Title :   CRYSTAL STRUCTURE OF THE CARBOXYPEPTIDASE A FROM HELICOVERPA ARMIGERA

Authors :   E. Estebanez-Perpina, A. Bayes, J. Vendrell, M. A. Jongsma, D. P. Bown, J. A. Gatehouse, R. Huber, W. Bode, F. X. Aviles, D. Reverter

Date :   07 Aug 01 (Deposition) - 07 Aug 02 (Release) - 24 Feb 09 (Revision)

Method :   X-RAY DIFFRACTION

Resolution :   2.50

Chains :   Asym./Biol. Unit : A

Keywords :   Pro-Protein, Hydrolase (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :   E. Estebanez-Perpina, A. Bayes, J. Vendrell, M. A. Jongsma, D. P. Bown, J. A. Gatehouse, R. Huber, W. Bode, F. X. Aviles, D. Reverter
Crystal Structure Of A Novel Mid-Gut Procarboxypeptidase From The Cotton Pest Helicoverpa Armigera.
J. Mol. Biol. V. 313 629 2001
PubMed-ID: 11676544 | Reference-DOI: 10.1006/JMBI.2001.5076
(for further references see the PDB file header)

Molecule 1 - CARBOXYPEPTIDASE A
	Chains	:	A
	EC Number	:	3.4.17.1
	Engineered	:	YES
	Expression System	:	PICHIA PASTORIS
	Expression System Plasmid	:	PPIC9
	Expression System Strain	:	GS115
	Expression System Taxid	:	4922
	Expression System Vector Type	:	PLASMID
	Organism Common	:	COTTON BOLLWORM
	Organism Scientific	:	HELICOVERPA ARMIGERA
	Organism Taxid	:	29058
	Synonym	:	PROCARBOXYPEPTIDASE A
	Tissue	:	MIDGUT

		1
Asymmetric/Biological Unit	:	A

Summary Information (see also Sequences/Alignments below)

Asymmetric/Biological Unit (1, 1)

No.	Name	Count	Type	Full Name
1	ZN	1	Ligand/Ion	ZINC ION

Asymmetric Unit (1, 1)

No.	Name	Evidence	Residues	Description
1	AC1	SOFTWARE	HIS A:69 , GLU A:72 , HIS A:196 , HOH A:513	BINDING SITE FOR RESIDUE ZN A 413

Asymmetric/Biological Unit

No.	Residues
1	A:138	-	A:161

(no "Cis Peptide Bond" information available for 1JQG)

(no "SAP(SNP)/Variant" information available for 1JQG)

(no "PROSITE Motif" information available for 1JQG)

(no "Exon" information available for 1JQG)

Asymmetric/Biological Unit

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain A from PDB  Type:PROTEIN  Length:409
 aligned with O97389_HELAM | O97389 from UniProtKB/TrEMBL  Length:433

    Alignment length:409
                                    27        37        47        57        67        77        87        97       107       117       127       137       147       157       167       177       187       197       207       217       227       237       247       257       267       277       287       297       307       317       327       337       347       357       367       377       387       397       407       417
        O97389_HELAM     18 HEIYDGHAVYQVDVASMDQVKLVHDFENDLMLDVWSDAVPGRPGKVLVPKFKREIFENFLKQSGVQYKLEVENVKEQLELEDQLLAAAAAKSNSTRSRLSFDKIHSYEEVDAYLQELAKEFPNVVTVVEGGKSFEGRSIKYLRISTTNFQDASKPVVMMQSLLHCREWVTLPATLYAIHKLVIDVTESDLINNIDWIILPVANPDGYVHTFGGDRYWRKNRATGYMAGNLCMGVDLNRNFGMNWGTASSSSVCSDTFHGRSAFSEPESSVIRDIIAEHRNRMALYLDIHSFGSMILYGYGNGVLPSNALQLHLIGVQMAQAIDRVKWSSNKDYIVGNIFHVLYAASGGASDYAMQAAAPFSYTYELPAYRNSVWFDGFLVDPDFIEQAGFETWEGIKVGARAAAAAAKE  426
               SCOP domains d1jqga2 A:4P-100P Procarboxypeptidase A                                                     d1jqga1 A:1-310 Carboxypeptidase A                                                                                                                                                                                                                                                                                            SCOP domains
               CATH domains 1jqgA01 A:4P-99P  [code=3.30.70.340, no name defined]                                      ---------1jqgA02 A:9-310 Zn peptidases                                                                                                                                                                                                                                                                                         CATH domains
               Pfam domains ---------Propep_M14-1jqgA02 A:13P-90P                                             ---------------------------Peptidase_M14-1jqgA01 A:18-296                                                                                                                                                                                                                                                                -------------- Pfam domains
         Sec.struct. author ...............hhhhhhhhhhhhhhh..................hhhhhhhhhhhhhhhh.........hhhhhhhhhhhhhhhhhhh.............hhhhhhhhhhhhhhhh...eeeeeeee.....eeeeeee...........eeeeee.......hhhhhhhhhhhhhhh....hhhhhh.eeeee...hhhhhhhhhh.............hhhhh....hhhhh.........................hhhhhhhhhhhhhh...eeeeeeee....eeee.........hhhhhhhhhhhhhhhhhh.........eeeehhhhh.....hhhhhhhhhh..eeeeee..................hhhhhhhhhhhhhhhhhhhhhh.... Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                1jqg A   4P HEIYDGHAVYQVDVASMDQVKLVHDFENDLMLDVWSDAVPGRPGKVLVPKFKREIFENFLKQSGVQYKLEVENVKEQLELEDQLLAAAAAKSNSTRSRLSFDKIHSYEEVDAYLQELAKEFPNVVTVVEGGKSFEGRSIKYLRISTTNFQDASKPVVMMQSLLHCREWVTLPATLYAIHKLVIDVTESDLINNIDWIILPVANPDGYVHTFGGDRYWRKNRATGYMAGNLCMGVDLNRNFGMNWGTASSSSVCSDTFHGRSAFSEPESSVIRDIIAEHRNRMALYLDIHSFGSMILYGYGNGVLPSNALQLHLIGVQMAQAIDRVKWSSNKDYIVGNIFHVLYAASGGASDYAMQAAAPFSYTYELPAYRNSVWFDGFLVDPDFIEQAGFETWEGIKVGARAAAAAAKE  310
                            |||||||13P|||||||23P|||||||33P|||||||48P|||||||58P|||||||68P|||||||78P|||||||88P|||||||98P|||      8        18        28        38        48       55C        65        75        85       |99       109       119       129    || 137       147   ||  158       168       178       187       197       207|      218       228      |235       245       255       265      |272     | 281       291       301
                            ||||||12P||||||21P||||||30P||||||39P||||||53P||||||62P||||||71P||||||80P||||||89P||||||98P|||                                                    55A||                                    93|                                133A|               151|                              186A                  207|                      234A||                                  271A||   277A
                           4P||||||13P||||||22P||||||31P||||||40P||||||54P||||||63P||||||72P||||||81P||||||90P||||||99P||                                                     55B|                                     98                                 133B                153                                                     209                       234B|                                   271B|
                            5P||||||14P||||||23P||||||32P||||||41P||||||55P||||||64P||||||73P||||||82P||||||91P|||||100P|                                                      55C                                                                                                                                                                               234C                                    271C
                             6P||||| 15P||||| 24P||||| 33P||||| 42P||||| 56P||||| 65P||||| 74P||||| 83P||||| 92P|||||   1
                              7P||||  16P||||  25P||||  34P||||  48P||||  57P||||  66P||||  75P||||  84P||||  93P||||
                               8P|||   17P|||   26P|||   35P|||   49P|||   58P|||   67P|||   76P|||   85P|||   94P|||
                                9P||    18P||    27P||    36P||    50P||    59P||    68P||    77P||    86P||    95P||
                                10P|     19P|     28P|     37P|     51P|     60P|     69P|     78P|     87P|     96P|
                                 11P      20P      29P      38P      52P      61P      70P      79P      88P      97P

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Asymmetric/Biological Unit

Classes(

)

Architectures( (-)

)

Topologies( (-)

)

Homologous Superfamilies( (-)

)

Organisms( (-)

)

Class: Alpha Beta (26913)

Architecture: 2-Layer Sandwich (8480)

Topology: Alpha-Beta Plaits (1688)

Homologous Superfamily: [code=3.30.70.340, no name defined] (8)

Cotton bollworm (Helicoverpa armigera) (1)

1jqgA01

A:4P-99P

Architecture: 3-Layer(aba) Sandwich (12045)

Topology: Aminopeptidase (284)

Homologous Superfamily: Zn peptidases (137)

Cotton bollworm (Helicoverpa armigera) (1)

1jqgA02

A:9-310

Asymmetric/Biological Unit(hide GO term definitions)

Chain A (O97389_HELAM | O97389)

molecular function
	GO:0004180	carboxypeptidase activity	Catalysis of the hydrolysis of the terminal or penultimate peptide bond at the C-terminal end of a peptide or polypeptide.
	GO:0016787	hydrolase activity	Catalysis of the hydrolysis of various bonds, e.g. C-O, C-N, C-C, phosphoric anhydride bonds, etc. Hydrolase is the systematic name for any enzyme of EC class 3.
	GO:0046872	metal ion binding	Interacting selectively and non-covalently with any metal ion.
	GO:0004181	metallocarboxypeptidase activity	Catalysis of the hydrolysis of C-terminal amino acid residues from a polypeptide chain by a mechanism in which water acts as a nucleophile, one or two metal ions hold the water molecule in place, and charged amino acid side chains are ligands for the metal ions.
	GO:0008270	zinc ion binding	Interacting selectively and non-covalently with zinc (Zn) ions.
biological process
	GO:0006508	proteolysis	The hydrolysis of proteins into smaller polypeptides and/or amino acids by cleavage of their peptide bonds.
