(-) Description

Title :  CORE STREPTAVIDIN-BNA COMPLEX

Authors :  O. Livnah, T. Huberman, M. Wilchek, E. A. Bayer, Y. Eisenberg-Domovich
Date :  20 Mar 01  (Deposition) - 12 Sep 01  (Release) - 24 Feb 09  (Revision)
Method :  X-RAY DIFFRACTION
Resolution :  2.40
Chains :  Asym. Unit :  A,B
Biol. Unit 1:  A,B  (2x)
Keywords :  Classical Beta Barrel, Protein-Ligand Complex, Unknown Function (Keyword Search: [Gene Ontology, PubMed, Web (Google)] )

Reference :  T. Huberman, Y. Eisenberg-Domovich, G. Gitlin, T. Kulik, E. A. Bayer, M. Wilchek, O. Livnah
Chicken Avidin Exhibits Pseudo-Catalytic Properties. Biochemical, Structural, And Electrostatic Consequences.
J. Biol. Chem. V. 276 32031 2001
PubMed-ID: 11395489  |  Reference-DOI: 10.1074/JBC.M102018200
(for further references see the PDB file header)

(-) Compounds

Molecule 1 - STREPTAVIDIN
    Chains: A, B
    Engineered: YES
    Expression System: ESCHERICHIA COLI
    Expression System Taxid: 562
    Fragment: RESIDUES 25-163
    Organism Scientific: STREPTOMYCES AVIDINII
    Organism Taxid: 1895

 Structural Features

(-) Chains, Units

  12
Asymmetric Unit : AB
Biological Unit 1 (2x): AB

Summary Information (see also Sequences/Alignments below)

(-) Ligands, Modified Residues, Ions  (1, 2)

Asymmetric Unit (1, 2)
No.NameCountTypeFull Name
1BNI2Ligand/Ion5-(2-OXO-HEXAHYDRO-THIENO[3,4-D]IMIDAZOL-6-YL)-PENTANOIC ACID (4-NITRO-PHENYL)-AMIDE
Biological Unit 1 (1, 4)
No.NameCountTypeFull Name
1BNI4Ligand/Ion5-(2-OXO-HEXAHYDRO-THIENO[3,4-D]IMIDAZOL-6-YL)-PENTANOIC ACID (4-NITRO-PHENYL)-AMIDE

(-) Sites  (2, 2)

Asymmetric Unit (2, 2)
No.NameEvidenceResiduesDescription
1AC1SOFTWAREASN A:23 , LEU A:25 , SER A:27 , TYR A:43 , SER A:45 , VAL A:47 , GLY A:48 , ASN A:49 , TRP A:79 , SER A:88 , THR A:90 , TRP A:108 , LEU A:110 , SER A:112 , ASP A:128BINDING SITE FOR RESIDUE BNI A 501
2AC2SOFTWARETRP A:120 , ASN B:223 , SER B:227 , TYR B:243 , SER B:245 , VAL B:247 , GLY B:248 , ASN B:249 , TRP B:279 , SER B:288 , THR B:290 , TRP B:308 , SER B:312 , ASP B:328BINDING SITE FOR RESIDUE BNI B 502

(-) SS Bonds  (0, 0)

(no "SS Bond" information available for 1I9H)

(-) Cis Peptide Bonds  (0, 0)

(no "Cis Peptide Bond" information available for 1I9H)

 Sequence-Structure Mapping

(-) SAPs(SNPs)/Variants  (0, 0)

(no "SAP(SNP)/Variant" information available for 1I9H)

(-) PROSITE Motifs  (2, 3)

Asymmetric Unit (2, 3)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1AVIDIN_2PS51326 Avidin-like domain profile.SAV_STRAV37-159  1B:213-335
2AVIDIN_1PS00577 Avidin-like domain signature.SAV_STRAV142-156
 		  2A:118-132
B:318-332
Biological Unit 1 (2, 6)
 PROSITEUniProtKBPDB
No.IDACDescriptionIDLocationCountLocation
1AVIDIN_2PS51326 Avidin-like domain profile.SAV_STRAV37-159  2B:213-335
2AVIDIN_1PS00577 Avidin-like domain signature.SAV_STRAV142-156
 		  4A:118-132
B:318-332

(-) Exons   (0, 0)

(no "Exon" information available for 1I9H)

(-) Sequences/Alignments

Asymmetric Unit
   Reformat: Number of residues per line =  ('0' or empty: single-line sequence representation)
  Number of residues per labelling interval =
  UniProt sequence: complete  aligned part
   Show mapping: SCOP domains CATH domains Pfam domains Secondary structure (by author)
SAPs(SNPs) PROSITE motifs Exons
(details for a mapped element are shown in a popup box when the mouse pointer rests over it)
Chain A from PDB  Type:PROTEIN  Length:121
 aligned with SAV_STRAV | P22629 from UniProtKB/Swiss-Prot  Length:183

    Alignment length:121
                                    48        58        68        78        88        98       108       118       128       138       148       158
            SAV_STRAV    39 AGITGTWYNQLGSTFIVTAGADGALTGTYESAVGNAESRYVLTGRYDSAPATDGSGTALGWTVAWKNNYRNAHSATTWSGQYVGGAEARINTQWLLTSGTTEANAWKSTLVGHDTFTKVKP 159
               SCOP domains d1i9ha_ A: Streptavidin                                                                                                   SCOP domains
               CATH domains 1i9hA00 A:15-135  [code=2.40.128.30, no name defined]                                                                     CATH domains
               Pfam domains ------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ....eeeee....eeeeee....eeeeeee.........eeeeeee..........eeeeeeeeee....eeeeeeeeeeeee.....eeeeeeeeee..hhhhhhh.eeeeeeeeee... Sec.struct. author
                 SAPs(SNPs) ------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                PROSITE (1) AVIDIN_2  PDB: - UniProt: 37-159                                                                                          PROSITE (1)
                PROSITE (2) -------------------------------------------------------------------------------------------------------AVIDIN_1       --- PROSITE (2)
                 Transcript ------------------------------------------------------------------------------------------------------------------------- Transcript
                 1i9h A  15 AGITGTWYNQLGSTFIVTAGADGALTGTYESAVGNAESRYVLTGRYDSAPATDGSGTALGWTVAWKNNYRNAHSATTWSGQYVGGAEARINTQWLLTSGTTEANAWKSTLVGHDTFTKVKP 135
                                    24        34        44        54        64        74        84        94       104       114       124       134


Chain B from PDB  Type:PROTEIN  Length:123
 aligned with SAV_STRAV | P22629 from UniProtKB/Swiss-Prot  Length:183

    Alignment length:123
                                    46        56        66        76        86        96       106       116       126       136       146       156
            SAV_STRAV    37 AEAGITGTWYNQLGSTFIVTAGADGALTGTYESAVGNAESRYVLTGRYDSAPATDGSGTALGWTVAWKNNYRNAHSATTWSGQYVGGAEARINTQWLLTSGTTEANAWKSTLVGHDTFTKVKP 159
               SCOP domains d1i9hb_ B: Streptavidin                                                                                                     SCOP domains
               CATH domains 1i9hB00 B:213-335  [code=2.40.128.30, no name defined]                                                                      CATH domains
               Pfam domains --------------------------------------------------------------------------------------------------------------------------- Pfam domains
         Sec.struct. author ......eeeee....eeeeee....eeeeeee.........eeeeeee..........eeeeeeeeee....eeeeeeeeeeeee.....eeeeeeeeee..hhhhhhh.eeeeeeeee.... Sec.struct. author
                 SAPs(SNPs) --------------------------------------------------------------------------------------------------------------------------- SAPs(SNPs)
                PROSITE (1) AVIDIN_2  PDB: B:213-335 UniProt: 37-159                                                                                    PROSITE (1)
                PROSITE (2) ---------------------------------------------------------------------------------------------------------AVIDIN_1       --- PROSITE (2)
                 Transcript --------------------------------------------------------------------------------------------------------------------------- Transcript
                 1i9h B 213 AEAGITGTWYNQLGSTFIVTAGADGALTGTYESAVGNAESRYVLTGRYDSAPATDGSGTALGWTVAWKNNYRNAHSATTWSGQYVGGAEARINTQWLLTSGTTEANAWKSTLVGHDTFTKVKP 335
                                   222       232       242       252       262       272       282       292       302       312       322       332
   Legend:   → Mismatch (orange background)
  - → Gap (green background, '-', border residues have a numbering label)
    → Modified Residue (blue background, lower-case, 'x' indicates undefined single-letter code, labelled with number + name)
  x → Chemical Group (purple background, 'x', labelled with number + name, e.g. ACE or NH2)
  extra numbering lines below/above indicate numbering irregularities and modified residue names etc., number ends below/above '|'

 Classification and Annotation

(-) SCOP Domains  (1, 2)

Asymmetric Unit
(-)
Class: All beta proteins (24004)

(-) CATH Domains  (1, 2)

Asymmetric Unit
(-)
Class: Mainly Beta (13760)

(-) Pfam Domains  (0, 0)

(no "Pfam Domain" information available for 1I9H)

(-) Gene Ontology  (1, 1)

Asymmetric Unit(hide GO term definitions)
Chain A,B   (SAV_STRAV | P22629)
cellular component
    GO:0005576    extracellular region    The space external to the outermost structure of a cell. For cells without external protective or external encapsulating structures this refers to space outside of the plasma membrane. This term covers the host cell environment outside an intracellular parasite.
