(-) Description

Title :  THE USE OF MOLECULAR-REPLACEMENT PHASES FOR THE REFINEMENT OF THE HUMAN RHINOVIRUS 14 STRUCTURE

Authors :  E. Arnold, M. G. Rossmann
Date :  25 Jan 88  (Deposition) - 16 Apr 88  (Release) - 24 Feb 09  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  3.00
Chains :  Asym. Unit :  1,2,3,4
Biol. Unit 1:  1,2,3,4  (60x)
Keywords :  Rhinovirus Coat Protein, Icosahedral Virus (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  E. Arnold, M. G. Rossmann
The Use Of Molecular-Replacement Phases For The Refinement Of The Human Rhinovirus 14 Structure.
Acta Crystallogr. , Sect. A V. 44 270 1988
PubMed-ID: 2856083  |  Reference-DOI: 10.1107/S0108767387011875
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - HUMAN RHINOVIRUS 14 COAT PROTEIN (SUBUNIT VP1)
    Chains: 1
    Engineered: YES
    Expression System: HOMO SAPIENS
    Expression System Cell Line: HELA CELLS
    Expression System Common: HUMAN
    Expression System Taxid: 9606
    Organism Scientific: HUMAN RHINOVIRUS 14
    Organism Taxid: 12131

Molecule 2 - HUMAN RHINOVIRUS 14 COAT PROTEIN (SUBUNIT VP2)
    Chains: 2
    Engineered: YES
    Expression System: HOMO SAPIENS
    Expression System Cell Line: HELA CELLS
    Expression System Common: HUMAN
    Expression System Taxid: 9606
    Organism Scientific: HUMAN RHINOVIRUS 14
    Organism Taxid: 12131

Molecule 3 - HUMAN RHINOVIRUS 14 COAT PROTEIN (SUBUNIT VP3)
    Chains: 3
    Engineered: YES
    Expression System: HOMO SAPIENS
    Expression System Cell Line: HELA CELLS
    Expression System Common: HUMAN
    Expression System Taxid: 9606
    Organism Scientific: HUMAN RHINOVIRUS 14
    Organism Taxid: 12131

Molecule 4 - HUMAN RHINOVIRUS 14 COAT PROTEIN (SUBUNIT VP4)
    Chains: 4
    Engineered: YES
    Expression System: HOMO SAPIENS
    Expression System Cell Line: HELA CELLS
    Expression System Common: HUMAN
    Expression System Taxid: 9606
    Organism Scientific: HUMAN RHINOVIRUS 14
    Organism Taxid: 12131

 Structural Features

(-) Chains, Units

  1234
Asymmetric Unit : 1234
Biological Unit 1 (60x): 1234

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (0, 0)

(no "Ligand,Modified Residues,Ions" information available for 4RHV)

(-) Sites  (0, 0)

(no "Site" information available for 4RHV)

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 4RHV)

(-) Cis Peptide Bonds  (1, 1)

Asymmetric Unit
No.Residues
1Leu 2:82 -Pro 2:83

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 4RHV)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 4RHV)

(-) Exons   (0, 0)

(no "Exon" information available for 4RHV)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain 1 from PDB  Type:PROTEIN  Length:273

               SCOP domains d4rhv1_ 1: Rhinovirus coat proteins                                                                                                                                                                                                                                               SCOP domains
               CATH domains 4rhv100 1:17-289  [code=2.60.120.20, no name defined]                                                                                                                                                                                                                             CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .................................................hhhhhhh..eeeeeeeeee...............eeeee.....hhhhhhhhhheeeeeeeeeeeeeeee..........eeeeeeee...........hhhhhh...eeeeeee.eeeeeee........eeee.....................eeeeeeee.......eeeeeeeeeeeeeeeeee................................... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4rhv 1  17 TVASISSGPKHTQKVPILTANETGATMPVLPSDSIETRTTYMHFNGSETDVECFLGRAACVHVTEIQNKDATGIDNHREAKLFNDWKINLSSLVQLRKKLELFTYVRFDSEYTILATASQPDSANYSSNLVVQAMYVPPGAPNPKEWDDYTWQSASNPSVFFKVGDTSRFSVPYVGLASAYNCFYDGYSHDDAETQYGITVLNHMGSMAFRIVNEHDEHKTLVKIRVYHRAKHVEAWIPRAPRALPYTSIGRTNYPKNTEPVIKKRKGDIKSY 289
                                    26        36        46        56        66        76        86        96       106       116       126       136       146       156       166       176       186       196       206       216       226       236       246       256       266       276       286


Chain 2 from PDB  Type:PROTEIN  Length:255

               SCOP domains d4rhv.1 4:,2: Rhinovirus coat proteins                                                                                                                                                                                                                          SCOP domains
               CATH domains 4rhv200 2:8-262  [code=2.60.120.20, no name defined]                                                                                                                                                                                                            CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ....eeeeeee..eeeeeeee...........................hhhhhh..eeeeeeee.....eeeeee......hhhhhhhhhhheeeeeeeeeeeee......eeeeeeeee.................................................hhhhhhhheeeeeee...eeeeeee........eee.....eeeeeeeeeeee........eeeeeeeeeeeeeeee......... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4rhv 2   8 GYSDRVQQITLGNSTITTQEAANAVVCYAEWPEYLPDVDASDVNKTSKPDTSVCRFYTLDSKTWTTGSKGWCWKLPDALKDMGVFGQNMFFHSLGRSGYTVHVQCNATKFHSGCLLVVVIPEHQLASHEGGNVSVKYTFTHPGERGIDLSSANEVGGPVKDVLYNMNGTLLGNLLIFPHQFINLRTNNTATIVIPYINSVPIDSMTRHNNVSLMVIPIAPLTVPTGATPSLPITVTIAPMCTEFSGIRSKSIVPQ 262
                                    17        27        37        47        57        67        77        87        97       107       117       127       137       147       157       167       177       187       197       207       217       227       237       247       257


Chain 3 from PDB  Type:PROTEIN  Length:236

               SCOP domains d4rhv3_ 3: Rhinovirus coat proteins                                                                                                                                                                                                          SCOP domains
               CATH domains 4rhv300 3:1-236  [code=2.60.120.20, no name defined]                                                                                                                                                                                         CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .........................................hhhhhhhh.eee...............eee.........eeeee.........hhhhhhhhhheeeeeeeeeeeeee.....eeeeeeeee........hhhhhhhheeeeeee...eeeeeee........eee........eeeeeeeeeeee........eeeeeeeeeeeeeeeee............... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 4rhv 3   1 GLPTTTLPGSGQFLTTDDRQSPSALPNYEPTPRIHIPGKVHNLLEIIQVDTLIPMNNTHTKDEVNSYLIPLNANRQNEQVFGTNLFIGDGVFKTTLLGEIVQYYTHWSGSLRFSLMYTGPALSSAKLILAYTPPGARGPQDRREAMLGTHVVWDIGLQSTIVMTIPWTSGVQFRYTDPDTYTSAGFLSCWYQTSLILPPETTGQVYLLSFISACPDFKLRLMKDTQTISQTVALTE 236
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230


Chain 4 from PDB  Type:PROTEIN  Length:40

               SCOP domains d4rhv.1 4:,2: Rhinovirus coat proteins   SCOP domains
               CATH domains 4rhv400 4:29-68 Rhinovirus 14, subunit 4 CATH domains
               Pfam domains ---------------------------------------- Pfam domains
         Sec.struct. author ........................................ Sec.struct. author
                 SAPs(SNPs) ---------------------------------------- SAPs(SNPs)
                    PROSITE ---------------------------------------- PROSITE
                 Transcript ---------------------------------------- Transcript
                 4rhv 4  29 INYYKDAASTSSAGQSLSMDPSKFTEPVKDLMLKGAPALN  68
                                    38        48        58        68
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 3)

Asymmetric Unit
(-)
Class: All beta proteins (24004)

(-) CATH Domains  (2, 4)

Asymmetric Unit
(-)
Class: Few Secondary Structures (1120)
(-)
Class: Mainly Beta (13760)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 4RHV)

(-) Gene Ontology  (50, 50)

Asymmetric Unit(hide GO term definitions)

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
(no "Ligands, Modified Residues, Ions" information available for 4rhv)

  Sites
(no "Sites" information available for 4rhv)

  Cis Peptide Bonds
    Leu 2:82 - Pro 2:83   [ RasMol ]

Biological Unit
  Complete Structure
    Biological Unit 1  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Biol. Unit 1 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  4rhv
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  POLG_HRV14 | P03303
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/SwissProt

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  POLG_HRV14 | P03303
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/Swiss-Prot
        POLG_HRV14 | P03303: 1d3i 1hri 1hrv 1k5m 1na1 1ncq 1r08 1r09 1rmu 1ruc 1rud 1rue 1ruf 1rug 1ruh 1rui 1ruj 1rvf 1vrh 1xr5 2b0f 2hwb 2hwc 2in2 2r04 2r06 2r07 2rm2 2rmu 2rr1 2rs1 2rs3 2rs5 4pdw 5w3e 5w3l 5w3m 5w3o

(-) Related Entries Specified in the PDB File

(no "Related Entries Specified in the PDB File" available for 4RHV)
