Title :   ESCHERICHIA COLI HEAT LABILE ENTEROTOXIN TYPE IIB

Authors :   F. Van Den Akker, W. G. J. Hol

Date :   20 Mar 96 (Deposition) - 17 Aug 96 (Release) - 24 Feb 09 (Revision)

Method :   X-RAY DIFFRACTION

Resolution :   2.25

Chains :   Asym./Biol. Unit : A,C,D,E,F,G,H

Keywords :   Adp-Ribosyl Transferase, Adp-Ribosylation, Enterotoxin, Ganglioside Receptor (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :   F. Van Den Akker, S. Sarfaty, E. M. Twiddy, T. D. Connell, R. K. Holmes, W. G. Hol
Crystal Structure Of A New Heat-Labile Enterotoxin, Lt-Iib.
Structure V. 4 665 1996
PubMed-ID: 8805549 | Reference-DOI: 10.1016/S0969-2126(96)00073-1
(for further references see the PDB file header)

Molecule 1 - HEAT LABILE ENTEROTOXIN TYPE IIB
	Chains	:	D, E, F, G, H
	Engineered	:	YES
	Expression System	:	ESCHERICHIA COLI
	Expression System Plasmid	:	BLUESCRIPT-KS VECTOR
	Expression System Taxid	:	562
	Organism Scientific	:	ESCHERICHIA COLI
	Organism Taxid	:	562
	Other Details	:	LATENT/INACTIVE FORM
	Strain	:	HB101
	Synonym	:	LT-IIB

Molecule 2 - HEAT LABILE ENTEROTOXIN TYPE IIB
	Chains	:	A
	Engineered	:	YES
	Expression System	:	ESCHERICHIA COLI
	Expression System Plasmid	:	BLUESCRIPT-KS VECTOR
	Expression System Taxid	:	562
	Organism Scientific	:	ESCHERICHIA COLI
	Organism Taxid	:	562
	Other Details	:	LATENT/INACTIVE FORM
	Strain	:	HB101
	Synonym	:	LT-IIB

Molecule 3 - HEAT LABILE ENTEROTOXIN TYPE IIB
	Chains	:	C
	Engineered	:	YES
	Expression System	:	ESCHERICHIA COLI
	Expression System Plasmid	:	BLUESCRIPT-KS VECTOR
	Expression System Taxid	:	562
	Organism Scientific	:	ESCHERICHIA COLI
	Organism Taxid	:	562
	Other Details	:	LATENT/INACTIVE FORM
	Strain	:	HB101
	Synonym	:	LT-IIB

		1	2	3	4	5	6	7
Asymmetric/Biological Unit	:	A	C	D	E	F	G	H

Summary Information (see also Sequences/Alignments below)

(no "Ligand,Modified Residues,Ions" information available for 1TII)

(no "Site" information available for 1TII)

Asymmetric/Biological Unit

No.	Residues
1	A:185	-	C:197
2	D:10	-	D:81
3	E:10	-	E:81
4	F:10	-	F:81
5	G:10	-	G:81
6	H:10	-	H:81

Asymmetric/Biological Unit

No.	Residues
1	Tyr D:55	-	Pro D:56
2	Ser D:87	-	Pro D:88
3	Tyr E:55	-	Pro E:56
4	Ser E:87	-	Pro E:88
5	Tyr F:55	-	Pro F:56
6	Ser F:87	-	Pro F:88
7	Tyr G:55	-	Pro G:56
8	Ser G:87	-	Pro G:88
9	Tyr H:55	-	Pro H:56
10	Ser H:87	-	Pro H:88
11	Val A:175	-	Pro A:176

(no "SAP(SNP)/Variant" information available for 1TII)

(no "PROSITE Motif" information available for 1TII)

(no "Exon" information available for 1TII)

Asymmetric/Biological Unit

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain A from PDB  Type:PROTEIN  Length:186
 aligned with E2BA_ECOLX | P43528 from UniProtKB/Swiss-Prot  Length:263

    Alignment length:187
                                    30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200
           E2BA_ECOLX    21 NDYFRADSRTPDEVRRSGGLIPRGQDEAYERGTPININLYDHARGTATGNTRYNDGYVSTTTTLRQAHFLGQNMLGGYNEYYIYVVAAAPNLFDVNGVLGRYSPYPSENEYAALGGIPLSQIIGWYRVSFGAIEGGMHRNRDYRRDLFRGLSAAPNEDGYRIAGFPDGFPAWEEVPWREFAPNSCLP 207
               SCOP domains d1tii.1 A:,C: Heat-labile toxin, A-chain                                                                                                                                                    SCOP domains
               CATH domains 1tiiA00 A:1-187 Heat-Labile Enterotoxin, subun it A                                                                                                                                         CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeeeee...hhhhhhh.....................hhhhhh..-.........eeee...hhhhhhhhhhh......eeeeeee....eeehhhhhhhh...hhh..eeee....hhheeeeeee................hhhh.......hhhhhhh.......hhhh...hhh...hhh.. Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1tii A   1 NDYFRADSRTPDEVRRSGGLIPRGQDEAYERGTPININLYDHARGT-TGNTRYNDGYVSTTTTLRQAHLLGQNMLGGYNEYYIYVVAAAPNLFDVNGVLGRYSPYPSENEYAALGGIPLSQIIGWYRVSFGAIEGGMHRNRDYRRDLFRGLSAAPNEDGYRIAGFPDGFPAWEEVPWREFAPNSCLP 187
                                    10        20        30        40     | |50        60        70        80        90       100       110       120       130       140       150       160       170       180
                                                                        46 |
                                                                          48

Chain C from PDB  Type:PROTEIN  Length:36
 aligned with E2BA_ECOLX | P43528 from UniProtKB/Swiss-Prot  Length:263

    Alignment length:36
                                   224       234       244
           E2BA_ECOLX   215 TTCASLTNKLSQHDLADFKKYIKRKFTLMTLLSINN 250
               SCOP domains d1tii.1 A:,C:                        SCOP domains
               CATH domains 1tiiC00 C:195-230                    CATH domains
           Pfam domains (1) Enterotoxin_a-1tiiC01 C:195-230      Pfam domains (1)
           Pfam domains (2) Enterotoxin_a-1tiiC02 C:195-230      Pfam domains (2)
         Sec.struct. author ..hhhhhhhhhhhhhhhhhhhhhhhhhhhhhhhh.. Sec.struct. author
                 SAPs(SNPs) ------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------ PROSITE
                 Transcript ------------------------------------ Transcript
                 1tii C 195 TTCASLTNKLSQHDLADFKKYIKRKFTLMTLLSINN 230
                                   204       214       224

Chain D from PDB  Type:PROTEIN  Length:98
 aligned with E2BB_ECOLX | P43529 from UniProtKB/Swiss-Prot  Length:122

    Alignment length:98
                                    33        43        53        63        73        83        93       103       113
           E2BB_ECOLX    24 GASQFFKDNCNRTTASLVEGVELTKYISDINNNTDGMYVVSSTGGVWRISRAKDYPDNVMTAEMRKIAMAAVLSGMRVNMCASPASSPNVIWAIELEA 121
               SCOP domains d1tiid_ D: Heat-labile toxin                                                                       SCOP domains
               CATH domains 1tiiD00 D:1-98  [code=2.40.50.50, no name defined]                                                 CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...hhhhhhh.....eee....eeeeeee......eeeeee....eeee.......hhhhhhhhhhhhhhhhhh...eeeeee.....eeeeeeeee. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------- Transcript
                 1tii D   1 GASQFFKDNCNRTTASLVEGVELTKYISDINNNTDGMYVVSSTGGVWRISRAKDYPDNVMTAEMRKIAMAAVLSGMRVNMCASPASSPNVIWAIELEA  98
                                    10        20        30        40        50        60        70        80        90

Chain E from PDB  Type:PROTEIN  Length:98
 aligned with E2BB_ECOLX | P43529 from UniProtKB/Swiss-Prot  Length:122

    Alignment length:98
                                    33        43        53        63        73        83        93       103       113
           E2BB_ECOLX    24 GASQFFKDNCNRTTASLVEGVELTKYISDINNNTDGMYVVSSTGGVWRISRAKDYPDNVMTAEMRKIAMAAVLSGMRVNMCASPASSPNVIWAIELEA 121
               SCOP domains d1tiie_ E: Heat-labile toxin                                                                       SCOP domains
               CATH domains 1tiiE00 E:1-98  [code=2.40.50.50, no name defined]                                                 CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...hhhhhhh.....eee....eeeeeee......eeeeee....eeee.......hhhhhhhhhhhhhhhhhh...eeeeee.....eeeeeeeee. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------- Transcript
                 1tii E   1 GASQFFKDNCNRTTASLVEGVELTKYISDINNNTDGMYVVSSTGGVWRISRAKDYPDNVMTAEMRKIAMAAVLSGMRVNMCASPASSPNVIWAIELEA  98
                                    10        20        30        40        50        60        70        80        90

Chain F from PDB  Type:PROTEIN  Length:98
 aligned with E2BB_ECOLX | P43529 from UniProtKB/Swiss-Prot  Length:122

    Alignment length:98
                                    33        43        53        63        73        83        93       103       113
           E2BB_ECOLX    24 GASQFFKDNCNRTTASLVEGVELTKYISDINNNTDGMYVVSSTGGVWRISRAKDYPDNVMTAEMRKIAMAAVLSGMRVNMCASPASSPNVIWAIELEA 121
               SCOP domains d1tiif_ F: Heat-labile toxin                                                                       SCOP domains
               CATH domains 1tiiF00 F:1-98  [code=2.40.50.50, no name defined]                                                 CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...hhhhhhhh....eee....eeeeeee......eeeeee....eeee.......hhhhhhhhhhhhhhhhhh...eeeeee.....eeeeeeeee. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------- Transcript
                 1tii F   1 GASQFFKDNCNRTTASLVEGVELTKYISDINNNTDGMYVVSSTGGVWRISRAKDYPDNVMTAEMRKIAMAAVLSGMRVNMCASPASSPNVIWAIELEA  98
                                    10        20        30        40        50        60        70        80        90

Chain G from PDB  Type:PROTEIN  Length:98
 aligned with E2BB_ECOLX | P43529 from UniProtKB/Swiss-Prot  Length:122

    Alignment length:98
                                    33        43        53        63        73        83        93       103       113
           E2BB_ECOLX    24 GASQFFKDNCNRTTASLVEGVELTKYISDINNNTDGMYVVSSTGGVWRISRAKDYPDNVMTAEMRKIAMAAVLSGMRVNMCASPASSPNVIWAIELEA 121
               SCOP domains d1tiig_ G: Heat-labile toxin                                                                       SCOP domains
               CATH domains 1tiiG00 G:1-98  [code=2.40.50.50, no name defined]                                                 CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...hhhhhhhh....eee....eeeeeee......eeeeee....eeee.......hhhhhhhhhhhhhhhhhh...eeeeee.....eeeeeeeee. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------- Transcript
                 1tii G   1 GASQFFKDNCNRTTASLVEGVELTKYISDINNNTDGMYVVSSTGGVWRISRAKDYPDNVMTAEMRKIAMAAVLSGMRVNMCASPASSPNVIWAIELEA  98
                                    10        20        30        40        50        60        70        80        90

Chain H from PDB  Type:PROTEIN  Length:98
 aligned with E2BB_ECOLX | P43529 from UniProtKB/Swiss-Prot  Length:122

    Alignment length:98
                                    33        43        53        63        73        83        93       103       113
           E2BB_ECOLX    24 GASQFFKDNCNRTTASLVEGVELTKYISDINNNTDGMYVVSSTGGVWRISRAKDYPDNVMTAEMRKIAMAAVLSGMRVNMCASPASSPNVIWAIELEA 121
               SCOP domains d1tiih_ H: Heat-labile toxin                                                                       SCOP domains
               CATH domains 1tiiH00 H:1-98  [code=2.40.50.50, no name defined]                                                 CATH domains
           Pfam domains (1) LT-IIB-1tiiH01 H:1-98                                                                              Pfam domains (1)
           Pfam domains (2) LT-IIB-1tiiH02 H:1-98                                                                              Pfam domains (2)
           Pfam domains (3) LT-IIB-1tiiH03 H:1-98                                                                              Pfam domains (3)
           Pfam domains (4) LT-IIB-1tiiH04 H:1-98                                                                              Pfam domains (4)
           Pfam domains (5) LT-IIB-1tiiH05 H:1-98                                                                              Pfam domains (5)
         Sec.struct. author ...hhhhhhhh....eee....eeeeeee......eeeeee....eeee.......hhhhhhhhhhhhhhhhhh...eeeeee.....eeeeeeeee. Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------- Transcript
                 1tii H   1 GASQFFKDNCNRTTASLVEGVELTKYISDINNNTDGMYVVSSTGGVWRISRAKDYPDNVMTAEMRKIAMAAVLSGMRVNMCASPASSPNVIWAIELEA  98
                                    10        20        30        40        50        60        70        80        90

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Asymmetric/Biological Unit

Classes(

)

Folds(

)

Superfamilies( (-)

)

Families(

)

Protein Domains( (-)

)

Organisms( (-)

)

Class: All beta proteins (24004)

Fold: OB-fold (1179)

Superfamily: Bacterial enterotoxins (188)

Family: Bacterial AB5 toxins, B-subunits (85)

Protein domain: Heat-labile toxin (24)

Escherichia coli, type IIB [TaxId: 562] (3)

1a	d1tiid_	D:
1b	d1tiie_	E:
1c	d1tiif_	F:
1d	d1tiig_	G:
1e	d1tiih_	H:

Class: Alpha and beta proteins (a+b) (23004)

Fold: ADP-ribosylation (157)

Superfamily: ADP-ribosylation (157)

Family: ADP-ribosylating toxins (85)

Protein domain: Heat-labile toxin, A-chain (10)

Escherichia coli, type IIB [TaxId: 562] (1)

d1tii.1

A:,C:

Asymmetric/Biological Unit

Clans(

)

Families(

)

Organisms( (-)

)

Clan: ADP-ribosyl (56)

Family: Enterotoxin_a (14)

Escherichia coli (8)

1a	Enterotoxin_a-1tiiC01	C:195-230
1b	Enterotoxin_a-1tiiC02	C:195-230

Clan: no clan defined [family: LT-IIB] (3)

Family: LT-IIB (3)

Escherichia coli (3)

2a	LT-IIB-1tiiH01	H:1-98
2b	LT-IIB-1tiiH02	H:1-98
2c	LT-IIB-1tiiH03	H:1-98
2d	LT-IIB-1tiiH04	H:1-98
2e	LT-IIB-1tiiH05	H:1-98

Asymmetric/Biological Unit(hide GO term definitions)

Chain A,C (E2BA_ECOLX | P43528)

molecular function
	GO:0003824	catalytic activity	Catalysis of a biochemical reaction at physiological temperatures. In biologically catalyzed reactions, the reactants are known as substrates, and the catalysts are naturally occurring macromolecular substances known as enzymes. Enzymes possess specific binding sites for substrates, and are usually composed wholly or largely of protein, but RNA that has catalytic activity (ribozyme) is often also regarded as enzymatic.
biological process
	GO:0009405	pathogenesis	The set of specific processes that generate the ability of an organism to induce an abnormal, generally detrimental state in another organism.
cellular component
	GO:0005576	extracellular region	The space external to the outermost structure of a cell. For cells without external protective or external encapsulating structures this refers to space outside of the plasma membrane. This term covers the host cell environment outside an intracellular parasite.

Chain D,E,F,G,H (E2BB_ECOLX | P43529)

biological process
	GO:0009405	pathogenesis	The set of specific processes that generate the ability of an organism to induce an abnormal, generally detrimental state in another organism.
cellular component
	GO:0005576	extracellular region	The space external to the outermost structure of a cell. For cells without external protective or external encapsulating structures this refers to space outside of the plasma membrane. This term covers the host cell environment outside an intracellular parasite.

Asymmetric/Biological Unit
	Complete Structure
		Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
		WebMol \| AstexViewer[tm]@PDBe (Java Applets, require no local installation except for Java; loading may be slow)
		STRAP (Java WebStart application, automatic local installation, requires Java; full application with system access!)
		RasMol (require local installation)
		Molscript (VRML) (requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

	Ligands, Modified Residues, Ions
(no "Ligands, Modified Residues, Ions" information available for 1tii)

	Sites
(no "Sites" information available for 1tii)

	Cis Peptide Bonds
		Ser D:87 - Pro D:88	[ RasMol ]
		Ser E:87 - Pro E:88	[ RasMol ]
		Ser F:87 - Pro F:88	[ RasMol ]
		Ser G:87 - Pro G:88	[ RasMol ]
		Ser H:87 - Pro H:88	[ RasMol ]
		Tyr D:55 - Pro D:56	[ RasMol ]
		Tyr E:55 - Pro E:56	[ RasMol ]
		Tyr F:55 - Pro F:56	[ RasMol ]
		Tyr G:55 - Pro G:56	[ RasMol ]
		Tyr H:55 - Pro H:56	[ RasMol ]
		Val A:175 - Pro A:176	[ RasMol ]

Jmol
	protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick [ Asym./Biol. Unit PNG format ](automatic orientation, automatically generated)
Molscript
	protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick [ mono PDF format \| stereo PDF format ](default orientation, automatically generated)
Ribbons
	ribbon, secondary structure, chain-specific coloring, gray background [ mono GIF format \| stereo GIF format ]
	ribbon, secondary structure, grey background [ mono GIF format \| stereo GIF format ]

Access by PDB/NDB ID
	1tii
		Family and Domain Information	:	ProDom \| SYSTERS
		General Structural Information	:	GlycoscienceDB \| MMDB \| NDB \| OCA \| PDB \| PDBe \| PDBj \| PDBsum \| PDBWiki \| PQS \| PROTEOPEDIA
		Orientation in Membranes	:	OPM
		Protein Surface	:	SURFACE
		Secondary Structure	:	DSSP (structure derived) \| HSSP (homology derived)
		Structural Genomics	:	GeneCensus
		Structural Neighbours	:	CE \| VAST
		Structure Classification	:	CATH \| Dali \| SCOP
		Validation and Original Data	:	BMRB Data View \| BMRB Restraints Grid \| EDS \| PROCHECK \| RECOORD \| WHAT_CHECK

Access by UniProt ID/Accession number
	E2BA_ECOLX \| P43528
		Comparative Protein Structure Models	:	ModBase
		Genomic Information	:	Ensembl
		Protein-protein Interaction	:	DIP
		Sequence, Family and Domain Information	:	InterPro \| Pfam \| SMART \| UniProtKB/SwissProt
	E2BB_ECOLX \| P43529
		Comparative Protein Structure Models	:	ModBase
		Genomic Information	:	Ensembl
		Protein-protein Interaction	:	DIP
		Sequence, Family and Domain Information	:	InterPro \| Pfam \| SMART \| UniProtKB/SwissProt

Access by Enzyme Classificator (EC Number)
	(no 'Enzyme Classificator' available)
		General Enzyme Information	:	BRENDA \| EC-PDB \| Enzyme \| IntEnz
		Pathway	:	KEGG \| MetaCyc

Access by Disease Identifier (MIM ID)
	(no 'MIM ID' available)
		Disease Information	:	OMIM

Access by GenAge ID
	(no 'GenAge ID' available)
		Age Related Information	:	GenAge

Access by PDB/NDB ID
		Domain Information	:	XDom
		Interatomic Contacts of Structural Units	:	CSU
		Ligand-protein Contacts	:	LPC
		Protein Cavities	:	castP
		Sequence and Secondary Structure	:	PDBCartoon
		Structure Alignment	:	STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
		Structure and Sequence Browser	:	STING

Access by UniProt ID/Accession number
	E2BA_ECOLX \| P43528
		Protein Disorder Prediction	:	DisEMBL \| FoldIndex \| GLOBPLOT (for more information see DisProt)
	E2BB_ECOLX \| P43529
		Protein Disorder Prediction	:	DisEMBL \| FoldIndex \| GLOBPLOT (for more information see DisProt)

UniProtKB/Swiss-Prot
	E2BB_ECOLX \| P43529	:	1qb5 1qcb 4fnf 4fo2 4fp5 5g3l

(no "Related Entries Specified in the PDB File" available for 1TII)

Description

Compounds

Structural Features

Chains, Units

Ligands, Modified Residues, Ions (0, 0)

Sites (0, 0)

SS Bonds (6, 6)

Cis Peptide Bonds (11, 11)

Sequence-Structure Mapping

SAPs(SNPs)/Variants (0, 0)

PROSITE Motifs (0, 0)

Exons (0, 0)

Sequences/Alignments

Classification and Annotation

SCOP Domains (2, 6)

CATH Domains (3, 7)

Pfam Domains (2, 7)

Gene Ontology (3, 5)

Visualization

Interactive Views

Still Images

Databases and Analysis Tools

Databases

Analysis Tools

Related Entries

Entries Sharing at Least One Protein Chain (UniProt ID)

Related Entries Specified in the PDB File
