Title :   CONFORMATIONAL CHANGE OF PSEUDOURIDINE 55 SYNTHASE UPON ITS ASSOCIATION WITH RNA SUBSTRATE

Authors :   K. Phannachet, R. H. Huang

Date :   16 Apr 05 (Deposition) - 26 Apr 05 (Release) - 24 Feb 09 (Revision)

Method :   X-RAY DIFFRACTION

Resolution :   2.90

Chains :   Asym. Unit : A,B,C,D
Biol. Unit 1: A  (1x)
Biol. Unit 2: B  (1x)
Biol. Unit 3: C  (1x)
Biol. Unit 4: D  (1x)

Keywords :   Rna Modification Enzyme, Lyase (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :   K. Phannachet, R. H. Huang
Conformational Change Of Pseudouridine 55 Synthase Upon Its Association With Rna Substrate
Nucleic Acids Res. V. 32 1422 2004
PubMed-ID: 14990747 | Reference-DOI: 10.1093/NAR/GKH287
(for further references see the PDB file header)

Molecule 1 - TRNA PSEUDOURIDINE SYNTHASE B
	Chains	:	A, B, C, D
	EC Number	:	4.2.1.70
	Engineered	:	YES
	Expression System	:	ESCHERICHIA COLI BL21(DE3)
	Expression System Plasmid	:	PLM1
	Expression System Strain	:	BL21DE3
	Expression System Taxid	:	469008
	Expression System Vector Type	:	PLASMID
	Gene	:	TRUB
	Organism Scientific	:	THERMOTOGA MARITIMA
	Organism Taxid	:	2336
	Synonym	:	TRNA PSEUDOURIDINE 55 SYNTHASE, PSI55 SYNTHASE, PSEUDOURIDYLATE SYNTHASE, URACIL HYDROLYASE

		1	2	3	4
Asymmetric Unit	:	A	B	C	D
Biological Unit 1 (1x)	:	A
Biological Unit 2 (1x)	:		B
Biological Unit 3 (1x)	:			C
Biological Unit 4 (1x)	:				D

Summary Information (see also Sequences/Alignments below)

Asymmetric Unit (1, 4)

No.	Name	Count	Type	Full Name
1	MG	4	Ligand/Ion	MAGNESIUM ION

Biological Unit 1 (0, 0)

No.	Name	Count	Type	Full Name
1	MG	-1	Ligand/Ion	MAGNESIUM ION

Biological Unit 2 (0, 0)

No.	Name	Count	Type	Full Name
1	MG	-1	Ligand/Ion	MAGNESIUM ION

Biological Unit 3 (0, 0)

No.	Name	Count	Type	Full Name
1	MG	-1	Ligand/Ion	MAGNESIUM ION

Biological Unit 4 (0, 0)

No.	Name	Count	Type	Full Name
1	MG	-1	Ligand/Ion	MAGNESIUM ION

Asymmetric Unit (4, 4)

No.	Name	Evidence	Residues	Description
1	AC1	SOFTWARE	HIS A:17 , HIS A:34 , HOH A:328	BINDING SITE FOR RESIDUE MG A 310
2	AC2	SOFTWARE	HIS B:17 , HIS B:34 , HOH B:316	BINDING SITE FOR RESIDUE MG B 310
3	AC3	SOFTWARE	HIS C:17 , HIS C:34	BINDING SITE FOR RESIDUE MG C 310
4	AC4	SOFTWARE	HIS D:17 , HIS D:34	BINDING SITE FOR RESIDUE MG D 310

Asymmetric Unit

No.	Residues
1	A:92	-	A:184
2	B:92	-	B:184
3	C:92	-	C:184
4	D:92	-	D:184

(no "Cis Peptide Bond" information available for 1ZE1)

(no "SAP(SNP)/Variant" information available for 1ZE1)

Asymmetric Unit (1, 4)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	PUA	PS50890	PUA domain profile.	TRUB_THEMA	229-306	4	A:229-306 B:229-306 C:229-306 D:229-306

Biological Unit 1 (1, 1)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	PUA	PS50890	PUA domain profile.	TRUB_THEMA	229-306	1	A:229-306 - - -

Biological Unit 2 (1, 1)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	PUA	PS50890	PUA domain profile.	TRUB_THEMA	229-306	1	- B:229-306 - -

Biological Unit 3 (1, 1)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	PUA	PS50890	PUA domain profile.	TRUB_THEMA	229-306	1	- - C:229-306 -

Biological Unit 4 (1, 1)

	PROSITE			UniProtKB		PDB
No.	ID	AC	Description	ID	Location	Count	Location
1	PUA	PS50890	PUA domain profile.	TRUB_THEMA	229-306	1	- - - D:229-306

(no "Exon" information available for 1ZE1)

Asymmetric Unit

Reformat:	Number of residues per line = ('0' or empty: single-line sequence representation)
	Number of residues per labelling interval =
	UniProt sequence: complete aligned part

Show mapping:	SCOP domains	CATH domains	Pfam domains	Secondary structure (by author)
	SAPs(SNPs)	PROSITE motifs	Exons
	(details for a mapped element are shown in a popup box when the mouse pointer rests over it)

Chain A from PDB  Type:PROTEIN  Length:308
 aligned with TRUB_THEMA | Q9WZW0 from UniProtKB/Swiss-Prot  Length:309

    Alignment length:308
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300
           TRUB_THEMA     1 MKHGILVAYKPKGPTSHDVVDEVRKKLKTRKVGHGGTLDPFACGVLIIGVNQGTRILEFYKDLKKVYWVKMRLGLITETFDITGEVVEERECNVTEEEIREAIFSFVGEYDQVPPAYSAKKYKGERLYKLAREGKIINLPPKRVKIFKIWDVNIEGRDVSFRVEVSPGTYIRSLCMDIGYKLGCGATAVELVRESVGPHTIEESLNVFEAAPEEIENRIIPLEKCLEWLPRVVVHQESTKMILNGSQIHLEMLKEWDGFKKGEVVRVFNEEGRLLALAEAERNSSFLETLRKHERNERVLTLRKVFNT 308
               SCOP domains d1ze1a2 A:1-228 Pseudouridine synthase II TruB                                                                                                                                                                                      d1ze1a1 A:229-308 Pseudouridine synthase II TruB, C-terminal domain              SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...eeeeeee....hhhhhhhhhhhhhh...eeee.......eeeeeeee.hhhhhhhhhhh..eeeeeeeee..ee........eee......hhhhhhhhhhhhhee................hhhhhhhh...........eeeeeeeeeee..eeeeeeee....hhhhhhhhhhhhh...eeeeeeeeeee..ee.....hhhhhhhhhhhh..ee.hhh.....eeee...hhhhhhh...ee...eee........eeeeee....eeeeeee.....hhhhhh......eeeeeeee... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------PUA  PDB: A:229-306 UniProt: 229-306                                          -- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1ze1 A   1 MKHGILVAYKPKGPTSHDVVDEVRKKLKTRKVGHGGTLDPFACGVLIIGVNQGTRILEFYKDLKKVYWVKMRLGLITETFDITGEVVEERECNVTEEEIREAIFSFVGEYDQVPPAYSAKKYKGERLYKLAREGKIINLPPKRVKIFKIWDVNIEGRDVSFRVEVSPGTYIRSLCMDIGYKLGCGATAVELVRESVGPHTIEESLNVFEAAPEEIENRIIPLEKCLEWLPRVVVHQESTKMILNGSQIHLEMLKEWDGFKKGEVVRVFNEEGRLLALAEAERNSSFLETLRKHERQRRVLTLRKVFQT 308
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300

Chain B from PDB  Type:PROTEIN  Length:308
 aligned with TRUB_THEMA | Q9WZW0 from UniProtKB/Swiss-Prot  Length:309

    Alignment length:308
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300
           TRUB_THEMA     1 MKHGILVAYKPKGPTSHDVVDEVRKKLKTRKVGHGGTLDPFACGVLIIGVNQGTRILEFYKDLKKVYWVKMRLGLITETFDITGEVVEERECNVTEEEIREAIFSFVGEYDQVPPAYSAKKYKGERLYKLAREGKIINLPPKRVKIFKIWDVNIEGRDVSFRVEVSPGTYIRSLCMDIGYKLGCGATAVELVRESVGPHTIEESLNVFEAAPEEIENRIIPLEKCLEWLPRVVVHQESTKMILNGSQIHLEMLKEWDGFKKGEVVRVFNEEGRLLALAEAERNSSFLETLRKHERNERVLTLRKVFNT 308
               SCOP domains d1ze1b2 B:1-228 Pseudouridine synthase II TruB                                                                                                                                                                                      d1ze1b1 B:229-308 Pseudouridine synthase II TruB, C-terminal domain              SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...eeeeeee....hhhhhhhhhhhhhh...eeee.......eeeeeeee.hhhhhhhhhhh..eeeeeeeee..ee........eeee.....hhhhhhhhhhhhhee.............hhhhhhhhhhh...........eeeeeeeeeee..eeeeeeee....hhhhhhhhhhhhh...eeeeeeeeeee..ee.....hhhhhhhhhhhh..ee.hhh.....eeee...hhhhhhh...ee...eee........eeeeee....eeeeeee.....hhhhhhhh....eeeeeeee... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------PUA  PDB: B:229-306 UniProt: 229-306                                          -- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1ze1 B   1 MKHGILVAYKPKGPTSHDVVDEVRKKLKTRKVGHGGTLDPFACGVLIIGVNQGTRILEFYKDLKKVYWVKMRLGLITETFDITGEVVEERECNVTEEEIREAIFSFVGEYDQVPPAYSAKKYKGERLYKLAREGKIINLPPKRVKIFKIWDVNIEGRDVSFRVEVSPGTYIRSLCMDIGYKLGCGATAVELVRESVGPHTIEESLNVFEAAPEEIENRIIPLEKCLEWLPRVVVHQESTKMILNGSQIHLEMLKEWDGFKKGEVVRVFNEEGRLLALAEAERNSSFLETLRKHERQRRVLTLRKVFQT 308
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300

Chain C from PDB  Type:PROTEIN  Length:308
 aligned with TRUB_THEMA | Q9WZW0 from UniProtKB/Swiss-Prot  Length:309

    Alignment length:308
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300
           TRUB_THEMA     1 MKHGILVAYKPKGPTSHDVVDEVRKKLKTRKVGHGGTLDPFACGVLIIGVNQGTRILEFYKDLKKVYWVKMRLGLITETFDITGEVVEERECNVTEEEIREAIFSFVGEYDQVPPAYSAKKYKGERLYKLAREGKIINLPPKRVKIFKIWDVNIEGRDVSFRVEVSPGTYIRSLCMDIGYKLGCGATAVELVRESVGPHTIEESLNVFEAAPEEIENRIIPLEKCLEWLPRVVVHQESTKMILNGSQIHLEMLKEWDGFKKGEVVRVFNEEGRLLALAEAERNSSFLETLRKHERNERVLTLRKVFNT 308
               SCOP domains d1ze1c2 C:1-228 Pseudouridine synthase II TruB                                                                                                                                                                                      d1ze1c1 C:229-308 Pseudouridine synthase II TruB, C-terminal domain              SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
               Pfam domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ...eeeeeee....hhhhhhhhhhhhhh...eeee.......eeeeeeee.hhhhhhhhhhh..eeeeeeee...ee........eee......hhhhhhhhhhhhhee..............hhhhhhhh.............eeeeeeeeeee..eeeeeeee....hhhhhhhhhhhhh....eeeeeeeeee..ee.hhh.hhhhhhhhhhhh.............eeee...hhhhhhh...ee...eee........eeeeee....eeeeeee...hhhhh.........eeeeeeee... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------PUA  PDB: C:229-306 UniProt: 229-306                                          -- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1ze1 C   1 MKHGILVAYKPKGPTSHDVVDEVRKKLKTRKVGHGGTLDPFACGVLIIGVNQGTRILEFYKDLKKVYWVKMRLGLITETFDITGEVVEERECNVTEEEIREAIFSFVGEYDQVPPAYSAKKYKGERLYKLAREGKIINLPPKRVKIFKIWDVNIEGRDVSFRVEVSPGTYIRSLCMDIGYKLGCGATAVELVRESVGPHTIEESLNVFEAAPEEIENRIIPLEKCLEWLPRVVVHQESTKMILNGSQIHLEMLKEWDGFKKGEVVRVFNEEGRLLALAEAERNSSFLETLRKHERQRRVLTLRKVFQT 308
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300

Chain D from PDB  Type:PROTEIN  Length:284
 aligned with TRUB_THEMA | Q9WZW0 from UniProtKB/Swiss-Prot  Length:309

    Alignment length:308
                                    10        20        30        40        50        60        70        80        90       100       110       120       130       140       150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300
           TRUB_THEMA     1 MKHGILVAYKPKGPTSHDVVDEVRKKLKTRKVGHGGTLDPFACGVLIIGVNQGTRILEFYKDLKKVYWVKMRLGLITETFDITGEVVEERECNVTEEEIREAIFSFVGEYDQVPPAYSAKKYKGERLYKLAREGKIINLPPKRVKIFKIWDVNIEGRDVSFRVEVSPGTYIRSLCMDIGYKLGCGATAVELVRESVGPHTIEESLNVFEAAPEEIENRIIPLEKCLEWLPRVVVHQESTKMILNGSQIHLEMLKEWDGFKKGEVVRVFNEEGRLLALAEAERNSSFLETLRKHERNERVLTLRKVFNT 308
               SCOP domains d1ze1d2 D:1-228 Pseudouridine synthase II TruB                                                                                                                                                                                      d1ze1d1 D:229-308 Pseudouridine synthase II TruB, C-terminal domain              SCOP domains
               CATH domains -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- CATH domains
           Pfam domains (1) -----------------------TruB_N-1ze1D05 D:24-171                                                                                                                             ----------------------------------------------------------PUA-1ze1D01 D:230-300                                                  -------- Pfam domains (1)
           Pfam domains (2) -----------------------TruB_N-1ze1D06 D:24-171                                                                                                                             ----------------------------------------------------------PUA-1ze1D02 D:230-300                                                  -------- Pfam domains (2)
           Pfam domains (3) -----------------------TruB_N-1ze1D07 D:24-171                                                                                                                             ----------------------------------------------------------PUA-1ze1D03 D:230-300                                                  -------- Pfam domains (3)
           Pfam domains (4) -----------------------TruB_N-1ze1D08 D:24-171                                                                                                                             ----------------------------------------------------------PUA-1ze1D04 D:230-300                                                  -------- Pfam domains (4)
         Sec.struct. author ...eeeeeee....hhhhhhhhhhhhhh...eeee.......eeeeeeee.hhhhhhhhhhhh.eeeeeeeee..ee........eee......hhhhhhhhhhhhh.........------------------------.....eeeeeeee....eeeeeeee....hhhhhhhhhhhhhh..eeeeeeeeeee..ee..........hhhhhhh..ee.hhh.....eeee...hhhhhhh...ee...eee........eeeee.....eeeeeee....hhhhhhh......eeeeeeee... Sec.struct. author
                 SAPs(SNPs) -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                    PROSITE ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------PUA  PDB: D:229-306 UniProt: 229-306                                          -- PROSITE
                 Transcript -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Transcript
                 1ze1 D   1 MKHGILVAYKPKGPTSHDVVDEVRKKLKTRKVGHGGTLDPFACGVLIIGVNQGTRILEFYKDLKKVYWVKMRLGLITETFDITGEVVEERECNVTEEEIREAIFSFVGEYDQVPPA------------------------PKRVKIFKIWDVNIEGRDVSFRVEVSPGTYIRSLCMDIGYKLGCGATAVELVRESVGPHTIEESLNVFEAAPEEIENRIIPLEKCLEWLPRVVVHQESTKMILNGSQIHLEMLKEWDGFKKGEVVRVFNEEGRLLALAEAERNSSFLETLRKHERQRRVLTLRKVFQT 308
                                    10        20        30        40        50        60        70        80        90       100       110     |   -         -         -|      150       160       170       180       190       200       210       220       230       240       250       260       270       280       290       300
                                                                                                                                             116                      141

Legend:		→ Mismatch	(orange background)
	-	→ Gap	(green background, '-', border residues have a numbering label)
		→ Modified Residue	(blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
	x	→ Chemical Group	(purple background, 'x', labelled with number + name, e.g. ACE or NH2)
	extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '\|'

Asymmetric Unit

Classes(

)

Folds(

)

Superfamilies( (-)

)

Families(

)

Protein Domains( (-)

)

Organisms( (-)

)

Class: All beta proteins (24004)

Fold: PUA domain-like (96)

Superfamily: PUA domain-like (96)

Family: PUA domain (22)

Protein domain: Pseudouridine synthase II TruB, C-terminal domain (11)

Thermotoga maritima [TaxId: 2336] (4)

1a	d1ze1a1	A:229-308
1b	d1ze1b1	B:229-308
1c	d1ze1c1	C:229-308
1d	d1ze1d1	D:229-308

Class: Alpha and beta proteins (a+b) (23004)

Fold: Pseudouridine synthase (30)

Superfamily: Pseudouridine synthase (30)

Family: Pseudouridine synthase II TruB (12)

Protein domain: Pseudouridine synthase II TruB (11)

Thermotoga maritima [TaxId: 2336] (4)

2a	d1ze1a2	A:1-228
2b	d1ze1b2	B:1-228
2c	d1ze1c2	C:1-228
2d	d1ze1d2	D:1-228

(no "CATH Domain" information available for 1ZE1)

Asymmetric Unit

Clans(

)

Families(

)

Organisms( (-)

)

Clan: PUA (42)

Family: PUA (12)

Thermotoga maritima (2)

1a	PUA-1ze1D01	D:230-300
1b	PUA-1ze1D02	D:230-300
1c	PUA-1ze1D03	D:230-300
1d	PUA-1ze1D04	D:230-300

Clan: no clan defined [family: TruB_N] (12)

Family: TruB_N (12)

Thermotoga maritima (2)

2a	TruB_N-1ze1D05	D:24-171
2b	TruB_N-1ze1D06	D:24-171
2c	TruB_N-1ze1D07	D:24-171
2d	TruB_N-1ze1D08	D:24-171

Asymmetric Unit(hide GO term definitions)

Chain A,B,C,D (TRUB_THEMA | Q9WZW0)

molecular function
	GO:0003723	RNA binding	Interacting selectively and non-covalently with an RNA molecule or a portion thereof.
	GO:0016853	isomerase activity	Catalysis of the geometric or structural changes within one molecule. Isomerase is the systematic name for any enzyme of EC class 5.
	GO:0009982	pseudouridine synthase activity	Catalysis of the reaction: RNA uridine = RNA pseudouridine. Conversion of uridine in an RNA molecule to pseudouridine by rotation of the C1'-N-1 glycosidic bond of uridine in RNA to a C1'-C5.
biological process
	GO:0009451	RNA modification	The covalent alteration of one or more nucleotides within an RNA molecule to produce an RNA molecule with a sequence that differs from that coded genetically.
	GO:0006396	RNA processing	Any process involved in the conversion of one or more primary RNA transcripts into one or more mature RNA molecules.
	GO:1990481	mRNA pseudouridine synthesis	The intramolecular conversion of uridine to pseudouridine in an mRNA molecule.
	GO:0001522	pseudouridine synthesis	The intramolecular conversion of uridine to pseudouridine within an RNA molecule. This posttranscriptional base modification occurs in tRNA, rRNA, and snRNAs.
	GO:0006400	tRNA modification	The covalent alteration of one or more nucleotides within a tRNA molecule to produce a tRNA molecule with a sequence that differs from that coded genetically.
	GO:0008033	tRNA processing	The process in which a pre-tRNA molecule is converted to a mature tRNA, ready for addition of an aminoacyl group.
	GO:0031119	tRNA pseudouridine synthesis	The intramolecular conversion of uridine to pseudouridine in a tRNA molecule.

Asymmetric Unit
	Complete Structure
		Jena3D(integrated viewing of ligand, site, SAP, PROSITE, SCOP information)
		WebMol \| AstexViewer[tm]@PDBe (Java Applets, require no local installation except for Java; loading may be slow)
		STRAP (Java WebStart application, automatic local installation, requires Java; full application with system access!)
		RasMol (require local installation)
		Molscript (VRML) (requires installation of a VRML viewer; select preferred view via VRML and generate a mono or stereo PDF format file)

	Ligands, Modified Residues, Ions
		MG	[ RasMol \| Jena3D ]	+environment [ RasMol \| Jena3D ]

	Sites
		AC1	[ RasMol ]	+environment [ RasMol ]
		AC2	[ RasMol ]	+environment [ RasMol ]
		AC3	[ RasMol ]	+environment [ RasMol ]
		AC4	[ RasMol ]	+environment [ RasMol ]

	Cis Peptide Bonds
(no "Cis Peptide Bonds" information available for 1ze1)

Biological Units
	Complete Structure
		Biological Unit 1	[ Jena3D ]
		Biological Unit 2	[ Jena3D ]
		Biological Unit 3	[ Jena3D ]
		Biological Unit 4	[ Jena3D ]

Jmol
	protein: cartoon or spacefill or dots and stick; nucleic acid: cartoon and stick; ligands: spacefill; active site: stick [ Asym. Unit PNG format \| Asym. Unit - sites PNG format \| Biol. Unit 1 PNG format \| Biol. Unit 1 - sites PNG format \| Biol. Unit 2 PNG format \| Biol. Unit 3 PNG format \| Biol. Unit 4 PNG format ](automatic orientation, automatically generated)
Molscript
	protein, nucleic acid: cartoon; ligands: spacefill; active site: ball and stick [ mono PDF format \| stereo PDF format ](default orientation, automatically generated)

Access by PDB/NDB ID
	1ze1
		Family and Domain Information	:	ProDom \| SYSTERS
		General Structural Information	:	GlycoscienceDB \| MMDB \| NDB \| OCA \| PDB \| PDBe \| PDBj \| PDBsum \| PDBWiki \| PQS \| PROTEOPEDIA
		Orientation in Membranes	:	OPM
		Protein Surface	:	SURFACE
		Secondary Structure	:	DSSP (structure derived) \| HSSP (homology derived)
		Structural Genomics	:	GeneCensus
		Structural Neighbours	:	CE \| VAST
		Structure Classification	:	CATH \| Dali \| SCOP
		Validation and Original Data	:	BMRB Data View \| BMRB Restraints Grid \| EDS \| PROCHECK \| RECOORD \| WHAT_CHECK

Access by UniProt ID/Accession number
	TRUB_THEMA \| Q9WZW0
		Comparative Protein Structure Models	:	ModBase
		Genomic Information	:	Ensembl
		Protein-protein Interaction	:	DIP
		Sequence, Family and Domain Information	:	InterPro \| Pfam \| SMART \| UniProtKB/SwissProt

Access by Enzyme Classificator (EC Number)
	4.2.1.70
		General Enzyme Information	:	BRENDA \| EC-PDB \| Enzyme \| IntEnz
		Pathway	:	KEGG \| MetaCyc

Access by Disease Identifier (MIM ID)
	(no 'MIM ID' available)
		Disease Information	:	OMIM

Access by GenAge ID
	(no 'GenAge ID' available)
		Age Related Information	:	GenAge

Access by PDB/NDB ID
		Domain Information	:	XDom
		Interatomic Contacts of Structural Units	:	CSU
		Ligand-protein Contacts	:	LPC
		Protein Cavities	:	castP
		Sequence and Secondary Structure	:	PDBCartoon
		Structure Alignment	:	STRAP(Java WebStart application, automatic local installation, requires Java; full application with system access!)
		Structure and Sequence Browser	:	STING

Access by UniProt ID/Accession number
	TRUB_THEMA \| Q9WZW0
		Protein Disorder Prediction	:	DisEMBL \| FoldIndex \| GLOBPLOT (for more information see DisProt)

UniProtKB/Swiss-Prot
	TRUB_THEMA \| Q9WZW0	:	1r3e 1ze2 2ab4

1ze2	THE SAME PROTEIN COMPLEXED WITH RNA

Description

Compounds

Structural Features

Chains, Units

Ligands, Modified Residues, Ions (1, 4)

Sites (4, 4)

SS Bonds (4, 4)

Cis Peptide Bonds (0, 0)

Sequence-Structure Mapping

SAPs(SNPs)/Variants (0, 0)

PROSITE Motifs (1, 4)

Exons (0, 0)

Sequences/Alignments

Classification and Annotation

SCOP Domains (2, 8)

CATH Domains (0, 0)

Pfam Domains (2, 8)

Gene Ontology (10, 10)

Visualization

Interactive Views

Still Images

Databases and Analysis Tools

Databases

Analysis Tools

Related Entries

Entries Sharing at Least One Protein Chain (UniProt ID)

Related Entries Specified in the PDB File
