Title :   CA-LIKE DOMAIN OF MOUSE PTPRG

Authors :   S. Bouyain

Date :   19 Sep 09 (Deposition) - 22 Dec 09 (Release) - 16 Feb 10 (Revision)

Method :   X-RAY DIFFRACTION

Resolution :   1.70

Chains :   Asym. Unit : A,B,C,D
Biol. Unit 1: A  (1x)
Biol. Unit 2: B  (1x)
Biol. Unit 3: C  (1x)
Biol. Unit 4: D  (1x)

Keywords :   Ca-Like Domain, Glycoprotein, Hydrolase, Membrane, Phosphoprotein, Protein Phosphatase, Transmembrane, Cell Adhesion (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :   S. Bouyain, D. J. Watkins
The Protein Tyrosine Phosphatases Ptprz And Ptprg Bind To Distinct Members Of The Contactin Family Of Neural Recognition Molecules.
Proc. Natl. Acad. Sci. Usa V. 107 2443 2010
PubMed-ID: 20133774 | Reference-DOI: 10.1073/PNAS.0911235107

Molecule 1 - RECEPTOR-TYPE TYROSINE-PROTEIN PHOSPHATASE GAMMA
	Chains	:	A, B, C, D
	EC Number	:	3.1.3.48
	Engineered	:	YES
	Expression System	:	ESCHERICHIA COLI
	Expression System Plasmid	:	PET32
	Expression System Strain	:	ORIGAMI2(DE3)
	Expression System Taxid	:	562
	Expression System Vector Type	:	PLASMID
	Fragment	:	CARBONIC ANHYDRASE-LIKE DOMAIN (UNP RESIDUES 55- 320)
	Gene	:	PTPRG
	Organism Common	:	MOUSE
	Organism Scientific	:	MUS MUSCULUS
	Organism Taxid	:	10090
	Synonym	:	PROTEIN-TYROSINE PHOSPHATASE GAMMA, R-PTP-GAMMA

		1	2	3	4
Asymmetric Unit	:	A	B	C	D
Biological Unit 1 (1x)	:	A
Biological Unit 2 (1x)	:		B
Biological Unit 3 (1x)	:			C
Biological Unit 4 (1x)	:				D

Summary Information (see also Sequences/Alignments below)

(no "Ligand,Modified Residues,Ions" information available for 3JXG)

(no "Site" information available for 3JXG)

Asymmetric Unit

No.	Residues
1	A:78	-	A:261
2	B:78	-	B:261
3	C:78	-	C:261
4	D:78	-	D:261

Asymmetric Unit

No.	Residues
1	Ser A:84	-	Pro A:85
2	Pro A:259	-	Pro A:260
3	Ser B:84	-	Pro B:85
4	Pro B:259	-	Pro B:260
5	Ser C:84	-	Pro C:85
6	Pro C:259	-	Pro C:260
7	Ser D:84	-	Pro D:85
8	Pro D:259	-	Pro D:260

(no "SAP(SNP)/Variant" information available for 3JXG)

Asymmetric Unit (1, 4)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	ALPHA_CA_2	PS51144	Alpha-carbonic anhydrases profile.	PTPRG_MOUSE	58-321	4	A:58-320 B:58-320 C:58-320 D:58-320

Biological Unit 1 (1, 1)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	ALPHA_CA_2	PS51144	Alpha-carbonic anhydrases profile.	PTPRG_MOUSE	58-321	1	A:58-320 - - -

Biological Unit 2 (1, 1)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	ALPHA_CA_2	PS51144	Alpha-carbonic anhydrases profile.	PTPRG_MOUSE	58-321	1	- B:58-320 - -

Biological Unit 3 (1, 1)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	ALPHA_CA_2	PS51144	Alpha-carbonic anhydrases profile.	PTPRG_MOUSE	58-321	1	- - C:58-320 -

Biological Unit 4 (1, 1)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	ALPHA_CA_2	PS51144	Alpha-carbonic anhydrases profile.	PTPRG_MOUSE	58-321	1	- - - D:58-320

(no "Exon" information available for 3JXG)

Asymmetric Unit

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain A from PDB  Type:PROTEIN  Length:257
 aligned with PTPRG_MOUSE | Q05909 from UniProtKB/Swiss-Prot  Length:1442

    Alignment length:263
                                    67        77        87        97       107       117       127       137       147       157       167       177       187       197       207       217       227       237       247       257       267       277       287       297       307       317
          PTPRG_MOUSE    58 PYWAYSGAYGPEHWVTSSVSCGGSHQSPIDILDHHARVGDEYQELQLDGFDNESSNKTWMKNTGKTVAILLKDDYFVSGAGLPGRFKAEKVEFHWGHSNGSAGSEHSVNGRRFPVEMQIFFYNPDDFDSFQTAISENRIIGAMAIFFQVSPRDNSALDPIIHGLKGVVHHEKETFLDPFILRDLLPASLGSYYRYTGSLTTPPCSEIVEWIVFRRPVPISYHQLEAFYSIFTTEQQDHVKSVEYLRNNFRPQQALNDRVVSKS 320
               SCOP domains d3jxga_ A: automated matches                                                                                                                                                                                                                                            SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .....hhhhhhhhhhhhhhhhhh......eehhhhhee.......eee..........eeee....eeee.....eee.......eeeeeeeeee...........ee......eeeeeeee......hhhhhhhh...eeeeeeeeee....hhhhhhhhhhhhh......eee....hhhhhh......eeeeee..........eeeeee...eeehhhhhhhhhh.ee..------..ee................ee. Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ALPHA_CA_2  PDB: A:58-320 UniProt: 58-321                                                                                                                                                                                                                               PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3jxg A  58 PYWAYSGAYGPEHWVTSSVSCGGSHQSPIDILDHHARVGDEYQELQLDGFDNESSNKTWMKNTGKTVAILLKDDYFVSGAGLPGRFKAEKVEFHWGHSNGSAGSEHSVNGRRFPVEMQIFFYNPDDFDSFQTAISENRIIGAMAIFFQVSPRDNSALDPIIHGLKGVVHHEKETFLDPFILRDLLPASLGSYYRYTGSLTTPPCSEIVEWIVFRRPVPISYHQLEAFYSIFTTE------SVEYLRNNFRPQQALNDRVVSKS 320
                                    67        77        87        97       107       117       127       137       147       157       167       177       187       197       207       217       227       237       247       257       267       277       287   |     -|      307       317
                                                                                                                                                                                                                                                                   291    298

Chain B from PDB  Type:PROTEIN  Length:259
 aligned with PTPRG_MOUSE | Q05909 from UniProtKB/Swiss-Prot  Length:1442

    Alignment length:263
                                    67        77        87        97       107       117       127       137       147       157       167       177       187       197       207       217       227       237       247       257       267       277       287       297       307       317
          PTPRG_MOUSE    58 PYWAYSGAYGPEHWVTSSVSCGGSHQSPIDILDHHARVGDEYQELQLDGFDNESSNKTWMKNTGKTVAILLKDDYFVSGAGLPGRFKAEKVEFHWGHSNGSAGSEHSVNGRRFPVEMQIFFYNPDDFDSFQTAISENRIIGAMAIFFQVSPRDNSALDPIIHGLKGVVHHEKETFLDPFILRDLLPASLGSYYRYTGSLTTPPCSEIVEWIVFRRPVPISYHQLEAFYSIFTTEQQDHVKSVEYLRNNFRPQQALNDRVVSKS 320
               SCOP domains d3jxgb_ B: automated matches                                                                                                                                                                                                                                            SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .....hhhhhhhhhhhhhhhhhh......eehhhhhee.......eee..........eeee....eeee.....eee.......eeeeeeeeee...........ee......eeeeeeee......hhhhhhhhh..eeeeeeeeeee...hhhhhhhhhhhhh......eee....hhhhhh......eeeeee..........eeeeee...eeeehhhhhhhh..eeee.----.eeee................ee. Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ALPHA_CA_2  PDB: B:58-320 UniProt: 58-321                                                                                                                                                                                                                               PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3jxg B  58 PYWAYSGAYGPEHWVTSSVSCGGSHQSPIDILDHHARVGDEYQELQLDGFDNESSNKTWMKNTGKTVAILLKDDYFVSGAGLPGRFKAEKVEFHWGHSNGSAGSEHSVNGRRFPVEMQIFFYNPDDFDSFQTAISENRIIGAMAIFFQVSPRDNSALDPIIHGLKGVVHHEKETFLDPFILRDLLPASLGSYYRYTGSLTTPPCSEIVEWIVFRRPVPISYHQLEAFYSIFTTEQ----KSVEYLRNNFRPQQALNDRVVSKS 320
                                    67        77        87        97       107       117       127       137       147       157       167       177       187       197       207       217       227       237       247       257       267       277       287    |  297       307       317
                                                                                                                                                                                                                                                                    292  297

Chain C from PDB  Type:PROTEIN  Length:264
 aligned with PTPRG_MOUSE | Q05909 from UniProtKB/Swiss-Prot  Length:1442

    Alignment length:264
                                    66        76        86        96       106       116       126       136       146       156       166       176       186       196       206       216       226       236       246       256       266       276       286       296       306       316
          PTPRG_MOUSE    57 DPYWAYSGAYGPEHWVTSSVSCGGSHQSPIDILDHHARVGDEYQELQLDGFDNESSNKTWMKNTGKTVAILLKDDYFVSGAGLPGRFKAEKVEFHWGHSNGSAGSEHSVNGRRFPVEMQIFFYNPDDFDSFQTAISENRIIGAMAIFFQVSPRDNSALDPIIHGLKGVVHHEKETFLDPFILRDLLPASLGSYYRYTGSLTTPPCSEIVEWIVFRRPVPISYHQLEAFYSIFTTEQQDHVKSVEYLRNNFRPQQALNDRVVSKS 320
               SCOP domains d3jxgc_ C: automated matches                                                                                                                                                                                                                                             SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author ......hhhhhhhhhhhhhhhhhh......eehhhhh.........eee..........eeee....eeee.....eee.......eeeeeeeeee...........ee......eeeeeeee......hhhhhhhh...eeeeeeeeeee...hhhhhhhhhhhhh......eee....hhhhhh......eeeeee..........eeeeee...eeeehhhhhhhhh.eeeeee..eeeeee................ee. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE -ALPHA_CA_2  PDB: C:58-320 UniProt: 58-321                                                                                                                                                                                                                               PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Transcript
                 3jxg C  57 DPYWAYSGAYGPEHWVTSSVSCGGSHQSPIDILDHHARVGDEYQELQLDGFDNESSNKTWMKNTGKTVAILLKDDYFVSGAGLPGRFKAEKVEFHWGHSNGSAGSEHSVNGRRFPVEMQIFFYNPDDFDSFQTAISENRIIGAMAIFFQVSPRDNSALDPIIHGLKGVVHHEKETFLDPFILRDLLPASLGSYYRYTGSLTTPPCSEIVEWIVFRRPVPISYHQLEAFYSIFTTEQQDHVKSVEYLRNNFRPQQALNDRVVSKS 320
                                    66        76        86        96       106       116       126       136       146       156       166       176       186       196       206       216       226       236       246       256       266       276       286       296       306       316

Chain D from PDB  Type:PROTEIN  Length:259
 aligned with PTPRG_MOUSE | Q05909 from UniProtKB/Swiss-Prot  Length:1442

    Alignment length:263
                                    67        77        87        97       107       117       127       137       147       157       167       177       187       197       207       217       227       237       247       257       267       277       287       297       307       317
          PTPRG_MOUSE    58 PYWAYSGAYGPEHWVTSSVSCGGSHQSPIDILDHHARVGDEYQELQLDGFDNESSNKTWMKNTGKTVAILLKDDYFVSGAGLPGRFKAEKVEFHWGHSNGSAGSEHSVNGRRFPVEMQIFFYNPDDFDSFQTAISENRIIGAMAIFFQVSPRDNSALDPIIHGLKGVVHHEKETFLDPFILRDLLPASLGSYYRYTGSLTTPPCSEIVEWIVFRRPVPISYHQLEAFYSIFTTEQQDHVKSVEYLRNNFRPQQALNDRVVSKS 320
               SCOP domains d3jxgd_ D: automated matches                                                                                                                                                                                                                                            SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
           Pfam domains (1) --Carb_anhydrase-3jxgD01 D:60-320                                                                                                                                                                                                                                       Pfam domains (1)
           Pfam domains (2) --Carb_anhydrase-3jxgD02 D:60-320                                                                                                                                                                                                                                       Pfam domains (2)
           Pfam domains (3) --Carb_anhydrase-3jxgD03 D:60-320                                                                                                                                                                                                                                       Pfam domains (3)
           Pfam domains (4) --Carb_anhydrase-3jxgD04 D:60-320                                                                                                                                                                                                                                       Pfam domains (4)
         Sec.struct. author .....hhhhhhhhhhhhhhhhhh......eehhhhhee.......eee..........eeee....eeee.....eee.......eeeeeeeeee...........ee......eeeeeeee..---.hhhhhhhh...eeeeeeeeeee...hhhhhhhhhhhhhh.....eee....hhhhhh......eeeeee..........eeeeee...eeeehhhhhhhhh.eeeee.-..eeeee................ee. Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ALPHA_CA_2  PDB: D:58-320 UniProt: 58-321                                                                                                                                                                                                                               PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 3jxg D  58 PYWAYSGAYGPEHWVTSSVSCGGSHQSPIDILDHHARVGDEYQELQLDGFDNESSNKTWMKNTGKTVAILLKDDYFVSGAGLPGRFKAEKVEFHWGHSNGSAGSEHSVNGRRFPVEMQIFFYNP---DSFQTAISENRIIGAMAIFFQVSPRDNSALDPIIHGLKGVVHHEKETFLDPFILRDLLPASLGSYYRYTGSLTTPPCSEIVEWIVFRRPVPISYHQLEAFYSIFTTEQQ-HVKSVEYLRNNFRPQQALNDRVVSKS 320
                                    67        77        87        97       107       117       127       137       147       157       167       177   |   187       197       207       217       227       237       247       257       267       277       287     | 297       307       317
                                                                                                                                                     181 185                                                                                                         293 |
                                                                                                                                                                                                                                                                       295

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Asymmetric Unit

Classes(

)

Folds(

)

Superfamilies( (-)

)

Families(

)

Protein Domains( (-)

)

Organisms( (-)

)

Class: All beta proteins (24004)

Fold: Carbonic anhydrase (525)

Superfamily: Carbonic anhydrase (525)

Family: automated matches (12)

Protein domain: automated matches (12)

Mouse (Mus musculus) [TaxId: 10090] (2)

1a	d3jxga_	A:
1b	d3jxgb_	B:
1c	d3jxgc_	C:
1d	d3jxgd_	D:

(no "CATH Domain" information available for 3JXG)

Asymmetric Unit

Clans(

)

Families(

)

Organisms( (-)

)

Clan: no clan defined [family: Carb_anhydrase] (168)

Family: Carb_anhydrase (168)

Mus musculus (Mouse) (6)

1a	Carb_anhydrase-3jxgD01	D:60-320
1b	Carb_anhydrase-3jxgD02	D:60-320
1c	Carb_anhydrase-3jxgD03	D:60-320
1d	Carb_anhydrase-3jxgD04	D:60-320

Asymmetric Unit(hide GO term definitions)

Chain A,B,C,D (PTPRG_MOUSE | Q05909)

molecular function
	GO:0016787	hydrolase activity	Catalysis of the hydrolysis of various bonds, e.g. C-O, C-N, C-C, phosphoric anhydride bonds, etc. Hydrolase is the systematic name for any enzyme of EC class 3.
	GO:0042802	identical protein binding	Interacting selectively and non-covalently with an identical protein or proteins.
	GO:0016791	phosphatase activity	Catalysis of the hydrolysis of phosphoric monoesters, releasing inorganic phosphate.
	GO:0004721	phosphoprotein phosphatase activity	Catalysis of the reaction: a phosphoprotein + H2O = a protein + phosphate. Together with protein kinases, these enzymes control the state of phosphorylation of cell proteins and thereby provide an important mechanism for regulating cellular activity.
	GO:0004725	protein tyrosine phosphatase activity	Catalysis of the reaction: protein tyrosine phosphate + H2O = protein tyrosine + phosphate.
biological process
	GO:0016311	dephosphorylation	The process of removing one or more phosphoric (ester or anhydride) residues from a molecule.
	GO:0010633	negative regulation of epithelial cell migration	Any process that stops, prevents, or reduces the frequency, rate or extent of epithelial cell migration.
	GO:0035335	peptidyl-tyrosine dephosphorylation	The removal of phosphoric residues from peptidyl-O-phospho-tyrosine to form peptidyl-tyrosine.
	GO:0006470	protein dephosphorylation	The process of removing one or more phosphoric residues from a protein.
	GO:1901998	toxin transport	The directed movement of a toxin into, out of or within a cell, or between cells, by means of some agent such as a transporter or pore.
cellular component
	GO:0070062	extracellular exosome	A vesicle that is released into the extracellular region by fusion of the limiting endosomal membrane of a multivesicular body with the plasma membrane. Extracellular exosomes, also simply called exosomes, have a diameter of about 40-100 nm.
	GO:0016021	integral component of membrane	The component of a membrane consisting of the gene products and protein complexes having at least some part of their peptide sequence embedded in the hydrophobic region of the membrane.
	GO:0016020	membrane	A lipid bilayer along with all the proteins and protein complexes embedded in it an attached to it.

Asymmetric Unit
	Complete Structure
		Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
		WebMol \| AstexViewer[tm]@PDBe (Java Applets, require no local installation except for Java; loading may be slow)
		STRAP (Java WebStart application, automatic local installation, requires Java; full application with system access!)
		RasMol (require local installation)
		Molscript (VRML) (requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

	Ligands, Modified Residues, Ions
(no "Ligands, Modified Residues, Ions" information available for 3jxg)

	Sites
(no "Sites" information available for 3jxg)

	Cis Peptide Bonds
		Pro A:259 - Pro A:260	[ RasMol ]
		Pro B:259 - Pro B:260	[ RasMol ]
		Pro C:259 - Pro C:260	[ RasMol ]
		Pro D:259 - Pro D:260	[ RasMol ]
		Ser A:84 - Pro A:85	[ RasMol ]
		Ser B:84 - Pro B:85	[ RasMol ]
		Ser C:84 - Pro C:85	[ RasMol ]
		Ser D:84 - Pro D:85	[ RasMol ]

Biological Units
	Complete Structure
		Biological Unit 1	[ Jena3D ]
		Biological Unit 2	[ Jena3D ]
		Biological Unit 3	[ Jena3D ]
		Biological Unit 4	[ Jena3D ]

Jmol
	protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick [ Asym. Unit PNG format \| Biol. Unit 1 PNG format \| Biol. Unit 2 PNG format \| Biol. Unit 3 PNG format \| Biol. Unit 4 PNG format ](automatic orientation, automatically generated)
Molscript
	protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick [ mono PDF format \| stereo PDF format ](default orientation, automatically generated)

Access by PDB/NDB ID
	3jxg
		Family and Domain Information	:	ProDom \| SYSTERS
		General Structural Information	:	GlycoscienceDB \| MMDB \| NDB \| OCA \| PDB \| PDBe \| PDBj \| PDBsum \| PDBWiki \| PQS \| PROTEOPEDIA
		Orientation in Membranes	:	OPM
		Protein Surface	:	SURFACE
		Secondary Structure	:	DSSP (structure derived) \| HSSP (homology derived)
		Structural Genomics	:	GeneCensus
		Structural Neighbours	:	CE \| VAST
		Structure Classification	:	CATH \| Dali \| SCOP
		Validation and Original Data	:	BMRB Data View \| BMRB Restraints Grid \| EDS \| PROCHECK \| RECOORD \| WHAT_CHECK

Access by UniProt ID/Accession number
	PTPRG_MOUSE \| Q05909
		Comparative Protein Structure Models	:	ModBase
		Genomic Information	:	Ensembl
		Protein-protein Interaction	:	DIP
		Sequence, Family and Domain Information	:	InterPro \| Pfam \| SMART \| UniProtKB/SwissProt

Access by Enzyme Classificator (EC Number)
	3.1.3.48
		General Enzyme Information	:	BRENDA \| EC-PDB \| Enzyme \| IntEnz
		Pathway	:	KEGG \| MetaCyc

Access by Disease Identifier (MIM ID)
	(no 'MIM ID' available)
		Disease Information	:	OMIM

Access by GenAge ID
	(no 'GenAge ID' available)
		Age Related Information	:	GenAge

Access by PDB/NDB ID
		Domain Information	:	XDom
		Interatomic Contacts of Structural Units	:	CSU
		Ligand-protein Contacts	:	LPC
		Protein Cavities	:	castP
		Sequence and Secondary Structure	:	PDBCartoon
		Structure Alignment	:	STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
		Structure and Sequence Browser	:	STING

Access by UniProt ID/Accession number
	PTPRG_MOUSE \| Q05909
		Protein Disorder Prediction	:	DisEMBL \| FoldIndex \| GLOBPLOT (for more information see DisProt)

UniProtKB/Swiss-Prot
	PTPRG_MOUSE \| Q05909	:	3kld 5e5u

Description

Compounds

Structural Features

Chains, Units

Ligands, Modified Residues, Ions (0, 0)

Sites (0, 0)

SS Bonds (4, 4)

Cis Peptide Bonds (8, 8)

Sequence-Structure Mapping

SAPs(SNPs)/Variants (0, 0)

PROSITE Motifs (1, 4)

Exons (0, 0)

Sequences/Alignments

Classification and Annotation

SCOP Domains (1, 4)

CATH Domains (0, 0)

Pfam Domains (1, 4)

Gene Ontology (13, 13)

Visualization

Interactive Views

Still Images

Databases and Analysis Tools

Databases

Analysis Tools

Related Entries

Entries Sharing at Least One Protein Chain (UniProt ID)

Related Entries Specified in the PDB File
