(-) Description

Title :  NMR SOLUTION STRUCTURE OF TM0212 AT 40 C

Authors :  B. Pedrini, T. Herrmann, B. Mohanty, M. Geralt, I. Wilson, K. Wuthrich, Center For Structural Genomics (Jcsg)
Date :  31 Oct 08  (Deposition) - 13 Jan 09  (Release) - 09 Jan 13  (Revision)
Method :  SOLUTION NMR
Resolution :  NOT APPLICABLE
Chains :  NMR Structure  :  A  (20x)
NMR Structure *:  A  (1x)
Keywords :  Protein, Lipoyl, Structural Genomics, Psi-2, Protein Structure Initiative, Joint Center For Structural Genomics, Jcsg, Unknown Function (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  P. Serrano, B. Pedrini, B. Mohanty, M. Geralt, T. Herrmann, K. Wuthric
The J-Unio Protocol For Automated Protein Structure Determination By Nmr In Solution.
J. Biomol. Nmr V. 53 341 2012
PubMed-ID: 22752932  |  Reference-DOI: 10.1007/S10858-012-9645-2

(-) Compounds

Molecule 1 - GLYCINE CLEAVAGE SYSTEM H PROTEIN
    Chains: A
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Plasmid: PET 25B
    Expression System Taxid: 562
    Expression System Vector Type: PLASMID
    Gene: GCVH, TM_0212
    Organism Scientific: THERMOTOGA MARITIMA
    Organism Taxid: 2336

 Structural Features

(-) Chains, Units

  1
NMR Structure (20x): A
NMR Structure * (1x): A

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (0, 0)

(no "Ligand,Modified Residues,Ions" information available for 2KA7)

(-) Sites  (0, 0)

(no "Site" information available for 2KA7)

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 2KA7)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 2KA7)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 2KA7)

(-) PROSITE Motifs  (2, 2)

NMR Structure (2, 2)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1BIOTINYL_LIPOYLPS50968 Biotinyl/lipoyl domain profile.GCSH_THEMA19-101  1A:19-101
2LIPOYLPS00189 2-oxo acid dehydrogenases acyltransferase component lipoyl binding site.GCSH_THEMA44-73  1A:44-73
NMR Structure * (2, 2)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1BIOTINYL_LIPOYLPS50968 Biotinyl/lipoyl domain profile.GCSH_THEMA19-101  1A:19-101
2LIPOYLPS00189 2-oxo acid dehydrogenases acyltransferase component lipoyl binding site.GCSH_THEMA44-73  1A:44-73

(-) Exons   (0, 0)

(no "Exon" information available for 2KA7)

(-) Sequences/Alignments

NMR Structure
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:124
 aligned with GCSH_THEMA | Q9WY55 from UniProtKB/Swiss-Prot  Length:124

    Alignment length:124
                                    10        20        30        40        50        60        70        80        90       100       110       120
           GCSH_THEMA     1 MKMKKYTKTHEWVSIEDKVATVGITNHAQEQLGDVVYVDLPEVGREVKKGEVVASIESVKAAADVYAPLSGKIVEVNEKLDTEPELINKDPEGEGWLFKMEISDEGELEDLLDEQAYQEFCAQE 124
               SCOP domains ---------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains 2ka7A00 A:1-124  [code=2.40.50.100, no name defined]                                                                         CATH domains
               Pfam domains ---GCV_H-2ka7A01 A:4-124                                                                                                     Pfam domains
         Sec.struct. author ..........ee......eeeeeehhhhhhhhh............ee........eee..eee.......eeeeee.hhhhhh.hhhhhh.....eeeeeee.hhhhhhhh.hhhhhhhhhh.. Sec.struct. author
                 SAPs(SNPs) ---------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                PROSITE (1) ------------------BIOTINYL_LIPOYL  PDB: A:19-101 UniProt: 19-101                                     ----------------------- PROSITE (1)
                PROSITE (2) -------------------------------------------LIPOYL  PDB: A:44-73          --------------------------------------------------- PROSITE (2)
                 Transcript ---------------------------------------------------------------------------------------------------------------------------- Transcript
                 2ka7 A   1 MKMKKYTKTHEWVSIEDKVATVGITNHAQEQLGDVVYVDLPEVGREVKKGEVVASIESVKAAADVYAPLSGKIVEVNEKLDTEPELINKDPEGEGWLFKMEISDEGELEDLLDEQAYQEFCAQE 124
                                    10        20        30        40        50        60        70        80        90       100       110       120
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 2KA7)

(-) CATH Domains  (1, 1)

NMR Structure
(-)
Class: Mainly Beta (13760)

(-) Pfam Domains  (1, 1)

NMR Structure
(-)
Clan: Hybrid (58)

(-) Gene Ontology  (2, 2)

NMR Structure(hide GO term definitions)
Chain A   (GCSH_THEMA | Q9WY55)
biological process
    GO:0019464    glycine decarboxylation via glycine cleavage system    The chemical reactions and pathways resulting in the breakdown of glycine by oxidative cleavage to carbon dioxide, ammonia, and a methylene group, mediated by enzymes of the glycine cleavage complex.
cellular component
    GO:0005960    glycine cleavage complex    A protein complex that catalyzes the reversible oxidation of glycine. In E. coli, it has four components: dihydrolipoamide dehydrogenase, glycine dehydrogenase (decarboxylating), lipoyl-GcvH-protein and aminomethyltransferase, also known as L, P, H, and T.

 Visualization

(-) Interactive Views

NMR Structure
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
(no "Ligands, Modified Residues, Ions" information available for 2ka7)

  Sites
(no "Sites" information available for 2ka7)

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 2ka7)


(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ NMR Structure - model 1 PNG format | NMR Structure - all models PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  2ka7
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  GCSH_THEMA | Q9WY55
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/SwissProt

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  GCSH_THEMA | Q9WY55
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/Swiss-Prot
        GCSH_THEMA | Q9WY55: 1zko

(-) Related Entries Specified in the PDB File

1zko X-RAY STRUCTURE RELATED ID: 16016 RELATED DB: BMRB RELATED ID: 282092 RELATED DB: TARGETDB
