(-) Description

Title :  XYLOSE ISOMERASE FROM THERMUS THERMOPHILUS

Authors :  C. Chang, B. C. Park, D. -S. Lee, S. W. Suh
Date :  02 Oct 98  (Deposition) - 16 Feb 99  (Release) - 13 Jul 11  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  2.20
Chains :  Asym./Biol. Unit :  A,B,C,D
Keywords :  Isomerase, Xylose Metabolism (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  C. Chang, B. C. Park, D. S. Lee, S. W. Suh
Crystal Structures Of Thermostable Xylose Isomerases From Thermus Caldophilus And Thermus Thermophilus: Possible Structural Determinants Of Thermostability.
J. Mol. Biol. V. 288 623 1999
PubMed-ID: 10329168  |  Reference-DOI: 10.1006/JMBI.1999.2696

(-) Compounds

Molecule 1 - XYLOSE ISOMERASE
    Chains: A, B, C, D
    EC Number: 5.3.1.5
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Plasmid: PKK322-2
    Expression System Taxid: 562
    Gene: XYLA
    Organism Scientific: THERMUS THERMOPHILUS
    Organism Taxid: 300852
    Strain: HB8
    Synonym: XYLOSE (GLUCOSE) ISOMERASE

 Structural Features

(-) Chains, Units

  1234
Asymmetric/Biological Unit : ABCD

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (0, 0)

(no "Ligand,Modified Residues,Ions" information available for 1BXB)

(-) Sites  (0, 0)

(no "Site" information available for 1BXB)

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 1BXB)

(-) Cis Peptide Bonds  (4, 4)

Asymmetric/Biological Unit
No.Residues
1Glu A:185 -Pro A:186
2Glu B:185 -Pro B:186
3Glu C:185 -Pro C:186
4Glu D:185 -Pro D:186

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 1BXB)

(-) PROSITE Motifs  (1, 4)

Asymmetric/Biological Unit (1, 4)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1XYLOSE_ISOMERASEPS51415 Xylose isomerase family profile.XYLA_THET83-382


 		  4A:3-382
B:3-382
C:3-382
D:3-382

(-) Exons   (0, 0)

(no "Exon" information available for 1BXB)

(-) Sequences/Alignments

Asymmetric/Biological Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:387
 aligned with XYLA_THET8 | P26997 from UniProtKB/Swiss-Prot  Length:387

    Alignment length:387
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380
           XYLA_THET8     1 MYEPKPEHRFTFGLWTVGNVGRDPFGDAVRERLDPVYVVHKLAELGAYGVNLHDEDLIPRGTPPQERDQIVRRFKKALDETGLKVPMVTANLFSDPAFKDGAFTSPDPWVRAYALRKSLETMDLGAELGAEIYVVWPGREGAEVEATGKARKVWDWVREALNFMAAYAEDQGYGYRFALEPKPNEPRGDIYFATVGSMLAFIHTLDRPERFGLNPEFAHETMAGLNFVHAVAQALDAGKLFHIDLNDQRMSRFDQDLRFGSENLKAAFFLVDLLESSGYQGPRHFDAHALRTEDEEGVWAFARGCMRTYLILKERAEAFREDPEVKELLAAYYQEDPAALALLGPYSREKAEALKRAELPLEAKRRRGYALERLDQLAVEYLLGVRG 387
               SCOP domains d1bxba_ A: D-xylose isomerase                                                                                                                                                                                                                                                                                                                                                                       SCOP domains
               CATH domains 1bxbA00 A:1-387 Divalent-metal-dependent TIM barrel enzymes                                                                                                                                                                                                                                                                                                                                         CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .....hhh..eeehhhh.................hhhhhhhhhhh...eee..hhhh........hhhhhhhhhhhhhhhh..............hhhhh.......hhhhhhhhhhhhhhhhhhhhh...eeeee........hhh.hhh.hhhhhhhhhhhhhhhhhhh....eeeee..............hhhhhhhhhh...hhheeeeeehhhhhhh...hhhhhhhhhh...eeeee...................hhhhhhhhhhhhh..................hhhhhhhhhhhhhhhhhhhhhhhhhh..hhhhhhhhhh....hhhhhh......hhhhhhh.....hhhhhh....hhhhhhhhhhhh..... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --XYLOSE_ISOMERASE  PDB: A:3-382 UniProt: 3-382                                                                                                                                                                                                                                                                                                                                               ----- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1bxb A   1 MYEPKPEHRFTFGLWTVGNVGRDPFGDAVRERLDPVYVVHKLAELGAYGVNLHDEDLIPRGTPPQERDQIVRRFKKALDETGLKVPMVTANLFSDPAFKDGAFTSPDPWVRAYALRKSLETMDLGAELGAEIYVVWPGREGAEVEATGKARKVWDWVREALNFMAAYAEDQGYGYRFALEPKPNEPRGDIYFATVGSMLAFIHTLDRPERFGLNPEFAHETMAGLNFVHAVAQALDAGKLFHIDLNDQRMSRFDQDLRFGSENLKAAFFLVDLLESSGYQGPRHFDAHALRTEDEEGVWAFARGCMRTYLILKERAEAFREDPEVKELLAAYYQEDPAALALLGPYSREKAEALKRAELPLEAKRRRGYALERLDQLAVEYLLGVRG 387
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380


Chain B from PDB  Type:PROTEIN  Length:387
 aligned with XYLA_THET8 | P26997 from UniProtKB/Swiss-Prot  Length:387

    Alignment length:387
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380
           XYLA_THET8     1 MYEPKPEHRFTFGLWTVGNVGRDPFGDAVRERLDPVYVVHKLAELGAYGVNLHDEDLIPRGTPPQERDQIVRRFKKALDETGLKVPMVTANLFSDPAFKDGAFTSPDPWVRAYALRKSLETMDLGAELGAEIYVVWPGREGAEVEATGKARKVWDWVREALNFMAAYAEDQGYGYRFALEPKPNEPRGDIYFATVGSMLAFIHTLDRPERFGLNPEFAHETMAGLNFVHAVAQALDAGKLFHIDLNDQRMSRFDQDLRFGSENLKAAFFLVDLLESSGYQGPRHFDAHALRTEDEEGVWAFARGCMRTYLILKERAEAFREDPEVKELLAAYYQEDPAALALLGPYSREKAEALKRAELPLEAKRRRGYALERLDQLAVEYLLGVRG 387
               SCOP domains d1bxbb_ B: D-xylose isomerase                                                                                                                                                                                                                                                                                                                                                                       SCOP domains
               CATH domains 1bxbB00 B:1-387 Divalent-metal-dependent TIM barrel enzymes                                                                                                                                                                                                                                                                                                                                         CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .....hhh..eeehhhh.................hhhhhhhhhhh...eee..hhhh........hhhhhhhhhhhhhhhh..............hhhhh.......hhhhhhhhhhhhhhhhhhhhh...eeeee........hhh.hhh.hhhhhhhhhhhhhhhhhhh....eeeee..............hhhhhhhhhh...hhheeeeeehhhhhhh...hhhhhhhhhh...eeeee...................hhhhhhhhhhhhh..................hhhhhhhhhhhhhhhhhhhhhhhhhh..hhhhhhhhhh....hhhhhh......hhhhhhh.....hhhhh.....hhhhhhhhhhhh..... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --XYLOSE_ISOMERASE  PDB: B:3-382 UniProt: 3-382                                                                                                                                                                                                                                                                                                                                               ----- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1bxb B   1 MYEPKPEHRFTFGLWTVGNVGRDPFGDAVRERLDPVYVVHKLAELGAYGVNLHDEDLIPRGTPPQERDQIVRRFKKALDETGLKVPMVTANLFSDPAFKDGAFTSPDPWVRAYALRKSLETMDLGAELGAEIYVVWPGREGAEVEATGKARKVWDWVREALNFMAAYAEDQGYGYRFALEPKPNEPRGDIYFATVGSMLAFIHTLDRPERFGLNPEFAHETMAGLNFVHAVAQALDAGKLFHIDLNDQRMSRFDQDLRFGSENLKAAFFLVDLLESSGYQGPRHFDAHALRTEDEEGVWAFARGCMRTYLILKERAEAFREDPEVKELLAAYYQEDPAALALLGPYSREKAEALKRAELPLEAKRRRGYALERLDQLAVEYLLGVRG 387
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380


Chain C from PDB  Type:PROTEIN  Length:387
 aligned with XYLA_THET8 | P26997 from UniProtKB/Swiss-Prot  Length:387

    Alignment length:387
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380
           XYLA_THET8     1 MYEPKPEHRFTFGLWTVGNVGRDPFGDAVRERLDPVYVVHKLAELGAYGVNLHDEDLIPRGTPPQERDQIVRRFKKALDETGLKVPMVTANLFSDPAFKDGAFTSPDPWVRAYALRKSLETMDLGAELGAEIYVVWPGREGAEVEATGKARKVWDWVREALNFMAAYAEDQGYGYRFALEPKPNEPRGDIYFATVGSMLAFIHTLDRPERFGLNPEFAHETMAGLNFVHAVAQALDAGKLFHIDLNDQRMSRFDQDLRFGSENLKAAFFLVDLLESSGYQGPRHFDAHALRTEDEEGVWAFARGCMRTYLILKERAEAFREDPEVKELLAAYYQEDPAALALLGPYSREKAEALKRAELPLEAKRRRGYALERLDQLAVEYLLGVRG 387
               SCOP domains d1bxbc_ C: D-xylose isomerase                                                                                                                                                                                                                                                                                                                                                                       SCOP domains
               CATH domains 1bxbC00 C:1-387 Divalent-metal-dependent TIM barrel enzymes                                                                                                                                                                                                                                                                                                                                         CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .....hhh..eeehhhh.................hhhhhhhhhhh...eee..hhhh........hhhhhhhhhhhhhhhh..............hhhhh.......hhhhhhhhhhhhhhhhhhhhh...eeeee........hhh.hhh.hhhhhhhhhhhhhhhhhhh....eeeee..............hhhhhhhhhh...hhheeeeeehhhhhhh...hhhhhhhhhh...eeeee...................hhhhhhhhhhhhh..................hhhhhhhhhhhhhhhhhhhhhhhhhh..hhhhhhhhhh....hhhhhh......hhhhhhhh....hhhhhh....hhhhhhhhhhhhh.... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --XYLOSE_ISOMERASE  PDB: C:3-382 UniProt: 3-382                                                                                                                                                                                                                                                                                                                                               ----- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1bxb C   1 MYEPKPEHRFTFGLWTVGNVGRDPFGDAVRERLDPVYVVHKLAELGAYGVNLHDEDLIPRGTPPQERDQIVRRFKKALDETGLKVPMVTANLFSDPAFKDGAFTSPDPWVRAYALRKSLETMDLGAELGAEIYVVWPGREGAEVEATGKARKVWDWVREALNFMAAYAEDQGYGYRFALEPKPNEPRGDIYFATVGSMLAFIHTLDRPERFGLNPEFAHETMAGLNFVHAVAQALDAGKLFHIDLNDQRMSRFDQDLRFGSENLKAAFFLVDLLESSGYQGPRHFDAHALRTEDEEGVWAFARGCMRTYLILKERAEAFREDPEVKELLAAYYQEDPAALALLGPYSREKAEALKRAELPLEAKRRRGYALERLDQLAVEYLLGVRG 387
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380


Chain D from PDB  Type:PROTEIN  Length:387
 aligned with XYLA_THET8 | P26997 from UniProtKB/Swiss-Prot  Length:387

    Alignment length:387
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380
           XYLA_THET8     1 MYEPKPEHRFTFGLWTVGNVGRDPFGDAVRERLDPVYVVHKLAELGAYGVNLHDEDLIPRGTPPQERDQIVRRFKKALDETGLKVPMVTANLFSDPAFKDGAFTSPDPWVRAYALRKSLETMDLGAELGAEIYVVWPGREGAEVEATGKARKVWDWVREALNFMAAYAEDQGYGYRFALEPKPNEPRGDIYFATVGSMLAFIHTLDRPERFGLNPEFAHETMAGLNFVHAVAQALDAGKLFHIDLNDQRMSRFDQDLRFGSENLKAAFFLVDLLESSGYQGPRHFDAHALRTEDEEGVWAFARGCMRTYLILKERAEAFREDPEVKELLAAYYQEDPAALALLGPYSREKAEALKRAELPLEAKRRRGYALERLDQLAVEYLLGVRG 387
               SCOP domains d1bxbd_ D: D-xylose isomerase                                                                                                                                                                                                                                                                                                                                                                       SCOP domains
               CATH domains 1bxbD00 D:1-387 Divalent-metal-dependent TIM barrel enzymes                                                                                                                                                                                                                                                                                                                                         CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .....hhh..eeehhhh.................hhhhhhhhhhh...eee..hhhh........hhhhhhhhhhhhhhhh..............hhhhh.......hhhhhhhhhhhhhhhhhhhhh...eeeee........hhh.hhh.hhhhhhhhhhhhhhhhhhh....eeeee..............hhhhhhhhhh...hhheeeeeehhhhhhh...hhhhhhhhhh...eeeee...................hhhhhhhhhhhhh..................hhhhhhhhhhhhhhhhhhhhhhhhhh..hhhhhhhhhh....hhhhhh......hhhhhhhh....hhhhhh....hhhhhhhhhhhh..... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --XYLOSE_ISOMERASE  PDB: D:3-382 UniProt: 3-382                                                                                                                                                                                                                                                                                                                                               ----- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1bxb D   1 MYEPKPEHRFTFGLWTVGNVGRDPFGDAVRERLDPVYVVHKLAELGAYGVNLHDEDLIPRGTPPQERDQIVRRFKKALDETGLKVPMVTANLFSDPAFKDGAFTSPDPWVRAYALRKSLETMDLGAELGAEIYVVWPGREGAEVEATGKARKVWDWVREALNFMAAYAEDQGYGYRFALEPKPNEPRGDIYFATVGSMLAFIHTLDRPERFGLNPEFAHETMAGLNFVHAVAQALDAGKLFHIDLNDQRMSRFDQDLRFGSENLKAAFFLVDLLESSGYQGPRHFDAHALRTEDEEGVWAFARGCMRTYLILKERAEAFREDPEVKELLAAYYQEDPAALALLGPYSREKAEALKRAELPLEAKRRRGYALERLDQLAVEYLLGVRG 387
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300       310       320       330       340       350       360       370       380
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 4)

Asymmetric/Biological Unit
(-)
Class: Alpha and beta proteins (a/b) (23833)

(-) CATH Domains  (1, 4)

Asymmetric/Biological Unit
(-)
Class: Alpha Beta (26913)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 1BXB)

(-) Gene Ontology  (8, 8)

Asymmetric/Biological Unit(hide GO term definitions)
Chain A,B,C,D   (XYLA_THET8 | P26997)
molecular function
    GO:0016853    isomerase activity    Catalysis of the geometric or structural changes within one molecule. Isomerase is the systematic name for any enzyme of EC class 5.
    GO:0000287    magnesium ion binding    Interacting selectively and non-covalently with magnesium (Mg) ions.
    GO:0046872    metal ion binding    Interacting selectively and non-covalently with any metal ion.
    GO:0009045    xylose isomerase activity    Catalysis of the reaction: D-xylose = D-xylulose.
biological process
    GO:0042732    D-xylose metabolic process    The chemical reactions and pathways involving D-xylose, a naturally occurring plant polysaccharide.
    GO:0005975    carbohydrate metabolic process    The chemical reactions and pathways involving carbohydrates, any of a group of organic compounds based of the general formula Cx(H2O)y. Includes the formation of carbohydrate derivatives by the addition of a carbohydrate residue to another molecule.
    GO:0006098    pentose-phosphate shunt    The glucose-6-phosphate catabolic process in which, coupled to NADPH synthesis, glucose-6-P is oxidized with the formation of carbon dioxide (CO2) and ribulose 5-phosphate; ribulose 5-P then enters a series of reactions interconverting sugar phosphates. The pentose phosphate pathway is a major source of reducing equivalents for biosynthesis reactions and is also important for the conversion of hexoses to pentoses.
cellular component
    GO:0005737    cytoplasm    All of the contents of a cell excluding the plasma membrane and nucleus, but including other subcellular structures.

 Visualization

(-) Interactive Views

Asymmetric/Biological Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
(no "Ligands, Modified Residues, Ions" information available for 1bxb)

  Sites
(no "Sites" information available for 1bxb)

  Cis Peptide Bonds
    Glu A:185 - Pro A:186   [ RasMol ]
    Glu B:185 - Pro B:186   [ RasMol ]
    Glu C:185 - Pro C:186   [ RasMol ]
    Glu D:185 - Pro D:186   [ RasMol ]


(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym./Biol. Unit PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  1bxb
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  XYLA_THET8 | P26997
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/SwissProt

Access by Enzyme Classificator   (EC Number)
  5.3.1.5
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  XYLA_THET8 | P26997
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)
