(-) Description

Title :  STRUCTURE OF AZURIN FROM ALCALIGENES DENITRIFICANS. REFINEMENT AT 1.8 ANGSTROMS RESOLUTION AND COMPARISON OF THE TWO CRYSTALLOGRAPHICALLY INDEPENDENT MOLECULES

Authors :  E. N. Baker, G. E. Norris
Date :  14 Oct 86  (Deposition) - 15 Jan 87  (Release) - 24 Feb 09  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  1.80
Chains :  Asym. Unit :  A,B
Biol. Unit 1:  A  (1x)
Biol. Unit 2:  B  (1x)
Keywords :  Electron Transport Protein(Cuproprotein) (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  E. N. Baker
Structure Of Azurin From Alcaligenes Denitrificans Refinement At 1. 8 A Resolution And Comparison Of The Two Crystallographically Independent Molecules.
J. Mol. Biol. V. 203 1071 1988
PubMed-ID: 3210236  |  Reference-DOI: 10.1016/0022-2836(88)90129-5
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - AZURIN
    Chains: A, B
    Engineered: YES
    Organism Scientific: ACHROMOBACTER XYLOSOXIDANS
    Organism Taxid: 85698

 Structural Features

(-) Chains, Units

  12
Asymmetric Unit : AB
Biological Unit 1 (1x): A
Biological Unit 2 (1x):  B

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (2, 5)

Asymmetric Unit (2, 5)
No.NameCountTypeFull Name
1CU2Ligand/IonCOPPER (II) ION
2SO43Ligand/IonSULFATE ION
Biological Unit 1 (1, 2)
No.NameCountTypeFull Name
1CU-1Ligand/IonCOPPER (II) ION
2SO42Ligand/IonSULFATE ION
Biological Unit 2 (1, 1)
No.NameCountTypeFull Name
1CU-1Ligand/IonCOPPER (II) ION
2SO41Ligand/IonSULFATE ION

(-) Sites  (7, 7)

Asymmetric Unit (7, 7)
No.NameEvidenceResiduesDescription
1AC1SOFTWAREGLY A:45 , HIS A:46 , CYS A:112 , HIS A:117 , MET A:121BINDING SITE FOR RESIDUE CU A 130
2AC2SOFTWAREALA A:75 , GLY A:76 , HIS A:83 , HOH A:146 , HOH A:197BINDING SITE FOR RESIDUE SO4 A 135
3AC3SOFTWARELYS A:41BINDING SITE FOR RESIDUE SO4 A 136
4AC4SOFTWAREGLY B:45 , HIS B:46 , CYS B:112 , HIS B:117 , MET B:121BINDING SITE FOR RESIDUE CU B 130
5AC5SOFTWARELYS B:74 , GLY B:76 , HIS B:83 , HOH B:154 , HOH B:166BINDING SITE FOR RESIDUE SO4 B 135
6M1AAUTHORGLY A:45 , HIS A:46 , CYS A:112 , HIS A:117 , MET A:121RESIDUES INTERACTING WITH THE COPPER ATOM. THE COPPER FORMS FIVE BONDS
7M1BAUTHORGLY B:45 , HIS B:46 , CYS B:112 , HIS B:117 , MET B:121RESIDUES INTERACTING WITH THE COPPER ATOM. THE COPPER FORMS FIVE BONDS

(-) SS Bonds  (2, 2)

Asymmetric Unit
No.Residues
1A:3 -A:26
2B:3 -B:26

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 2AZA)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 2AZA)

(-) PROSITE Motifs  (1, 2)

Asymmetric Unit (1, 2)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1COPPER_BLUEPS00196 Type-1 copper (blue) proteins signature.AZUR_ACHDE125-141
 		  2A:105-121
B:105-121
Biological Unit 1 (1, 1)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1COPPER_BLUEPS00196 Type-1 copper (blue) proteins signature.AZUR_ACHDE125-141
 		  1A:105-121
-
Biological Unit 2 (1, 1)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1COPPER_BLUEPS00196 Type-1 copper (blue) proteins signature.AZUR_ACHDE125-141
 		  1-
B:105-121

(-) Exons   (0, 0)

(no "Exon" information available for 2AZA)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:129
 aligned with AZUR_ACHDE | P00280 from UniProtKB/Swiss-Prot  Length:149

    Alignment length:129
                                    30        40        50        60        70        80        90       100       110       120       130       140
           AZUR_ACHDE    21 AQCEATIESNDAMQYNLKEMVVDKSCKQFTVHLKHVGKMAKVAMGHNWVLTKEADKQGVATDGMNAGLAQDYVKAGDTRVIAHTKVIGGGESDSVTFDVSKLTPGEAYAYFCSFPGHWAMMKGTLKLSN 149
               SCOP domains d2azaa_ A: Azurin                                                                                                                 SCOP domains
               CATH domains 2azaA00 A:1-129 Cupredoxins -  blue copper proteins                                                                               CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------- Pfam domains
     Sec.struct. author (1) ..eeeeeeee...eee.eeeee....eeeeeeeeee.........eeeeee...hhhhhhhhhhhhh.............eeeeeee...-------hhhhh.....eeeee........eeeeeeee. Sec.struct. author (1)
     Sec.struct. author (2) ------------------------------------------------------------------------------------------eeeeeeeee------------------------------ Sec.struct. author (2)
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------COPPER_BLUE      -------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2aza A   1 AQCEATIESNDAMQYDLKEMVVDKSCKQFTVHLKHVGKMAKSAMGHNWVLTKEADKEGVATDGMNAGLAQDYVKAGDTRVIAHTKVIGGGESDSVTFDVSKLTPGEAYAYFCSFPGHWAMMKGTLKLSN 129
                                    10        20        30        40        50        60        70        80        90       100       110       120


Chain B from PDB  Type:PROTEIN  Length:129
 aligned with AZUR_ACHDE | P00280 from UniProtKB/Swiss-Prot  Length:149

    Alignment length:129
                                    30        40        50        60        70        80        90       100       110       120       130       140
           AZUR_ACHDE    21 AQCEATIESNDAMQYNLKEMVVDKSCKQFTVHLKHVGKMAKVAMGHNWVLTKEADKQGVATDGMNAGLAQDYVKAGDTRVIAHTKVIGGGESDSVTFDVSKLTPGEAYAYFCSFPGHWAMMKGTLKLSN 149
               SCOP domains d2azab_ B: Azurin                                                                                                                 SCOP domains
               CATH domains 2azaB00 B:1-129 Cupredoxins -  blue copper proteins                                                                               CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------- Pfam domains
     Sec.struct. author (1) ..eeeeeeee...eee.eeeee....eeeeeeeeee.........eeeeee...hhhhhhhhhhhhh.............eeeeeee...-------hhhhh.....eeeee........eeeeeeee. Sec.struct. author (1)
     Sec.struct. author (2) ------------------------------------------------------------------------------------------eeeeeeeee------------------------------ Sec.struct. author (2)
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------COPPER_BLUE      -------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2aza B   1 AQCEATIESNDAMQYDLKEMVVDKSCKQFTVHLKHVGKMAKSAMGHNWVLTKEADKEGVATDGMNAGLAQDYVKAGDTRVIAHTKVIGGGESDSVTFDVSKLTPGEAYAYFCSFPGHWAMMKGTLKLSN 129
                                    10        20        30        40        50        60        70        80        90       100       110       120
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 2)

Asymmetric Unit
(-)
Class: All beta proteins (24004)

(-) CATH Domains  (1, 2)

Asymmetric Unit
(-)
Class: Mainly Beta (13760)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 2AZA)

(-) Gene Ontology  (5, 5)

Asymmetric Unit(hide GO term definitions)
Chain A,B   (AZUR_ACHDE | P00280)
molecular function
    GO:0005507    copper ion binding    Interacting selectively and non-covalently with copper (Cu) ions.
    GO:0009055    electron carrier activity    Any molecular entity that serves as an electron acceptor and electron donor in an electron transport chain. An electron transport chain is a process in which a series of electron carriers operate together to transfer electrons from donors to any of several different terminal electron acceptors to generate a transmembrane electrochemical gradient.
    GO:0046872    metal ion binding    Interacting selectively and non-covalently with any metal ion.
biological process
    GO:0055114    oxidation-reduction process    A metabolic process that results in the removal or addition of one or more electrons to or from a substance, with or without the concomitant removal or addition of a proton or protons.
cellular component
    GO:0042597    periplasmic space    The region between the inner (cytoplasmic) and outer membrane (Gram-negative Bacteria) or cytoplasmic membrane and cell wall (Fungi and Gram-positive Bacteria).

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    CU  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]
    SO4  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    AC2  [ RasMol ]  +environment [ RasMol ]
    AC3  [ RasMol ]  +environment [ RasMol ]
    AC4  [ RasMol ]  +environment [ RasMol ]
    AC5  [ RasMol ]  +environment [ RasMol ]
    M1A  [ RasMol ]  +environment [ RasMol ]
    M1B  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 2aza)

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Asym. Unit - sites PNG format | Biol. Unit 1 PNG format | Biol. Unit 1 - sites PNG format | Biol. Unit 2 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)
