1XSF - JenaLib

Title :   SOLUTION STRUCTURE OF A RESUSCITATION PROMOTING FACTOR DOMAIN FROM MYCOBACTERIUM TUBERCULOSIS

Authors :   M. Cohen-Gonsaud, P. Barthe, B. Henderson, J. Ward, C. Roumestand, N. H. Keep

Date :   19 Oct 04 (Deposition) - 15 Feb 05 (Release) - 24 Feb 09 (Revision)

Method :   SOLUTION NMR

Resolution :   NOT APPLICABLE

Chains :   NMR Structure  : A  (30x)

Keywords :   Lysozyme-Like Structure, Cell Cycle, Hydrolase (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :   M. Cohen-Gonsaud, P. Barthe, C. Bagneris, B. Henderson, J. Ward, C. Roumestand, N. H. Keep
The Structure Of A Resuscitation-Promoting Factor Domain From Mycobacterium Tuberculosis Shows Homology To Lysozymes
Nat. Struct. Mol. Biol. V. 12 270 2005
PubMed-ID: 15723078 | Reference-DOI: 10.1038/NSMB905
(for further references see the PDB file header)

Compounds

Structural Features

Chains, Units

Ligands, Modified Residues, Ions (0, 0)

Sites (0, 0)

SS Bonds (1, 1)

Cis Peptide Bonds (0, 0)

Sequence-Structure Mapping

SAPs(SNPs)/Variants (0, 0)

PROSITE Motifs (0, 0)

Exons (0, 0)

Sequences/Alignments

NMR Structure

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain A from PDB  Type:PROTEIN  Length:108
 aligned with RPFB_MYCTO | P9WG28 from UniProtKB/Swiss-Prot  Length:362

    Alignment length:108
                                   264       274       284       294       304       314       324       334       344       354
           RPFB_MYCTO   255 NVVVTPAHEAVVRVGTKPGTEVPPVIDGSIWDAIAGCEAGGNWAINTGNGYYGGVQFDQGTWEANGGLRYAPRADLATREEQIAVAEVTRLRQGWGAWPVCAARAGAR 362
               SCOP domains ----------------------d1xsfa1 A:23-108 Probable resuscitation-promoting factor RpfB                          SCOP domains
               CATH domains 1xsfA00 A:1-108  [code=1.10.530.10, no name defined]                                                         CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author ..........................hhhhhhhhhhhhh..................hhhhhhhhhhhhh.......hhhhhhhhhhhhhhhhh....hhhhhhhh.. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------ Transcript
                 1xsf A   1 NVVVTPAHEAVVRVGTKPGTEVPPVIDGSIWDAIAGCEAGGNWAINTGNGYYGGVQFDQGTWEANGGLRYAPRADLATREEQIAVAEVTRLRQGWGAWPVCAARAGAR 108
                                    10        20        30        40        50        60        70        80        90       100

Chain A from PDB  Type:PROTEIN  Length:108
 aligned with RPFB_MYCTU | P9WG29 from UniProtKB/Swiss-Prot  Length:362

    Alignment length:108
                                   264       274       284       294       304       314       324       334       344       354
           RPFB_MYCTU   255 NVVVTPAHEAVVRVGTKPGTEVPPVIDGSIWDAIAGCEAGGNWAINTGNGYYGGVQFDQGTWEANGGLRYAPRADLATREEQIAVAEVTRLRQGWGAWPVCAARAGAR 362
               SCOP domains ----------------------d1xsfa1 A:23-108 Probable resuscitation-promoting factor RpfB                          SCOP domains
               CATH domains 1xsfA00 A:1-108  [code=1.10.530.10, no name defined]                                                         CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author ..........................hhhhhhhhhhhhh..................hhhhhhhhhhhhh.......hhhhhhhhhhhhhhhhh....hhhhhhhh.. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------ Transcript
                 1xsf A   1 NVVVTPAHEAVVRVGTKPGTEVPPVIDGSIWDAIAGCEAGGNWAINTGNGYYGGVQFDQGTWEANGGLRYAPRADLATREEQIAVAEVTRLRQGWGAWPVCAARAGAR 108
                                    10        20        30        40        50        60        70        80        90       100

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Classification and Annotation

SCOP Domains (1, 1)

CATH Domains (1, 1)

Pfam Domains (0, 0)

Gene Ontology (10, 14)

NMR Structure(hide GO term definitions)

Chain A (RPFB_MYCTU | P9WG29)

molecular function
	GO:0016787	hydrolase activity	Catalysis of the hydrolysis of various bonds, e.g. C-O, C-N, C-C, phosphoric anhydride bonds, etc. Hydrolase is the systematic name for any enzyme of EC class 3.
	GO:0005515	protein binding	Interacting selectively and non-covalently with any protein or protein complex (a complex of two or more proteins that may include other nonprotein molecules).
biological process
	GO:0085016	dormancy exit of symbiont in host	Exit from dormant state, also known as resuscitation, of the symbiont within the host organism.
	GO:0010629	negative regulation of gene expression	Any process that decreases the frequency, rate or extent of gene expression. Gene expression is the process in which a gene's coding sequence is converted into a mature gene product or products (proteins or RNA). This includes the production of an RNA transcript as well as any processing to produce a mature RNA product or an mRNA or circRNA (for protein-coding genes) and the translation of that mRNA or circRNA into protein. Protein maturation is included when required to form an active form of a product from an inactive precursor form.
	GO:0009405	pathogenesis	The set of specific processes that generate the ability of an organism to induce an abnormal, generally detrimental state in another organism.
	GO:0010628	positive regulation of gene expression	Any process that increases the frequency, rate or extent of gene expression. Gene expression is the process in which a gene's coding sequence is converted into a mature gene product or products (proteins or RNA). This includes the production of an RNA transcript as well as any processing to produce a mature RNA product or an mRNA or circRNA (for protein-coding genes) and the translation of that mRNA or circRNA into protein. Protein maturation is included when required to form an active form of a product from an inactive precursor form.
	GO:0040010	positive regulation of growth rate	Any process that increases the rate of growth of all or part of an organism.
cellular component
	GO:0005576	extracellular region	The space external to the outermost structure of a cell. For cells without external protective or external encapsulating structures this refers to space outside of the plasma membrane. This term covers the host cell environment outside an intracellular parasite.
	GO:0016020	membrane	A lipid bilayer along with all the proteins and protein complexes embedded in it an attached to it.
	GO:0005886	plasma membrane	The membrane surrounding a cell that separates the cell from its external environment. It consists of a phospholipid bilayer and associated proteins.

Chain A (RPFB_MYCTO | P9WG28)

molecular function
	GO:0016787	hydrolase activity	Catalysis of the hydrolysis of various bonds, e.g. C-O, C-N, C-C, phosphoric anhydride bonds, etc. Hydrolase is the systematic name for any enzyme of EC class 3.
biological process
	GO:0009405	pathogenesis	The set of specific processes that generate the ability of an organism to induce an abnormal, generally detrimental state in another organism.
cellular component
	GO:0016020	membrane	A lipid bilayer along with all the proteins and protein complexes embedded in it an attached to it.
	GO:0005886	plasma membrane	The membrane surrounding a cell that separates the cell from its external environment. It consists of a phospholipid bilayer and associated proteins.

Visualization

Interactive Views

NMR Structure
	Complete Structure
		Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
		WebMol \| AstexViewer[tm]@PDBe (Java Applets, require no local installation except for Java; loading may be slow)
		STRAP (Java WebStart application, automatic local installation, requires Java; full application with system access!)
		RasMol (require local installation)
		Molscript (VRML) (requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

	Ligands, Modified Residues, Ions
(no "Ligands, Modified Residues, Ions" information available for 1xsf)

	Sites
(no "Sites" information available for 1xsf)

	Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 1xsf)

Still Images

Databases and Analysis Tools

Databases

Access by PDB/NDB ID
	1xsf
		Family and Domain Information	:	ProDom \| SYSTERS
		General Structural Information	:	GlycoscienceDB \| MMDB \| NDB \| OCA \| PDB \| PDBe \| PDBj \| PDBsum \| PDBWiki \| PQS \| PROTEOPEDIA
		Orientation in Membranes	:	OPM
		Protein Surface	:	SURFACE
		Secondary Structure	:	DSSP (structure derived) \| HSSP (homology derived)
		Structural Genomics	:	GeneCensus
		Structural Neighbours	:	CE \| VAST
		Structure Classification	:	CATH \| Dali \| SCOP
		Validation and Original Data	:	BMRB Data View \| BMRB Restraints Grid \| EDS \| PROCHECK \| RECOORD \| WHAT_CHECK

Access by UniProt ID/Accession number
	RPFB_MYCTO \| P9WG28
		Comparative Protein Structure Models	:	ModBase
		Genomic Information	:	Ensembl
		Protein-protein Interaction	:	DIP
		Sequence, Family and Domain Information	:	InterPro \| Pfam \| SMART \| UniProtKB/SwissProt
	RPFB_MYCTU \| P9WG29
		Comparative Protein Structure Models	:	ModBase
		Genomic Information	:	Ensembl
		Protein-protein Interaction	:	DIP
		Sequence, Family and Domain Information	:	InterPro \| Pfam \| SMART \| UniProtKB/SwissProt

Access by Enzyme Classificator (EC Number)
	(no 'Enzyme Classificator' available)
		General Enzyme Information	:	BRENDA \| EC-PDB \| Enzyme \| IntEnz
		Pathway	:	KEGG \| MetaCyc

Access by Disease Identifier (MIM ID)
	(no 'MIM ID' available)
		Disease Information	:	OMIM

Access by GenAge ID
	(no 'GenAge ID' available)
		Age Related Information	:	GenAge
