1TS9 - JenaLib

Title :   CRYSTAL STRUCTURE OF THE ARCHAEAL HOMOLOG OF HUMAN RNASE P PROTEIN RPP29 FROM ARCHAEOGLOBUS FULGIDUS

Authors :   D. J. Sidote, J. Heideker, D. W. Hoffman

Date :   21 Jun 04 (Deposition) - 12 Oct 04 (Release) - 24 Feb 09 (Revision)

Method :   X-RAY DIFFRACTION

Resolution :   1.70

Chains :   Asym./Biol. Unit : A

Keywords :   Anti-Parallel, Beta-Sheet, Alpha Helix, Internal Salt Bridge, Selenomethionine, Sm-Fold, Hydrolase (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :   D. J. Sidote, J. Heideker, D. W. Hoffman
Crystal Structure Of Archaeal Ribonuclease P Protein Arpp29 From Archaeoglobus Fulgidus.
Biochemistry V. 43 14128 2004
PubMed-ID: 15518563 | Reference-DOI: 10.1021/BI048578Z
(for further references see the PDB file header)

Compounds

Molecule 1 - RIBONUCLEASE P PROTEIN COMPONENT 1
	Chains	:	A
	EC Number	:	3.1.26.5
	Engineered	:	YES
	Expression System	:	ESCHERICHIA COLI BL21(DE3)
	Expression System Plasmid	:	PMAL-C2T
	Expression System Strain	:	BL21(DE3)
	Expression System Taxid	:	469008
	Expression System Vector Type	:	MALTOSE BINDING PROTEIN FUSION
	Gene	:	RNP1, AF1917
	Organism Scientific	:	ARCHAEOGLOBUS FULGIDUS
	Organism Taxid	:	2234
	Synonym	:	RNASE P COMPONENT 1, ARPP29

Structural Features

Chains, Units

Ligands, Modified Residues, Ions (1, 5)

Sites (0, 0)

SS Bonds (0, 0)

Cis Peptide Bonds (0, 0)

Sequence-Structure Mapping

SAPs(SNPs)/Variants (0, 0)

PROSITE Motifs (0, 0)

Exons (0, 0)

Sequences/Alignments

Asymmetric/Biological Unit

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain A from PDB  Type:PROTEIN  Length:98
 aligned with RNP1_ARCFU | O28362 from UniProtKB/Swiss-Prot  Length:102

    Alignment length:98
                                    14        24        34        44        54        64        74        84        94
           RNP1_ARCFU     5 LQGVELIARDWIGLMVEVVESPNHSEVGIKGEVVDETQNTLKIMTEKGLKVVAKRGRTFRVWYKGKIMRIKGDLINFRPEDRIKRGLMMLKRAKGVWI 102
               SCOP domains d1ts9a_ A: Hypothetical protein AF1917                                                             SCOP domains
               CATH domains 1ts9A00 A:5-102 RNase P subunit p29-like                                                           CATH domains
               Pfam domains UPF0086-1ts9A01 A:5-90                                                                ------------ Pfam domains
         Sec.struct. author hhhhhhhhh.....eeeeee..hhhhh..eeeeeee...eeeeee...eeeee....eeeeee..eeeeee.hhh..hhhhhhhhhhhhhhhh..... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------- Transcript
                 1ts9 A   5 LQGVELIARDWIGLmVEVVESPNHSEVGIKGEVVDETQNTLKImTEKGLKVVAKRGRTFRVWYKGKImRIKGDLINFRPEDRIKRGLmmLKRAKGVWI 102
                                    14    |   24        34        44   |    54        64       |74        84       |94
                                         19-MSE                       48-MSE                  72-MSE              92-MSE
                                                                                                                   93-MSE

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Classification and Annotation

SCOP Domains (1, 1)

CATH Domains (1, 1)

Pfam Domains (1, 1)

Gene Ontology (14, 14)

Asymmetric/Biological Unit(hide GO term definitions)

Chain A (RNP1_ARCFU | O28362)

molecular function
	GO:0003723	RNA binding	Interacting selectively and non-covalently with an RNA molecule or a portion thereof.
	GO:0004519	endonuclease activity	Catalysis of the hydrolysis of ester linkages within nucleic acids by creating internal breaks.
	GO:0016787	hydrolase activity	Catalysis of the hydrolysis of various bonds, e.g. C-O, C-N, C-C, phosphoric anhydride bonds, etc. Hydrolase is the systematic name for any enzyme of EC class 3.
	GO:0004518	nuclease activity	Catalysis of the hydrolysis of ester linkages within nucleic acids.
	GO:0004526	ribonuclease P activity	Catalysis of the endonucleolytic cleavage of RNA, removing 5' extra nucleotides from tRNA precursor.
	GO:0004540	ribonuclease activity	Catalysis of the hydrolysis of phosphodiester bonds in chains of RNA.
biological process
	GO:0090502	RNA phosphodiester bond hydrolysis, endonucleolytic	The chemical reactions and pathways involving the hydrolysis of internal 3',5'-phosphodiester bonds in one or two strands of ribonucleotides.
	GO:0006379	mRNA cleavage	Any process in which a pre-mRNA or mRNA molecule is cleaved at specific sites or in a regulated manner.
	GO:0006364	rRNA processing	Any process involved in the conversion of a primary ribosomal RNA (rRNA) transcript into one or more mature rRNA molecules.
	GO:0001682	tRNA 5'-leader removal	Generation of the mature 5'-end of the tRNA, usually via an endonucleolytic cleavage by RNase P.
	GO:0008033	tRNA processing	The process in which a pre-tRNA molecule is converted to a mature tRNA, ready for addition of an aminoacyl group.
cellular component
	GO:0005737	cytoplasm	All of the contents of a cell excluding the plasma membrane and nucleus, but including other subcellular structures.
	GO:0000172	ribonuclease MRP complex	A ribonucleoprotein complex that contains an RNA molecule of the snoRNA family, and cleaves the rRNA precursor as part of rRNA transcript processing. It also has other roles: In S. cerevisiae it is involved in cell cycle-regulated degradation of daughter cell-specific mRNAs, while in mammalian cells it also enters the mitochondria and processes RNAs to create RNA primers for DNA replication.
	GO:0030677	ribonuclease P complex	A ribonucleoprotein complex that catalyzes cleavage of the leader sequence of precursor tRNAs (pre-tRNAs), generating the mature 5' end of tRNAs.

Visualization

Interactive Views

Asymmetric/Biological Unit
	Complete Structure
		Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
		WebMol \| AstexViewer[tm]@PDBe (Java Applets, require no local installation except for Java; loading may be slow)
		STRAP (Java WebStart application, automatic local installation, requires Java; full application with system access!)
		RasMol (require local installation)
		Molscript (VRML) (requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

	Ligands, Modified Residues, Ions
		MSE	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]

	Sites
(no "Sites" information available for 1ts9)

	Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 1ts9)

Still Images

Databases and Analysis Tools

Databases

Access by PDB/NDB ID
	1ts9
		Family and Domain Information	:	ProDom \| SYSTERS
		General Structural Information	:	GlycoscienceDB \| MMDB \| NDB \| OCA \| PDB \| PDBe \| PDBj \| PDBsum \| PDBWiki \| PQS \| PROTEOPEDIA
		Orientation in Membranes	:	OPM
		Protein Surface	:	SURFACE
		Secondary Structure	:	DSSP (structure derived) \| HSSP (homology derived)
		Structural Genomics	:	GeneCensus
		Structural Neighbours	:	CE \| VAST
		Structure Classification	:	CATH \| Dali \| SCOP
		Validation and Original Data	:	BMRB Data View \| BMRB Restraints Grid \| EDS \| PROCHECK \| RECOORD \| WHAT_CHECK

Access by UniProt ID/Accession number
	RNP1_ARCFU \| O28362
		Comparative Protein Structure Models	:	ModBase
		Genomic Information	:	Ensembl
		Protein-protein Interaction	:	DIP
		Sequence, Family and Domain Information	:	InterPro \| Pfam \| SMART \| UniProtKB/SwissProt

Access by Enzyme Classificator (EC Number)
	3.1.26.5
		General Enzyme Information	:	BRENDA \| EC-PDB \| Enzyme \| IntEnz
		Pathway	:	KEGG \| MetaCyc

Access by Disease Identifier (MIM ID)
	(no 'MIM ID' available)
		Disease Information	:	OMIM

Access by GenAge ID
	(no 'GenAge ID' available)
		Age Related Information	:	GenAge

Analysis Tools

Access by PDB/NDB ID
		Domain Information	:	XDom
		Interatomic Contacts of Structural Units	:	CSU
		Ligand-protein Contacts	:	LPC
		Protein Cavities	:	castP
		Sequence and Secondary Structure	:	PDBCartoon
		Structure Alignment	:	STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
		Structure and Sequence Browser	:	STING

Access by UniProt ID/Accession number
	RNP1_ARCFU \| O28362
		Protein Disorder Prediction	:	DisEMBL \| FoldIndex \| GLOBPLOT (for more information see DisProt)

Description
