(-) Description

Title :  STRUCTURE OF A. AEOLICUS PILT WITH 6 MONOMERS PER ASYMMETRIC UNIT

Authors :  K. T. Forest, K. A. Satyshur
Date :  27 Apr 06  (Deposition) - 20 Mar 07  (Release) - 24 Feb 09  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  4.20
Chains :  Asym./Biol. Unit :  A,B,C,D,E,F
Keywords :  P-Loop, Domain Motion, Atpase, Pas, Reca, Protein Transport (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  K. A. Satyshur, G. A. Worzalla, L. S. Meyer, E. K. Heiniger, K. G. Aukema, A. M. Misic, K. T. Forest
Crystal Structures Of The Pilus Retraction Motor Pilt Suggest Large Domain Movements And Subunit Cooperation Drive Motility.
Structure V. 15 363 2007
PubMed-ID: 17355871  |  Reference-DOI: 10.1016/J.STR.2007.01.018
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - TWITCHING MOTILITY PROTEIN PILT
    Chains: A, B, C, D, E, F
    Engineered: YES
    Expression System: ESCHERICHIA COLI BL21(DE3)
    Expression System Plasmid: PET23A+
    Expression System Strain: BL21DE3
    Expression System Taxid: 469008
    Expression System Vector Type: PLASMID
    Gene: PILT
    Organism Scientific: AQUIFEX AEOLICUS
    Organism Taxid: 63363

 Structural Features

(-) Chains, Units

  123456
Asymmetric/Biological Unit : ABCDEF

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (3, 58)

Asymmetric/Biological Unit (3, 58)
No.NameCountTypeFull Name
1ADP1Ligand/IonADENOSINE-5'-DIPHOSPHATE
2MSE54Mod. Amino AcidSELENOMETHIONINE
3SO43Ligand/IonSULFATE ION

(-) Sites  (4, 4)

Asymmetric Unit (4, 4)
No.NameEvidenceResiduesDescription
1AC1SOFTWARETHR B:145 , GLY B:146 , SER B:147 , GLY B:148 , LYS B:149 , SER B:150BINDING SITE FOR RESIDUE SO4 B 375
2AC2SOFTWARETHR C:145 , GLY C:146 , SER C:147 , GLY C:148 , LYS C:149 , SER C:150BINDING SITE FOR RESIDUE SO4 C 375
3AC3SOFTWAREGLY E:146 , SER E:147 , GLY E:148 , LYS E:149 , SER E:150 , THR E:151BINDING SITE FOR RESIDUE SO4 E 375
4AC4SOFTWAREGLY F:146 , SER F:147 , GLY F:148 , LYS F:149 , SER F:150 , THR F:151 , GLU F:176 , LEU F:281 , ARG F:289BINDING SITE FOR RESIDUE ADP F 500

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 2GSZ)

(-) Cis Peptide Bonds  (6, 6)

Asymmetric/Biological Unit
No.Residues
1Asp A:173 -Pro A:174
2Asp B:173 -Pro B:174
3Asp C:173 -Pro C:174
4Asp D:173 -Pro D:174
5Asp E:173 -Pro E:174
6Asp F:173 -Pro F:174

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 2GSZ)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 2GSZ)

(-) Exons   (0, 0)

(no "Exon" information available for 2GSZ)

(-) Sequences/Alignments

Asymmetric/Biological Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:343
 aligned with O66950_AQUAE | O66950 from UniProtKB/TrEMBL  Length:366

    Alignment length:350
                                    21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361
         O66950_AQUAE    12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVMSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKMGLILVTGPTGSGKSTTIASMIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEMRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLMQSGQAETGMQTMNQTLYKLYKQGLITLEDAMEASPDPKELERM 361
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..hhhhhhhhhhhh...eee.......eeee..eeee..........hhhhhhhh..hhhhhhhhhhh.....eee.....eee...ee....ee.eeeee.....hhhhhh.hhhhhhhhhh..eeee.......hhhhhhhhhhhhhhhhh..eeeeee............eeeeee......hhhhhhhhhh.....eeee....hhhhhhhhhhhhh...eeee.....hhhhhhhhhhhhh...hhhhhhhhhhhheeeeeeeeee.......eeeeeee..hhhhhhhhhh..hhhhhhh..-------....hhhhhhhhh.......hhhhhh......... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2gsz A  12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVmSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKmGLILVTGPTGSGKSTTIASmIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEmRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLmQ-------mQTmNQTLYKLYKQGLITLEDAmEASPDPKELERm 361
                                    21        31        41        51        61      | 71        81        91       101       111       121       131    |  141       151    |  161       171       181       191       201       211      |221       231       241       251       261       271       281       291       301       311      || -     | 331       341       351       361
                                                                                   68-MSE                                                             136-MSE             156-MSE                                                       218-MSE                                                                                             318-MSE  327-MSE               349-MSE     361-MSE
                                                                                                                                                                                                                                                                                                                                             319        330-MSE


Chain B from PDB  Type:PROTEIN  Length:343
 aligned with O66950_AQUAE | O66950 from UniProtKB/TrEMBL  Length:366

    Alignment length:350
                                    21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361
         O66950_AQUAE    12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVMSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKMGLILVTGPTGSGKSTTIASMIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEMRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLMQSGQAETGMQTMNQTLYKLYKQGLITLEDAMEASPDPKELERM 361
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..hhhhhhhhhhhh...eee.......eeee..eeee..........hhhhhhhh..hhhhhhhhhhh....eeee.....eeee...........eeeee.....hhhhhh.hhhhhhhhhh..eeee.......hhhhhhhhhhhhhhhhh..eeeeee............eeeeee......hhhhhhhhhh.....eeee....hhhhhhhhhhhhh...eeee.....hhhhhhhhhhhhh....hhhhhhhhhhheeeeeeeeee.......eeeeeee..hhhhhhhhhh..hhhhhhh..-------....hhhhhhhhh.......hhhhhh......... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2gsz B  12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVmSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKmGLILVTGPTGSGKSTTIASmIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEmRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLmQ-------mQTmNQTLYKLYKQGLITLEDAmEASPDPKELERm 361
                                    21        31        41        51        61      | 71        81        91       101       111       121       131    |  141       151    |  161       171       181       191       201       211      |221       231       241       251       261       271       281       291       301       311      || -     | 331       341       351       361
                                                                                   68-MSE                                                             136-MSE             156-MSE                                                       218-MSE                                                                                             318-MSE  327-MSE               349-MSE     361-MSE
                                                                                                                                                                                                                                                                                                                                             319        330-MSE


Chain C from PDB  Type:PROTEIN  Length:343
 aligned with O66950_AQUAE | O66950 from UniProtKB/TrEMBL  Length:366

    Alignment length:350
                                    21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361
         O66950_AQUAE    12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVMSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKMGLILVTGPTGSGKSTTIASMIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEMRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLMQSGQAETGMQTMNQTLYKLYKQGLITLEDAMEASPDPKELERM 361
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..hhhhhhhhhhhh...eee.......eeee..eeee..........hhhhhhhh..hhhhhhhhhhh....eeee.....eeee...........eeee......hhhhhh.hhhhhhhhhh..eeee.......hhhhhhhhhhhhhhhhh..eeeeee............eeeeee......hhhhhhhhhh.....eeee....hhhhhhhhhhhhh...eeee.....hhhhhhhhhhhhh....hhhhhhhhhhheeeeeeeeee.......eeeeeee..hhhhhhhhhh..hhhhhhh..-------....hhhhhhhhh.......hhhhhh......... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2gsz C  12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVmSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKmGLILVTGPTGSGKSTTIASmIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEmRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLmQ-------mQTmNQTLYKLYKQGLITLEDAmEASPDPKELERm 361
                                    21        31        41        51        61      | 71        81        91       101       111       121       131    |  141       151    |  161       171       181       191       201       211      |221       231       241       251       261       271       281       291       301       311      || -     | 331       341       351       361
                                                                                   68-MSE                                                             136-MSE             156-MSE                                                       218-MSE                                                                                             318-MSE  327-MSE               349-MSE     361-MSE
                                                                                                                                                                                                                                                                                                                                             319        330-MSE


Chain D from PDB  Type:PROTEIN  Length:343
 aligned with O66950_AQUAE | O66950 from UniProtKB/TrEMBL  Length:366

    Alignment length:350
                                    21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361
         O66950_AQUAE    12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVMSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKMGLILVTGPTGSGKSTTIASMIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEMRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLMQSGQAETGMQTMNQTLYKLYKQGLITLEDAMEASPDPKELERM 361
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..hhhhhhhhhhhh...eee.......eeee..eeee..........hhhhhhhh..hhhhhhhhhhh.....eee.....eee............eeee......hhhhhh.hhhhhhhhhh..eeee.......hhhhhhhhhhhhhhhhh..eeeeee............eeeeee......hhhhhhhhhh.....eeee....hhhhhhhhhhhhh...eeee.....hhhhhhhhhhhhhhhhhhhhhhhhhhhheeeeeeeeee.......eeeeeee..hhhhhhhhhh..hhhhhhh..-------....hhhhhhhhh.......hhhhhh......... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2gsz D  12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVmSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKmGLILVTGPTGSGKSTTIASmIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEmRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLmQ-------mQTmNQTLYKLYKQGLITLEDAmEASPDPKELERm 361
                                    21        31        41        51        61      | 71        81        91       101       111       121       131    |  141       151    |  161       171       181       191       201       211      |221       231       241       251       261       271       281       291       301       311      || -     | 331       341       351       361
                                                                                   68-MSE                                                             136-MSE             156-MSE                                                       218-MSE                                                                                             318-MSE  327-MSE               349-MSE     361-MSE
                                                                                                                                                                                                                                                                                                                                             319        330-MSE


Chain E from PDB  Type:PROTEIN  Length:343
 aligned with O66950_AQUAE | O66950 from UniProtKB/TrEMBL  Length:366

    Alignment length:350
                                    21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361
         O66950_AQUAE    12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVMSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKMGLILVTGPTGSGKSTTIASMIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEMRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLMQSGQAETGMQTMNQTLYKLYKQGLITLEDAMEASPDPKELERM 361
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..hhhhhhhhhhhh...eee.......eeee..eeee..........hhhhhhhh..hhhhhhhhhhh.....eee.....eee............eee.......hhhhhh.hhhhhhhhhh..eeee.......hhhhhhhhhhhhhhhhh..eeeeee............eeeeee......hhhhhhhhhh.....eeee....hhhhhhhhhhhhh...eeee.....hhhhhhhhhhhhh....hhhhhhhhhhheeeeeeeeee.......eeeeeee..hhhhhhhhhh..hhhhhhh..-------....hhhhhhhhh.......hhhhhh......... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2gsz E  12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVmSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKmGLILVTGPTGSGKSTTIASmIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEmRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLmQ-------mQTmNQTLYKLYKQGLITLEDAmEASPDPKELERm 361
                                    21        31        41        51        61      | 71        81        91       101       111       121       131    |  141       151    |  161       171       181       191       201       211      |221       231       241       251       261       271       281       291       301       311      || -     | 331       341       351       361
                                                                                   68-MSE                                                             136-MSE             156-MSE                                                       218-MSE                                                                                             318-MSE  327-MSE               349-MSE     361-MSE
                                                                                                                                                                                                                                                                                                                                             319        330-MSE


Chain F from PDB  Type:PROTEIN  Length:343
 aligned with O66950_AQUAE | O66950 from UniProtKB/TrEMBL  Length:366

    Alignment length:350
                                    21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361
         O66950_AQUAE    12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVMSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKMGLILVTGPTGSGKSTTIASMIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEMRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLMQSGQAETGMQTMNQTLYKLYKQGLITLEDAMEASPDPKELERM 361
               SCOP domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..hhhhhhhhhhhh...eee.......eeee..eeee..........hhhhhhhh..hhhhhhhhhhh.....eee.....eee............eeee......hhhhhh.hhhhhhhhhh..eeee.......hhhhhhhhhhhhhhhhh..eeeee.............eeee........hhhhhhhhhh.....eeee....hhhhhhhhhhhhh...eeee.....hhhhhhhhhhhhh....hhhhhhhhhhheeeeeeeeee.......eeeeeee..hhhhhhhhhh..hhhhhhh..-------....hhhhhhhhh.......hhhhhh......... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2gsz F  12 ELKILEIIKEAIELGASDIHLTAGAPPAVRIDGYIKFLKDFPRLTPEDTQKLAYSVmSEKHRQKLEENGQVDFSFGVRGVGRFRANVFYQRGSVAAALRSLPAEIPEFKKLGLPDKVLELCHRKmGLILVTGPTGSGKSTTIASmIDYINQTKSYHIITIEDPIEYVFKHKKSIVNQREVGEDTKSFADALRAALREDPDVIFVGEmRDLETVETALRAAETGHLVFGTLHTNTAIDTIHRIVDIFPLNQQEQVRIVLSFILQGIISQRLLPKIGGGRVLAYELLIPNTAIRNLIRENKLQQVYSLmQ-------mQTmNQTLYKLYKQGLITLEDAmEASPDPKELERm 361
                                    21        31        41        51        61      | 71        81        91       101       111       121       131    |  141       151    |  161       171       181       191       201       211      |221       231       241       251       261       271       281       291       301       311      || -     | 331       341       351       361
                                                                                   68-MSE                                                             136-MSE             156-MSE                                                       218-MSE                                                                                             318-MSE  327-MSE               349-MSE     361-MSE
                                                                                                                                                                                                                                                                                                                                             319        330-MSE
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 2GSZ)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 2GSZ)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 2GSZ)

(-) Gene Ontology  (3, 3)

Asymmetric/Biological Unit(hide GO term definitions)
Chain A,B,C,D,E,F   (O66950_AQUAE | O66950)
molecular function
    GO:0005524    ATP binding    Interacting selectively and non-covalently with ATP, adenosine 5'-triphosphate, a universally important coenzyme and enzyme regulator.
    GO:0000166    nucleotide binding    Interacting selectively and non-covalently with a nucleotide, any compound consisting of a nucleoside that is esterified with (ortho)phosphate or an oligophosphate at any hydroxyl group on the ribose or deoxyribose.
biological process
    GO:0006810    transport    The directed movement of substances (such as macromolecules, small molecules, ions) or cellular components (such as complexes and organelles) into, out of or within a cell, or between cells, or within a multicellular organism by means of some agent such as a transporter, pore or motor protein.

 Visualization

(-) Interactive Views

Asymmetric/Biological Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    ADP  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]
    MSE  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]
    SO4  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    AC2  [ RasMol ]  +environment [ RasMol ]
    AC3  [ RasMol ]  +environment [ RasMol ]
    AC4  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
    Asp A:173 - Pro A:174   [ RasMol ]
    Asp B:173 - Pro B:174   [ RasMol ]
    Asp C:173 - Pro C:174   [ RasMol ]
    Asp D:173 - Pro D:174   [ RasMol ]
    Asp E:173 - Pro E:174   [ RasMol ]
    Asp F:173 - Pro F:174   [ RasMol ]


(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym./Biol. Unit PNG format | Asym./Biol. Unit - sites PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  2gsz
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  O66950_AQUAE | O66950
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/TrEMBL

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  O66950_AQUAE | O66950
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/TrEMBL
        O66950_AQUAE | O66950: 2ewv 2eww 2eyu

(-) Related Entries Specified in the PDB File

2ewv A. AEOLICUS PILT W/ADP, 1 MOL/AU
2eww A. AEOLICUS PILT W/ATP, 1 MOL/AU
2eyu C-TERMINAL DOMAIN OF A. AEOLICUS PILT
