(-) Description

Title :  CRYSTAL STRUCTURE OF PCRH IN COMPLEX WITH THE CHAPERONE BINDING REGION OF POPD

Authors :  V. Job, P. -J. Mattei, D. Lemaire, I. Attree, A. Dessen
Date :  22 Apr 10  (Deposition) - 05 May 10  (Release) - 03 Oct 12  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  1.85
Chains :  Asym. Unit :  A,B,C
Biol. Unit 1:  A (1x),B (1x),C (1x)
Biol. Unit 2:  A,B,C  (1x)
Keywords :  Protein Transport, Bacterial Toxin, Type Iii Secretion, Protein Binding (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  V. Job, P. -J. Mattei, D. Lemaire, I. Attree, A. Dessen
Structural Basis Of Chaperone Recognition Of Type Iii Secretion System Minor Translocator Proteins.
J. Biol. Chem. V. 285 23224 2010
PubMed-ID: 20385547  |  Reference-DOI: 10.1074/JBC.M110.111278

(-) Compounds

Molecule 1 - REGULATORY PROTEIN PCRH
    Chains: A, B
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Plasmid: PET DUET 1
    Expression System Strain: BL21(DE3)
    Expression System Taxid: 469008
    Fragment: RESIDUES 21-160
    Organism Scientific: PSEUDOMONAS AERUGINOSA
    Organism Taxid: 287
    Strain: CHA
    Synonym: PCRH

Molecule 2 - PEPD
    Chains: C
    Fragment: CHAPERONE BINDING DOMAIN, RESIDUES 47-56
    Organism Scientific: PSEUDOMONAS AERUGINOSA
    Organism Taxid: 287
    Strain: CHA
    Synonym: POPD
    Synthetic: YES

 Structural Features

(-) Chains, Units

  123
Asymmetric Unit : ABC
Biological Unit 1 (1x): A (1x)B (1x)C (1x)
Biological Unit 2 (1x): ABC

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (1, 1)

Asymmetric Unit (1, 1)
No.NameCountTypeFull Name
1NO31Ligand/IonNITRATE ION
Biological Unit 1 (0, 0)
No.NameCountTypeFull Name
1NO3-1Ligand/IonNITRATE ION
Biological Unit 2 (1, 1)
No.NameCountTypeFull Name
1NO31Ligand/IonNITRATE ION

(-) Sites  (1, 1)

Asymmetric Unit (1, 1)
No.NameEvidenceResiduesDescription
1AC1SOFTWAREHIS A:67 , TYR A:68 , GLN B:60 , CYS B:63 , MET B:64 , PHE B:73 , LEU B:76 , HOH B:2035 , HOH B:2036BINDING SITE FOR RESIDUE NO3 B1157

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 2XCB)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 2XCB)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 2XCB)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 2XCB)

(-) Exons   (0, 0)

(no "Exon" information available for 2XCB)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:133
 aligned with Q9I325_PSEAE | Q9I325 from UniProtKB/TrEMBL  Length:167

    Alignment length:133
                                    36        46        56        66        76        86        96       106       116       126       136       146       156
         Q9I325_PSEAE    27 MLRGLSEDTLEQLYALGFNQYQAGKWDDAQKIFQALCMLDHYDARYFLGLGACRQSLGLYEQALQSYSYGALMDINEPRFPFHAAECHLQLGDLDGAESGFYSARALAAAQPAHEALAARAGAMLEAVTARKD 159
               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .....hhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhh...hhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2xcb A  27 MLRGLSEDTLEQLYALGFNQYQAGKWDDAQKIFQALCMLDHYDARYFLGLGACRQSLGLYEQALQSYSYGALMDINEPRFPFHAAECHLQLGDLDGAESGFYSARALAAAQPAHEALAARAGAMLEAVTARKD 159
                                    36        46        56        66        76        86        96       106       116       126       136       146       156


Chain B from PDB  Type:PROTEIN  Length:132
 aligned with Q9I325_PSEAE | Q9I325 from UniProtKB/TrEMBL  Length:167

    Alignment length:132
                                    34        44        54        64        74        84        94       104       114       124       134       144       154
         Q9I325_PSEAE    25 LAMLRGLSEDTLEQLYALGFNQYQAGKWDDAQKIFQALCMLDHYDARYFLGLGACRQSLGLYEQALQSYSYGALMDINEPRFPFHAAECHLQLGDLDGAESGFYSARALAAAQPAHEALAARAGAMLEAVTA 156
               SCOP domains ------------------------------------------------------------------------------------------------------------------------------------ SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------ CATH domains
           Pfam domains (1) ---------TPR_11-2xcbB01 B:34-100                                            -------------------------------------------------------- Pfam domains (1)
           Pfam domains (2) ---------TPR_11-2xcbB02 B:34-100                                            -------------------------------------------------------- Pfam domains (2)
         Sec.struct. author .......hhhhhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhh..hhhhhhhhhhhhhhh.hhhhhhhhhhhhhhhh...hhhhhhhhhhhhhh.hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------ Transcript
                 2xcb B  25 LAMLRGLSEDTLEQLYALGFNQYQAGKWDDAQKIFQALCMLDHYDARYFLGLGACRQSLGLYEQALQSYSYGALMDINEPRFPFHAAECHLQLGDLDGAESGFYSARALAAAQPAHEALAARAGAMLEAVTA 156
                                    34        44        54        64        74        84        94       104       114       124       134       144       154


Chain C from PDB  Type:PROTEIN  Length:8
 aligned with O50280_PSEAI | O50280 from UniProtKB/TrEMBL  Length:295

    Alignment length:8
         O50280_PSEAI    48 RVELNAPR  55
               SCOP domains -------- SCOP domains
               CATH domains -------- CATH domains
               Pfam domains -------- Pfam domains
         Sec.struct. author ........ Sec.struct. author
                 SAPs(SNPs) -------- SAPs(SNPs)
                    PROSITE -------- PROSITE
                 Transcript -------- Transcript
                 2xcb C  48 RVELNAPR  55
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 2XCB)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 2XCB)

(-) Pfam Domains  (1, 2)

Asymmetric Unit
(-)
Clan: TPR (230)

(-) Gene Ontology  (3, 3)

Asymmetric Unit(hide GO term definitions)
Chain A,B   (Q9I325_PSEAE | Q9I325)
biological process
    GO:0051131    chaperone-mediated protein complex assembly    The aggregation, arrangement and bonding together of a set of components to form a protein complex, mediated by chaperone molecules that do not form part of the finished complex.
    GO:0030254    protein secretion by the type III secretion system    The process in which proteins are transferred into the extracellular milieu or directly into host cells by the bacterial type III secretion system; secretion occurs in a continuous process without the distinct presence of periplasmic intermediates and does not involve proteolytic processing of secreted proteins.
    GO:0006950    response to stress    Any process that results in a change in state or activity of a cell or an organism (in terms of movement, secretion, enzyme production, gene expression, etc.) as a result of a disturbance in organismal or cellular homeostasis, usually, but not necessarily, exogenous (e.g. temperature, humidity, ionizing radiation).

Chain C   (O50280_PSEAI | O50280)

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    NO3  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 2xcb)

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Asym. Unit - sites PNG format | Biol. Unit 1 PNG format | Biol. Unit 1 - sites PNG format | Biol. Unit 2 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  2xcb
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  O50280_PSEAI | O50280
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/TrEMBL
  Q9I325_PSEAE | Q9I325
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/TrEMBL

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  O50280_PSEAI | O50280
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)
  Q9I325_PSEAE | Q9I325
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/TrEMBL
        Q9I325_PSEAE | Q9I325: 2xcc

(-) Related Entries Specified in the PDB File

2xcc CRYSTAL STRUCTURE OF PCRH FROM PSEUDOMONAS AERUGINOSA
