(-) Description

Title :  CRYSTAL STRUCTURE OF SALIVARY CYSTATIN FROM THE SOFT TICK ORNITHODOROS MOUBATA

Authors :  P. Rezacova, J. Brynda, J. F. Andersen, J. Salat, Z. Kovarova, M. Mares
Date :  10 Dec 09  (Deposition) - 30 Jun 10  (Release) - 30 Jun 10  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  2.45
Chains :  Asym. Unit :  A,B
Biol. Unit 1:  A  (1x)
Biol. Unit 2:  B  (1x)
Keywords :  Soft Tick, Cystatin, Protease Inhibitor, Thiol Protease Inhibitor, Hydrolase Inhibitor (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  J. Salat, G. C. Paesen, P. Rezacova, M. Kotsyfakis, Z. Kovarova, M. Sanda, J. Majtan, L. Grunclova, H. Horka, J. F. Andersen, J. Brynda, M. Horn, M. A. Nunn, P. Kopacek, J. Kopecky, M. Mares
Crystal Structure And Functional Characterization Of An Immunomodulatory Salivary Cystatin From The Soft Tick Ornithodoros Moubata
Biochem. J. V. 429 103 2010
PubMed-ID: 20545626  |  Reference-DOI: 10.1042/BJ20100280

(-) Compounds

Molecule 1 - CYSTATIN-2
    Chains: A, B
    Engineered: YES
    Expression System: SPODOPTERA FRUGIPERDA
    Expression System Plasmid: PBACPAK9
    Expression System Strain: SF9
    Expression System Taxid: 7108
    Expression System Vector Type: BACULOVIRUS
    Gene: OMC2
    Organism Common: SOFT TICK
    Organism Scientific: ORNITHODOROS MOUBATA
    Organism Taxid: 6938
    Synonym: OMC2

 Structural Features

(-) Chains, Units

  12
Asymmetric Unit : AB
Biological Unit 1 (1x): A
Biological Unit 2 (1x):  B

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (2, 5)

Asymmetric Unit (2, 5)
No.NameCountTypeFull Name
1CL2Ligand/IonCHLORIDE ION
2GOL3Ligand/IonGLYCEROL
Biological Unit 1 (1, 1)
No.NameCountTypeFull Name
1CL-1Ligand/IonCHLORIDE ION
2GOL1Ligand/IonGLYCEROL
Biological Unit 2 (1, 2)
No.NameCountTypeFull Name
1CL-1Ligand/IonCHLORIDE ION
2GOL2Ligand/IonGLYCEROL

(-) Sites  (4, 4)

Asymmetric Unit (4, 4)
No.NameEvidenceResiduesDescription
1AC1SOFTWARETRP A:7BINDING SITE FOR RESIDUE CL A 116
2AC2SOFTWAREARG A:16 , HIS A:94BINDING SITE FOR RESIDUE GOL A 117
3AC3SOFTWAREHIS B:94 , ASN B:99 , LYS B:101BINDING SITE FOR RESIDUE GOL B 117
4AC4SOFTWARETHR B:29 , GLU B:30 , GLY B:31BINDING SITE FOR RESIDUE GOL B 118

(-) SS Bonds  (4, 4)

Asymmetric Unit
No.Residues
1A:65 -A:77
2A:88 -A:108
3B:65 -B:77
4B:88 -B:108

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 3L0R)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 3L0R)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 3L0R)

(-) Exons   (0, 0)

(no "Exon" information available for 3L0R)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:108
 aligned with Q6QD55_ORNMO | Q6QD55 from UniProtKB/TrEMBL  Length:128

    Alignment length:108
                                                                                                                                    128
                                    31        41        51        61        71        81        91       101       111       121      |
         Q6QD55_ORNMO    22 IPGGWTRQDPTEARFLELAHFATSSQTEGREFYDTVVTVKEVETQVVAGMNYKLTIEISPSVCKIGEVQYSAEQCVPKDAQQKSTCVAVIYHVPWQNQKSVTSYRCE-   -
               SCOP domains ------------------------------------------------------------------------------------------------------------ SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------ CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------ Pfam domains
         Sec.struct. author .....eee...hhhhhhhhhhhhh.......eeeeeeeeeeeeeee...eeeeeeeeeeeeeee...................eeeeeeeeeehhhheeeeeeeeeee Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------ Transcript
                 3l0r A   3 IPGGWTRQDPTEARFLELAHFATSSQTEGREFYDTVVTVKEVETQVVAGMNYKLTIEISPSVCKIGEVQYSAEQCVPKDAQQKSTCVAVIYHVPWQNQKSVTSYRCEH 110
                                    12        22        32        42        52        62        72        82        92       102


Chain B from PDB  Type:PROTEIN  Length:108
 aligned with Q6QD55_ORNMO | Q6QD55 from UniProtKB/TrEMBL  Length:128

    Alignment length:108
                                                                                                                                    128
                                    31        41        51        61        71        81        91       101       111       121      |
         Q6QD55_ORNMO    22 IPGGWTRQDPTEARFLELAHFATSSQTEGREFYDTVVTVKEVETQVVAGMNYKLTIEISPSVCKIGEVQYSAEQCVPKDAQQKSTCVAVIYHVPWQNQKSVTSYRCE-   -
               SCOP domains ------------------------------------------------------------------------------------------------------------ SCOP domains
               CATH domains ------------------------------------------------------------------------------------------------------------ CATH domains
           Pfam domains (1) --Cystatin-3l0rB01 B:5-97                                                                      ------------- Pfam domains (1)
           Pfam domains (2) --Cystatin-3l0rB02 B:5-97                                                                      ------------- Pfam domains (2)
         Sec.struct. author .....eee...hhhhhhhhhhhhhh......eeeeeeeeeeeeeee...eeeeeeeeeeeeeee...................eeeeeeeeeehhhheeeeeeee... Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------ SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------ PROSITE
                 Transcript ------------------------------------------------------------------------------------------------------------ Transcript
                 3l0r B   3 IPGGWTRQDPTEARFLELAHFATSSQTEGREFYDTVVTVKEVETQVVAGMNYKLTIEISPSVCKIGEVQYSAEQCVPKDAQQKSTCVAVIYHVPWQNQKSVTSYRCEH 110
                                    12        22        32        42        52        62        72        82        92       102
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 3L0R)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 3L0R)

(-) Pfam Domains  (1, 2)

Asymmetric Unit
(-)
Clan: Cystatin (20)

(-) Gene Ontology  (4, 4)

Asymmetric Unit(hide GO term definitions)
Chain A,B   (Q6QD55_ORNMO | Q6QD55)
molecular function
    GO:0004869    cysteine-type endopeptidase inhibitor activity    Stops, prevents or reduces the activity of a cysteine-type endopeptidase, any enzyme that hydrolyzes peptide bonds in polypeptides by a mechanism in which the sulfhydryl group of a cysteine residue at the active center acts as a nucleophile.
    GO:0030414    peptidase inhibitor activity    Stops, prevents or reduces the activity of a peptidase, any enzyme that catalyzes the hydrolysis peptide bonds.
biological process
    GO:0010951    negative regulation of endopeptidase activity    Any process that decreases the frequency, rate or extent of endopeptidase activity, the endohydrolysis of peptide bonds within proteins.
    GO:0010466    negative regulation of peptidase activity    Any process that stops or reduces the rate of peptidase activity, the hydrolysis of peptide bonds within proteins.

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    CL  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]
    GOL  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    AC2  [ RasMol ]  +environment [ RasMol ]
    AC3  [ RasMol ]  +environment [ RasMol ]
    AC4  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 3l0r)

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Asym. Unit - sites PNG format | Biol. Unit 1 PNG format | Biol. Unit 1 - sites PNG format | Biol. Unit 2 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)
