(-) Description

Title :  CRYSTAL STRUCTURE OF APO MVL

Authors :  D. C. Williams, J. Y. Lee, M. Cai, C. A. Bewley, G. M. Clore
Date :  26 Apr 05  (Deposition) - 07 Jun 05  (Release) - 24 Feb 09  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  1.90
Chains :  Asym. Unit :  A,B,C,D,E,F,G,H
Biol. Unit 1:  A,B  (1x)
Biol. Unit 2:  C,D  (1x)
Biol. Unit 3:  E,F  (1x)
Biol. Unit 4:  G,H  (1x)
Keywords :  Hiv-1, Mvl, Cyanobacteria, Carbohydrate Binding, Sugar Binding Protein (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  D. C. Williams, J. Y. Lee, M. Cai, C. A. Bewley, G. M. Clore
Crystal Structures Of The Hiv-1 Inhibitory Cyanobacterial Protein Mvl Free And Bound To Man3Glcnac2: Structural Basis For Specificity And High-Affinity Binding To The Core Pentasaccharide From N-Linked Oligomannoside.
J. Biol. Chem. V. 280 29269 2005
PubMed-ID: 15937331  |  Reference-DOI: 10.1074/JBC.M504642200
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - MANNAN-BINDING LECTIN
    Chains: A, B, C, D, E, F, G, H
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Taxid: 562
    Organism Scientific: MICROCYSTIS VIRIDIS
    Organism Taxid: 44822
    Synonym: MVL

 Structural Features

(-) Chains, Units

  12345678
Asymmetric Unit : ABCDEFGH
Biological Unit 1 (1x): AB
Biological Unit 2 (1x):   CD
Biological Unit 3 (1x):     EF
Biological Unit 4 (1x):       GH

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (2, 19)

Asymmetric Unit (2, 19)
No.NameCountTypeFull Name
1EDO13Ligand/Ion1,2-ETHANEDIOL
2PO46Ligand/IonPHOSPHATE ION
Biological Unit 1 (2, 9)
No.NameCountTypeFull Name
1EDO5Ligand/Ion1,2-ETHANEDIOL
2PO44Ligand/IonPHOSPHATE ION
Biological Unit 2 (2, 3)
No.NameCountTypeFull Name
1EDO2Ligand/Ion1,2-ETHANEDIOL
2PO41Ligand/IonPHOSPHATE ION
Biological Unit 3 (2, 5)
No.NameCountTypeFull Name
1EDO4Ligand/Ion1,2-ETHANEDIOL
2PO41Ligand/IonPHOSPHATE ION
Biological Unit 4 (1, 2)
No.NameCountTypeFull Name
1EDO2Ligand/Ion1,2-ETHANEDIOL
2PO4-1Ligand/IonPHOSPHATE ION

(-) Sites  (19, 19)

Asymmetric Unit (19, 19)
No.NameEvidenceResiduesDescription
01AC1SOFTWARELYS A:63 , LYS A:110 , HOH A:1060BINDING SITE FOR RESIDUE PO4 A 901
02AC2SOFTWAREHOH A:1041 , GLU B:76 , LYS B:79 , LEU B:80 , HOH B:1116BINDING SITE FOR RESIDUE PO4 B 902
03AC3SOFTWAREGLU B:61 , HOH B:1065BINDING SITE FOR RESIDUE PO4 B 903
04AC4SOFTWARELYS B:63 , LYS B:110 , HOH B:1103 , LYS E:4BINDING SITE FOR RESIDUE PO4 B 904
05AC5SOFTWAREGLU D:91 , LYS D:110BINDING SITE FOR RESIDUE PO4 D 905
06AC6SOFTWAREASP F:65 , ARG F:97 , GLN F:108 , TRP H:37 , THR H:38 , HOH H:1016 , HOH H:1021 , HOH H:1093BINDING SITE FOR RESIDUE PO4 F 906
07AC7SOFTWAREGLU E:55 , ASN E:56 , GLY E:89 , ALA E:90 , HOH E:1047 , HOH E:1057BINDING SITE FOR RESIDUE EDO E 1001
08AC8SOFTWAREHIS F:29 , SER F:87 , TYR F:88 , HOH F:1015 , HOH F:1018BINDING SITE FOR RESIDUE EDO F 1002
09AC9SOFTWAREHIS E:29 , SER E:87 , TYR E:88 , HOH E:1005 , HOH E:1012BINDING SITE FOR RESIDUE EDO E 1003
10BC1SOFTWAREHIS A:29 , SER A:87 , TYR A:88 , HOH A:1013 , HOH A:1025BINDING SITE FOR RESIDUE EDO A 1004
11BC2SOFTWAREPRO A:8 , HIS B:29 , SER B:87 , HOH B:1015 , HOH B:1028BINDING SITE FOR RESIDUE EDO B 1005
12BC3SOFTWAREHIS C:29 , SER C:87 , TYR C:88 , HOH C:1010 , HOH C:1015BINDING SITE FOR RESIDUE EDO C 1006
13BC4SOFTWAREPRO C:8 , HIS D:29 , LEU D:52 , SER D:87 , TYR D:88 , HOH D:1021 , HOH D:1025BINDING SITE FOR RESIDUE EDO D 1007
14BC5SOFTWAREVAL F:54 , GLU F:55 , ASN F:56 , GLY F:89 , ALA F:90 , HOH F:1017BINDING SITE FOR RESIDUE EDO F 1008
15BC6SOFTWAREASP B:65 , TRP B:96 , ARG B:97 , GLN E:36 , TRP E:37BINDING SITE FOR RESIDUE EDO B 1009
16BC7SOFTWAREHIS G:29 , LEU G:52 , SER G:87 , HOH G:1014 , HOH G:1021 , HOH G:1099BINDING SITE FOR RESIDUE EDO G 1010
17BC8SOFTWARELEU G:67 , TYR G:88 , ALA H:28 , HIS H:29 , GLN H:30 , TYR H:88 , TYR H:111 , HOH H:1018 , HOH H:1019BINDING SITE FOR RESIDUE EDO H 1011
18BC9SOFTWAREARG B:97 , HOH B:1109 , ASN E:15BINDING SITE FOR RESIDUE EDO B 1012
19CC1SOFTWAREPRO B:70 , LEU B:71 , GLU B:101 , GLY B:102BINDING SITE FOR RESIDUE EDO B 1013

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 1ZHQ)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 1ZHQ)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 1ZHQ)

(-) PROSITE Motifs  (0, 0)

(no "PROSITE Motif" information available for 1ZHQ)

(-) Exons   (0, 0)

(no "Exon" information available for 1ZHQ)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:113
 aligned with MVL_MICVR | Q9RHG4 from UniProtKB/Swiss-Prot  Length:114

    Alignment length:113
                                    11        21        31        41        51        61        71        81        91       101       111
            MVL_MICVR     2 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 114
               SCOP domains ----------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeeeeeeee...hhhhhhhhhhhhhhhh..eeeeeeeeee...eeeeeeeee......eeeeeeeeee...hhhhhhhhhhhhhhh...eeeeeeeeee...eeeeeeeeee Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------- Transcript
                 1zhq A   1 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 113
                                    10        20        30        40        50        60        70        80        90       100       110


Chain B from PDB  Type:PROTEIN  Length:113
 aligned with MVL_MICVR | Q9RHG4 from UniProtKB/Swiss-Prot  Length:114

    Alignment length:113
                                    11        21        31        41        51        61        71        81        91       101       111
            MVL_MICVR     2 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 114
               SCOP domains ----------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeeeeeeee...hhhhhhhhhhhhhhhh..eeeeeeeeee...eeeeeeeee......eeeeeeeeee...hhhhhhhhhhhhhhh...eeeeeeeeee...eeeeeeeeee Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------- Transcript
                 1zhq B   1 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 113
                                    10        20        30        40        50        60        70        80        90       100       110


Chain C from PDB  Type:PROTEIN  Length:113
 aligned with MVL_MICVR | Q9RHG4 from UniProtKB/Swiss-Prot  Length:114

    Alignment length:113
                                    11        21        31        41        51        61        71        81        91       101       111
            MVL_MICVR     2 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 114
               SCOP domains ----------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeeeeeeee...hhhhhhhhhhhhhhhh..eeeeeeeeee...eeeeeeeee......eeeeeeeeee...hhhhhhhhhhhhhhh...eeeeeeeeee...eeeeeeeeee Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------- Transcript
                 1zhq C   1 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 113
                                    10        20        30        40        50        60        70        80        90       100       110


Chain D from PDB  Type:PROTEIN  Length:113
 aligned with MVL_MICVR | Q9RHG4 from UniProtKB/Swiss-Prot  Length:114

    Alignment length:113
                                    11        21        31        41        51        61        71        81        91       101       111
            MVL_MICVR     2 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 114
               SCOP domains ----------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeeeeeeee...hhhhhhhhhhhhhhhh..eeeeeeeeee...eeeeeeeee......eeeeeeeeee...hhhhhhhhhhhhhhh...eeeeeeeeee...eeeeeeeeee Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------- Transcript
                 1zhq D   1 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 113
                                    10        20        30        40        50        60        70        80        90       100       110


Chain E from PDB  Type:PROTEIN  Length:113
 aligned with MVL_MICVR | Q9RHG4 from UniProtKB/Swiss-Prot  Length:114

    Alignment length:113
                                    11        21        31        41        51        61        71        81        91       101       111
            MVL_MICVR     2 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 114
               SCOP domains ----------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeeeeeeee...hhhhhhhhhhhhhhhh..eeeeeeeeee...eeeeeeeee......eeeeeeeeee...hhhhhhhhhhhhhhh...eeeeeeeeee...eeeeeeeeee Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------- Transcript
                 1zhq E   1 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 113
                                    10        20        30        40        50        60        70        80        90       100       110


Chain F from PDB  Type:PROTEIN  Length:113
 aligned with MVL_MICVR | Q9RHG4 from UniProtKB/Swiss-Prot  Length:114

    Alignment length:113
                                    11        21        31        41        51        61        71        81        91       101       111
            MVL_MICVR     2 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 114
               SCOP domains ----------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeeeeeeee...hhhhhhhhhhhhhhhh..eeeeeeeeee...eeeeeeeee......eeeeeeeeee...hhhhhhhhhhhhhhh...eeeeeeeeee...eeeeeeeeee Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------- Transcript
                 1zhq F   1 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 113
                                    10        20        30        40        50        60        70        80        90       100       110


Chain G from PDB  Type:PROTEIN  Length:113
 aligned with MVL_MICVR | Q9RHG4 from UniProtKB/Swiss-Prot  Length:114

    Alignment length:113
                                    11        21        31        41        51        61        71        81        91       101       111
            MVL_MICVR     2 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 114
               SCOP domains ----------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains ----------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author .eeeeeeeee...hhhhhhhhhhhhhhhh..eeeeeeeeee...eeeeeeeee......eeeeeeeeee...hhhhhhhhhhhhhhh...eeeeeeeeee...eeeeeeeeee Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------- Transcript
                 1zhq G   1 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 113
                                    10        20        30        40        50        60        70        80        90       100       110


Chain H from PDB  Type:PROTEIN  Length:113
 aligned with MVL_MICVR | Q9RHG4 from UniProtKB/Swiss-Prot  Length:114

    Alignment length:113
                                    11        21        31        41        51        61        71        81        91       101       111
            MVL_MICVR     2 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 114
               SCOP domains ----------------------------------------------------------------------------------------------------------------- SCOP domains
               CATH domains ----------------------------------------------------------------------------------------------------------------- CATH domains
           Pfam domains (1) -------------------------------------------------------------------------MVL-1zhqH01 H:74-110                 --- Pfam domains (1)
           Pfam domains (2) -------------------------------------------------------------------------MVL-1zhqH02 H:74-110                 --- Pfam domains (2)
           Pfam domains (3) -------------------------------------------------------------------------MVL-1zhqH03 H:74-110                 --- Pfam domains (3)
           Pfam domains (4) -------------------------------------------------------------------------MVL-1zhqH04 H:74-110                 --- Pfam domains (4)
           Pfam domains (5) -------------------------------------------------------------------------MVL-1zhqH05 H:74-110                 --- Pfam domains (5)
           Pfam domains (6) -------------------------------------------------------------------------MVL-1zhqH06 H:74-110                 --- Pfam domains (6)
           Pfam domains (7) -------------------------------------------------------------------------MVL-1zhqH07 H:74-110                 --- Pfam domains (7)
           Pfam domains (8) -------------------------------------------------------------------------MVL-1zhqH08 H:74-110                 --- Pfam domains (8)
           Pfam domains (9) -------------------------------------------------------------------------MVL-1zhqH09 H:74-110                 --- Pfam domains (9)
          Pfam domains (10) -------------------------------------------------------------------------MVL-1zhqH10 H:74-110                 --- Pfam domains (10)
          Pfam domains (11) -------------------------------------------------------------------------MVL-1zhqH11 H:74-110                 --- Pfam domains (11)
          Pfam domains (12) -------------------------------------------------------------------------MVL-1zhqH12 H:74-110                 --- Pfam domains (12)
          Pfam domains (13) -------------------------------------------------------------------------MVL-1zhqH13 H:74-110                 --- Pfam domains (13)
          Pfam domains (14) -------------------------------------------------------------------------MVL-1zhqH14 H:74-110                 --- Pfam domains (14)
          Pfam domains (15) -------------------------------------------------------------------------MVL-1zhqH15 H:74-110                 --- Pfam domains (15)
          Pfam domains (16) -------------------------------------------------------------------------MVL-1zhqH16 H:74-110                 --- Pfam domains (16)
         Sec.struct. author .eeeeeeeee...hhhhhhhhhhhhhhhh..eeeeeeeeee...eeeeeeeee......eeeeeeeeee...hhhhhhhhhhhhhhh...eeeeeeeeee...eeeeeeeeee Sec.struct. author
                 SAPs(SNPs) ----------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ----------------------------------------------------------------------------------------------------------------- PROSITE
                 Transcript ----------------------------------------------------------------------------------------------------------------- Transcript
                 1zhq H   1 ASYKVNIPAGPLWSNAEAQQVGPKIAAAHQGNFTGQWTTVVESAMSVVEVELQVENTGIHEFKTDVLAGPLWSNDEAQKLGPQIAASYGAEFTGQWRTIVEGVMSVIQIKYTF 113
                                    10        20        30        40        50        60        70        80        90       100       110
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (0, 0)

(no "SCOP Domain" information available for 1ZHQ)

(-) CATH Domains  (0, 0)

(no "CATH Domain" information available for 1ZHQ)

(-) Pfam Domains  (1, 16)

Asymmetric Unit
(-)
Clan: no clan defined [family: MVL] (2)
(-)
Family: MVL (2)
(-)
Microcystis viridis (2)
1aMVL-1zhqH01H:74-110
1bMVL-1zhqH02H:74-110
1cMVL-1zhqH03H:74-110
1dMVL-1zhqH04H:74-110
1eMVL-1zhqH05H:74-110
1fMVL-1zhqH06H:74-110
1gMVL-1zhqH07H:74-110
1hMVL-1zhqH08H:74-110
1iMVL-1zhqH09H:74-110
1jMVL-1zhqH10H:74-110
1kMVL-1zhqH11H:74-110
1lMVL-1zhqH12H:74-110
1mMVL-1zhqH13H:74-110
1nMVL-1zhqH14H:74-110
1oMVL-1zhqH15H:74-110
1pMVL-1zhqH16H:74-110

(-) Gene Ontology  (6, 6)

Asymmetric Unit(hide GO term definitions)
Chain A,B,C,D,E,F,G,H   (MVL_MICVR | Q9RHG4)
molecular function
    GO:0030246    carbohydrate binding    Interacting selectively and non-covalently with any carbohydrate, which includes monosaccharides, oligosaccharides and polysaccharides as well as substances derived from monosaccharides by reduction of the carbonyl group (alditols), by oxidation of one or more hydroxy groups to afford the corresponding aldehydes, ketones, or carboxylic acids, or by replacement of one or more hydroxy group(s) by a hydrogen atom. Cyclitols are generally not regarded as carbohydrates.
    GO:0016787    hydrolase activity    Catalysis of the hydrolysis of various bonds, e.g. C-O, C-N, C-C, phosphoric anhydride bonds, etc. Hydrolase is the systematic name for any enzyme of EC class 3.
    GO:0016798    hydrolase activity, acting on glycosyl bonds    Catalysis of the hydrolysis of any glycosyl bond.
biological process
    GO:0008152    metabolic process    The chemical reactions and pathways, including anabolism and catabolism, by which living organisms transform chemical substances. Metabolic processes typically transform small molecules, but also include macromolecular processes such as DNA repair and replication, and protein synthesis and degradation.
    GO:0050688    regulation of defense response to virus    Any process that modulates the frequency, rate or extent of the antiviral response of a cell or organism.
cellular component
    GO:0005737    cytoplasm    All of the contents of a cell excluding the plasma membrane and nucleus, but including other subcellular structures.

 Visualization

(-) Interactive Views

Asymmetric Unit
  Complete Structure
    Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
    WebMol | AstexViewer[tm]@PDBe
(Java Applets, require no local installation except for Java; loading may be slow)
    STRAP
(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    RasMol
(require local installation)
    Molscript (VRML)
(requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

  Ligands, Modified Residues, Ions
    EDO  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]
    PO4  [ RasMol | Jena3D ]  +environment [ RasMol | Jena3D ]

  Sites
    AC1  [ RasMol ]  +environment [ RasMol ]
    AC2  [ RasMol ]  +environment [ RasMol ]
    AC3  [ RasMol ]  +environment [ RasMol ]
    AC4  [ RasMol ]  +environment [ RasMol ]
    AC5  [ RasMol ]  +environment [ RasMol ]
    AC6  [ RasMol ]  +environment [ RasMol ]
    AC7  [ RasMol ]  +environment [ RasMol ]
    AC8  [ RasMol ]  +environment [ RasMol ]
    AC9  [ RasMol ]  +environment [ RasMol ]
    BC1  [ RasMol ]  +environment [ RasMol ]
    BC2  [ RasMol ]  +environment [ RasMol ]
    BC3  [ RasMol ]  +environment [ RasMol ]
    BC4  [ RasMol ]  +environment [ RasMol ]
    BC5  [ RasMol ]  +environment [ RasMol ]
    BC6  [ RasMol ]  +environment [ RasMol ]
    BC7  [ RasMol ]  +environment [ RasMol ]
    BC8  [ RasMol ]  +environment [ RasMol ]
    BC9  [ RasMol ]  +environment [ RasMol ]
    CC1  [ RasMol ]  +environment [ RasMol ]

  Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 1zhq)

Biological Units
  Complete Structure
    Biological Unit 1  [ Jena3D ]
    Biological Unit 2  [ Jena3D ]
    Biological Unit 3  [ Jena3D ]
    Biological Unit 4  [ Jena3D ]

(-) Still Images

Jmol
  protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick
[ Asym. Unit PNG format | Asym. Unit - sites PNG format | Biol. Unit 1 PNG format | Biol. Unit 1 - sites PNG format | Biol. Unit 2 PNG format | Biol. Unit 3 PNG format | Biol. Unit 4 PNG format ](automatic orientation, automatically generated)
Molscript
  protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick
[ mono PDF format | stereo PDF format ](default orientation, automatically generated)

 Databases and Analysis Tools

(-) Databases

Access by PDB/NDB ID
  1zhq
    Family and Domain Information: ProDom | SYSTERS
    General Structural Information: GlycoscienceDB | MMDB | NDB | OCA | PDB | PDBe | PDBj | PDBsum | PDBWiki | PQS | PROTEOPEDIA
    Orientation in Membranes: OPM
    Protein Surface: SURFACE
    Secondary Structure: DSSP (structure derived) | HSSP (homology derived)
    Structural Genomics: GeneCensus
    Structural Neighbours: CE | VAST
    Structure Classification: CATH | Dali | SCOP
    Validation and Original Data: BMRB Data View | BMRB Restraints Grid | EDS | PROCHECK | RECOORD | WHAT_CHECK

Access by UniProt ID/Accession number
  MVL_MICVR | Q9RHG4
    Comparative Protein Structure Models: ModBase
    Genomic Information: Ensembl
    Protein-protein Interaction: DIP
    Sequence, Family and Domain Information: InterPro | Pfam | SMART | UniProtKB/SwissProt

Access by Enzyme Classificator   (EC Number)
  (no 'Enzyme Classificator' available)
    General Enzyme Information: BRENDA | EC-PDB | Enzyme | IntEnz
    Pathway: KEGG | MetaCyc

Access by Disease Identifier   (MIM ID)
  (no 'MIM ID' available)
    Disease Information: OMIM

Access by GenAge ID
  (no 'GenAge ID' available)
    Age Related Information: GenAge

(-) Analysis Tools

Access by PDB/NDB ID
    Domain Information: XDom
    Interatomic Contacts of Structural Units: CSU
    Ligand-protein Contacts: LPC
    Protein Cavities: castP
    Sequence and Secondary Structure: PDBCartoon
    Structure Alignment: STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
    Structure and Sequence Browser: STING

Access by UniProt ID/Accession number
  MVL_MICVR | Q9RHG4
    Protein Disorder Prediction: DisEMBL | FoldIndex | GLOBPLOT (for more information see DisProt)

 Related Entries

(-) Entries Sharing at Least One Protein Chain (UniProt ID)

UniProtKB/Swiss-Prot
        MVL_MICVR | Q9RHG4: 1zhs

(-) Related Entries Specified in the PDB File

1zhs CRYSTAL STRUCTURE OF MVL BOUND TO MAN3GLCNAC2
