(-) Description

Title :  RV0216, A CONSERVED HYPOTHETICAL PROTEIN FROM MYCOBACTERIUM TUBERCULOSIS THAT IS ESSENTIAL FOR BACTERIAL SURVIVAL DURING INFECTION, HAS A DOUBLE HOTDOGFOLD

Authors :  A. Castell, P. Johansson, T. Unge, T. A. Jones, K. Backbro
Date :  20 Jan 05  (Deposition) - 25 Apr 05  (Release) - 24 Feb 09  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  1.90
Chains :  Asym. Unit :  A
Biol. Unit 1:  A  (3x)
Keywords :  Hypothetical Protein, Conserved Hypothetical, Rv0216, Mycobacterium Tuberculosis, Hotdog-Fold, Structural Proteomics In Europe, Spine, Structural Genomics (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  A. Castell, P. Johansson, T. Unge, T. A. Jones, K. Backbro
Rv0216, A Conserved Hypothetical Protein From Mycobacterium Tuberculosis That Is Essential For Bacterial Survival During Infection, Has A Double Hotdog Fold
Protein Sci. V. 14 1850 2005
PubMed-ID: 15987908  |  Reference-DOI: 10.1110/PS.051442305

(-) Compounds

Molecule 1 - HYPOTHETICAL PROTEIN RV0216
    Chains: A
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Plasmid: PCR T7/CT-TOPO
    Expression System Strain: BL21
    Expression System Taxid: 511693
    Organism Scientific: MYCOBACTERIUM TUBERCULOSIS
    Organism Taxid: 83332
    Strain: H37RV

 Structural Features

(-) Chains, Units

  1
Asymmetric Unit : A
Biological Unit 1 (3x): A

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (2, 4)

Asymmetric Unit (2, 4)
No.NameCountTypeFull Name
1CL1Ligand/IonCHLORIDE ION
2MSE3Mod. Amino AcidSELENOMETHIONINE
Biological Unit 1 (1, 9)
No.NameCountTypeFull Name
1CL-1Ligand/IonCHLORIDE ION
2MSE9Mod. Amino AcidSELENOMETHIONINE

(-) Sites  (1, 1)

Asymmetric Unit (1, 1)
No.NameEvidenceResiduesDescription
1AC1SOFTWARELYS A:89BINDING SITE FOR RESIDUE CL A1338

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 2BI0)

(-) Cis Peptide Bonds  (1, 1)

Asymmetric Unit
No.Residues
1Gly A:201 -Pro A:202

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 2BI0)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 2BI0)

(-) Exons   (0, 0)

(no "Exon" information available for 2BI0)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:330
 aligned with P96398_MYCTO | P96398 from UniProtKB/TrEMBL  Length:337

    Alignment length:330
                                    17        27        37        47        57        67        77        87        97       107       117       127       137       147       157       167       177       187       197       207       217       227       237       247       257       267       277       287       297       307       317       327       337
         P96398_MYCTO     8 IRVGGPYFDDLSKGQVFDWAPGVTLSLGLAAAHQSIVGNRLRLALDSDLCAAVTGMPGPLAHPGLVCDVAIGQSTLATQRVKANLFYRGLRFHRFPAVGDTLYTRTEVVGLRANSPKPGRAPTGLAGLRMTTIDRTDRLVLDFYRCAMLPASPDWKPGAVPGDDLSRIGADAPAPAADPTAHWDGAVFRKRVPGPHFDAGIAGAVLHSTADLVSGAPELARLTLNIAATHHDWRVSGRRLVYGGHTIGLALAQATRLLPNLATVLDWESCDHTAPVHEGDTLYSELHIESAQAHADGGVLGLRSLVYAVSDSASEPDRQVLDWRFSALQF 337
               SCOP domains d2bi0a1 A:8-185 Hypothetical protein Rv0216/MT0226                                                                                                                                d2bi0a2 A:186-337 Hypothetical protein Rv0216/MT0226                                                                                                     SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author ......hhhhh....ee.....ee.hhhhhhhhhhhhh..hhhhhhhhhhhhhhh......hhhhhhhhhhhhhh.......eeeeee.ee.........eeeeeeeeeeeee.........eeeeeeeeeee.....eeeeeeeeeeee.................................hhhhhhhhh.....hhhhh..eee...ee..hhhhhhhhh...hhhhh..........hhhhhhhhhhhhhhhhh....eeeeeeeeee........eeeeeeeeeeeee....eeeeeeeeeee.........eeeeeeeeeeee. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Transcript
                 2bi0 A   8 IRVGGPYFDDLSKGQVFDWAPGVTLSLGLAAAHQSIVGNRLRLALDSDLCAAVTGmPGPLAHPGLVCDVAIGQSTLATQRVKANLFYRGLRFHRFPAVGDTLYTRTEVVGLRANSPKPGRAPTGLAGLRmTTIDRTDRLVLDFYRCAmLPASPDWKPGAVPGDDLSRIGADAPAPAADPTAHWDGAVFRKRVPGPHFDAGIAGAVLHSTADLVSGAPELARLTLNIAATHHDWRVSGRRLVYGGHTIGLALAQATRLLPNLATVLDWESCDHTAPVHEGDTLYSELHIESAQAHADGGVLGLRSLVYAVSDSASEPDRQVLDWRFSALQF 337
                                    17        27        37        47        57     |  67        77        87        97       107       117       127       137       147       157       167       177       187       197       207       217       227       237       247       257       267       277       287       297       307       317       327       337
                                                                                  63-MSE                                                                   137-MSE           155-MSE
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 2)

Asymmetric Unit
(-)
Class: Alpha and beta proteins (a+b) (23004)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 2BI0)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 2BI0)

(-) Gene Ontology  (1, 1)

Asymmetric Unit(hide GO term definitions)
Chain A   (P96398_MYCTO | P96398)
cellular component
    GO:0005886    plasma membrane    The membrane surrounding a cell that separates the cell from its external environment. It consists of a phospholipid bilayer and associated proteins.
