(-) Description

Title :  CRYSTAL STRUCTURE OF TRIOSEPHOSPHATE ISOMERASE FROM STREPTOMYCES COELICOLOR

Authors :  S. Romero-Romero, A. Rodriguez-Romero, D. A. Fernandez-Velasco
Date :  17 Feb 15  (Deposition) - 15 Jul 15  (Release) - 12 Aug 15  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  2.29
Chains :  Asym. Unit :  A,B,C,D
Biol. Unit 1:  A,B  (1x)
Biol. Unit 2:  C,D  (1x)
Keywords :  Tim Barrel, Isomerase, Tpi (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  S. Romero-Romero, M. Costas, A. Rodriguez-Romero, D. Alejandro Fernandez-Velasco
Reversibility And Two State Behaviour In The Thermal Unfolding Of Oligomeric Tim Barrel Proteins.
Phys Chem Chem Phys V. 17 20699 2015
PubMed-ID: 26206330  |  Reference-DOI: 10.1039/C5CP01599E

(-) Compounds

Molecule 1 - TRIOSEPHOSPHATE ISOMERASE
    Chains: A, B, C, D
    EC Number: 5.3.1.1
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Plasmid: PET-28B(+)
    Expression System Strain: BL21(DE3)PLYSS
    Expression System Taxid: 469008
    Expression System Vector Type: PLASMID
    Gene: TPIA, TPI, SCO1945, SCC54.05C
    Organism Scientific: STREPTOMYCES COELICOLOR
    Organism Taxid: 100226
    Other Details: EXPRESSION TAG: GSH
    Strain: A3(2) / M145
    Synonym: TIM,TRIOSE-PHOSPHATE ISOMERASE

 Structural Features

(-) Chains, Units

  1234
Asymmetric Unit : ABCD
Biological Unit 1 (1x): AB
Biological Unit 2 (1x):   CD

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (0, 0)

(no "Ligand,Modified Residues,Ions" information available for 4Y9A)

(-) Sites  (0, 0)

(no "Site" information available for 4Y9A)

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 4Y9A)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 4Y9A)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 4Y9A)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 4Y9A)

(-) Exons   (0, 0)

(no "Exon" information available for 4Y9A)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:254

               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...eeeee.....hhhhhhhhhhhhhhhhhhhhhhhheeeee.hhhhhhhhhhhhhhh....eeee...............hhhhhhhh...eeee.hhhhhhhh..hhhhhhhhhhhhhhh..eeeeee..hhhhhhh.hhhhhhhhhhhhhh...hhhhhh..eeee.hhhhh......hhhhhhhhhhhhhhhhhhhhhhhhhh..eeee.......hhhhhhh.....eeeehhhhhhhhhhhhhhh... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4y9a A   7 RTPLMAGNWKMNLNHLEAIAHVQKLAFALADKDYDAVEVAVLAPFTDLRSVQTLVDGDKLKIKYGAQDISAHDGGAYTGEISGPMLAKLKCTYVAVGHSERRQYHAETDEIVNAKVKAAYKHGLTPILCVGEELDVREAGNHVEHTLAQVEGGLKDLAAEQAESVVIAYEPVWAIGTGKVCGADDAQEVCAAIRGKLAELYSQELADKVRIQYGGSVKSGNVAEIMAKPDIDGALVGGASLDSDEFVKIVRFRD 260
                                    16        26        36        46        56        66        76        86        96       106       116       126       136       146       156       166       176       186       196       206       216       226       236       246       256


Chain B from PDB  Type:PROTEIN  Length:255

               SCOP domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ....eeeee.....hhhhhhhhhhhhhhhhhhhhhhhheeeee.hhhhhhhhhhhhhhh....eeee...............hhhhhhhh...eeee.hhhhhhhh..hhhhhhhhhhhhhhh..eeeeee..hhhhhhh.hhhhhhhhhhhhhh...hhhhhh..eeee.hhhhh......hhhhhhhhhhhhhhhhhhhhhhhhhh..eeee.......hhhhhhhh....eeeehhhhhhhhhhhhhhh... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4y9a B   6 TRTPLMAGNWKMNLNHLEAIAHVQKLAFALADKDYDAVEVAVLAPFTDLRSVQTLVDGDKLKIKYGAQDISAHDGGAYTGEISGPMLAKLKCTYVAVGHSERRQYHAETDEIVNAKVKAAYKHGLTPILCVGEELDVREAGNHVEHTLAQVEGGLKDLAAEQAESVVIAYEPVWAIGTGKVCGADDAQEVCAAIRGKLAELYSQELADKVRIQYGGSVKSGNVAEIMAKPDIDGALVGGASLDSDEFVKIVRFRD 260
                                    15        25        35        45        55        65        75        85        95       105       115       125       135       145       155       165       175       185       195       205       215       225       235       245       255


Chain C from PDB  Type:PROTEIN  Length:254

               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...eeeee.....hhhhhhhhhhhhhhhhhhhhhhhheeeee.hhhhhhhhhhhhhhhh...eeee...............hhhhhhhh...eeee.hhhhhhhh..hhhhhhhhhhhhhhh..eeeeee..hhhhhhh.hhhhhhhhhhhhhh...hhhhhh..eeee.hhhhh......hhhhhhhhhhhhhhhhhhhhhhhhhh..eeee.......hhhhhhh.....eeeehhhhhhhhhhhhhhh... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4y9a C   7 RTPLMAGNWKMNLNHLEAIAHVQKLAFALADKDYDAVEVAVLAPFTDLRSVQTLVDGDKLKIKYGAQDISAHDGGAYTGEISGPMLAKLKCTYVAVGHSERRQYHAETDEIVNAKVKAAYKHGLTPILCVGEELDVREAGNHVEHTLAQVEGGLKDLAAEQAESVVIAYEPVWAIGTGKVCGADDAQEVCAAIRGKLAELYSQELADKVRIQYGGSVKSGNVAEIMAKPDIDGALVGGASLDSDEFVKIVRFRD 260
                                    16        26        36        46        56        66        76        86        96       106       116       126       136       146       156       166       176       186       196       206       216       226       236       246       256


Chain D from PDB  Type:PROTEIN  Length:255

               SCOP domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ....eeeee.....hhhhhhhhhhhhhhhhhhhhhhhheeeee.hhhhhhhhhhhhhhh....eeee...............hhhhhhhh...eeee.hhhhhhhh..hhhhhhhhhhhhhhh..eeeeee..hhhhhhh.hhhhhhhhhhhhhh...hhhhhh..eeee.hhhhhh.....hhhhhhhhhhhhhhhhhhhhhhhhhh..eeee....hhhhhhhhh......eeeehhhhhhhhhhhhhhh... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4y9a D   6 TRTPLMAGNWKMNLNHLEAIAHVQKLAFALADKDYDAVEVAVLAPFTDLRSVQTLVDGDKLKIKYGAQDISAHDGGAYTGEISGPMLAKLKCTYVAVGHSERRQYHAETDEIVNAKVKAAYKHGLTPILCVGEELDVREAGNHVEHTLAQVEGGLKDLAAEQAESVVIAYEPVWAIGTGKVCGADDAQEVCAAIRGKLAELYSQELADKVRIQYGGSVKSGNVAEIMAKPDIDGALVGGASLDSDEFVKIVRFRD 260
                                    15        25        35        45        55        65        75        85        95       105       115       125       135       145       155       165       175       185       195       205       215       225       235       245       255
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 4Y9A)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 4Y9A)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 4Y9A)

(-) Gene Ontology  (11, 11)
