(-) Description

Title :  THE CRYSTAL STRUCTURE OF IUS-SPRY DOMAIN FROM RANBP10

Authors :  S. K. Hong, K. -H. Kim, E. E. Kim
Date :  22 Apr 16  (Deposition) - 09 Nov 16  (Release) - 09 Nov 16  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  1.80
Chains :  Asym. Unit :  A,B,C,D,E,F,G,H,I,J,K,L,M,N,O,P
Biol. Unit 1:  A  (1x)
Biol. Unit 2:  B  (1x)
Biol. Unit 3:  C  (1x)
Biol. Unit 4:  D  (1x)
Biol. Unit 5:  E  (1x)
Biol. Unit 6:  F  (1x)
Biol. Unit 7:  G  (1x)
Biol. Unit 8:  H  (1x)
Biol. Unit 9:  I  (1x)
Biol. Unit 10:  J  (1x)
Biol. Unit 11:  K  (1x)
Biol. Unit 12:  L  (1x)
Biol. Unit 13:  M  (1x)
Biol. Unit 14:  N  (1x)
Biol. Unit 15:  O  (1x)
Biol. Unit 16:  P  (1x)
Keywords :  Beta Sandwich, Transport Protein, Ran-Binding Protein (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  S. K. Hong, K. H. Kim, E. J. Song, E. E. Kim
Structural Basis For The Interaction Between The Ius-Spry Domain Of Ranbpm And Ddx-4 In Germ Cell Development.
J. Mol. Biol. V. 428 4330 2016
PubMed-ID: 27622290  |  Reference-DOI: 10.1016/J.JMB.2016.09.004

(-) Compounds

Molecule 1 - RAN-BINDING PROTEIN 10
    Chains: A, B, C, D, E, F, G, H, I, J, K, L, M, N, O, P
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Plasmid: PET28A
    Expression System Strain: ROSETTA(DE3)
    Expression System Taxid: 562
    Expression System Vector Type: PLASMID
    Fragment: IUS-SPRY DOMAIN, UNP RESIDUES 29-238
    Gene: RANBP10, KIAA1464
    Organism Common: MOUSE
    Organism Scientific: MUS MUSCULUS
    Organism Taxid: 10090
    Synonym: RANBP10

 Structural Features

(-) Chains, Units

  12345678910111213141516
Asymmetric Unit : ABCDEFGHIJKLMNOP
Biological Unit 1 (1x): A
Biological Unit 2 (1x):  B
Biological Unit 3 (1x):   C
Biological Unit 4 (1x):    D
Biological Unit 5 (1x):     E
Biological Unit 6 (1x):      F
Biological Unit 7 (1x):       G
Biological Unit 8 (1x):        H
Biological Unit 9 (1x):         I
Biological Unit 10 (1x):          J
Biological Unit 11 (1x):           K
Biological Unit 12 (1x):            L
Biological Unit 13 (1x):             M
Biological Unit 14 (1x):              N
Biological Unit 15 (1x):               O
Biological Unit 16 (1x):                P

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (1, 8)

Asymmetric Unit (1, 8)
No.NameCountTypeFull Name
1IMD8Ligand/IonIMIDAZOLE
Biological Unit 1 (1, 1)
No.NameCountTypeFull Name
1IMD1Ligand/IonIMIDAZOLE
Biological Unit 2 (0, 0)
No.NameCountTypeFull Name
1IMD-1Ligand/IonIMIDAZOLE
Biological Unit 3 (0, 0)
No.NameCountTypeFull Name
1IMD-1Ligand/IonIMIDAZOLE
Biological Unit 4 (1, 1)
No.NameCountTypeFull Name
1IMD1Ligand/IonIMIDAZOLE
Biological Unit 5 (1, 1)
No.NameCountTypeFull Name
1IMD1Ligand/IonIMIDAZOLE
Biological Unit 6 (0, 0)
No.NameCountTypeFull Name
1IMD-1Ligand/IonIMIDAZOLE
Biological Unit 7 (1, 1)
No.NameCountTypeFull Name
1IMD1Ligand/IonIMIDAZOLE
Biological Unit 8 (1, 1)
No.NameCountTypeFull Name
1IMD1Ligand/IonIMIDAZOLE
Biological Unit 9 (0, 0)
No.NameCountTypeFull Name
1IMD-1Ligand/IonIMIDAZOLE
Biological Unit 10 (1, 1)
No.NameCountTypeFull Name
1IMD1Ligand/IonIMIDAZOLE
Biological Unit 11 (0, 0)
No.NameCountTypeFull Name
1IMD-1Ligand/IonIMIDAZOLE
Biological Unit 12 (0, 0)
No.NameCountTypeFull Name
1IMD-1Ligand/IonIMIDAZOLE
Biological Unit 13 (0, 0)
No.NameCountTypeFull Name
1IMD-1Ligand/IonIMIDAZOLE
Biological Unit 14 (1, 1)
No.NameCountTypeFull Name
1IMD1Ligand/IonIMIDAZOLE
Biological Unit 15 (0, 0)
No.NameCountTypeFull Name
1IMD-1Ligand/IonIMIDAZOLE
Biological Unit 16 (1, 1)
No.NameCountTypeFull Name
1IMD1Ligand/IonIMIDAZOLE

(-) Sites  (8, 8)

Asymmetric Unit (8, 8)
No.NameEvidenceResiduesDescription
1AC1SOFTWAREHIS A:84 , ARG A:131 , TRP A:135 , GLY A:154 , HIS M:84 , ARG M:131 , GLY M:154binding site for residue IMD A 901
2AC2SOFTWAREARG D:131 , TRP D:135 , GLY D:154 , ARG O:131 , GLY O:154binding site for residue IMD D 301
3AC3SOFTWAREARG C:131 , TRP C:135 , GLY C:154 , HIS E:84 , ARG E:131 , GLY E:154binding site for residue IMD E 301
4AC4SOFTWAREARG G:131 , TRP G:135 , GLY G:154binding site for residue IMD G 301
5AC5SOFTWAREARG F:131 , TRP F:135 , GLY F:154 , HIS H:84 , ARG H:131 , TRP H:135 , GLY H:154binding site for residue IMD H 301
6AC6SOFTWAREARG I:131 , TRP I:135 , GLY I:154 , HIS J:84 , ARG J:131 , TRP J:135 , GLY J:154binding site for residue IMD J 301
7AC7SOFTWAREHIS N:84 , ARG N:131 , TRP N:135 , GLY N:154binding site for residue IMD N 301
8AC8SOFTWAREHIS P:84 , ARG P:131 , TRP P:135 , GLY P:154binding site for residue IMD P 301

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 5JIA)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 5JIA)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 5JIA)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 5JIA)

(-) Exons   (0, 0)

(no "Exon" information available for 5JIA)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:206

               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author hhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhhhhhh. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia A  33 QELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRAKVQ 238
                                    42        52        62        72        82        92       102       112       122       132       142       152       162       172       182       192       202       212       222       232


Chain B from PDB  Type:PROTEIN  Length:207

               SCOP domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhhhhhh. Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia B  32 EQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRAKVQ 238
                                    41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231


Chain C from PDB  Type:PROTEIN  Length:205

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia C  31 GEQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRA 235
                                    40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230


Chain D from PDB  Type:PROTEIN  Length:210

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author .hhhhhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeeee..............eeeee.....eee................eeeeeee....eeeeee..eeeeeee......eeeeeee....eeeeee........hhhhhhhhhhhhh. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Transcript
                 5jia D  29 SPGEQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRAKVQ 238
                                    38        48        58        68        78        88        98       108       118       128       138       148       158       168       178       188       198       208       218       228       238


Chain E from PDB  Type:PROTEIN  Length:207

               SCOP domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhhhhh. Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia E  31 GEQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRAKV 237
                                    40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230


Chain F from PDB  Type:PROTEIN  Length:207

               SCOP domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia F  29 SPGEQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRA 235
                                    38        48        58        68        78        88        98       108       118       128       138       148       158       168       178       188       198       208       218       228


Chain G from PDB  Type:PROTEIN  Length:203

               SCOP domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee.....eee................eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia G  31 GEQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREW 233
                                    40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230


Chain H from PDB  Type:PROTEIN  Length:203

               SCOP domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia H  33 QELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRA 235
                                    42        52        62        72        82        92       102       112       122       132       142       152       162       172       182       192       202       212       222       232


Chain I from PDB  Type:PROTEIN  Length:206

               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee.....eee................eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia I  32 EQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRAKV 237
                                    41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231


Chain J from PDB  Type:PROTEIN  Length:199

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee.....eee................eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhh. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia J  33 QELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMR 231
                                    42        52        62        72        82        92       102       112       122       132       142       152       162       172       182       192       202       212       222


Chain K from PDB  Type:PROTEIN  Length:203

               SCOP domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia K  31 GEQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREW 233
                                    40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230


Chain L from PDB  Type:PROTEIN  Length:205

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia L  32 EQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRAK 236
                                    41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231


Chain M from PDB  Type:PROTEIN  Length:208

               SCOP domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeeee..............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee......eeeeeee....eeeeee........hhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia M  29 SPGEQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRAK 236
                                    38        48        58        68        78        88        98       108       118       128       138       148       158       168       178       188       198       208       218       228


Chain N from PDB  Type:PROTEIN  Length:203

               SCOP domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee.....eee................eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhh. Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia N  31 GEQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREW 233
                                    40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230


Chain O from PDB  Type:PROTEIN  Length:202

               SCOP domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhh Sec.struct. author
                 SAPs(SNPs) ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 5jia O  31 GEQELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMRE 232
                                    40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230


Chain P from PDB  Type:PROTEIN  Length:204

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author .hhhhhhhhh.............eeeeee...eeee....eeee.....hhhhheeeee....hhhh.eeeeeeeeeee......eeeee...............eeeee....eeee.....ee.........eeeeeee....eeeeee..eeeeeee.......eeeeee....eeeeee........hhhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Transcript
                 5jia P  34 ELSRRLQRLYPAVNQHETPLPRSWSPKDKYNYIGLSQGNLRVHYKGHGKNHKDAASVRATHPIPAACGIYYFEVKIVSKGRDGYMGIGLSAQGVNMNRLPGWDKHSYGYHGDDGHSFCSSGTGQPYGPTFTTGDVIGCCVNLINGTCFYTKNGHSLGIAFTDLPANLYPTVGLQTPGEIVDANFGQQPFLFDIEDYMREWRAKV 237
                                    43        53        63        73        83        93       103       113       123       133       143       153       163       173       183       193       203       213       223       233
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 5JIA)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 5JIA)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 5JIA)

(-) Gene Ontology  (8, 8)

Asymmetric Unit(hide GO term definitions)

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    IMD  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    AC2  [ RasMol ]  +environment [ RasMol ]
    AC3  [ RasMol ]  +environment [ RasMol ]
    AC4  [ RasMol ]  +environment [ RasMol ]
    AC5  [ RasMol ]  +environment [ RasMol ]
    AC6  [ RasMol ]  +environment [ RasMol ]
    AC7  [ RasMol ]  +environment [ RasMol ]
    AC8  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 5jia)

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]
    Biological Unit 3  [ Jena3D ]
    Biological Unit 4  [ Jena3D ]
    Biological Unit 5  [ Jena3D ]
    Biological Unit 6  [ Jena3D ]
    Biological Unit 7  [ Jena3D ]
    Biological Unit 8  [ Jena3D ]
    Biological Unit 9  [ Jena3D ]
    Biological Unit 10  [ Jena3D ]
    Biological Unit 11  [ Jena3D ]
    Biological Unit 12  [ Jena3D ]
    Biological Unit 13  [ Jena3D ]
    Biological Unit 14  [ Jena3D ]
    Biological Unit 15  [ Jena3D ]
    Biological Unit 16  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Asym. Unit - sites PNG format | Biol. Unit 1 PNG format | Biol. Unit 1 - sites PNG format | Biol. Unit 2 PNG format | Biol. Unit 3 PNG format | Biol. Unit 4 PNG format | Biol. Unit 5 PNG format | Biol. Unit 6 PNG format | Biol. Unit 7 PNG format | Biol. Unit 8 PNG format | Biol. Unit 9 PNG format | Biol. Unit 10 PNG format | Biol. Unit 11 PNG format | Biol. Unit 12 PNG format | Biol. Unit 13 PNG format | Biol. Unit 14 PNG format | Biol. Unit 15 PNG format | Biol. Unit 16 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  5jia
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  RBP10_MOUSE | Q6VN19
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/SwissProt

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  RBP10_MOUSE | Q6VN19
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

(no "Entries Sharing at Least One Protein Chain" available for 5JIA)

(-) Related Entries Specified in the PDB File

5ji7 5ji9 5jiu
