(-) Description

Title :  CRYSTAL STRUCTURE OF E. COLI PROTEIN YAJL (THIJ)

Authors :  M. A. Wilson, D. Ringe, G. A. Petsko
Date :  14 Jul 05  (Deposition) - 11 Oct 05  (Release) - 24 Feb 09  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  1.10
Chains :  Asym./Biol. Unit :  A,B
Keywords :  Dj-1/Thij Superfamily, Alpha-Beta Hydrolase Fold, Unknown Function (Keyword Search: [Gene Ontology, PubMed, Web (Google))

Reference :  M. A. Wilson, D. Ringe, G. A. Petsko
The Atomic Resolution Crystal Structure Of The Yajl (Thij) Protein From Escherichia Coli: A Close Prokaryotic Homologue Of The Parkinsonism-Associated Protein Dj-1.
J. Mol. Biol. V. 353 678 2005
PubMed-ID: 16181642  |  Reference-DOI: 10.1016/J.JMB.2005.08.033
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - YAJL
    ChainsA, B
    EngineeredYES
    Expression SystemESCHERICHIA COLI BL21(DE3)
    Expression System PlasmidPET21A
    Expression System StrainBL21(DE3)
    Expression System Taxid469008
    Expression System Vector TypePLASMID
    GeneTHIJ
    Organism ScientificESCHERICHIA COLI
    Organism Taxid562

 Structural Features

(-) Chains, Units

  12
Asymmetric/Biological Unit AB

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (0, 0)

(no "Ligand,Modified Residues,Ions" information available for 2AB0)

(-) Sites  (0, 0)

(no "Site" information available for 2AB0)

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 2AB0)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 2AB0)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 2AB0)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 2AB0)

(-) Exons   (0, 0)

(no "Exon" information available for 2AB0)

(-) Sequences/Alignments

Asymmetric/Biological Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:195
 aligned with YAJL_ECOLI | Q46948 from UniProtKB/Swiss-Prot  Length:196

    Alignment length:195
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191
           YAJL_ECOLI     2 SASALVCLAPGSEETEAVTTIDLLVRGGIKVTTASVASDGNLAITCSRGVKLLADAPLVEVADGEYDVIVLPGGIKGAECFRDSTLLVETVKQFHRSGRIVAAICAAPATVLVPHDIFPIGNMTGFPTLKDKIPAEQWLDKRVVWDARVKLLTSQGPGTAIDFGLKIIDLLVGREKAHEVASQLVMAAGIYNYYE 196
               SCOP domains d2ab0a1 A:2-196 Protein ThiJ (YajL)                                                                                                                                                                 SCOP domains
               CATH domains 2ab0A00 A:2-196  [code=3.40.50.880, no name defined]                                                                                                                                                CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeee....hhhhhhhhhhhhhhh..eeeeee.......eee.....eee..eehhhhh.....eeee..hhhhhhhhhhhhhhhhhhhhhhhh..eeeee.hhhhhhh.............hhhhhhhh.........eeee....eeee.hhhhhhhhhhhhhhhhhhhhhhhhhhh............. Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2ab0 A   2 SASALVCLAPGSEETEAVTTIDLLVRGGIKVTTASVASDGNLAITCSRGVKLLADAPLVEVADGEYDVIVLPGGIKGAECFRDSTLLVETVKQFHRSGRIVAAICAAPATVLVPHDIFPIGNMTGFPTLKDKIPAEQWLDKRVVWDARVKLLTSQGPGTAIDFGLKIIDLLVGREKAHEVASQLVMAAGIYNYYE 196
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191

Chain B from PDB  Type:PROTEIN  Length:195
 aligned with YAJL_ECOLI | Q46948 from UniProtKB/Swiss-Prot  Length:196

    Alignment length:195
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191
           YAJL_ECOLI     2 SASALVCLAPGSEETEAVTTIDLLVRGGIKVTTASVASDGNLAITCSRGVKLLADAPLVEVADGEYDVIVLPGGIKGAECFRDSTLLVETVKQFHRSGRIVAAICAAPATVLVPHDIFPIGNMTGFPTLKDKIPAEQWLDKRVVWDARVKLLTSQGPGTAIDFGLKIIDLLVGREKAHEVASQLVMAAGIYNYYE 196
               SCOP domains d2ab0b_ B: automated matches                                                                                                                                                                        SCOP domains
               CATH domains 2ab0B00 B:2-196  [code=3.40.50.880, no name defined]                                                                                                                                                CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..eeeeee....hhhhhhhhhhhhhhh..eeeeee.......eee.....eee..eehhhhh.....eeee..hhhhhhhhhhhhhhhhhhhhhhhh..eeeee.hhhhhhh.............hhhhhhhh.........eeee....eeee.hhhhhhhhhhhhhhhhhhhhhhhhhhhh............ Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 2ab0 B   2 SASALVCLAPGSEETEAVTTIDLLVRGGIKVTTASVASDGNLAITCSRGVKLLADAPLVEVADGEYDVIVLPGGIKGAECFRDSTLLVETVKQFHRSGRIVAAICAAPATVLVPHDIFPIGNMTGFPTLKDKIPAEQWLDKRVVWDARVKLLTSQGPGTAIDFGLKIIDLLVGREKAHEVASQLVMAAGIYNYYE 196
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191

   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (2, 2)

Asymmetric/Biological Unit

(-) CATH Domains  (1, 2)

Asymmetric/Biological Unit
(-)
Class: Alpha Beta (26913)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 2AB0)

(-) Gene Ontology  (15, 15)

Asymmetric/Biological Unit(hide GO term definitions)
Chain A,B   (YAJL_ECOLI | Q46948)
molecular function
    GO:0019172    glyoxalase III activity    Catalysis of the reaction: methylglyoxal + H2O = D-lactate.
    GO:0016787    hydrolase activity    Catalysis of the hydrolysis of various bonds, e.g. C-O, C-N, C-C, phosphoric anhydride bonds, etc. Hydrolase is the systematic name for any enzyme of EC class 3.
    GO:0003713    transcription coactivator activity    Interacting selectively and non-covalently with a activating transcription factor and also with the basal transcription machinery in order to increase the frequency, rate or extent of transcription. Cofactors generally do not bind the template nucleic acid, but rather mediate protein-protein interactions between activating transcription factors and the basal transcription machinery.
biological process
    GO:0070301    cellular response to hydrogen peroxide    Any process that results in a change in state or activity of a cell (in terms of movement, secretion, enzyme production, gene expression, etc.) as a result of a hydrogen peroxide (H2O2) stimulus.
    GO:0034599    cellular response to oxidative stress    Any process that results in a change in state or activity of a cell (in terms of movement, secretion, enzyme production, gene expression, etc.) as a result of oxidative stress, a state often resulting from exposure to high levels of reactive oxygen species, e.g. superoxide anions, hydrogen peroxide (H2O2), and hydroxyl radicals.
    GO:0019249    lactate biosynthetic process    The chemical reactions and pathways resulting in the formation of lactate, the anion of lactic acid.
    GO:0019243    methylglyoxal catabolic process to D-lactate via S-lactoyl-glutathione    The chemical reactions and pathways resulting in the breakdown of methylglyoxal, CH3-CO-CHO, into D-lactate via the intermediate S-lactoyl-glutathione. Glutathione is used in the first step of the pathway and then regenerated in the second step.
    GO:0042026    protein refolding    The process carried out by a cell that restores the biological activity of an unfolded or misfolded protein, using helper proteins such as chaperones.
    GO:0006357    regulation of transcription from RNA polymerase II promoter    Any process that modulates the frequency, rate or extent of transcription from an RNA polymerase II promoter.
    GO:0009408    response to heat    Any process that results in a change in state or activity of a cell or an organism (in terms of movement, secretion, enzyme production, gene expression, etc.) as a result of a heat stimulus, a temperature stimulus above the optimal temperature for that organism.
    GO:0042254    ribosome biogenesis    A cellular process that results in the biosynthesis of constituent macromolecules, assembly, and arrangement of constituent parts of ribosome subunits; includes transport to the sites of protein synthesis.
    GO:0009228    thiamine biosynthetic process    The chemical reactions and pathways resulting in the formation of thiamine (vitamin B1), a water soluble vitamin present in fresh vegetables and meats, especially liver.
cellular component
    GO:0005829    cytosol    The part of the cytoplasm that does not contain organelles but which does contain other particulate matter, such as protein complexes.
    GO:0005739    mitochondrion    A semiautonomous, self replicating organelle that occurs in varying numbers, shapes, and sizes in the cytoplasm of virtually all eukaryotic cells. It is notably the site of tissue respiration.
    GO:0005634    nucleus    A membrane-bounded organelle of eukaryotic cells in which chromosomes are housed and replicated. In most cells, the nucleus contains all of the cell's chromosomes except the organellar chromosomes, and is the site of RNA synthesis and processing. In some species, or in specialized cell types, RNA metabolism or DNA replication may be absent.
