(-) Description

Title :  CRYSTAL STRUCTURE OF XYLOSE ISOMERASE FROM STREPTOMYCES DIASTATICUS NO.7 M1033 AT 1.85 A RESOLUTION

Authors :  L. Niu, M. Teng, X. Zhu
Date :  29 Jun 99  (Deposition) - 29 Jun 00  (Release) - 13 Jul 11  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  1.85
Chains :  Asym. Unit :  A,B
Biol. Unit 1:  A,B  (2x)
Keywords :  Isomerase, Xylose Isomerase, Glucose Isomerase, Streptomyces, True Space Group (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  X. Zhu, M. Teng, L. Niu, C. Xu, Y. Wang
Structure Of Xylose Isomerase From Streptomyces Diastaticus No. 7 Strain M1033 At 1. 85 A Resolution.
Acta Crystallogr. , Sect. D V. 56 129 2000
PubMed-ID: 10666592  |  Reference-DOI: 10.1107/S0907444999015097
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - PROTEIN (XYLOSE ISOMERASE)
    Chains: A, B
    EC Number: 5.3.1.5
    Organism Scientific: STREPTOMYCES DIASTATICUS
    Organism Taxid: 1956
    Strain: M1033
    Synonym: D-XYLOSE KETOL ISOMERASE, D-GLUCOSE ISOMERASE

 Structural Features

(-) Chains, Units

  12
Asymmetric Unit : AB
Biological Unit 1 (2x): AB

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (1, 4)

Asymmetric Unit (1, 4)
No.NameCountTypeFull Name
1CO4Ligand/IonCOBALT (II) ION
Biological Unit 1 (0, 0)
No.NameCountTypeFull Name
1CO-1Ligand/IonCOBALT (II) ION

(-) Sites  (4, 4)

Asymmetric Unit (4, 4)
No.NameEvidenceResiduesDescription
1AC1SOFTWAREGLU A:180 , GLU A:216 , ASP A:244 , ASP A:286BINDING SITE FOR RESIDUE CO A 400
2AC2SOFTWAREGLU B:680 , GLU B:716 , ASP B:744 , ASP B:786BINDING SITE FOR RESIDUE CO B 900
3AC3SOFTWAREGLU A:216 , HIS A:219 , ASP A:254 , ASP A:256 , HOH A:1635BINDING SITE FOR RESIDUE CO A 401
4AC4SOFTWAREGLU B:716 , HIS B:719 , ASP B:754 , ASP B:756 , HOH B:1636BINDING SITE FOR RESIDUE CO B 901

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 1QT1)

(-) Cis Peptide Bonds  (2, 2)

Asymmetric Unit
No.Residues
1Glu A:185 -Pro A:186
2Glu B:685 -Pro B:686

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 1QT1)

(-) PROSITE Motifs  (1, 2)

Asymmetric Unit (1, 2)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1XYLOSE_ISOMERASEPS51415 Xylose isomerase family profile.XYLA_STRDI4-383
 		  2A:3-382
B:503-882
Biological Unit 1 (1, 4)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1XYLOSE_ISOMERASEPS51415 Xylose isomerase family profile.XYLA_STRDI4-383
 		  4A:3-382
B:503-882

(-) Exons   (0, 0)

(no "Exon" information available for 1QT1)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:387
 aligned with XYLA_STRDI | P50910 from UniProtKB/Swiss-Prot  Length:388

    Alignment length:387
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361       371       381
           XYLA_STRDI     2 SYQPTPEDKFTFGLWTVGWQGRDPFGDATRGALDPAESVRRLAELGAHGVTFHDDDLIPFGATDSERAEHIKRFRQGLDETGMKVPMATTNLFTHPVFKDGGFTANDRDVRRYAVRKTIRNIDLAVELGAQTYVAWGGREGAESGAAKDVRVALDRMKEAFDLLGEYVTSQGYDTPFAIEPKPNEPRGDILLPTIGHALAFIDGLERPELYGVNPEVGHEQMAGLNFPHGIAQALWAGKLFHIDLNGQSGIKYDQDLRFGPGDLAAAFWLVDLLESAGYEGPRHFDFKPPRTEDFDGVWASAAGCMRNYLILKERAAAFRADPEVQEALRAARLDELAQPTAGDGLQALLPDRSAFEDFDPDAAAARGMAFERLDQLAMDHLLGARG 388
               SCOP domains d1qt1a_ A: D-xylose isomerase                                                                                                                                                                                                                                                                                                                                                                       SCOP domains
               CATH domains 1qt1A00 A:1-387 Divalent-metal-dependent TIM barrel enzymes                                                                                                                                                                                                                                                                                                                                         CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .....hhh.eeeehhhh.................hhhhhhhhhhh...eeeeehhhh......hhhhhhhhhhhhhhhhhh.....eee......hhh.........hhhhhhhhhhhhhhhhhhhhh...eeee..............hhhhhhhhhhhhhhhhhhhhhh....eeee...............hhhhhhhhhh...hhheeeeeehhhhhhh...hhhhhhhhhh...eeeee...................hhhhhhhhhhhhhh.....eee.........hhhhhhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhh..hhhhh.......hhhhhh.hhh.....hhhhhh....hhhhhhhhhhhhh.... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --XYLOSE_ISOMERASE  PDB: A:3-382 UniProt: 4-383                                                                                                                                                                                                                                                                                                                                               ----- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1qt1 A   1 SYQPTPEDKFTFGLWTVGWQGRDPFGDATRGALDPAESVRRLAELGAHGVTFHDDDLIPFGATDSERAEHIKRFRQGLDETGMKVPMATTNLFTHPVFKDGGFTANDRDVRRYALRKTIRNIDLAVELGAQTYVAWGGREGAESGAAKDVRVALDRMKEAFDLLGEYVTSQGYDTPFAIEPKPNEPRGDILLPTIGHALAFIDGLERPELYGVNPEVGHEQMAGLNFPHGIAQALWAGKLFHIDLNGQSGIKYDQDLRFGPGDLRAAFWLVDLLESAGYEGPRHFDFKPPRTEDFDGVWASAAGCMRNYLILKERAAAFRADPEVQEALRAARLDELAQPTAGDGLQALLPDRSAFEDFDPDAAAARGMAFERLDQLAMDHLLGARG 387
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380


Chain B from PDB  Type:PROTEIN  Length:387
 aligned with XYLA_STRDI | P50910 from UniProtKB/Swiss-Prot  Length:388

    Alignment length:387
                                    11        21        31        41        51        61        71        81        91       101       111       121       131       141       151       161       171       181       191       201       211       221       231       241       251       261       271       281       291       301       311       321       331       341       351       361       371       381
           XYLA_STRDI     2 SYQPTPEDKFTFGLWTVGWQGRDPFGDATRGALDPAESVRRLAELGAHGVTFHDDDLIPFGATDSERAEHIKRFRQGLDETGMKVPMATTNLFTHPVFKDGGFTANDRDVRRYAVRKTIRNIDLAVELGAQTYVAWGGREGAESGAAKDVRVALDRMKEAFDLLGEYVTSQGYDTPFAIEPKPNEPRGDILLPTIGHALAFIDGLERPELYGVNPEVGHEQMAGLNFPHGIAQALWAGKLFHIDLNGQSGIKYDQDLRFGPGDLAAAFWLVDLLESAGYEGPRHFDFKPPRTEDFDGVWASAAGCMRNYLILKERAAAFRADPEVQEALRAARLDELAQPTAGDGLQALLPDRSAFEDFDPDAAAARGMAFERLDQLAMDHLLGARG 388
               SCOP domains d1qt1b_ B: D-xylose isomerase                                                                                                                                                                                                                                                                                                                                                                       SCOP domains
               CATH domains 1qt1B00 B:501-887 Divalent-metal-dependent TIM barrel enzymes                                                                                                                                                                                                                                                                                                                                       CATH domains
           Pfam domains (1) --------------------------------------AP_endonuc_2-1qt1B01 B:539-764                                                                                                                                                                                                    --------------------------------------------------------------------------------------------------------------------------- Pfam domains (1)
           Pfam domains (2) --------------------------------------AP_endonuc_2-1qt1B02 B:539-764                                                                                                                                                                                                    --------------------------------------------------------------------------------------------------------------------------- Pfam domains (2)
         Sec.struct. author .....hhh.eeeehhhh.................hhhhhhhhhhh...eeeeehhhh......hhhhhhhhhhhhhhhhhh.....eee......hhh.........hhhhhhhhhhhhhhhhhhhh....eeee.........hhh..hhhhhhhhhhhhhhhhhhhhhh....eeee...............hhhhhhhhhh...hhheeeeeehhhhhhh...hhhhhhhhhhh..eeeee...................hhhhhhhhhhhhhh.....eee.........hhhhhhhhhhhhhhhhhhhhhhhhhhh.hhhhhhhhh..hhhhh.......hhhhhh.hhh.....hhhhhh....hhhhhhhhhhhh..... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --XYLOSE_ISOMERASE  PDB: B:503-882 UniProt: 4-383                                                                                                                                                                                                                                                                                                                                             ----- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1qt1 B 501 SYQPTPEDKFTFGLWTVGWQGRDPFGDATRGALDPAESVRRLAELGAHGVTFHDDDLIPFGATDSERAEHIKRFRQGLDETGMKVPMATTNLFTHPVFKDGGFTANDRDVRRYALRKTIRNIDLAVELGAQTYVAWGGREGAESGAAKDVRVALDRMKEAFDLLGEYVTSQGYDTPFAIEPKPNEPRGDILLPTIGHALAFIDGLERPELYGVNPEVGHEQMAGLNFPHGIAQALWAGKLFHIDLNGQSGIKYDQDLRFGPGDLRAAFWLVDLLESAGYEGPRHFDFKPPRTEDFDGVWASAAGCMRNYLILKERAAAFRADPEVQEALRAARLDELAQPTAGDGLQALLPDRSAFEDFDPDAAAARGMAFERLDQLAMDHLLGARG 887
                                   510       520       530       540       550       560       570       580       590       600       610       620       630       640       650       660       670       680       690       700       710       720       730       740       750       760       770       780       790       800       810       820       830       840       850       860       870       880
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 2)

Asymmetric Unit
(-)
Class: Alpha and beta proteins (a/b) (23833)

(-) CATH Domains  (1, 2)

Asymmetric Unit
(-)
Class: Alpha Beta (26913)

(-) Pfam Domains  (1, 2)

Asymmetric Unit
(-)
Clan: TIM_barrel (694)

(-) Gene Ontology  (8, 8)

Asymmetric Unit(hide GO term definitions)
Chain A,B   (XYLA_STRDI | P50910)
molecular function
    GO:0016853    isomerase activity    Catalysis of the geometric or structural changes within one molecule. Isomerase is the systematic name for any enzyme of EC class 5.
    GO:0000287    magnesium ion binding    Interacting selectively and non-covalently with magnesium (Mg) ions.
    GO:0046872    metal ion binding    Interacting selectively and non-covalently with any metal ion.
    GO:0009045    xylose isomerase activity    Catalysis of the reaction: D-xylose = D-xylulose.
biological process
    GO:0042732    D-xylose metabolic process    The chemical reactions and pathways involving D-xylose, a naturally occurring plant polysaccharide.
    GO:0005975    carbohydrate metabolic process    The chemical reactions and pathways involving carbohydrates, any of a group of organic compounds based of the general formula Cx(H2O)y. Includes the formation of carbohydrate derivatives by the addition of a carbohydrate residue to another molecule.
    GO:0006098    pentose-phosphate shunt    The glucose-6-phosphate catabolic process in which, coupled to NADPH synthesis, glucose-6-P is oxidized with the formation of carbon dioxide (CO2) and ribulose 5-phosphate; ribulose 5-P then enters a series of reactions interconverting sugar phosphates. The pentose phosphate pathway is a major source of reducing equivalents for biosynthesis reactions and is also important for the conversion of hexoses to pentoses.
cellular component
    GO:0005737    cytoplasm    All of the contents of a cell excluding the plasma membrane and nucleus, but including other subcellular structures.

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    CO  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    AC2  [ RasMol ]  +environment [ RasMol ]
    AC3  [ RasMol ]  +environment [ RasMol ]
    AC4  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
    Glu A:185 - Pro A:186   [ RasMol ]
    Glu B:685 - Pro B:686   [ RasMol ]

Biological Unit
  Complete Structure
    Biological Unit 1  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Asym. Unit - sites PNG format | Biol. Unit 1 PNG format | Biol. Unit 1 - sites PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  1qt1
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  XYLA_STRDI | P50910
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/SwissProt

Access by Enzyme Classificator   (EC Number)
  5.3.1.5
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  XYLA_STRDI | P50910
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/Swiss-Prot
        XYLA_STRDI | P50910: 1clk

(-) Related Entries Specified in the PDB File

(no "Related Entries Specified in the PDB File" available for 1QT1)
