(-) Description

Title :  IMMEDIATE-EARLY 1 PROTEIN (IE1) OF RHESUS MACAQUE CYTOMEGALOVIRUS

Authors :  S. Klingl, M. Scherer, M. Sevvana, Y. A. Muller, T. Stamminger
Date :  25 Sep 14  (Deposition) - 15 Jul 15  (Release) - 15 Jul 15  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  2.85
Chains :  Asym. Unit :  A,B,C,D
Biol. Unit 1:  A,B  (1x)
Biol. Unit 2:  C,D  (1x)
Keywords :  Cytomegalovirus, Antagonist, All-Alpha, Viral Protein (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  S. Klingl, M. Scherer, T. Stamminger, Y. A. Muller
Controlled Crystal Dehydration Triggers A Space-Group Switc And Shapes The Tertiary Structure Of Cytomegalovirus Immediate-Early 1 (Ie1) Protein.
Acta Crystallogr. , Sect. D V. 71 1493 2015
PubMed-ID: 26143921  |  Reference-DOI: 10.1107/S1399004715008792

(-) Compounds

Molecule 1 - RHUL123
    Chains: A, B, C, D
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Plasmid: PGEX-6P-1
    Expression System Strain: BL21(DE3)
    Expression System Taxid: 469008
    Expression System Vector Type: PLASMID
    Organism Common: RHESUS CYTOMEGALOVIRUS
    Organism Scientific: MACACINE HERPESVIRUS 3
    Organism Taxid: 47929

 Structural Features

(-) Chains, Units

  1234
Asymmetric Unit : ABCD
Biological Unit 1 (1x): AB
Biological Unit 2 (1x):   CD

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (0, 0)

(no "Ligand,Modified Residues,Ions" information available for 4WIC)

(-) Sites  (0, 0)

(no "Site" information available for 4WIC)

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 4WIC)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 4WIC)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 4WIC)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 4WIC)

(-) Exons   (0, 0)

(no "Exon" information available for 4WIC)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:349

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...hhhhhhhhhhhhhhhhhhhhh.............hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4wic A  41 DMALQHAVDLLEKMLADEEKKLTEFNLGDPLFESPIKTLEEIIQEGDDVVGAHQLVVTQIKLRVQRNRRLADEIIREQLTDIRKVFSDKFEKLEQGIQNSYLLLDKLKTPFQDMRCLFEVANEQFNDTPVPPQYKEKFMVCLKQIVQYAVNSSSKLEKFVMLKIKTKKDDIKDRVTYTCMKYLLMAMQGTGGPKAINNEEHAKLFFKQLSNYDDLTDANHDGLELIKKLDKEQKEVAFHVNNFTHLVTTLGMALYKEGHQKNDEAMLGMHTPITMLSDQVRVLILYLIDEIVHAIHTNSNQSNDELIDGLKPKVRIVINEFHATLMMGIDKMKFYSLNELREIVNDKIN 393
                                    50        60        70   ||   84        94       104       114       124       134       144       154       164       174       184       194       204       214       224       234       244       254       264       274       284       294       304       314       324       334       344       354       364       374       384
                                                            74|
                                                             79


Chain B from PDB  Type:PROTEIN  Length:341

               SCOP domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...hhhhhhhhhhhhhhhhhh.........hhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4wic B  41 DMALQHAVDLLEKMLADEEKKLTPLFEPIKTLEEIIQEGDDVVGAHQLVVTQIKLRVQRNRRLADEIIREQLTDIRKVFSDKFEKLEQGIQNSYLLLDKLKTPFQDMRCLFEVANEQFNDTPVPPQYKEKFMVCLKQIVQYAVNSSSKLEKFVMLKIKTKKDDIKDRVTYTCMKYLLMAMQGTGGPKAINNEEHAKLFFKQLSNYDDLTDANHDGLELIKKLDKEQKEVAFHVNNFTHLVTTLGMALYKEGHQKNDEAMLGMHTPITMLSDQVRVLILYLIDEIVHAIHTNSNQSNDELIDGLKPKVRIVINEFHATLMMGIDKMKFYSLNELREIVNDKI 392
                                    50        60  ||  ||81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361       371       381       391
                                                 63| 73|
                                                  70  79


Chain C from PDB  Type:PROTEIN  Length:349

               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...hhhhhhhhhhhhhhhhhhhhh.............hhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhhhh.. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4wic C  41 DMALQHAVDLLEKMLADEEKKLTEFNLGDPLFESPIKTLEEIIQEGDDVVGAHQLVVTQIKLRVQRNRRLADEIIREQLTDIRKVFSDKFEKLEQGIQNSYLLLDKLKTPFQDMRCLFEVANEQFNDTPVPPQYKEKFMVCLKQIVQYAVNSSSKLEKFVMLKIKTKKDDIKDRVTYTCMKYLLMAMQGTGGPKAINNEEHAKLFFKQLSNYDDLTDANHDGLELIKKLDKEQKEVAFHVNNFTHLVTTLGMALYKEGHQKNDEAMLGMHTPITMLSDQVRVLILYLIDEIVHAIHTNSNQSNDELIDGLKPKVRIVINEFHATLMMGIDKMKFYSLNELREIVNDKIN 393
                                    50        60        70   ||   84        94       104       114       124       134       144       154       164       174       184       194       204       214       224       234       244       254       264       274       284       294       304       314       324       334       344       354       364       374       384
                                                            74|
                                                             79


Chain D from PDB  Type:PROTEIN  Length:340

               SCOP domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...hhhhhhhhhhhhhhhhh............hhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh......hhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh...hhhhhhhhhhhhhhhhhhhhhhhhhh.......hhhhhhhhhhh.. Sec.struct. author
                 SAPs(SNPs) ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4wic D  41 DMALQHAVDLLEKMLADEEKKLTPLFEDDPIKTLEEIIQEGDDVVGAHQLVVTQIKLRVQRNRRLADEIIREQLTDIRKVFSDKFEKLEQGIQNSYLLLDKLKTPFQDMRCLFEVANEQFNDTPVPPQYKEKFMVCLKQIVQYAVNSSSKLEKFVMLKIKTKKDDIKDRVTYTCMKYLLMAMQGTGGPKAINNEEHAKLFFKQLSNYDDLTDANHDGLELIKKLDKEQKEVAFHVNNFTHLVTTLGMALYKEGHQKNDEAMLGMHTPITMLSDQVRVLILYLIDEIVHAIHTNSNDELIDGLKPKVRIVINEFHATLMMGIDKMKFYSLNELREIVNDKI 392
                                    50        60  ||  ||79        89        99       109       119       129       139       149       159       169       179       189       199       209       219       229       239       249       259       269       279       289       299       309       319       329       339  ||   352       362       372       382       392
                                                 63| 73|                                                                                                                                                                                                                                                                      342|
                                                  70  77                                                                                                                                                                                                                                                                       346
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 4WIC)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 4WIC)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 4WIC)

(-) Gene Ontology  (2, 2)

Asymmetric Unit(hide GO term definitions)

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
(no "Ligands, Modified Residues, Ions" information available for 4wic)

  Sites
(no "Sites" information available for 4wic)

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 4wic)

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Biol. Unit 1 PNG format | Biol. Unit 2 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  4wic
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  Q2FAE9_9BETA | Q2FAE9
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/TrEMBL

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  Q2FAE9_9BETA | Q2FAE9
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/TrEMBL
        Q2FAE9_9BETA | Q2FAE9: 4wid

(-) Related Entries Specified in the PDB File

(no "Related Entries Specified in the PDB File" available for 4WIC)
