(-) Description

Title :  CRYSTAL STRUCTURE OF 4-DEOXY-L-THREO-5-HEXOSULOSE-URONATE KETOL-ISOMERASE COMPLEXED WITH A TARTRATE

Authors :  Y. Maruyama, S. Oiki, R. Takase, B. Mikami, K. Murata, W. Hashimoto
Date :  03 Aug 14  (Deposition) - 24 Dec 14  (Release) - 01 Apr 15  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  1.55
Chains :  Asym. Unit :  A,B
Biol. Unit 1:  A,B  (2x)
Keywords :  Glycosaminoglycan Metabolism, Isomerase, Rossman Fold (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  Y. Maruyama, S. Oiki, R. Takase, B. Mikami, K. Murata, W. Hashimoto
Metabolic Fate Of Unsaturated Glucuronic/Iduronic Acids Fro Glycosaminoglycans: Molecular Identification And Structure Determination Of Streptococcal Isomerase And Dehydrogenase.
J. Biol. Chem. V. 290 6281 2015
PubMed-ID: 25605731  |  Reference-DOI: 10.1074/JBC.M114.604546

(-) Compounds

Molecule 1 - PUTATIVE UNCHARACTERIZED PROTEIN GBS1892
    Chains: A, B
    Engineered: YES
    Expression System: ESCHERICHIA COLI BL21(DE3)
    Expression System Taxid: 469008
    Gene: GBS1892
    Mutation: YES
    Organism Scientific: STREPTOCOCCUS AGALACTIAE NEM316
    Organism Taxid: 211110
    Strain: NEM316

 Structural Features

(-) Chains, Units

  12
Asymmetric Unit : AB
Biological Unit 1 (2x): AB

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (1, 2)

Asymmetric Unit (1, 2)
No.NameCountTypeFull Name
1TLA2Ligand/IonL(+)-TARTARIC ACID
Biological Unit 1 (1, 4)
No.NameCountTypeFull Name
1TLA4Ligand/IonL(+)-TARTARIC ACID

(-) Sites  (2, 2)

Asymmetric Unit (2, 2)
No.NameEvidenceResiduesDescription
1AC1SOFTWAREGLU A:8 , SER A:10 , TYR A:49 , CYS A:72 , GLY A:73 , ALA A:74 , HOH A:511 , HOH A:522 , TRP B:121 , ARG B:147binding site for residue TLA A 301
2AC2SOFTWAREVAL A:105 , TRP A:121 , ARG A:147 , GLU A:151 , GLU B:8 , SER B:10 , TYR B:49 , CYS B:72 , GLY B:73 , ALA B:74 , HOH B:475 , HOH B:622binding site for residue TLA B 301

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 4U8F)

(-) Cis Peptide Bonds  (4, 4)

Asymmetric Unit
No.Residues
1Gly A:37 -Met A:38
2Tyr A:143 -Pro A:144
3Gly B:37 -Met B:38
4Tyr B:143 -Pro B:144

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 4U8F)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 4U8F)

(-) Exons   (0, 0)

(no "Exon" information available for 4U8F)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:213

               SCOP domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeee..hhhhhhhhhhhhhhhhhhhhhhh.eeee............hhhhhhhhhhhhhhh....eeeeee..hhhhhhhhh......eee..hhhhhhhhhhhh...eeeee.......hhhhhhhhhhhhhh........hhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhh...hhhhhhhhhh.hhhhhhhhhhhh.. Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4u8f A   1 MKIALINENSQASKNTIIYKELKAVSDEKGFEVFNYGMYGKEEESQLTYVQNGLLTAILLNSGAADFVITGCGAGIGAMLACNSFPGVVCGFAADPVDAYLFSQVNGGNALSLPFAKGFGWGAELNLRYLFERLFEDEKGGGYPKERAVPEQRNARILSEIKQITYRDLLSVLKEIDQDFLKETISGEHFQEYFFANCQNQNIADYLKSVLDL 213
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210


Chain B from PDB  Type:PROTEIN  Length:212

               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeee.....hhhhhhhhhhhhhhhhhhhh.eeee............hhhhhhhhhhhhhhh....eeeeee..hhhhhhhhh......eee..hhhhhhhhhhhh...eeeee.......hhhhhhhhhhhhhh...........hhhhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhh...hhhhhhhhhh.hhhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4u8f B   1 MKIALINENSQASKNTIIYKELKAVSDEKGFEVFNYGMYGKEEESQLTYVQNGLLTAILLNSGAADFVITGCGAGIGAMLACNSFPGVVCGFAADPVDAYLFSQVNGGNALSLPFAKGFGWGAELNLRYLFERLFEDEKGGGYPKERAVPEQRNARILSEIKQITYRDLLSVLKEIDQDFLKETISGEHFQEYFFANCQNQNIADYLKSVLD 212
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 4U8F)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 4U8F)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 4U8F)
