.eeeee........hhhhheee...............eeee.......hhhhhhhhhhhhh..eeeeeeeee....eeeeeeee......eeeeeee......hhhhhhhhh......eeeee...hhhhhhhhhh..........hhhhh.hhhh.......hhhhhhh..eeeeeee..eeeeeeeee........eeeeeeee......hhhhhhhhhhhhhhhhhh..... Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------VOC  PDB: A:12-129 UniProt: 12-129                                                                                    ----------------------------VOC  PDB: A:159-313 UniProt: 158-313                                                                                                                        ------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1cjx A   4 YENPMGLMGFEFIEFASPTPGTLEPIFEIMGFTKVATHRSKNVHLYRQGEINLILNNEPNSIASYFAAEHGPSVCGMAFRVKDSQKAYNRALELGAQPIHIDTGPMELNLPAIKGIGGAPLYLIDRFGEGSSIYDIDFVYLEGVERNPVGAGLKVIDHLTHNVYRGRMVYWANFYEKLFNFREARYFDIKGEYTGLTSKAMSAPDGMIRIPLNEESSKGAGQIEEFLMQFNGEGIQHVAFLTDDLVKTWDALKKIGMRFMTAPPDTYYEMLEGRLPDHGEPVDQLQARGILLDGSSVEGDKRLLLQIFSETLMGPVFFEFIQRKGDDGFGEGNFKALFESIERDQVRRGVLAT 356
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273       283       293       303       313       323       333       343       353


Chain B from PDB  Type:PROTEIN  Length:353
 aligned with HPPD_PSEUJ | P80064 from UniProtKB/Swiss-Prot  Length:357

    Alignment length:353
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273       283       293       303       313       323       333       343       353
           HPPD_PSEUJ     4 YENPMGLMGFEFIELASPTPNTLEPIFEIMGFTKVATHRSKDVHLYRQGAINLILNNEPHSVASYFAAEHGPSVCGMAFRVKDSQKAYKRALELGAQPIHIETGPMELNLPAIKGIGGAPLYLIDRFGEGSSIYDIDFVFLEGVDRHPVGAGLKIIDHLTHNVYRGRMAYWANFYEKLFNFREIRYFDIKGEYTGLTSKAMTAPDGMIRIPLNEESSKGAGQIEEFLMQFNGEGIQHVAFLSDDLIKTWDHLKSIGMRFMTAPPDTYYEMLEGRLPNHGEPVGELQARGILLDGSSESGDKRLLLQIFSETLMGPVFFEFIQRKGDDGFGEGNFKALFESIERDQVRRGVLST 356
               SCOP domains d1cjxb1 B:4-153 4-hydroxyphenylpyruvate dioxygenase, HppD                                                                                             d1cjxb2 B:154-356 4-hydroxyphenylpyruvate dioxygenase, HppD                                                                                                                                                 SCOP domains
               CATH domains 1cjxB01 B:4-153 2,3-Dihydroxybiphenyl 1,2-Dioxygenase, domain 1                                                                                       1cjxB02 B:154-355 2,3-Dihydroxybiphenyl 1,2-Dioxygenase, domain 1                                                                                                                                         - CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .........eeeeee.......hhhhhhhh..eeeeee....eeeeee..eeeeee.....hhhhhhhhh.....eeeee...hhhhhhhhhhh.................eee.hhh.eeeee........hhhhheee............eeee....eee...hhhhhhhhhhhhh..eeeeeeeee....eeeeeeee......eeeeeee......hhhhhhhhh......eeeeee..hhhhhhhhhhh.........hhhhhhhhhh.......hhhhhhh..eeeeeee..eeeeeeeee........eeeeeeee......hhhhhhhhhhhhhhhhhh..... Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------VOC  PDB: B:12-129 UniProt: 12-129                                                                                    ----------------------------VOC  PDB: B:159-313 UniProt: 158-313                                                                                                                        ------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1cjx B   4 YENPMGLMGFEFIEFASPTPGTLEPIFEIMGFTKVATHRSKNVHLYRQGEINLILNNEPNSIASYFAAEHGPSVCGMAFRVKDSQKAYNRALELGAQPIHIDTGPMELNLPAIKGIGGAPLYLIDRFGEGSSIYDIDFVYLEGVERNPVGAGLKVIDHLTHNVYRGRMVYWANFYEKLFNFREARYFDIKGEYTGLTSKAMSAPDGMIRIPLNEESSKGAGQIEEFLMQFNGEGIQHVAFLTDDLVKTWDALKKIGMRFMTAPPDTYYEMLEGRLPDHGEPVDQLQARGILLDGSSVEGDKRLLLQIFSETLMGPVFFEFIQRKGDDGFGEGNFKALFESIERDQVRRGVLAT 356
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273       283       293       303       313       323       333       343       353


Chain C from PDB  Type:PROTEIN  Length:353
 aligned with HPPD_PSEUJ | P80064 from UniProtKB/Swiss-Prot  Length:357

    Alignment length:353
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273       283       293       303       313       323       333       343       353
           HPPD_PSEUJ     4 YENPMGLMGFEFIELASPTPNTLEPIFEIMGFTKVATHRSKDVHLYRQGAINLILNNEPHSVASYFAAEHGPSVCGMAFRVKDSQKAYKRALELGAQPIHIETGPMELNLPAIKGIGGAPLYLIDRFGEGSSIYDIDFVFLEGVDRHPVGAGLKIIDHLTHNVYRGRMAYWANFYEKLFNFREIRYFDIKGEYTGLTSKAMTAPDGMIRIPLNEESSKGAGQIEEFLMQFNGEGIQHVAFLSDDLIKTWDHLKSIGMRFMTAPPDTYYEMLEGRLPNHGEPVGELQARGILLDGSSESGDKRLLLQIFSETLMGPVFFEFIQRKGDDGFGEGNFKALFESIERDQVRRGVLST 356
               SCOP domains d1cjxc1 C:4-153 4-hydroxyphenylpyruvate dioxygenase, HppD                                                                                             d1cjxc2 C:154-356 4-hydroxyphenylpyruvate dioxygenase, HppD                                                                                                                                                 SCOP domains
               CATH domains 1cjxC01 C:4-153 2,3-Dihydroxybiphenyl 1,2-Dioxygenase, domain 1                                                                                       1cjxC02 C:154-355 2,3-Dihydroxybiphenyl 1,2-Dioxygenase, domain 1                                                                                                                                         - CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .........eeeeee........hhhhhh...eeeeee....eeeeee..eeeeee.....hhhhhhhhh.....eeeee...hhhhhhhhhh..................eee.hhh.eeeee........hhhhheee...............eeeeeee....hhhhhhhhhhhhh..eeeeeeeee....eeeeeeee......eeeeeee......hhhhhhhhh......eeeee...hhhhhhhhhh..........hhhhhhhhhh.......hhhhhhh..eeeeeee..eeeeeeeee........eeeeeeee......hhhhhhhhhhhhhhhhh...... Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------VOC  PDB: C:12-129 UniProt: 12-129                                                                                    ----------------------------VOC  PDB: C:159-313 UniProt: 158-313                                                                                                                        ------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1cjx C   4 YENPMGLMGFEFIEFASPTPGTLEPIFEIMGFTKVATHRSKNVHLYRQGEINLILNNEPNSIASYFAAEHGPSVCGMAFRVKDSQKAYNRALELGAQPIHIDTGPMELNLPAIKGIGGAPLYLIDRFGEGSSIYDIDFVYLEGVERNPVGAGLKVIDHLTHNVYRGRMVYWANFYEKLFNFREARYFDIKGEYTGLTSKAMSAPDGMIRIPLNEESSKGAGQIEEFLMQFNGEGIQHVAFLTDDLVKTWDALKKIGMRFMTAPPDTYYEMLEGRLPDHGEPVDQLQARGILLDGSSVEGDKRLLLQIFSETLMGPVFFEFIQRKGDDGFGEGNFKALFESIERDQVRRGVLAT 356
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273       283       293       303       313       323       333       343       353


Chain D from PDB  Type:PROTEIN  Length:353
 aligned with HPPD_PSEUJ | P80064 from UniProtKB/Swiss-Prot  Length:357

    Alignment length:353
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273       283       293       303       313       323       333       343       353
           HPPD_PSEUJ     4 YENPMGLMGFEFIELASPTPNTLEPIFEIMGFTKVATHRSKDVHLYRQGAINLILNNEPHSVASYFAAEHGPSVCGMAFRVKDSQKAYKRALELGAQPIHIETGPMELNLPAIKGIGGAPLYLIDRFGEGSSIYDIDFVFLEGVDRHPVGAGLKIIDHLTHNVYRGRMAYWANFYEKLFNFREIRYFDIKGEYTGLTSKAMTAPDGMIRIPLNEESSKGAGQIEEFLMQFNGEGIQHVAFLSDDLIKTWDHLKSIGMRFMTAPPDTYYEMLEGRLPNHGEPVGELQARGILLDGSSESGDKRLLLQIFSETLMGPVFFEFIQRKGDDGFGEGNFKALFESIERDQVRRGVLST 356
               SCOP domains d1cjxd1 D:4-153 4-hydroxyphenylpyruvate dioxygenase, HppD                                                                                             d1cjxd2 D:154-356 4-hydroxyphenylpyruvate dioxygenase, HppD                                                                                                                                                 SCOP domains
               CATH domains 1cjxD01 D:4-153 2,3-Dihydroxybiphenyl 1,2-Dioxygenase, domain 1                                                                                       1cjxD02 D:154-355 2,3-Dihydroxybiphenyl 1,2-Dioxygenase, domain 1                                                                                                                                         - CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .........eeeeee.......hhhhhhh...eeeeee....eeeeee..eeeeee.....hhhhhhhhh.....eeeee...hhhhhhhhhh..................eee.hhh.eeeee........hhhhheee..............eeeee.......hhhhhhhhhhhhh..eeeeeeeee....eeeeeeee......eeeeeee......hhhhhhhhh......eeeee...hhhhhhhhhh..........hhhhh.hhhh.......hhhhhhh..eeeeeee..eeeeeeeee........eeeeeeee......hhhhhhhhhhhhhhhhhh..... Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------VOC  PDB: D:12-129 UniProt: 12-129                                                                                    ----------------------------VOC  PDB: D:159-313 UniProt: 158-313                                                                                                                        ------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1cjx D   4 YENPMGLMGFEFIEFASPTPGTLEPIFEIMGFTKVATHRSKNVHLYRQGEINLILNNEPNSIASYFAAEHGPSVCGMAFRVKDSQKAYNRALELGAQPIHIDTGPMELNLPAIKGIGGAPLYLIDRFGEGSSIYDIDFVYLEGVERNPVGAGLKVIDHLTHNVYRGRMVYWANFYEKLFNFREARYFDIKGEYTGLTSKAMSAPDGMIRIPLNEESSKGAGQIEEFLMQFNGEGIQHVAFLTDDLVKTWDALKKIGMRFMTAPPDTYYEMLEGRLPDHGEPVDQLQARGILLDGSSVEGDKRLLLQIFSETLMGPVFFEFIQRKGDDGFGEGNFKALFESIERDQVRRGVLAT 356
                                    13        23        33        43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233       243       253       263       273       283       293       303       313       323       333       343       353
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 8)

Asymmetric/Biological Unit
(-)
Class: Alpha and beta proteins (a+b) (23004)

(-) CATH Domains  (1, 8)

Asymmetric/Biological Unit
(-)
Class: Alpha Beta (26913)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 1CJX)

(-) Gene Ontology  (9, 9)

Asymmetric/Biological Unit(hide GO term definitions)
Chain A,B,C,D   (HPPD_PSEUJ | P80064)
molecular function
    GO:0003868    4-hydroxyphenylpyruvate dioxygenase activity    Catalysis of the reaction: 4-hydroxyphenylpyruvate + O2 = homogentisate + CO2.
    GO:0051213    dioxygenase activity    Catalysis of an oxidation-reduction (redox) reaction in which both atoms of oxygen from one molecule of O2 are incorporated into the (reduced) product(s) of the reaction. The two atoms of oxygen may be distributed between two different products.
    GO:0046872    metal ion binding    Interacting selectively and non-covalently with any metal ion.
    GO:0016491    oxidoreductase activity    Catalysis of an oxidation-reduction (redox) reaction, a reversible chemical reaction in which the oxidation state of an atom or atoms within a molecule is altered. One substrate acts as a hydrogen or electron donor and becomes oxidized, while the other acts as hydrogen or electron acceptor and becomes reduced.
    GO:0016701    oxidoreductase activity, acting on single donors with incorporation of molecular oxygen    Catalysis of an oxidation-reduction (redox) reaction in which hydrogen or electrons are transferred from one donor, and molecular oxygen is incorporated into a donor.
biological process
    GO:0006559    L-phenylalanine catabolic process    The chemical reactions and pathways resulting in the breakdown of phenylalanine, 2-amino-3-phenylpropanoic acid.
    GO:0009072    aromatic amino acid family metabolic process    The chemical reactions and pathways involving aromatic amino acid family, amino acids with aromatic ring (phenylalanine, tyrosine, tryptophan).
    GO:0055114    oxidation-reduction process    A metabolic process that results in the removal or addition of one or more electrons to or from a substance, with or without the concomitant removal or addition of a proton or protons.
    GO:0006572    tyrosine catabolic process    The chemical reactions and pathways resulting in the breakdown of tyrosine, an aromatic amino acid, 2-amino-3-(4-hydroxyphenyl)propanoic acid.
