(-) Description

Title :  USTILAGO MAYDIS KILLER TOXIN KP6 ALPHA-SUBUNIT

Authors :  N. Li, M. Erman, W. Pangborn, W. L. Duax, C. -M. Park, J. Bruenn, D. Ghosh
Date :  28 May 99  (Deposition) - 21 Jul 99  (Release) - 24 Feb 09  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  1.80
Chains :  Asym./Biol. Unit :  A
Keywords :  Killer Toxin, Ion Channel Modulator (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  N. Li, M. Erman, W. Pangborn, W. L. Duax, C. M. Park, J. Bruenn, D. Ghosh
Structure Of Ustilago Maydis Killer Toxin Kp6 Alpha-Subunit. A Multimeric Assembly With A Central Pore.
J. Biol. Chem. V. 274 20425 1999
PubMed-ID: 10400668  |  Reference-DOI: 10.1074/JBC.274.29.20425
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - PROTEIN (TOXIN)
    Chains: A
    Organism Scientific: USTILAGO MAYDIS
    Organism Taxid: 5270

 Structural Features

(-) Chains, Units

  1
Asymmetric/Biological Unit : A

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (1, 1)

Asymmetric/Biological Unit (1, 1)
No.NameCountTypeFull Name
1SO41Ligand/IonSULFATE ION

(-) Sites  (1, 1)

Asymmetric Unit (1, 1)
No.NameEvidenceResiduesDescription
1AC1SOFTWAREASN A:1 , SER A:11 , LYS A:13 , HOH A:183BINDING SITE FOR RESIDUE SO4 A 1234

(-) SS Bonds  (4, 4)

Asymmetric/Biological Unit
No.Residues
1A:5 -A:12
2A:16 -A:74
3A:18 -A:65
4A:35 -A:51

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 1KP6)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (1, 1)

Asymmetric/Biological Unit (1, 1)
  dbSNPPDB
No.SourceVariant IDVariantUniProt IDStatusIDChainVariant
1UniProtVAR_KP6T_UMV6_001 *C78RKP6T_UMV6  ---  ---AC51R
   * ID not provided by source
  SNP/SAP Summary Statistics (UniProtKB/Swiss-Prot)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 1KP6)

(-) Exons   (0, 0)

(no "Exon" information available for 1KP6)

(-) Sequences/Alignments

Asymmetric/Biological Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:79
 aligned with KP6T_UMV6 | P16948 from UniProtKB/Swiss-Prot  Length:219

    Alignment length:79
                                    37        47        57        67        77        87        97
            KP6T_UMV6    28 NNAFCAGFGLSCKWECWCTAHGTGNELRYATAAGCGDHLSKSYYDARAGHCLFSDDLRNQFYSHCSSLNNNMSCRSLSK 106
               SCOP domains d1kp6a_ A: Killer toxin KP6 alpha-subunit                                       SCOP domains
               CATH domains 1kp6A00 A:1-79  [code=3.30.70.440, no name defined]                             CATH domains
               Pfam domains ------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .hhhhhhh.....eeeeee........hhhhhhh.hhh...eeee....eeee....hhhhhhhhhhh..eeeeee... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------R---------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------- Transcript
                 1kp6 A   1 NNAFCAGFGLSCKWECWCTAHGTGNELRYATAAGCGDHLSKSYYDARAGHCLFSDDLRNQFYSHCSSLNNNMSCRSLSK  79
                                    10        20        30        40        50        60        70
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 1)

Asymmetric/Biological Unit
(-)
Class: Alpha and beta proteins (a+b) (23004)

(-) CATH Domains  (1, 1)

Asymmetric/Biological Unit
(-)
Class: Alpha Beta (26913)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 1KP6)

(-) Gene Ontology  (1, 1)

Asymmetric/Biological Unit(hide GO term definitions)
Chain A   (KP6T_UMV6 | P16948)
cellular component
    GO:0005576    extracellular region    The space external to the outermost structure of a cell. For cells without external protective or external encapsulating structures this refers to space outside of the plasma membrane. This term covers the host cell environment outside an intracellular parasite.

 Visualization

(-) Interactive Views

Asymmetric/Biological Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    SO4  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 1kp6)


(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym./Biol. Unit PNG format | Asym./Biol. Unit - sites PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  1kp6
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  KP6T_UMV6 | P16948
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/SwissProt

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  KP6T_UMV6 | P16948
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/Swiss-Prot
        KP6T_UMV6 | P16948: 4gvb

(-) Related Entries Specified in the PDB File

(no "Related Entries Specified in the PDB File" available for 1KP6)
