1GJQ - JenaLib

Asym./Biol. Unit (Jmol Viewer)

Asym./Biol. Unit - sites (Jmol Viewer)

Title :   PSEUDOMONAS AERUGINOSA CD1 NITRITE REDUCTASE REDUCED CYANIDE COMPLEX

Authors :   D. Nurizzo, K. Brown, M. Tegoni, C. Cambillau

Date :   01 Aug 01 (Deposition) - 01 Aug 02 (Release) - 24 Feb 09 (Revision)

Method :   X-RAY DIFFRACTION

Resolution :   2.70

Chains :   Asym./Biol. Unit : A,B

Keywords :   Reductase, Oxidoreductase, Electron Transport, Heme (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :   W. Sun, M. Arese, M. Brunori, D. Nurizzo, K. Brown, C. Cambillau, M. Tegoni, F. Cutruzzola
Cyanide Binding To Cd(1) Nitrite Reductase From Pseudomonas Aeruginosa: Role Of The Active-Site His369 In Ligand Stabilization.
Biochem. Biophys. Res. Commun. V. 291 1 2002
PubMed-ID: 11829453 | Reference-DOI: 10.1006/BBRC.2002.6391

Molecule 1 - NITRITE REDUCTASE
	Chains	:	A, B
	EC Number	:	1.9.3.2
	Organism Scientific	:	PSEUDOMONAS AERUGINOSA
	Organism Taxid	:	287
	Synonym	:	CYTOCHROME CD1, CYTOCHROME OXIDASE

		1	2
Asymmetric/Biological Unit	:	A	B

Summary Information (see also Sequences/Alignments below)

Asymmetric/Biological Unit (3, 6)

No.	Name	Count	Type	Full Name
1	CYN	2	Ligand/Ion	CYANIDE ION
2	DHE	2	Ligand/Ion	HEME D
3	HEC	2	Ligand/Ion	HEME C

Asymmetric Unit (6, 6)

No.	Name	Evidence	Residues	Description
1	AC1	SOFTWARE	HIS A:327 , HIS A:369 , DHE A:602 , TYR B:10	BINDING SITE FOR RESIDUE CYN A 603
2	AC2	SOFTWARE	TYR A:10 , HIS B:327 , HIS B:369 , DHE B:602	BINDING SITE FOR RESIDUE CYN B 603
3	AC3	SOFTWARE	ARG A:46 , CYS A:47 , CYS A:50 , HIS A:51 , THR A:59 , GLY A:60 , LYS A:61 , LEU A:63 , ARG A:71 , LEU A:79 , THR A:84 , LEU A:86 , GLY A:87 , MET A:88 , TRP A:91	BINDING SITE FOR RESIDUE HEC A 601
4	AC4	SOFTWARE	ARG A:156 , HIS A:182 , ARG A:185 , ARG A:198 , ARG A:225 , SER A:226 , TYR A:245 , ALA A:284 , ILE A:285 , HIS A:327 , ARG A:372 , PHE A:425 , PHE A:441 , GLN A:483 , GLY A:531 , PHE A:533 , CYN A:603 , HOH A:2103 , HOH A:2107 , HOH A:2124 , HOH A:2185 , HOH A:2209 , HOH A:2282 , HOH A:2283 , HOH A:2284 , HOH A:2285 , TYR B:10 , HOH B:2009	BINDING SITE FOR RESIDUE DHE A 602
5	AC5	SOFTWARE	ARG B:46 , CYS B:47 , CYS B:50 , HIS B:51 , THR B:59 , GLY B:60 , LYS B:61 , LEU B:63 , ARG B:71 , LEU B:79 , THR B:84 , LEU B:86 , GLY B:87 , MET B:88 , TRP B:91 , HOH B:2308	BINDING SITE FOR RESIDUE HEC B 601
6	AC6	SOFTWARE	TYR A:10 , ALA A:13 , ARG B:156 , HIS B:182 , ILE B:183 , ARG B:185 , ARG B:198 , ARG B:225 , SER B:226 , TYR B:245 , ALA B:284 , ILE B:285 , HIS B:327 , ARG B:372 , PHE B:425 , PHE B:441 , GLN B:483 , GLY B:531 , PHE B:533 , CYN B:603 , HOH B:2120 , HOH B:2122 , HOH B:2124 , HOH B:2310 , HOH B:2311 , HOH B:2312 , HOH B:2313 , HOH B:2314	BINDING SITE FOR RESIDUE DHE B 602

(no "SS Bond" information available for 1GJQ)

Asymmetric/Biological Unit

No.	Residues
1	Trp A:246	-	Pro A:247
2	Trp B:246	-	Pro B:247

(no "SAP(SNP)/Variant" information available for 1GJQ)

Asymmetric/Biological Unit (1, 2)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	CYTC	PS51007	Cytochrome c family profile.	NIRS_PSEAE	59-138	2	A:34-113 B:34-113

(no "Exon" information available for 1GJQ)

Asymmetric/Biological Unit

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain A from PDB  Type:PROTEIN  Length:541
 aligned with NIRS_PSEAE | P24474 from UniProtKB/Swiss-Prot  Length:568

    Alignment length:541
                                    37        47        57        67        77        87        97       107       117       127       137       147       157       167       177       187       197       207       217       227       237       247       257       267       277       287       297       307       317       327       337       347       357       367       377       387       397       407       417       427       437       447       457       467       477       487       497       507       517       527       537       547       557       567
           NIRS_PSEAE    28 DMKAAEQYQGAASAVDPAHVVRTNGAPDMSESEFNEAKQIYFQRCAGCHGVLRKGATGKPLTPDITQQRGQQYLEALITYGTPLGMPNWGSSGELSKEQITLMAKYIQHTPPQPPEWGMPEMRESWKVLVKPEDRPKKQLNDLDLPNLFSVTLRDAGQIALVDGDSKKIVKVIDTGYAVHISRMSASGRYLLVIGRDARIDMIDLWAKEPTKVAEIKIGIEARSVESSKFKGYEDRYTIAGAYWPPQFAIMDGETLEPKQIVSTRGMTVDTQTYHPEPRVAAIIASHEHPEFIVNVKETGKVLLVNYKDIDNLTVTSIGAAPFLHDGGWDSSHRYFMTAANNSNKVAVIDSKDRRLSALVDVGKTPHPGRGANFVHPKYGPVWSTSHLGDGSISLIGTDPKNHPQYAWKKVAELQGQGGGSLFIKTHPKSSHLYVDTTFNPDARISQSVAVFDLKNLDAKYQVLPIAEWADLGEGAKRVVQPEYNKRGDEVWFSVWNGKNDSSALVVVDDKTLKLKAVVKDPRLITPTGKFNVYNTQHDVY 568
               SCOP domains d1gjqa1 A:3-117 N-terminal (heme c) domain of cytochrome cd1-nitrite reductase                                     d1gjqa2 A:118-543 C-terminal (heme d1) domain of cytochrome cd1-nitrite reductase                                                                                                                                                                                                                                                                                                                                                          SCOP domains
               CATH domains ---1gjqA01 A:6-116 Cytochrome c                                                                                   1gjqA02 A:117-543  [code=2.140.10.20, no name defined]                                                                                                                                                                                                                                                                                                                                                                                      CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ..hhhhhhh......hhhhh.........hhhhhhhhhhhhhhhhhhhhh...........hhhhhhhhhhhhhhhhhhhh..............hhhhhhhhhhhh..........hhhhhhhhhee..hhhhh........hhh.eeeeee....eeeeee.....eeeeee....eeeeee.....eeeeee...eeeeee......eeeeeee...eeeeeee.........eeeeeeee..eeeeee.....eeeeee..ee......ee....eeeeee.....eeeeee....eeeeee......eeeeeee....eeeeee.....eeeeee....eeeeee....eeeeeee....eeeeeeeeeee...eeeeeeee....eeeeee............eeeeee........ee......eeee......hhhhhh.eeeee........eeehhhhhhh......eeeeeee.....eeeeeee.......eeeeee.....eeeee.......eeeeeehhhhhh... Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------CYTC  PDB: A:34-113 UniProt: 59-138                                             ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1gjq A   3 DMKAAEQYQGAASAVDPAHVVRTNGAPDMSESEFNEAKQIYFQRCAGCHGVLRKGATGKPLTPDITQQRGQQYLEALITYGTPLGMPNWGSSGELSKEQITLMAKYIQHTPPQPPEWGMPEMRESWKVLVKPEDRPKKQLNDLDLPNLFSVTLRDAGQIALVDGDSKKIVKVIDTGYAVHISRMSASGRYLLVIGRDARIDMIDLWAKEPTKVAEIKIGIEARSVESSKFKGYEDRYTIAGAYWPPQFAIMDGETLEPKQIVSTRGMTVDTQTYHPEPRVAAIIASHEHPEFIVNVKETGKVLLVNYKDIDNLTVTSIGAAPFLHDGGWDSSHRYFMTAANNSNKVAVIDSKDRRLSALVDVGKTPHPGRGANFVHPKYGPVWSTSHLGDGSISLIGTDPKNHPQYAWKKVAELQGQGGGSLFIKTHPKSSHLYVDTTFNPDARISQSVAVFDLKNLDAKYQVLPIAEWADLGEGAKRVVQPEYNKRGDEVWFSVWNGKNDSSALVVVDDKTLKLKAVVKDPRLITPTGKFNVYNTQHDVY 543
                                    12        22        32        42        52        62        72        82        92       102       112       122       132       142       152       162       172       182       192       202       212       222       232       242       252       262       272       282       292       302       312       322       332       342       352       362       372       382       392       402       412       422       432       442       452       462       472       482       492       502       512       522       532       542

Chain B from PDB  Type:PROTEIN  Length:539
 aligned with NIRS_PSEAE | P24474 from UniProtKB/Swiss-Prot  Length:568

    Alignment length:539
                                    39        49        59        69        79        89        99       109       119       129       139       149       159       169       179       189       199       209       219       229       239       249       259       269       279       289       299       309       319       329       339       349       359       369       379       389       399       409       419       429       439       449       459       469       479       489       499       509       519       529       539       549       559
           NIRS_PSEAE    30 KAAEQYQGAASAVDPAHVVRTNGAPDMSESEFNEAKQIYFQRCAGCHGVLRKGATGKPLTPDITQQRGQQYLEALITYGTPLGMPNWGSSGELSKEQITLMAKYIQHTPPQPPEWGMPEMRESWKVLVKPEDRPKKQLNDLDLPNLFSVTLRDAGQIALVDGDSKKIVKVIDTGYAVHISRMSASGRYLLVIGRDARIDMIDLWAKEPTKVAEIKIGIEARSVESSKFKGYEDRYTIAGAYWPPQFAIMDGETLEPKQIVSTRGMTVDTQTYHPEPRVAAIIASHEHPEFIVNVKETGKVLLVNYKDIDNLTVTSIGAAPFLHDGGWDSSHRYFMTAANNSNKVAVIDSKDRRLSALVDVGKTPHPGRGANFVHPKYGPVWSTSHLGDGSISLIGTDPKNHPQYAWKKVAELQGQGGGSLFIKTHPKSSHLYVDTTFNPDARISQSVAVFDLKNLDAKYQVLPIAEWADLGEGAKRVVQPEYNKRGDEVWFSVWNGKNDSSALVVVDDKTLKLKAVVKDPRLITPTGKFNVYNTQHDVY 568
               SCOP domains d1gjqb1 B:5-117 N-terminal (heme c) domain of cytochrome cd1-nitrite reductase                                   d1gjqb2 B:118-543 C-terminal (heme d1) domain of cytochrome cd1-nitrite reductase                                                                                                                                                                                                                                                                                                                                                          SCOP domains
               CATH domains -1gjqB01 B:6-116 Cytochrome c                                                                                   1gjqB02 B:117-543  [code=2.140.10.20, no name defined]                                                                                                                                                                                                                                                                                                                                                                                      CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author hhhhhhh......hhhhh.........hhhhhhhhhhhhhhhhhhhhh...........hhhhhhhhhhhhhhhhhhhh..............hhhhhhhhhhhh..........hhhhhhhhhee..hhhhh........hhh.eeeeee....eeeeee.....eeeeee....eeeeee.....eeeeee...eeeeee......eeeeeee...eeeeeee.........eeeeeeee..eeeeee.....eeeeee..ee......ee....eeeeee.....eeeeee....eeeeee.......eeeeee....eeeeee.....eeeeee....eeeeee....eeeeeee....eeeeeeeeeee...eeeeeeee....eeeeee............eeeeee........ee......eeee......hhhhhh.eeeee........eeehhhhhhh......eeeeeee.....eeeeeee.......eeeeee....eeeeee.......eeeeeehhhhhh... Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -----------------------------CYTC  PDB: B:34-113 UniProt: 59-138                                             ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1gjq B   5 KAAEQYQGAASAVDPAHVVRTNGAPDMSESEFNEAKQIYFQRCAGCHGVLRKGATGKPLTPDITQQRGQQYLEALITYGTPLGMPNWGSSGELSKEQITLMAKYIQHTPPQPPEWGMPEMRESWKVLVKPEDRPKKQLNDLDLPNLFSVTLRDAGQIALVDGDSKKIVKVIDTGYAVHISRMSASGRYLLVIGRDARIDMIDLWAKEPTKVAEIKIGIEARSVESSKFKGYEDRYTIAGAYWPPQFAIMDGETLEPKQIVSTRGMTVDTQTYHPEPRVAAIIASHEHPEFIVNVKETGKVLLVNYKDIDNLTVTSIGAAPFLHDGGWDSSHRYFMTAANNSNKVAVIDSKDRRLSALVDVGKTPHPGRGANFVHPKYGPVWSTSHLGDGSISLIGTDPKNHPQYAWKKVAELQGQGGGSLFIKTHPKSSHLYVDTTFNPDARISQSVAVFDLKNLDAKYQVLPIAEWADLGEGAKRVVQPEYNKRGDEVWFSVWNGKNDSSALVVVDDKTLKLKAVVKDPRLITPTGKFNVYNTQHDVY 543
                                    14        24        34        44        54        64        74        84        94       104       114       124       134       144       154       164       174       184       194       204       214       224       234       244       254       264       274       284       294       304       314       324       334       344       354       364       374       384       394       404       414       424       434       444       454       464       474       484       494       504       514       524       534

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Asymmetric/Biological Unit

Classes(

)

Architectures( (-)

)

Topologies( (-)

)

Homologous Superfamilies( (-)

)

Organisms( (-)

)

Class: Mainly Alpha (13335)

Architecture: Orthogonal Bundle (10391)

Topology: Cytochrome Bc1 Complex; Chain D, domain 2 (279)

Homologous Superfamily: Cytochrome c (279)

Pseudomonas aeruginosa. Organism_taxid: 287 (4)

1a	1gjqA01	A:6-116
1b	1gjqB01	B:6-116

Class: Mainly Beta (13760)

Architecture: 8 Propellor (110)

Topology: Methanol Dehydrogenase; Chain A (110)

Homologous Superfamily: [code=2.140.10.20, no name defined] (22)

Pseudomonas aeruginosa. Organism_taxid: 287 (1)

2a	1gjqA02	A:117-543
2b	1gjqB02	B:117-543

(no "Pfam Domain" information available for 1GJQ)

Asymmetric/Biological Unit(hide GO term definitions)

Chain A,B (NIRS_PSEAE | P24474)

molecular function
	GO:0009055	electron carrier activity	Any molecular entity that serves as an electron acceptor and electron donor in an electron transport chain. An electron transport chain is a process in which a series of electron carriers operate together to transfer electrons from donors to any of several different terminal electron acceptors to generate a transmembrane electrochemical gradient.
	GO:0020037	heme binding	Interacting selectively and non-covalently with heme, any compound of iron complexed in a porphyrin (tetrapyrrole) ring.
	GO:0050418	hydroxylamine reductase activity	Catalysis of the reaction: NH3 + H2O + acceptor = hydroxylamine + reduced acceptor.
	GO:0046872	metal ion binding	Interacting selectively and non-covalently with any metal ion.
	GO:0050421	nitrite reductase (NO-forming) activity	Catalysis of the reaction: nitric oxide + H2O + ferricytochrome c = nitrite + ferrocytochrome c + 2 H+.
	GO:0016491	oxidoreductase activity	Catalysis of an oxidation-reduction (redox) reaction, a reversible chemical reaction in which the oxidation state of an atom or atoms within a molecule is altered. One substrate acts as a hydrogen or electron donor and becomes oxidized, while the other acts as hydrogen or electron acceptor and becomes reduced.
biological process
	GO:0055114	oxidation-reduction process	A metabolic process that results in the removal or addition of one or more electrons to or from a substance, with or without the concomitant removal or addition of a proton or protons.
cellular component
	GO:0042597	periplasmic space	The region between the inner (cytoplasmic) and outer membrane (Gram-negative Bacteria) or cytoplasmic membrane and cell wall (Fungi and Gram-positive Bacteria).

Asymmetric/Biological Unit
	Complete Structure
		Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
		WebMol \| AstexViewer[tm]@PDBe (Java Applets, require no local installation except for Java; loading may be slow)
		STRAP (Java WebStart application, automatic local installation, requires Java; full application with system access!)
		RasMol (require local installation)
		Molscript (VRML) (requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

	Ligands, Modified Residues, Ions
		CYN	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		DHE	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]
		HEC	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]

	Sites
		AC1	[ RasMol ]	+environment [ RasMol ]
		AC2	[ RasMol ]	+environment [ RasMol ]
		AC3	[ RasMol ]	+environment [ RasMol ]
		AC4	[ RasMol ]	+environment [ RasMol ]
		AC5	[ RasMol ]	+environment [ RasMol ]
		AC6	[ RasMol ]	+environment [ RasMol ]

	Cis Peptide Bonds
		Trp A:246 - Pro A:247	[ RasMol ]
		Trp B:246 - Pro B:247	[ RasMol ]

Jmol
	protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick [ Asym./Biol. Unit PNG format \| Asym./Biol. Unit - sites PNG format ](automatic orientation, automatically generated)
Molscript
	protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick [ mono PDF format \| stereo PDF format ](default orientation, automatically generated)

Access by PDB/NDB ID
	1gjq
		Family and Domain Information	:	ProDom \| SYSTERS
		General Structural Information	:	GlycoscienceDB \| MMDB \| NDB \| OCA \| PDB \| PDBe \| PDBj \| PDBsum \| PDBWiki \| PQS \| PROTEOPEDIA
		Orientation in Membranes	:	OPM
		Protein Surface	:	SURFACE
		Secondary Structure	:	DSSP (structure derived) \| HSSP (homology derived)
		Structural Genomics	:	GeneCensus
		Structural Neighbours	:	CE \| VAST
		Structure Classification	:	CATH \| Dali \| SCOP
		Validation and Original Data	:	BMRB Data View \| BMRB Restraints Grid \| EDS \| PROCHECK \| RECOORD \| WHAT_CHECK

Access by UniProt ID/Accession number
	NIRS_PSEAE \| P24474
		Comparative Protein Structure Models	:	ModBase
		Genomic Information	:	Ensembl
		Protein-protein Interaction	:	DIP
		Sequence, Family and Domain Information	:	InterPro \| Pfam \| SMART \| UniProtKB/SwissProt

Access by Enzyme Classificator (EC Number)
	1.9.3.2
		General Enzyme Information	:	BRENDA \| EC-PDB \| Enzyme \| IntEnz
		Pathway	:	KEGG \| MetaCyc

Access by Disease Identifier (MIM ID)
	(no 'MIM ID' available)
		Disease Information	:	OMIM

Access by GenAge ID
	(no 'GenAge ID' available)
		Age Related Information	:	GenAge

Access by PDB/NDB ID
		Domain Information	:	XDom
		Interatomic Contacts of Structural Units	:	CSU
		Ligand-protein Contacts	:	LPC
		Protein Cavities	:	castP
		Sequence and Secondary Structure	:	PDBCartoon
		Structure Alignment	:	STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
		Structure and Sequence Browser	:	STING

Access by UniProt ID/Accession number
	NIRS_PSEAE \| P24474
		Protein Disorder Prediction	:	DisEMBL \| FoldIndex \| GLOBPLOT (for more information see DisProt)

UniProtKB/Swiss-Prot
	NIRS_PSEAE \| P24474	:	1bl9 1hzu 1hzv 1n15 1n50 1n90 1nir 1nno

1bl9	CONFORMATIONAL CHANGES OCCURRING UPON REDUCTION IN NITRITE REDUCTASE FROM PSEUDOMONAS AERUGINOSA
1n15	FOLLOWING THE C HEME REDUCTION IN NITRITE REDUCTASE FROM PSEUDOMONAS AERUGINOSA
1n50	FOLLOWING THE C HEME REDUCTION IN NITRITE REDUCTASE FROM PSEUDOMONAS AERUGINOSA
1n90	FOLLOWING THE C HEME REDUCTION IN NITRITE REDUCTASE FROM PSEUDOMONAS AERUGINOSA
1nir	OXYDIZED NITRITE REDUCTASE FROM PSEUDOMONAS AERUGINOSA
1nno	CONFORMATIONAL CHANGES OCCURRING UPON NO BINDING IN NITRITE REDUCTASE FROM PSEUDOMONAS AERUGINOSA
